www.ti.com
SRIO Functional Description
Table 4. Bits of SERDES_CFG n_CNTL Register (0x120 - 0x12c) (continued)
Bit Name Value Description
5:1 MPY PLL multiply. Select PLL multiply factors between 4 and 60. Multiply modes shown below.
0000 4x
0001 5x
0010 6x
0011 Reserved
0100 8x
0101 10x
0110 12x
0111 12.5x
1000 15x
1001 20x
1010 25x
1011 Reserved
1100 Reserved
1101 50x
1110 60x
1111 Reserved
0 ENPLL Enable PLL. Enables the PLL.
Based on the MPY value, the following line rate versus PLL output clock frequency can be estimated:
Table 5. Line Rate versus PLL Output Clock Frequency
Rate Line Rate PLL Output Frequency RATESCALE
Full x Gbps 0.5x GHz 0.5
Half x Gbps x GHz 1
Quarter x Gbps 2x GHz 2
RIOCLK and RIOCLK
FREQ
= LINERATE × RATESCALE
MPY
The rate is defined by the RATE bits of the SERDES_CFGRX n_CNTL register and the
SERDES_CFGTX n_CNTL register, respectively.
The primary operating frequency of the SERDES macro is determined by the reference clock frequency
and PLL multiplication factor. However, to support lower frequency applications, each receiver and
transmitter can also be configured to operate at a half or quarter of this rate via the RATE bits of the
SERDES_CFGRX n_CNTL and SERDES_CFGTX n_CNTL registers as described in Table 6 .
Table 6. RATE Bit Effects
Value Description
0 0 Full rate. Two data samples taken per PLL output clock cycle.
0 1 Half rate. One data sample taken per PLL output clock cycle.
1 0 Quarter rate. One data sample taken every two PLL output clock cycles.
1 1 Reserved.
SPRU976 – March 2006 Serial RapidIO (SRIO) 27
Submit Documentation Feedback
