www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x1008 ASBLY_ID Assembly Identity CAR Section 5.66
0x100C ASBLY_INFO Assembly Information CAR Section 5.67
0x1010 PE_FEAT Processing Element Features CAR Section 5.68
0x1018 SRC_OP Source Operations CAR Section 5.69
0x101C DEST_OP Destination Operations CAR Section 5.70
0x104C PE_LL_CTL Processing Element Logical Layer Control CSR Section 5.71
0x1058 LCL_CFG_HBAR Local Configuration Space Base Address 0 CSR Section 5.72
0x105C LCL_CFG_BAR Local Configuration Space Base Address 1 CSR Section 5.73
0x1060 BASE_ID Base Device ID CSR Section 5.74
0x1068 HOST_BASE_ID_LO Host Base Device ID Lock CSR Section 5.75
CK
0x106C COMP_TAG Component Tag CSR Section 5.76
0x1100 SP_MB_HEAD 1x/4x LP_Serial Port Maintenance Block Header Section 5.77
0x1120 SP_LT_CTL Port Link Time-Out Control CSR Section 5.78
0x1124 SP_RT_CTL Port Response Time-Out Control CSR Section 5.79
0x113C SP_GEN_CTL Port General Control CSR Section 5.80
0x1140 SP0_LM_REQ Port 0 Link Maintenance Request CSR Section 5.81
0x1144 SP0_LM_RESP Port 0 Link Maintenance Response CSR Section 5.82
0x1148 SP0_ACKID_STAT Port 0 Local AckID Status CSR Section 5.83
0x1158 SP0_ERR_STAT Port 0 Error and Status CSR Section 5.84
0x115C SP0_CTL Port 0 Control CSR Section 5.85
0x1160 SP1_LM_REQ Port 1 Link Maintenance Request CSR Section 5.81
0x1164 SP1_LM_RESP Port 1 Link Maintenance Response CSR Section 5.82
0x1168 SP1_ACKID_STAT Port 1 Local AckID Status CSR Section 5.83
0x1178 SP1_ERR_STAT Port 1 Error and Status CSR Section 5.84
0x117C SP1_CTL Port 1 Control CSR Section 5.85
0x1180 SP2_LM_REQ Port 2 Link Maintenance Request CSR Section 5.81
0x1184 SP2_LM_RESP Port 2 Link Maintenance Response CSR Section 5.82
0x1188 SP2_ACKID_STAT Port 2 Local AckID Status CSR Section 5.83
0x1198 SP2_ERR_STAT Port 2 Error and Status CSR Section 5.84
0x119C SP2_CTL Port 2 Control CSR Section 5.85
0x11A0 SP3_LM_REQ Port 3 Link Maintenance Request CSR Section 5.81
0x11A4 SP3_LM_RESP Port 3 Link Maintenance Response CSR Section 5.82
0x11A8 SP3_ACKID_STAT Port 3 Local AckID Status CSR Section 5.83
0x11B8 SP3_ERR_STAT Port 3 Error and Status CSR Section 5.84
0x11BC SP3_CTL Port 3 Control CSR Section 5.85
0x2000 ERR_RPT_BH Error Reporting Block Header Section 5.86
0x2008 ERR_DET Logical/Transport Layer Error Detect CSR Section 5.87
0x200C ERR_EN Logical/Transport Layer Error Enable CSR Section 5.88
0x2010 H_ADDR_CAPT Logical/Transport Layer High Address Capture CSR Section 5.89
0x2014 ADDR_CAPT Logical/Transport Layer Address Capture CSR Section 5.90
0x2018 ID_CAPT Logical/Transport Layer Device ID Capture CSR Section 5.91
0x201C CTRL_CAPT Logical/Transport Layer Control Capture CSR Section 5.92
0x2028 PW_TGT_ID Port-Write Target Device ID CSR Section 5.93
0x2040 SP0_ERR_DET Port 0 Error Detect CSR Section 5.94
0x2044 SP0_RATE_EN Port 0 Error Enable CSR Section 5.95
