www.ti.com
Reserved
RIO_LSUn_FLOW_MASKS
(Address Offsets: 0x041C,
0x043C, 0x045C, 0x047C)
31-16
R, 0x0000
LSU n Flow Mask
15-0
R/W, 0xFFFF
TX Queue1
Flow Mask
RIO_TX_CPPI_FLOW_MASKS0
(Address Offsets: 0x0704)
31-16
R/W, 0xFFFF
TX Queue0
Flow Mask
15-0
R/W, 0xFFFF
TX Queue3
Flow Mask
RIO_TX_CPPI_FLOW_MASKS1
(Address Offsets: 0x0708)
31-16
R/W, 0xFFFF
TX Queue2
Flow Mask
15-0
R/W, 0xFFFF
TX Queue5
Flow Mask
RIO_TX_CPPI_FLOW_MASKS2
(Address Offsets: 0x070C)
31-16
R/W, 0xFFFF
TX Queue4
Flow Mask
15-0
R/W, 0xFFFF
TX Queue7
Flow Mask
RIO_TX_CPPI_FLOW_MASKS3
(Address Offsets: 0x0710)
31-16
R/W, 0xFFFF
TX Queue6
Flow Mask
15-0
R/W, 0xFFFF
TX Queue9
Flow Mask
RIO_TX_CPPI_FLOW_MASKS4
(Address Offsets: 0x0714)
31-16
R/W, 0xFFFF
TX Queue8
Flow Mask
15-0
R/W, 0xFFFF
TX Queue11
Flow Mask
RIO_TX_CPPI_FLOW_MASKS5
(Address Offsets: 0x0718)
31-16
R/W, 0xFFFF
TX Queue10
Flow Mask
15-0
R/W, 0xFFFF
TX Queue13
Flow Mask
RIO_TX_CPPI_FLOW_MASKS6
(Address Offsets: 0x071C)
31-16
R/W, 0xFFFF
TX Queue12
Flow Mask
15-0
R/W, 0xFFFF
TX Queue15
Flow Mask
RIO_TX_CPPI_FLOW_MASKS7
(Address Offsets: 0x0720)
31-16
R/W, 0xFFFF
TX Queue14
Flow Mask
15-0
R/W, 0xFFFF
SRIO Functional Description
Figure 28. Transmit Source Flow Control Masks
Table 23. Transmit Source Flow Control Masks
Name Bit Access Reset Value Description
Flow Mask 0 R/W 1b 0b – TX source doesn’t support Flow0 from table entry
1b – TX source does support Flow0 from table entry
Flow Mask 1 R/W 1b 0b – TX source doesn’t support Flow1 from table entry
1b – TX source does support Flow1 from table entry
Flow Mask 2 R/W 1b 0b – TX source doesn’t support Flow2 from table entry
1b – TX source does support Flow2 from table entry
Flow Mask 3 R/W 1b 0b – TX source doesn’t support Flow3 from table entry
1b – TX source does support Flow3 from table entry
Flow Mask 4 R/W 1b 0b – TX source doesn’t support Flow4 from table entry
1b – TX source does support Flow4 from table entry
Flow Mask 5 R/W 1b 0b – TX source doesn’t support Flow5 from table entry
1b – TX source does support Flow5 from table entry
Flow Mask 6 R/W 1b 0b – TX source doesn’t support Flow6 from table entry
1b – TX source does support Flow6 from table entry
Flow Mask 7 R/W 1b 0b – TX source doesn’t support Flow7 from table entry
1b – TX source does support Flow7 from table entry
Flow Mask 8 R/W 1b 0b – TX source doesn’t support Flow8 from table entry
1b – TX source does support Flow8 from table entry
Flow Mask 9 R/W 1b 0b – TX source doesn’t support Flow9 from table entry
1b – TX source does support Flow9 from table entry
Flow Mask 10 R/W 1b 0b – TX source doesn’t support Flow10 from table entry
1b – TX source does support Flow10 from table entry
Flow Mask 11 R/W 1b 0b – TX source doesn’t support Flow11 from table entry
1b – TX source does support Flow11 from table entry
Flow Mask 12 R/W 1b 0b – TX source doesn’t support Flow12 from table entry
1b – TX source does support Flow12 from table entry
Flow Mask 13 R/W 1b 0b – TX source doesn’t support Flow13 from table entry
1b – TX source does support Flow13 from table entry
Flow Mask 14 R/W 1b 0b – TX source doesn’t support Flow14 from table entry
1b – TX source does support Flow14 from table entry
Flow Mask 15 R/W 1b 0b – TX source doesn’t support Flow15 from table entry
1b – TX source does support Flow15 from table entry
Serial RapidIO (SRIO)62 SPRU976 – March 2006
