www.ti.com
Descriptor
Descriptor
Buffer
Buffer
Port Rx DMA
State
Rx Queue Head Descriptor
Pointer
SRIO Functional Description
Figure 24. RX Buffer Descriptor
TX Buffer Descriptor
TX_DESCP0_0->TXDESC0 = CSL_FMK( SRIO_TXDESC0_N_POINTER,(int )TX_DESCP0_1 );
//link to TX_DESCP0_1
//NDP
TX_DESCP0_0->TXDESC1 = CSL_FMK( SRIO_TXDESC1_B_POINTER,(int )&xmtBuff1[0] );
//Buffer Pointer
TX_DESCP0_0->TXDESC2 = CSL_FMK( SRIO_TXDESC2_DESTID, 0xBEEF)|
CSL_FMK( SRIO_TXDESC2_PRI, 1)|
CSL_FMK( SRIO_TXDESC2_TT, 1)|
CSL_FMK( SRIO_TXDESC2_PORTID, 3)|
CSL_FMK( SRIO_TXDESC2_SSIZE, SSIZE_256B)|
CSL_FMK( SRIO_TXDESC2_MAILBOX, 0);
TX_DESCP0_0->TXDESC3 = CSL_FMK( SRIO_TXDESC3_SOP,1 )|
CSL_FMK( SRIO_TXDESC3_EOP,1 )|
CSL_FMK( SRIO_TXDESC3_OWNERSHIP,1 )|
CSL_FMK( SRIO_TXDESC3_EOQ,1 )|
CSL_FMK( SRIO_TXDESC3_TEARDOWN,0 )|
CSL_FMK( SRIO_TXDESC3_RETRY_COUNT,0 )|
CSL_FMK( SRIO_TXDESC3_CC,0 )|
CSL_FMK( SRIO_TXDESC3_MESSAGE_LENGTH,MLEN_512DW );
TX_DESCP0_1->TXDESC0 = CSL_FMK( SRIO_TXDESC0_N_POINTER, 0);
//end of message
//poll mode, extended address type 2,5,6
TX_DESCP0_1->TXDESC1 = CSL_FMK( SRIO_TXDESC1_B_POINTER,(int )&xmtBuff2[0] );
//32bit = type 2,5,6. 24bit = type 8
TX_DESCP0_1->TXDESC2 = CSL_FMK( SRIO_TXDESC2_DESTID, 0xBEEF)|
CSL_FMK( SRIO_TXDESC2_PRI, 1)|
CSL_FMK( SRIO_TXDESC2_TT, 1)|
CSL_FMK( SRIO_TXDESC2_PORTID, 3)|
CSL_FMK( SRIO_TXDESC2_SSIZE, SSIZE_256B)|
CSL_FMK( SRIO_TXDESC2_MAILBOX, 1);
TX_DESCP0_1->TXDESC3 = CSL_FMK( SRIO_TXDESC3_SOP,1 )|
CSL_FMK( SRIO_TXDESC3_EOP,1 )|
CSL_FMK( SRIO_TXDESC3_OWNERSHIP,1 )|
CSL_FMK( SRIO_TXDESC3_EOQ,1 )|
CSL_FMK( SRIO_TXDESC3_TEARDOWN,0 )|
CSL_FMK( SRIO_TXDESC3_RETRY_COUNT,0 )|
CSL_FMK( SRIO_TXDESC3_CC,0 )|
CSL_FMK( SRIO_TXDESC3_MESSAGE_LENGTH,MLEN_512DW );
SPRU976 – March 2006 Serial RapidIO (SRIO) 57
Submit Documentation Feedback
