5.95 Port Error Rate Enable CSR n (SP n_RATE_EN)
SRIO Registers
Each of the four ports is supported by a register of this type.
Figure 151. Port Error Rate Enable CSR n (SP n_RATE_EN)
31 30-24 23 22 21 20 19 18 17 16
EN_IM Reserved Reserv CORRU CNTL_S RCVED_ PKT_U RCVED RCVED Reserv
P_SPE ed PT_CNT YM_UN PKT_NO NEXPE _PKT_ _PKT_ ed
CIFIC L_SYM_ EXPECT T_ACCP CTED_ WITH_ OVER_
ENABLE ED_ACK T_EN ACKID BAD_C 276B_
ID_EN _EN RC_EN EN
RW- R-0x00 R-0x00 RW- RW- RW- RW- RW- RW- R-0x00
0x00 0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
15-6 5 4 3 2 1 0
Reserved NON_OU PROT Reserv DELIN UNSOLIC LINK_
TSTANDI OCOL ed EATIO ITED_AC TIMEO
NG_ACKI _ERR N_ER K_CNTL_ UT_E
D_EN OR_E ROR_ SYM_EN N
N EN
R-0x00 RW-0x00 RW- R-0x00 RW- RW-0x00 RW-
0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 125. Port Error Rate Enable CSR n (SP n_RATE_EN) Field Descriptions
Bit Field Value Description
31 EN_IMP_SPECIFIC Enable error rate counting of implementation specific errors
30-24 Reserved Reserved
23 Reserved Reserved
22 CORRUPT_CNTL_SYM_E Enable error rate counting of a corrupt control symbol
NABLE
21 CNTL_SYM_UNEXPECTE Enable error rate counting of an acknowledge control symbol with an unexpected ackID
D_ACKID_EN
20 RCVED_PKT_NOT_ACCPT Enable error rate counting of received packet-not-accepted control symbols
_EN
19 PKT_UNEXPECTED_ACKI Enable error rate counting of packet with unexpected ackID value- out-of-sequence ackID
D_EN
18 RCVED_PKT_WITH_BAD_ Enable error rate counting of packet with a bad CRC value
CRC_EN
17 RCVED_PKT_OVER_276B Enable error rate counting of packet which exceeds the maximum allowed size
_EN
16-6 Reserved Reserved
5 NON_OUTSTANDING_AC Enable error rate counting of link-responses received with an ackID that is not
KID_EN outstanding
4 PROTOCOL_ERROR_EN Enable error rate counting of protocol errors
3 Reserved Reserved
2 DELINEATION_ERROR_E Enable error rate counting of delineation errors
N
1 UNSOLICITED_ACK_CNTL Enable error rate counting of unsolicited acknowledge control symbol errors
_SYM_EN
0 LINK_TIMEOUT_EN Enable error rate counting of link time-out errors
