www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x02EC LSU_ICRR3 LSU Interrupt Condition Routing Register 3 Section 5.35
0x02F0 ERR_RST_EVNT_IC Error, Reset, and Special Event Interrupt Condition Routing Register Section 5.36
RR
0x02F4 ERR_RST_EVNT_IC Error, Reset, and Special Event Interrupt Condition Routing Register 2 Section 5.37
RR2
0x02F8 ERR_RST_EVNT_IC Error, Reset, and Special Event Interrupt Condition Routing Register 3 Section 5.38
RR3
0x0300 INTDST0_DECODE INTDST Interrupt Status Decode Register 0 Section 5.39
0x0304 INTDST1_DECODE INTDST Interrupt Status Decode Register 1 Section 5.39
0x0308 INTDST2_DECODE INTDST Interrupt Status Decode Register 2 Section 5.39
0x030C INTDST3_DECODE INTDST Interrupt Status Decode Register 3 Section 5.39
0x0310 INTDST4_DECODE INTDST Interrupt Status Decode Register 4 Section 5.39
0x0314 INTDST5_DECODE INTDST Interrupt Status Decode Register 5 Section 5.39
0x0318 INTDST6_DECODE INTDST Interrupt Status Decode Register 6 Section 5.39
0x031C INTDST7_DECODE INTDST Interrupt Status Decode Register 7 Section 5.39
0x0320 INTDST0_RATE_CN INTDST Interrupt Rate Control Register 0 Section 5.40
TL
0x0324 INTDST1_RATE_CN INTDST Interrupt Rate Control Register 1 Section 5.40
TL
0x0328 INTDST2_RATE_CN INTDST Interrupt Rate Control Register 2 Section 5.40
TL
0x032C INTDST3_RATE_CN INTDST Interrupt Rate Control Register 3 Section 5.40
TL
0x0330 INTDST4_RATE_CN INTDST Interrupt Rate Control Register 4 Section 5.40
TL
0x0334 INTDST5_RATE_CN INTDST Interrupt Rate Control Register 5 Section 5.40
TL
0x0338 INTDST6_RATE_CN INTDST Interrupt Rate Control Register 6 Section 5.40
TL
0x033C INTDST7_RATE_CN INTDST Interrupt Rate Control Register 7 Section 5.40
TL
0x040 LSU1_REG0 LSU1 Control Register 0 Section 5.41
0x0404 LSU1_REG1 LSU1 Control Register 1 Section 5.42
0x0408 LSU1_REG2 LSU1 Control Register 2 Section 5.43
0x040C LSU1_REG3 LSU1 Control Register 3 Section 5.44
0x0410 LSU1_REG4 LSU1 Control Register 4 Section 5.45
0x0414 LSU1_REG5 LSU1 Control Register 5 Section 5.46
0x0418 LSU1_REG6 LSU1 Control Register 6 Section 5.47
0x041C LSU1_FLOW_MASK Core 0 LSU Congestion Control Flow Mask Register Section 5.48
S
0x0420 LSU2_REG0 LSU2 Control Register 0 Section 5.41
0x0424 LSU2_REG1 LSU2 Control Register 1 Section 5.42
0x0428 LSU2_REG2 LSU2 Control Register 2 Section 5.43
0x042C LSU2_REG3 LSU2 Control Register 3 Section 5.44
0x0430 LSU2_REG4 LSU2 Control Register 4 Section 5.45
0x0434 LSU2_REG5 LSU2 Control Register 5 Section 5.46
0x0438 LSU2_REG6 LSU2 Control Register 6 Section 5.47
0x043C LSU2_FLOW_MASK Core 1 LSU Congestion Control Flow Mask Register Section 5.48
S1
0x0440 LSU3_REG0 LSU3 Control Register 0 Section 5.41
