Table 20. TX Buffer Descriptor Field Definitions (continued)
Field Description
tt RapidIO tt field specifying 8- or 16-bit DeviceIDs
00: 8b deviceIDs
01: 16b deviceIDs
10: reserved
11: reserved
PortID Port number for routing outgoing packet.
SSIZE RIO standard message payload size. Indicates how the hardware should segment the
outgoing message by specifying the maximum number of double-words per packet. If
the message is a multi-segment message, this field remains the same for all outgoing
segments. All segments of the message, except for the last segment, have payloads
equal to this size. The last message segment may be equal or less than this size.
Maximum message size for a 16 segment message is shown below.
Message_length/16 must be less than or equal to Ssize, if not, the message is not sent
and CC 101b is set.
0000b - 1000b: Reserved
1001b: 1 Double-word payload (Supports up to a 128B message)
1010b: 2 Double-word payload (Supports up to a 256B message)
1011b: 4 Double-word payload (Supports up to a 512B message)
1100b: 8 Double-word payload (Supports up to a 1024B message)
1101b: 16 Double-word payload (Supports up to a 2048B message)
1110b: 32 Double-word payload (Supports up to a 4096B message)
1111b: Reserved
mailbox Destination Mailbox: Specifies the mailbox to which the message will be sent.
000000b: Mailbox 0
000001b: Mailbox 1
. . .
000100b: Mailbox 4
. . .
111111b: Mailbox 63
For multi-segment messages, only the 2 LSBs of this mailbox field are valid. Hardware
will ignore the 4 MSBs of this field if the outgoing message is multi-segment.
Once the port controls the buffer descriptor, the DEST_ID field can be queried to determine flow control. If
the transaction has been flow controlled, the DMA bus READ request is postponed so that the TX buffer
space is not wasted. Because buffer descriptors cannot be reordered in the link list, if the transaction at
the head of the buffer descriptor queue is flow controlled, HOL blocking will occur on that queue. When
this occurs, all transactions located in that queue are stalled. To counter the affects and reduce back-up of
more TX packets, multiple queues are available. The peripheral supports a total of 16 assignable TX
queues and their associated TX DMA state registers. The transmission order between queues is based on
programmable weighted round-robin at the message level. The programmable registers are shown in
Figure 23 . This scheme allows configurability of the queue transmission order, as well as the weight of
each queue within the round robin. Upon enabling the peripheral with the Peripheral Control Register
(0x0004), the TX state machine begins by processing the TX_Queue_Map0. It will attempt to process the
queue and number of buffer descriptors from that queue programmed in this mapper. Then it will move to
TX_Queue_Map1, followed by TX_Queue_Map2 and so forth. It is important to note that this mapping
order is fixed in a circular pattern. Each mapper can point to any queue and multiple mappers can point to
a single queue. If a mapper points to an in-active queue, the peripheral recognizes this and moves to the
next mapper. In order for an active queue to transmit packets, at least one mapper must be pointing to
that queue. The default settings dictate an equally weighted round robin that starts on queue0 and
increments by one until reaching queue15. If the application requires precise control over the order of data
sent out of the device after power up or reset, you should program the map control registers, set up the
TX queues and initialize the HDP, and finally enable the peripheral with the Peripheral Control Register.
