www.ti.com
5.96 Port n Attributes Error Capture CSR 0 (SP n_ERR_ATTR_CAPT_DBG0)
SRIO Registers
Each of the four ports is supported by a register of this type.
Figure 152. Port n Attributes Error Capture CSR 0 (SP n_ERR_ATTR_CAPT_DBG0)
31-30 29 28-24 23-16
INFO_TYPE Reserv ERROR_TYPE IMP_SPECIFIC
ed
R-0x00 R- R-0x00 R-0x00
0x00
LEGEND: R = Read only; - n = value after reset
15-4 3-1 0
IMP_SPECIFIC Reserved CAPT
URE_
VALID
_INFO
R-0x00 R-0x00 RC-
0x00
LEGEND: R = Read only; - n = value after reset
Table 126. Port n Attributes Error Capture CSR 0 (SP n_ERR_ATTR_CAPT_DBG0) Field
Descriptions
Bit Field Value Description
31-30 INFO_TYPE Type of information logged.
00 Packet
01 Control symbol (only error capture register 0 is valid)
10 Implementation specific (capture register contents are implementation specific)
11 Undefined (S-bit error), capture as if a packet (parallel physical layer only)
29 Reserved Reserved
28-24 ERROR_TYPE Encoded value of captured error bit in the Port n Error Detect Register
23-4 IMP_SPECIFIC Implementation Dependent Error Information
3-1 Reserved Reserved
0 CAPTURE_VALI This bit is set by hardware to indicate that the Packet/control symbol capture registers contain valid
D_INFO information. For control symbols, only capture register 0 will contain meaningful information. A
software write of 0 clears this bit and subsequently unlocks all capture registers of port n.
Serial RapidIO (SRIO)200 SPRU976 – March 2006
Submit Documentation Feedback
