5.91 Logical/Transport Layer Device ID Capture CSR (ID_CAPT)
SRIO Registers
Figure 147. Logical/Transport Layer Device ID Capture CSR (ID_CAPT)
31-24 23-16
MSB_DESTID DESTID
R-0x00 R-0x00
LEGEND: R = Read only; - n = value after reset
15-8 7-0
MSB_SOURCEID SOURCEID
R-0x00 R-0x00
LEGEND: R = Read only; - n = value after reset
Table 121. Logical/Transport Layer Device ID Capture CSR (ID_CAPT) Field Descriptions
Bit Field Value Description
31-24 MSB_DESTID Most significant byte of the destinationID associated with the error (large transport systems only)
23-16 DESTID The destinationID associated with the error
15-8 MSB_SOURCEID Most significant byte of the source ID associated with the error (large transport systems only)
7-0 SOURCEID The sourceID associated with the error
SPRU976 – March 2006 Serial RapidIO (SRIO) 195
Submit Documentation Feedback
