www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x0890 RXU_MAP_L18 MailBox-to-Queue Mapping Register L18 Section 5.61
0x0894 RXU_MAP_H18 MailBox-to-Queue Mapping Register H18 Section 5.62
0x0898 RXU_MAP_L19 MailBox-to-Queue Mapping Register L19 Section 5.61
0x089C RXU_MAP_H19 MailBox-to-Queue Mapping Register H19 Section 5.62
0x08A0 RXU_MAP_L20 MailBox-to-Queue Mapping Register L20 Section 5.61
0x08A4 RXU_MAP_H20 MailBox-to-Queue Mapping Register H20 Section 5.62
0x08A8 RXU_MAP_L21 MailBox-to-Queue Mapping Register L21 Section 5.61
0x08AC RXU_MAP_H21 MailBox-to-Queue Mapping Register H21 Section 5.62
0x08B0 RXU_MAP_L22 MailBox-to-Queue Mapping Register L22 Section 5.61
0x08B4 RXU_MAP_H22 MailBox-to-Queue Mapping Register H22 Section 5.62
0x08B8 RXU_MAP_L23 MailBox-to-Queue Mapping Register L23 Section 5.61
0x08BC RXU_MAP_H23 MailBox-to-Queue Mapping Register H23 Section 5.62
0x08C0 RXU_MAP_L24 MailBox-to-Queue Mapping Register L24 Section 5.61
0x08C4 RXU_MAP_H24 MailBox-to-Queue Mapping Register H24 Section 5.62
0x08C8 RXU_MAP_L25 MailBox-to-Queue Mapping Register L25 Section 5.61
0x08CC RXU_MAP_H25 MailBox-to-Queue Mapping Register H25 Section 5.62
0x08D0 RXU_MAP_L26 MailBox-to-Queue Mapping Register L26 Section 5.61
0x08D4 RXU_MAP_H26 MailBox-to-Queue Mapping Register H26 Section 5.62
0x08D8 RXU_MAP_L27 MailBox-to-Queue Mapping Register L27 Section 5.61
0x08DC RXU_MAP_H27 MailBox-to-Queue Mapping Register H27 Section 5.62
0x08E0 RXU_MAP_L28 MailBox-to-Queue Mapping Register L28 Section 5.61
0x08E4 RXU_MAP_H28 MailBox-to-Queue Mapping Register H28 Section 5.62
0x08E8 RXU_MAP_L29 MailBox-to-Queue Mapping Register L29 Section 5.61
0x08EC RXU_MAP_H29 MailBox-to-Queue Mapping Register H29 Section 5.62
0x08F0 RXU_MAP_L30 MailBox-to-Queue Mapping Register L30 Section 5.61
0x08F4 RXU_MAP_H30 MailBox-to-Queue Mapping Register H30 Section 5.62
0x08F8 RXU_MAP_L31 MailBox-to-Queue Mapping Register L31 Section 5.61
0x08FC RXU_MAP_H31 MailBox-to-Queue Mapping Register H31 Section 5.62
0x0900 FLOW_CNTL0 Flow Control Table Entry Register 0 Section 5.63
0x0904 FLOW_CNTL1 Flow Control Table Entry Register 1 Section 5.63
0x0908 FLOW_CNTL2 Flow Control Table Entry Register 2 Section 5.63
0x090C FLOW_CNTL3 Flow Control Table Entry Register 3 Section 5.63
0x0910 FLOW_CNTL4 Flow Control Table Entry Register 4 Section 5.63
0x0914 FLOW_CNTL5 Flow Control Table Entry Register 5 Section 5.63
0x0918 FLOW_CNTL6 Flow Control Table Entry Register 6 Section 5.63
0x091C FLOW_CNTL7 Flow Control Table Entry Register 7 Section 5.63
0x0920 FLOW_CNTL8 Flow Control Table Entry Register 8 Section 5.63
0x0924 FLOW_CNTL9 Flow Control Table Entry Register 9 Section 5.63
0x0928 FLOW_CNTL10 Flow Control Table Entry Register 10 Section 5.63
0x092C FLOW_CNTL11 Flow Control Table Entry Register 11 Section 5.63
0x0930 FLOW_CNTL12 Flow Control Table Entry Register 12 Section 5.63
0x0934 FLOW_CNTL13 Flow Control Table Entry Register 13 Section 5.63
0x0938 FLOW_CNTL14 Flow Control Table Entry Register 14 Section 5.63
0x093C FLOW_CNTL15 Flow Control Table Entry Register 15 Section 5.63
0x1000 DEV_ID Device Identity CAR Section 5.64
0x1004 DEV_INFO Device Information CAR Section 5.65
