www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x0630 QUEUE12_RXDMA_ Queue Receive DMA Head Descriptor Pointer Register 12 Section 5.51
HDP
0x0634 QUEUE13_RXDMA_ Queue Receive DMA Head Descriptor Pointer Register 13 Section 5.51
HDP
0x0638 QUEUE14_RXDMA_ Queue Receive DMA Head Descriptor Pointer Register 14 Section 5.51
HDP
0x063C QUEUE15_RXDMA_ Queue Receive DMA Head Descriptor Pointer Register 15 Section 5.51
HDP
0x0680 QUEUE0_RXDMA_C Queue Receive DMA Completion Pointer Register 0 Section 5.52
P
0x0684 QUEUE1_RXDMA_C Queue Receive DMA Completion Pointer Register 1 Section 5.52
P
0x0688 QUEUE2_RXDMA_C Queue Receive DMA Completion Pointer Register 2 Section 5.52
P
0x068C QUEUE3_RXDMA_C Queue Receive DMA Completion Pointer Register 3 Section 5.52
P
0x0690 QUEUE4_RXDMA_C Queue Receive DMA Completion Pointer Register 4 Section 5.52
P
0x0694 QUEUE5_RXDMA_C Queue Receive DMA Completion Pointer Register 5 Section 5.52
P
0x0698 QUEUE6_RXDMA_C Queue Receive DMA Completion Pointer Register 6 Section 5.52
P
0x069C QUEUE7_RXDMA_C Queue Receive DMA Completion Pointer Register 7 Section 5.52
P
0x06A0 QUEUE8_RXDMA_C Queue Receive DMA Completion Pointer Register 8 Section 5.52
P
0x06A4 QUEUE9_RXDMA_C Queue Receive DMA Completion Pointer Register 9 Section 5.52
P
0x06A8 QUEUE10_RXDMA_ Queue Receive DMA Completion Pointer Register 10 Section 5.52
CP
0x06AC QUEUE11_RXDMA_ Queue Receive DMA Completion Pointer Register 11 Section 5.52
CP
0x06B0 QUEUE12_RXDMA_ Queue Receive DMA Completion Pointer Register 12 Section 5.52
CP
0x06B4 QUEUE13_RXDMA_ Queue Receive DMA Completion Pointer Register 13 Section 5.52
CP
0x06B8 QUEUE14_RXDMA_ Queue Receive DMA Completion Pointer Register 14 Section 5.52
CP
0x06BC QUEUE15_RXDMA_ Queue Receive DMA Completion Pointer Register 15 Section 5.52
CP
0x0700 TX_QUEUE_TEAR_ Transmit Queue Teardown Register Section 5.53
DOWN
0x0704 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 0 Section 5.54
SKS0
0x0708 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 1 Section 5.54
SKS1
0x070C TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 2 Section 5.54
SKS2
0x0710 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 3 Section 5.54
SKS3
0x0714 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 4 Section 5.54
SKS4
0x0718 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 5 Section 5.54
SKS5
SPRU976 – March 2006 Serial RapidIO (SRIO) 93
