www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x0110 SERDES_CFGTX0_ SERDES Transmit Channel Configuration Register 0 Section 5.14
CNTL
0x0114 SERDES_CFGTX1_ SERDES Transmit Channel Configuration Register 1 Section 5.14
CNTL
0x0118 SERDES_CFGTX2_ SERDES Transmit Channel Configuration Register 2 Section 5.14
CNTL
0x011C SERDES_CFGTX3_ SERDES Transmit Channel Configuration Register 3 Section 5.14
CNTL
0x0120 SERDES_CFG0_CN SERDES Macro Configuration Register 0 Section 5.15
TL
0x0124 SERDES_CFG1_CN SERDES Macro Configuration Register 1 Section 5.15
TL
0x0128 SERDES_CFG2_CN SERDES Macro Configuration Register 2 Section 5.15
TL
0x012C SERDES_CFG3_CN SERDES Macro Configuration Register 3 Section 5.15
TL
0x0200 DOORBELL0_ICSR DOORBELL Interrupt Status Register 0 Section 5.16
0x0208 DOORBELL0_ICCR DOORBELL Interrupt Clear Register 0 Section 5.17
0x0210 DOORBELL1_ICSR DOORBELL Interrupt Status Register 1 Section 5.16
0x0218 DOORBELL1_ICCR DOORBELL Interrupt Clear Register 1 Section 5.17
0x0220 DOORBELL2_ICSR DOORBELL Interrupt Status Register 2 Section 5.16
0x0228 DOORBELL2_ICCR DOORBELL Interrupt Clear Register 2 Section 5.17
0x0230 DOORBELL3_ICSR DOORBELL Interrupt Status Register 3 Section 5.16
0x0238 DOORBELL3_ICCR DOORBELL Interrupt Clear Register 3 Section 5.17
0x0240 RX_CPPI_ICSR RX CPPI Interrupt Status Register Section 5.18
0x0248 RX_CPPI_ICCR RX CPPI Interrupt Clear Register Section 5.19
0x0250 TX_CPPI_ICSR TX CPPI Interrupt Status Register Section 5.20
0x0258 TX_CPPI_ICCR TX CPPI Interrupt Clear Register Section 5.21
0x0260 LSU_ICSR LSU Interrupt Status Register Section 5.22
0x0268 LSU _ICCR LSU Interrupt Clear Register Section 5.23
0x0270 ERR_RST_EVNT_IC Error, Reset, and Special Event Interrupt Status Register Section 5.24
SR
0x0278 ERR_RST_EVNT_IC Error, Reset, and Special Event Interrupt Clear Register Section 5.25
CR
0x0280 DOORBELL0_ICRR DOORBELL0 Interrupt Condition Routing Register (bits 0 to 7) Section 5.26
0x0284 DOORBELL0_ICRR2 DOORBELL 0 Interrupt Condition Routing Register 2 (bits 8 to 15) Section 5.27
0x0290 DOORBELL1_ICRR DOORBELL1 Interrupt Condition Routing Register (bits 0 to 7) Section 5.26
0x0294 DOORBELL1_ICRR2 DOORBELL 1 Interrupt Condition Routing Register 2 (bits 8 to 15) Section 5.27
0x02A0 DOORBELL2_ICRR DOORBELL2 Interrupt Condition Routing Register (bits 0 to 7) Section 5.26
0x02A4 DOORBELL2_ICRR2 DOORBELL 2 Interrupt Condition Routing Register 2 (bits 8 to 15) Section 5.27
0x02B0 DOORBELL3_ICRR DOORBELL3 Interrupt Condition Routing Register (bits 0 to 7) Section 5.26
0x02B4 DOORBELL3_ICRR2 DOORBELL 3 Interrupt Condition Routing Register 2 (bits 8 to 15) Section 5.27
0x02C0 RX_CPPI _ICRR Receive CPPI Interrupt Condition Routing Register (0 to 7) Section 5.28
0x02C4 RX_CPPI _ICRR2 Receive CPPI Interrupt Condition Routing Register (8 to 15) Section 5.29
0x02D0 TX_CPPI _ICRR Transmit CPPI Interrupt Condition Routing Register (0 to 7) Section 5.30
0x02D4 TX_CPPI _ICRR2 Transmit CPPI Interrupt Condition Routing Register (8 to 15) Section 5.31
0x02E0 LSU_ICRR0 LSU Interrupt Condition Routing Register 0 Section 5.32
0x02E4 LSU_ICRR1 LSU Interrupt Condition Routing Register 1 Section 5.33
0x02E8 LSU_ICRR2 LSU Interrupt Condition Routing Register 2 Section 5.34
SPRU976 – March 2006 Serial RapidIO (SRIO) 89
