www.ti.com
SRIO Functional Description
Figure 23. Weighted Round Robin Programming Registers (Address Offset 0x7E0 – 0x7EC)
TX_QUEUE_CNTL0- Address Offset (0x7E0)
31 24 23 16
TX_Queue_Map3 TX_Queue_Map2
15 8 7 0
TX_Queue_Map1 TX_Queue_Map0
TX_QUEUE_CNTL1- Address Offset (0x7E4)
31 24 23 16
TX_Queue_Map7 TX_Queue_Map6
15 8 7 0
TX_Queue_Map5 TX_Queue_Map4
TX_QUEUE_CNTL2- Address Offset (0x7E8)
31 24 23 16
TX_Queue_Map11 TX_Queue_Map10
15 8 7 0
TX_Queue_Map9 TX_Queue_Map8
TX_QUEUE_CNTL3- Address Offset (0x7EC)
31 24 23 16
TX_Queue_Map15 TX_Queue_Map14
15 8 7 0
TX_Queue_Map13 TX_Queue_Map12
Table 21. Weighted Round Robin Programming Registers (Address Offset 0x7E0 – 0x7EC)
Name Bit Access Reset Value Description
TX_Queue_Map0 [7:0] R/W 0x00 [7:4] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map1
[3:0] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map1 [15:8] R/W 0x01 15:12] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map2
[11:8] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map2 [23:16] R/W 0x02 [23:20] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map3
[19:16] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map3 [31:24] R/W 0x03 [31:28] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map4
[27:24] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map4 [7:0] R/W 0x04 [7:4] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map5
[3:0] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map5 [15:8] R/W 0x05 [15:12] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map6
[11:8] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map6 [23:16] R/W 0x06 [23:20] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map7
[19:16] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map7 [31:24] R/W 0x07 [31:28] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map8
[27:24] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map8 [7:0] R/W 0x08 [7:4] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map9
[3:0] = Pointer to a Queue, programmable to any of the 16 TX queues
TX_Queue_Map9 [15:8] R/W 0x09 [15:12] = Number of contiguous messages (descriptors) to process before
moving to TX_Queue_Map10
[11:8] = Pointer to a Queue, programmable to any of the 16 TX queues
