SRIO Functional Description
Table 25. Emulation Control Signals
Name Bit Access Reset Value Description
Free 0 R/W 1b FREE = 0, SOFT Bit takes effect
FREE = 1, Free run mode (default mode) - Peripheral ignores the
EMUSUSP signal and functions normally.
Soft 1 R/W 0b SOFT = 0 -> Soft Stop (default mode)
SOFT = 1 -> Hard stop – All status registers are frozen in default state.
(Mode not supported)
PEREN 2 R/W 0b Peripheral Enable.
0b – Disabled
1b – Enabled
Reserved 31:3 0b Reserved
Free Run Mode: (default mode) Peripheral does not respond to EMUSUSP assertion. Module functions
normally, irrespective of CPU emulation state.
Soft Stop Mode: Peripheral gracefully halts operations. The peripheral halts operation at a point that
makes sense both to the internal DMA/data access operation and to the pin interface as described below,
after finishing packet reception or transmission in progress:
• DMA bus DMA master: DMA bus requests in progress are allowed to complete (DMA bus has no
means to throttle command in progress from the Master) DMA bus requests that correspond to the
same network packet are allowed to complete. No new DMA bus requests will be generated on the
next new packet.
• Configuration bus MMR interface: All MMR configuration bus requests are serviced as normal.
• Events/interrupts: New events/interrupts are not generated to the CPU for newly arriving packets.
Current transactions are allowed to finish and may cause an interrupt upon completion.
• Slave pin interface: The pin interface functions as normal. If buffering is available in the peripheral,
the peripheral services externally generated requests as long as possible. When the internal buffers
are consumed, the peripheral will retry incoming network packets in the physical layer.
• Master pin interface: No new master requests are generated. Master requests in progress are
allowed to complete, including all packets located in the physical layer transmit buffers.
Hard Stop Mode: Peripheral should halt immediately. This mode is not supported in the RapidIO
peripheral.
2.3.11 Initialization Example
2.3.11.1 Enabling the SRIO Peripherals
When the device is powered on, the SRIO peripheral is in a disabled state. Before any SRIO specific
initialization can take place, the peripheral needs to be enabled; otherwise, its registers cannot be written,
and the reads will all return a value of zero.
/* Glb enable srio */
SRIO_REGS->GBL_EN = 0x00000001 ;
SRIO_REGS->BLK0_EN = 0x00000001 ; //MMR_EN
SRIO_REGS->BLK5_EN = 0x00000001 ; //PORT0_EN
SRIO_REGS->BLK1_EN = 0x00000001 ; //LSU_EN
SRIO_REGS->BLK2_EN = 0x00000001 ; //MAU_EN
SRIO_REGS->BLK3_EN = 0x00000001 ; //TXU_EN
SRIO_REGS->BLK4_EN = 0x00000001 ; //RXU_EN
SRIO_REGS->BLK6_EN = 0x00000001 ; //PORT1_EN
SRIO_REGS->BLK7_EN = 0x00000001 ; //PORT2_EN
SRIO_REGS->BLK8_EN = 0x00000001 ; //PORT3_EN
