www.ti.com
SRIO Registers
Table 134. Port IP Mode CSR (SP_IP_MODE) Field Descriptions (continued)
Bit Field Value Description
3 RST_EN Reset Interrupt Enable. If enabled, the interrupt signal is High when the 4 reset control symbols are
received in a sequence
0b Reset interrupt disable
1b Reset interrupt enable
2 RST_CS Reset received status bit. It is set when 4 reset control symbols are received in a sequence. Once
set, it remains set until written with logic 1 to clear. The rst_irq output signal is driven by this bit.
1 PW_EN Port-Write-In Interrupt Enable. If enabled, the interrupt signal is High when the Port-Write-In request
is received
0b Port-Write-In interrupt disable
1b Port-Write-In interrupt enable
0 PW_IRQ Port-Write-In Request interrupt is set when the Port-Write-In request is received. The payload is
captured. Once set, it remains set until written with logic 1 to clear. The pw_irq output signal is
driven by this bit.
