www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x0444 LSU3_REG1 LSU3 Control Register 1 Section 5.42
0x0448 LSU3_REG2 LSU3 Control Register 2 Section 5.43
0x044C LSU3_REG3 LSU3 Control Register 3 Section 5.44
0x0450 LSU3_REG4 LSU3 Control Register 4 Section 5.45
0x0454 LSU3_REG5 LSU3 Control Register 5 Section 5.46
0x0458 LSU3_REG6 LSU3 Control Register 6 Section 5.47
0x045C LSU3_FLOW_MASK Core 2 LSU Congestion Control Flow Mask Register Section 5.48
S2
0x0460 LSU4_REG0 LSU4 Control Register 0 Section 5.41
0x0464 LSU4_REG1 LSU4 Control Register 1 Section 5.42
0x0468 LSU4_REG2 LSU4 Control Register 2 Section 5.43
0x046C LSU4_REG3 LSU4 Control Register 3 Section 5.44
0x0470 LSU4_REG4 LSU4 Control Register 4 Section 5.45
0x0474 LSU4_REG5 LSU4 Control Register 5 Section 5.46
0x0478 LSU4_REG6 LSU4 Control Register 6 Section 5.47
0x047C LSU4_FLOW_MASK Core 3 LSU Congestion Control Flow Mask Register Section 5.48
S3
0x0500 QUEUE0_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 0 Section 5.49
DP
0x0504 QUEUE1_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 1 Section 5.49
DP
0x0508 QUEUE2_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 2 Section 5.49
DP
0x050C QUEUE3_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 3 Section 5.49
DP
0x0510 QUEUE4_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 4 Section 5.49
DP
0x0514 QUEUE5_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 5 Section 5.49
DP
0x0518 QUEUE6_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 6 Section 5.49
DP
0x051C QUEUE7_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 7 Section 5.49
DP
0x0520 QUEUE8_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 8 Section 5.49
DP
0x0524 QUEUE9_TXDMA_H Queue Transmit DMA Head Descriptor Pointer Register 9 Section 5.49
DP
0x0528 QUEUE10_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 10 Section 5.49
HDP
0x052C QUEUE11_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 11 Section 5.49
HDP
0x0530 QUEUE12_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 12 Section 5.49
HDP
0x0534 QUEUE13_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 13 Section 5.49
HDP
0x0538 QUEUE14_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 14 Section 5.49
HDP
0x053C QUEUE15_TXDMA_ Queue Transmit DMA Head Descriptor Pointer Register 15 Section 5.49
HDP
0x0580 QUEUE0_TXDMA_C Queue Transmit DMA Completion Pointer Register 0 Section 5.50
P
SPRU976 – March 2006 Serial RapidIO (SRIO) 91
Submit Documentation Feedback
