www.ti.com
Interrupt Conditions
Where ICS0 - Doorbell1, bit 0, through ICS15 - Doorbell1, bit 15.
Figure 45. DOORBELL2 Interrupt Registers for Direct I/O Transfers
DOORBELL2 Interrupt Condition Status Registers (ICSR) (Address Offset 0x0220)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ICS15 ICS14 ICS13 ICS12 ICS11 ICS10 ICS9 ICS8 ICS7 ICS6 ICS5 ICS4 ICS3 ICS2 ICS1 ICS0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R = Read, W = Write, n = value at reset
DOORBELL2 Interrupt Condition Clear Registers (ICCR) (Address Offset 0x0228)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ICC15 ICC14 ICC13 ICC12 ICC11 ICC10 ICC9 ICC8 ICC7 ICC6 ICC5 ICC4 ICC3 ICC2 ICC1 ICC0
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
LEGEND: R = Read, W = Write, n = value at reset
Where ICS0 - Doorbell2, bit 0, through ICS15 - Doorbell2, bit 15.
Figure 46. DOORBELL3 Interrupt Registers for Direct I/O Transfers
DOORBELL3 Interrupt Condition Status Registers (ICSR) (Address Offset 0x0230)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ICS15 ICS14 ICS13 ICS12 ICS11 ICS10 ICS9 ICS8 ICS7 ICS6 ICS5 ICS4 ICS3 ICS2 ICS1 ICS0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R = Read, W = Write, n = value at reset
DOORBELL3 Interrupt Condition Clear Registers (ICCR) (Address Offset 0x0238)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ICC15 ICC14 ICC13 ICC12 ICC11 ICC10 ICC9 ICC8 ICC7 ICC6 ICC5 ICC4 ICC3 ICC2 ICC1 ICC0
W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0 W-0
LEGEND: R = Read, W = Write, n = value at reset
Where ICS0 - Doorbell3, bit 0, through ICS15 - Doorbell3, bit 15.
