5.104 Port IP Mode CSR (SP_IP_MODE)
SRIO Registers
Figure 160. Port IP Mode CSR (SP_IP_MODE)
31-30 29 28 27 26 25 24-16
SP_MODE IDLE_ TX_FI PW_DI TGT_I SELF_ Reserved
ERR_ FO_B S D_DIS RST
DIS YPAS
S
R-0x00 RW- RW- RW- R- RW- R-0x00
0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
15-6 5 4 3 2 1 0
Reserved MLTC MLTC RST_ RST_ PW_E PW_IR
_EN _IRQ EN CS N Q
R-0x00 RW- RC- RW- RC- RW- RC-
0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 134. Port IP Mode CSR (SP_IP_MODE) Field Descriptions
Bit Field Value Description
31-30 SP_MODE SRIO Port IP Mode of operation.
00 1x/4x LP-Serial RapidIO Specification
01 4 ports (1x mode each)
10 Reserved
11 Reserved
29 IDLE_ERR_DIS IDLE Error checking disable.
0 Error checking enabled (default), only |K|, |A| and |R| characters are available. If input receives any
other characters in idle sequence, it should enter the Input-Error-stopped state.
1 Error checking disabled, all not idle or invalid characters during idle sequence are ignored
28 TX_FIFO_BYPAS Transmit FIFO
S
0 The TX_FIFO is operational (Default)
1 The TX_FIFO is bypassed. The txbclk and the sys_clk must be locked during operation, but the
phase variation up to 1 clock cycle is allowable. The 4 deep FIFO is used to accommodate the
phase difference.
27 PW_DIS Port-Write Disable.
0 Enable Port-Write Error reporting (default)
1 Disable Port-Write Error reporting
26 TGT_ID_DIS Destination ID Decode Disable- Definition of packet acceptance by the physical layer.
0 Packet accepted if DestID = Base ID. When DestID is not equal to Base ID, the packet is ignored;
i.e., it is accepted by RapidIO port but is not forwarded to logical layer.
1 Packet accepted with any DestID and forwarded to the logical layer.
25 SELF_RST Self reset enable, when 4 Link-Request Reset Control Symbols are accepted.
0 Self reset interrupt disabled (default), interrupt signal is asserted
1 Self reset interrupt enabled, the reset signal is asserted by the SRIO_TE reset controller. The
SRIO_TE configuration registers are set to the default value after reset and loose a boot
initialization values.
24-6 Reserved Reserved
5 MLTC_EN Multicast-Event Interrupt Enable. If enabled, the interrupt signal is High when the Multicast-Event
control symbol is received by any port.
0b Multicast interrupt disable
1b Multicast interrupt enable
4 MLTC_IRQ Multicast-Event Interrupt Status bit. It is High when the Multicast-Event control symbol is received
by any port. Once set, it remains set until written with logic 1 to clear. The mltc_irq output signal is
driven by this bit.
