www.ti.com
SRIO Registers
Table 28. Serial Rapid IO (SRIO) Registers (continued)
Offset Acronym Register Description Section
0x2128 SP3_ERR_RATE Port 3 Error Rate CSR Section 5.101
0x212C SP3_ERR_THRESH Port 3 Error Rate Threshold CSR Section 5.102
0x12000 SP_IP_DISCOVERY Port IP Discovery Timer in 4x mode Section 5.103
_TIMER
0x12004 SP_IP_MODE Port IP Mode CSR Section 5.104
0x12008 IP_PRESCAL Serial Port IP Prescalar Section 5.105
0x12010 SP_IP_PW_IN_CAPT Port-Write-In Capture CSR Register 0 Section 5.106
0
0x12014 SP_IP_PW_IN_CAPT Port-Write-In Capture CSR Register 1 Section 5.106
1
0x12018 SP_IP_PW_IN_CAPT Port-Write-In Capture CSR Register 2 Section 5.106
2
0x1201C SP_IP_PW_IN_CAPT Port-Write-In Capture CSR Register 3 Section 5.106
3
0x14000 SP0_RST_OPT Port 0 Reset Option CSR Section 5.107
0x14004 SP0_CTL_INDEP Port 0 Control Independent Register Section 5.108
0x14008 SP0_SILENCE_TIME Port 0 Silence Timer Register Section 5.109
R
0x1400C SP0_MULT_EVNT_C Port 0 Multicast-Event Control Symbol Request Register Section 5.110
S
0x14014 SP0_CS_TX Port 0 Control Symbol Transmit Register Section 5.111
0x14100 SP1_RST_OPT Port 1 Reset Option CSR Section 5.107
0x14104 SP1_CTL_INDEP Port 1 Control Independent Register Section 5.108
0x14108 SP1_SILENCE_TIME Port 1 Silence Timer Register Section 5.109
R
0x1410C SP1_MULT_EVNT_C Port 1 Multicast-Event Control Symbol Request Register Section 5.110
S
0x14114 SP1_CS_TX Port 1 Control Symbol Transmit Register Section 5.111
0x14200 SP2_RST_OPT Port 2 Reset Option CSR Section 5.107
0x14204 SP2_CTL_INDEP Port 2 Control Independent Register Section 5.108
0x14208 SP2_SILENCE_TIME Port 2 Silence Timer Register Section 5.109
R
0x1420C SP2_MULT_EVNT_C Port 2 Multicast-Event Control Symbol Request Register Section 5.110
S
0x14214 SP2_CS_TX Port 2 Control Symbol Transmit Register Section 5.111
0x14300 SP3_RST_OPT Port 3 Reset Option CSR Section 5.107
0x14304 SP3_CTL_INDEP Port 3 Control Independent Register Section 5.108
0x14308 SP3_SILENCE_TIME Port 3 Silence Timer Register Section 5.109
R
0x1430C SP3_MULT_EVNT_C Port 3 Multicast-Event Control Symbol Request Register Section 5.110
S
0x14314 SP3_CS_TX Port 3 Control Symbol Transmit Register Section 5.111
Serial RapidIO (SRIO)98 SPRU976 – March 2006
