www.ti.com
5.108 Port Control Independent Register n (SP n_CTL_INDEP)
SRIO Registers
Each of the four ports is supported by a register of this type.
Figure 164. Port Control Independent Register n (SP n_CTL_INDEP)
31 30 29 28-27 26 25-24 23 22 21 20 19-18 17 16
Reserv TX_FL SOFT Reserved FORC TRANS_MODE DEBU SEND ILL_T ILL_T Reserved MAX_ MAX_
ed W _REC E_REI G _DBG RANS RANS RETR RETR
NIT _PKT _EN _ERR Y_EN Y_ER
R
R- RW- RW- R-0x00 W- RW-0x01 RW- RW- RW- RC- R-0x00 RW- RC-
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
15-8 7 6 5-0
MAX_RETRY_THR IRQ_E IRQ_E Reserved
N RR
RW-0x00 RW- RC- R-0x00
0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 138. Port Control Independent Register n (SP n_CTL_INDEP) Field Descriptions
Bit Field Value Description
31 Reserved Reserved
30 TX_FLW Transmit Link Flow Control enable
0b Disables transmit flow control (Enables receive link flow control)
1b Enables transmit flow control (not supported)
29 SOFT_REC Software controlled error recovery.
0b Transmission of error recovery sequence is performed by the hardware
1b Transmission of error recovery sequence is performed by the software. By default the transmission
error recovery sequence is performed by the hardware. If this bit is set, the hardware recovery is
disabled and the hardware transmission logic must wait until software has written the register Port n
Local ackID Status CSR.
28-27 Reserved Reserved
26 FORCE_REINIT Force reinitialization process. In 4x mode this bit affects all 4 lanes. This bit is write only, read
always "0".
25-24 TRANS_MODE Describes the transfer mode for each port.
00 Reserved (Cut-Through Mode)
01 Store & Forward Mode
1x Reserved
23 DEBUG Mode of operation.
0b Normal mode
1b Debug mode. The debug mode unlocks capture registers for write and enable debug packet
generator feature.
22 SEND_DBG_PKT Send debug packet. Write 1 force to send debug packet. This bit is set by software and cleared
after debug packet is sent. Writes when the bit is set are ignored. Debug mode only.
21 ILL_TRANS_EN Illegal Transfer Error reporting Enable. If enabled, the Port-Write and interrupt are reported errors.
0b Disables Illegal Transfer Error reporting
1b Enables Illegal Transfer Error reporting
20 ILL_TRANS_ERR Illegal Transfer Error. It is set to 1 as following:
• Received transaction has reserved tt field
• Reserved field of Maintenance transaction type
• DestID is not defined in look-up table
Once set, it remains set until written with logic 1 to clear. This bit also is cleared by writing all 0s to
the register SP0_ERR_DET. This error is also reported in registers SP0_ERR_DET and ERR_DET.
19-18 Reserved Reserved
SPRU976 – March 2006 Serial RapidIO (SRIO) 213
