www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x071C TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 6 Section 5.54
SKS6
0x0720 TX_CPPI_FLOW_MA Transmit CPPI Supported Flow Mask Register 7 Section 5.54
SKS7
0x0740 RX_QUEUE_TEAR_ Receive Queue Teardown Register Section 5.55
DOWN
0x0744 RX_CPPI_CNTL Receive CPPI Control Register Section 5.56
0x07E0 TX_QUEUE_CNTL0 Transmit CPPI Weighted Round Robin Control Register 0 Section 5.57
0x07E4 TX_QUEUE_CNTL1 Transmit CPPI Weighted Round Robin Control Register 1 Section 5.58
0x07E8 TX_QUEUE_CNTL2 Transmit CPPI Weighted Round Robin Control Register 2 Section 5.59
0x07EC TX_QUEUE_CNTL3 Transmit CPPI Weighted Round Robin Control Register 3 Section 5.60
0x0800 RXU_MAP_L0 MailBox-to-Queue Mapping Register L0 Section 5.61
0x0804 RXU_MAP_H0 MailBox-to-Queue Mapping Register H0 Section 5.62
0x0808 RXU_MAP_L1 MailBox-to-Queue Mapping Register L1 Section 5.61
0x080C RXU_MAP_H1 MailBox-to-Queue Mapping Register H1 Section 5.62
0x0810 RXU_MAP_L2 MailBox-to-Queue Mapping Register L2 Section 5.61
0x0814 RXU_MAP_H2 MailBox-to-Queue Mapping Register H2 Section 5.62
0x0818 RXU_MAP_L3 MailBox-to-Queue Mapping Register L3 Section 5.61
0x081C RXU_MAP_H3 MailBox-to-Queue Mapping Register H3 Section 5.62
0x0820 RXU_MAP_L4 MailBox-to-Queue Mapping Register L4 Section 5.61
0x0824 RXU_MAP_H4 MailBox-to-Queue Mapping Register H4 Section 5.62
0x0828 RXU_MAP_L5 MailBox-to-Queue Mapping Register L5 Section 5.61
0x082C RXU_MAP_H5 MailBox-to-Queue Mapping Register H5 Section 5.62
0x0830 RXU_MAP_L6 MailBox-to-Queue Mapping Register L6 Section 5.61
0x0834 RXU_MAP_H6 MailBox-to-Queue Mapping Register H6 Section 5.62
0x0838 RXU_MAP_L7 MailBox-to-Queue Mapping Register L7 Section 5.61
0x083C RXU_MAP_H7 MailBox-to-Queue Mapping Register H7 Section 5.62
0x0840 RXU_MAP_L8 MailBox-to-Queue Mapping Register L8 Section 5.61
0x0844 RXU_MAP_H8 MailBox-to-Queue Mapping Register H8 Section 5.62
0x0848 RXU_MAP_L9 MailBox-to-Queue Mapping Register L9 Section 5.61
0x084C RXU_MAP_H9 MailBox-to-Queue Mapping Register H9 Section 5.62
0x0850 RXU_MAP_L10 MailBox-to-Queue Mapping Register L10 Section 5.61
0x0854 RXU_MAP_H10 MailBox-to-Queue Mapping Register H10 Section 5.62
0x0858 RXU_MAP_L11 MailBox-to-Queue Mapping Register L11 Section 5.61
0x085C RXU_MAP_H11 MailBox-to-Queue Mapping Register H11 Section 5.62
0x0860 RXU_MAP_L12 MailBox-to-Queue Mapping Register L12 Section 5.61
0x0864 RXU_MAP_H12 MailBox-to-Queue Mapping Register H12 Section 5.62
0x0868 RXU_MAP_L13 MailBox-to-Queue Mapping Register L13 Section 5.61
0x086C RXU_MAP_H13 MailBox-to-Queue Mapping Register H13 Section 5.62
0x0870 RXU_MAP_L14 MailBox-to-Queue Mapping Register L14 Section 5.61
0x0874 RXU_MAP_H14 MailBox-to-Queue Mapping Register H14 Section 5.62
0x0878 RXU_MAP_L15 MailBox-to-Queue Mapping Register L15 Section 5.61
0x087C RXU_MAP_H15 MailBox-to-Queue Mapping Register H15 Section 5.62
0x0880 RXU_MAP_L16 MailBox-to-Queue Mapping Register L16 Section 5.61
0x0884 RXU_MAP_H16 MailBox-to-Queue Mapping Register H16 Section 5.62
0x0888 RXU_MAP_L17 MailBox-to-Queue Mapping Register L17 Section 5.61
0x088C RXU_MAP_H17 MailBox-to-Queue Mapping Register H17 Section 5.62
