Thomson ST516 v6, ST536 v6 and

ST546 v6

CLI Reference Guide R7.4

Summary of content (706 pages)

PAGE 1
Thomson ST516 v6, ST536 v6 and ST546 v6 CLI Reference Guide R7.
PAGE 2
PAGE 3
Thomson ST516 v6, ST536 v6 and ST546 v6 CLI Reference Guide R7.
PAGE 4
Copyright Copyright ©1999-2007 THOMSON. All rights reserved. Distribution and copying of this document, use and communication of its contents is not permitted without written authorization from THOMSON. The content of this document is furnished for informational use only, may be subject to change without notice, and should not be construed as a commitment by THOMSON. THOMSON assumes no responsibility or liability for any errors or inaccuracies that may appear in this document.
PAGE 5
Contents Contents: ? Command.................................................................................................. 23 .. Command.................................................................................................. 25 atm Commands............................................................................................27 atm cac config....................................................................................................................................................
PAGE 6
Contents atm qosbook ctddelete......................................................................................................................................... 60 atm qosbook ctdlist...............................................................................................................................................61 atm qosbook delete..............................................................................................................................................
PAGE 7
Contents cwmp debug traceconfig.................................................................................................................................... 100 cwmp server config............................................................................................................................................ 101 debug Command....................................................................................... 103 dhcp Commands..............................................................
PAGE 8
Contents dhcp rule delete...................................................................................................................................................142 dhcp rule flush.....................................................................................................................................................143 dhcp rule list........................................................................................................................................................
PAGE 9
Contents dhcp spoofing list................................................................................................................................................183 dhcp spoofing option-add.................................................................................................................................. 184 dhcp spoofing option-delete.............................................................................................................................. 185 dns Commands.......
PAGE 10
Contents dsd urlfilter rule add........................................................................................................................................... 222 dsd urlfilter rule delete....................................................................................................................................... 223 dsd urlfilter rule flush.........................................................................................................................................
PAGE 11
Contents eth bridge ifconfig...............................................................................................................................................262 eth bridge ifdelete............................................................................................................................................... 264 eth bridge ifdetach..............................................................................................................................................
PAGE 12
Contents eth iflist.................................................................................................................................................................303 eth switch group flush........................................................................................................................................304 eth switch group list...........................................................................................................................................
PAGE 13
Contents firewall clear.........................................................................................................................................................344 firewall config...................................................................................................................................................... 345 firewall debug clear............................................................................................................................................
PAGE 14
Contents ids Commands........................................................................................... 385 ids clear................................................................................................................................................................ 386 ids config..............................................................................................................................................................387 ids parser list.................................
PAGE 15
Contents ip auto ifadd.........................................................................................................................................................425 ip auto ifattach.....................................................................................................................................................426 ip auto ifconfig....................................................................................................................................................
PAGE 16
Contents ipqos queue stats................................................................................................................................................ 464 label Commands........................................................................................ 465 label add...............................................................................................................................................................466 label chain add..........................................
PAGE 17
Contents mbus listobjects...................................................................................................................................................502 mbus listsubscriptions........................................................................................................................................ 503 mbus listtypes......................................................................................................................................................
PAGE 18
Contents nat flush................................................................................................................................................................539 nat ifconfig........................................................................................................................................................... 540 nat iflist....................................................................................................................................................
PAGE 19
Contents ra Commands............................................................................................. 581 ra config............................................................................................................................................................... 582 ra start.................................................................................................................................................................. 583 ra stop......................................
PAGE 20
Contents snmp config......................................................................................................................................................... 620 snmp get.............................................................................................................................................................. 621 snmp getnext.......................................................................................................................................................
PAGE 21
Contents systemlog show...................................................................................................................................................660 tls Commands............................................................................................ 661 tls acs-client cert add.......................................................................................................................................... 662 tls acs-client cert delete....................................
PAGE 22
Contents xdsl config............................................................................................................................................................696 xdsl debug bitloadinginfo.................................................................................................................................. 697 xdsl debug deltconfig.........................................................................................................................................
PAGE 23
? Command ? Command Displays this help information E-DOC-CTC-20071119-0004 v1.
PAGE 24
.. Command 24 E-DOC-CTC-20071119-0004 v1.
PAGE 25
.. Command .. Command Exits group selection. E-DOC-CTC-20071119-0004 v1.
PAGE 26
atm Commands 26 E-DOC-CTC-20071119-0004 v1.
PAGE 27
atm Commands atm Commands atm cac config Configure ATM connection admission control. see page 29 atm cac list List all CAC parameters. see page 30 atm cac overbooking Configure ATM overbooking parameters. see page 31 atm debug aal5stats Display AAL5 port specific atm statistics. see page 32 atm debug gstats Display ATM global statistics. see page 33 atm debug portstats Display port specific atm statistics. see page 34 atm flush Flush all ATM interfaces.
PAGE 28
atm Commands 28 atm phonebook delete Delete a phonebook entry. see page 54 atm phonebook flush Flush all phonebook entries. see page 55 atm phonebook list Display the phonebook. see page 56 atm qosbook add Add a new qosbook entry. see page 57 atm qosbook config Modify the qosbook configuration. see page 58 atm qosbook ctdadd Add a new connection traffic descriptor. see page 59 atm qosbook ctddelete Delete a connection traffic descriptor.
PAGE 29
atm Commands atm cac config Configure ATM connection admission control. SYNTAX: atm cac config port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> state = <{disabled|enabled}> where: port The port for which CAC is configured. REQUIRED state Enable/disable CAC for an ATM port. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 30
atm Commands atm cac list List all CAC parameters. 30 E-DOC-CTC-20071119-0004 v1.
PAGE 31
atm Commands atm cac overbooking Configure ATM overbooking parameters. SYNTAX: atm cac overbooking [rt = [nrt = where: rt The realtime overbooking percentage. OPTIONAL nrt The non-realtime overbooking percentage. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 32
atm Commands atm debug aal5stats Display AAL5 port specific atm statistics. SYNTAX: atm debug aal5stats port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = [vci = [clear = <{disabled|enabled}]> where: 32 port The port number for which statistics will be retrieved. REQUIRED vpi The VPI number for which statistics will be retrieved. REQUIRED vci The VCI number for which statistics will be retrieved. OPTIONAL clear Clear the statistics after request.
PAGE 33
atm Commands atm debug gstats Display ATM global statistics. SYNTAX: atm debug gstats [clear = <{disabled|enabled}]> where: clear E-DOC-CTC-20071119-0004 v1.0 Clear the statistics after request.
PAGE 34
atm Commands atm debug portstats Display port specific atm statistics. SYNTAX: atm debug portstats port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> [clear = <{disabled|enabled}]> where: 34 port The port for which statistics will be retrieved. REQUIRED clear Clear the statistics after the request. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 35
atm Commands atm flush Flush all ATM interfaces. E-DOC-CTC-20071119-0004 v1.
PAGE 36
atm Commands atm ifadd Create a new ATM interface. SYNTAX: atm ifadd intf = where: intf 36 The name for the new ATM interface. If not specified, the destination will double as interface name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 37
atm Commands atm ifattach Attach an ATM interface. SYNTAX: atm ifattach intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the ATM interface.
PAGE 38
atm Commands atm ifconfig Modify an ATM interface. SYNTAX: atm ifconfig intf = <{atm_Internet}> [dest = <{}]> [qos = <{default}]> [clp = <{0|1|classification}]> [clpthresh = [encaps = <{llc|vcmux}]> [fcs = <{disabled|enabled|auto}]> [ulp = <{mac|ip|ppp}]> [retry = where: 38 intf The name of the ATM interface to configure. REQUIRED dest The WAN destination for this ATM interface. Typically, a phonebook entry.
PAGE 39
atm Commands atm ifdelete Delete an ATM interface. SYNTAX: atm ifdelete intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the ATM interface.
PAGE 40
atm Commands atm ifdetach Detach an ATM interface. SYNTAX: atm ifdetach intf = <{}> where: intf 40 The name of the ATM interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 41
atm Commands atm iflist Display the ATM interfaces. SYNTAX: atm iflist [intf = <{atm_Internet}]> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of an ATM interface.
PAGE 42
atm Commands atm oam cc list Display CC configuration. 42 E-DOC-CTC-20071119-0004 v1.
PAGE 43
atm Commands atm oam cc modify Modify CC on the connection. SYNTAX: atm oam cc modify port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = [vci = [transmit = <{disabled|enabled}]> [receive = <{disabled|enabled}]> [auto = <{disabled|enabled}]> [span = <{segment|end2end}]> where: port The ATM port number. REQUIRED vpi The Virtual Path Identifier. REQUIRED vci The Virtual Channel Identifier. OPTIONAL transmit Enable/disable transmission of CC cells.
PAGE 44
atm Commands atm oam cc send Send CC activate/deactivate to connection. SYNTAX: atm oam cc send port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = [vci = [span = <{segment|end2end}]> [action = <{activate|deactivate}]> [direction = <{source|sink|both}]> where: 44 port The ATM port number. REQUIRED vpi The Virtual Path Identifier. REQUIRED vci The Virtual Channel Identifier. OPTIONAL span Send CC action end2end or segment. OPTIONAL action The CC action.
PAGE 45
atm Commands atm oam config Modify the ATM OAM settings. SYNTAX: atm oam config [clp = [loopbackid = where: clp The CLP bit value of the OAM cells. OPTIONAL loopbackid The loopback id (hexadecimal string) for processing of segment loopback cells. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 46
atm Commands atm oam list Display the ATM OAM settings. 46 E-DOC-CTC-20071119-0004 v1.
PAGE 47
atm Commands atm oam modify Modify the ATM OAM data blocking mode. SYNTAX: atm oam modify port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> blocking = <{disabled|enabled}> where: port The port for which OAM blocking is configured. REQUIRED blocking Enable/disable OAM blocking. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 48
atm Commands atm oam ping Send ATM loopback cells. SYNTAX: atm oam ping dest = <{atm_pvc_8_35}> [count = [interval = where: 48 dest The destination address for the request. REQUIRED count The number of pings to send. OPTIONAL interval The interval in milliseconds between packets. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 49
atm Commands atm oam vclb add Create a loopback connection for VC SYNTAX: atm oam vclb add port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = [vci = where: port The ATM port number. REQUIRED vpi The Virtual Path Identifier. REQUIRED vci The Virtual Channel Identifier. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 50
atm Commands atm oam vclb del Delete a loopback connection for VC SYNTAX: atm oam vclb del port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number> vpi = [vci = where: 50 port The ATM port number. REQUIRED vpi The Virtual Path Identifier. REQUIRED vci The Virtual Channel Identifier. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 51
atm Commands atm oam vclb list List all VC loopback connections E-DOC-CTC-20071119-0004 v1.
PAGE 52
atm Commands atm phonebook add Add a new phonebook entry. SYNTAX: atm phonebook add name = addr = where: 52 name The phonebook name for this destination. REQUIRED addr The address for this destination. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 53
atm Commands atm phonebook autolist Display auto PVC's. E-DOC-CTC-20071119-0004 v1.
PAGE 54
atm Commands atm phonebook delete Delete a phonebook entry. SYNTAX: atm phonebook delete name = <{}> where: name 54 The name of the entry to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 55
atm Commands atm phonebook flush Flush all phonebook entries. E-DOC-CTC-20071119-0004 v1.
PAGE 56
atm Commands atm phonebook list Display the phonebook. 56 E-DOC-CTC-20071119-0004 v1.
PAGE 57
atm Commands atm qosbook add Add a new qosbook entry. SYNTAX: atm qosbook add name = [txctd = <{default}]> [rxctd = <{default}]> where: name The name for the new QoS entry. REQUIRED txctd The name of the CTD for transmit (upstream) direction. OPTIONAL rxctd The name of the CTD for receive (downstream) direction. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 58
atm Commands atm qosbook config Modify the qosbook configuration. SYNTAX: atm qosbook config [format = <{bytes|cells}]> where: format 58 The input, output format of the qosbook. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 59
atm Commands atm qosbook ctdadd Add a new connection traffic descriptor. SYNTAX: atm qosbook ctdadd name = conformance = <{UBR|CBR|VBR|UBR.1|UBR.2| UBR.mdcr|CBR.1|VBR.1|VBR.2|VBR.3|VBR.c|VBR.nt| VBR.t|GFR.1|GFR.
PAGE 60
atm Commands atm qosbook ctddelete Delete a connection traffic descriptor. SYNTAX: atm qosbook ctddelete name = <{default}> [force = <{disabled|enabled}]> where: 60 name The name of the CTD entry to delete. REQUIRED force Force delete even when the entry is still in use. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 61
atm Commands atm qosbook ctdlist Display all connection traffic descriptors. E-DOC-CTC-20071119-0004 v1.
PAGE 62
atm Commands atm qosbook delete Delete a qosbook entry. SYNTAX: atm qosbook delete name = <{default}> [force = <{disabled|enabled}]> where: 62 name The name of the qosbook entry to delete. REQUIRED force Force delete even when the entry is still in use. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 63
atm Commands atm qosbook flush Flush all qosbook entries. E-DOC-CTC-20071119-0004 v1.
PAGE 64
atm Commands atm qosbook list Display the qosbook. 64 E-DOC-CTC-20071119-0004 v1.
PAGE 65
autopvc Commands autopvc Commands autopvc config Configure autopvc. see page 66 autopvc list Show retreived information. see page 67 E-DOC-CTC-20071119-0004 v1.
PAGE 66
autopvc Commands autopvc config Configure autopvc. SYNTAX: autopvc config [mode = <{pseudo|passive|active}]> [type = <{bridge|pppoerelay|ipoa|ethoa|pppoa| pppoe}]> [overwrite = <{disabled|enabled}]> [peakrate = where: 66 mode Autopvc mode. OPTIONAL type Type of autopvc. OPTIONAL overwrite Enable/disable UBR peak rate overwrite. OPTIONAL peakrate The UBR peak rate (in kilobits per second) '0' to indicate linerate. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 67
autopvc Commands autopvc list Show retreived information. SYNTAX: autopvc list [table = <{Port|AtmLayer|Vpc|Vcc|Address| AddressRegistrationAdmin|AAL5Profile| AAL2CommonProfile|AAL2TrunkingProfile| AAL2LESProfile|AtmServiceConnInfoExtension| AtmServiceTypeExtension| AAL5ProfileExtension}]> where: table E-DOC-CTC-20071119-0004 v1.0 Autopvc table.
PAGE 68
config Commands 68 E-DOC-CTC-20071119-0004 v1.
PAGE 69
config Commands config Commands config delete Delete a user configuration file. see page 70 config dump Show the saved configuration file see page 71 config flush Flush the loaded configuration. see page 72 config list Show the current configuration set see page 73 config load Load saved or default configuration. see page 74 config save Store current configuration to backup file see page 75 E-DOC-CTC-20071119-0004 v1.
PAGE 70
config Commands config delete Delete a user configuration file. SYNTAX: config delete [filename = where: filename 70 configuration file to erase OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 71
config Commands config dump Show the saved configuration file E-DOC-CTC-20071119-0004 v1.
PAGE 72
config Commands config flush Flush the loaded configuration. SYNTAX: config flush [flush_ip = <{enabled|disabled}]> where: flush_ip 72 Flush IP settings or not. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 73
config Commands config list Show the current configuration set SYNTAX: config list [templates = <{disabled|enabled}]> where: templates E-DOC-CTC-20071119-0004 v1.
PAGE 74
config Commands config load Load saved or default configuration. SYNTAX: config load [load_ip = <{enabled|disabled}]> [defaults = <{disabled|enabled}]> [flush = <{enabled|disabled}]> [echo = <{disabled|enabled}]> [filename = where: 74 load_ip Load IP settings or not. OPTIONAL defaults Load default instead of saved configuration. OPTIONAL flush Flush current configuration before loading new one. OPTIONAL echo Echo each command string when loaded.
PAGE 75
config Commands config save Store current configuration to backup file SYNTAX: config save filename = where: filename E-DOC-CTC-20071119-0004 v1.
PAGE 76
connection Commands 76 E-DOC-CTC-20071119-0004 v1.
PAGE 77
connection Commands connection Commands connection appconfig Modify a CONN/NAT application helper configuration see page 78 connection appinfo Display CONN/NAT application specific info see page 79 connection applist Display the available CONN/NAT application helpers. see page 80 connection bind Create a CONN/NAT application helper/port binding. see page 81 connection bindlist Display the CONN/NAT application helper/port bindings.
PAGE 78
connection Commands connection appconfig Modify a CONN/NAT application helper configuration SYNTAX: connection appconfig application = <{IP6TO4|PPTP|ESP|IKE|SIP| JABBER|CU/SeeMe|RAUDIO(PNA)|RTSP|ILS|H245| H323|IRC|GAME(UDP)|CONE(UDP)|LOOSE(UDP)|FTP}> [trace = <{disabled|enabled}]> [timeout = [childqos = <{DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [floating = <{disabled|enabled}]> [proxy = <{disabled|enabled}]> [tracelevel = [SIP_ALG = <{disabled|
PAGE 79
connection Commands connection appinfo Display CONN/NAT application specific info SYNTAX: connection appinfo application = <{IP6TO4|PPTP|ESP|IKE|SIP| JABBER|CU/SeeMe|RAUDIO(PNA)|RTSP|ILS|H245| H323|IRC|GAME(UDP)|CONE(UDP)|LOOSE(UDP)|FTP}> where: application E-DOC-CTC-20071119-0004 v1.0 The name of a CONN/NAT application helper as listed by ':connection applist'.
PAGE 80
connection Commands connection applist Display the available CONN/NAT application helpers. 80 E-DOC-CTC-20071119-0004 v1.
PAGE 81
connection Commands connection bind Create a CONN/NAT application helper/port binding. SYNTAX: connection bind application = <{IP6TO4|PPTP|ESP|IKE|SIP| JABBER|CU/SeeMe|RAUDIO(PNA)|RTSP|ILS|H245| H323|IRC|GAME(UDP)|CONE(UDP)|LOOSE(UDP)|FTP}> port = where: application The name of a CONN/NAT application helper as listed by ':connection applist'. REQUIRED port The port number or range this application handler should work on. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 82
connection Commands connection bindlist Display the CONN/NAT application helper/port bindings. 82 E-DOC-CTC-20071119-0004 v1.
PAGE 83
connection Commands connection clean Clean connection database by forcing timeouts. SYNTAX: connection clean [level = where: level E-DOC-CTC-20071119-0004 v1.0 Scrubbing level.
PAGE 84
connection Commands connection clear Kill all connections. 84 E-DOC-CTC-20071119-0004 v1.
PAGE 85
connection Commands connection config Modify global connection configuration. SYNTAX: connection config [configchangemode = <{immediate|delayed}]> [probes = <{disabled|enabled}]> [udptrackmode = <{strict|loose}]> where: configchangemode Select how config changes are handled. OPTIONAL probes Enable/disable alive probes on idle connections. OPTIONAL udptrackmode UDP connection tracking mode. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 86
connection Commands connection debug Connection debug commands. SYNTAX: connection debug [trace = <{disabled|enabled}]> where: trace 86 Enable/disable traces. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 87
connection Commands connection describe Describe the streams of a connection. SYNTAX: connection describe [id = where: id E-DOC-CTC-20071119-0004 v1.0 The connection ID to describe.
PAGE 88
connection Commands connection flush Flush the connection configuration. 88 E-DOC-CTC-20071119-0004 v1.
PAGE 89
connection Commands connection info Display all modules with some info. E-DOC-CTC-20071119-0004 v1.
PAGE 90
connection Commands connection list Display the currently known connections. SYNTAX: connection list [nr = [history = <{disabled|enabled}]> where: 90 nr The number of connections to display. OPTIONAL history If enabled, show history. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 91
connection Commands connection refresh Invalidate all cached decisions. E-DOC-CTC-20071119-0004 v1.
PAGE 92
connection Commands connection stats Display connection and stream statistics. 92 E-DOC-CTC-20071119-0004 v1.
PAGE 93
connection Commands connection timerclear Clear connection timeout to default. SYNTAX: connection timerclear [timer = <{tcpidle|tcpneg|tcpkill|udpidle| udpkill|icmpkill|ipidle|ipkill|aiprefresh}]> where: timer E-DOC-CTC-20071119-0004 v1.0 The name of the connection idle timer.
PAGE 94
connection Commands connection timerconfig Modify connection timeout handling. SYNTAX: connection timerconfig [timer = <{tcpidle|tcpneg|tcpkill|udpidle| udpkill|icmpkill|ipidle|ipkill|aiprefresh}]> [value = where: 94 timer The name of the connection idle timer. OPTIONAL value The timer expire value in seconds. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 95
connection Commands connection unbind Delete a CONN/NAT application helper/port binding. SYNTAX: connection unbind application = <{IP6TO4|PPTP|ESP|IKE|SIP| JABBER|CU/SeeMe|RAUDIO(PNA)|RTSP|ILS|H245| H323|IRC|GAME(UDP)|CONE(UDP)|LOOSE(UDP)|FTP}> port = where: application The name of a CONN/NAT application helper as listed by ':connection applist'. REQUIRED port The port number or range this application handler should work on. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 96
cwmp Commands 96 E-DOC-CTC-20071119-0004 v1.
PAGE 97
cwmp Commands cwmp Commands cwmp config Configure the cwmpd as seen from the ACS. see page 98 cwmp debug traceconfig Enable or disable tracing. see page 100 cwmp server config Configure the cwmpd towards the ACS. see page 101 E-DOC-CTC-20071119-0004 v1.
PAGE 98
cwmp Commands cwmp config Configure the cwmpd as seen from the ACS.
PAGE 99
cwmp Commands connectionReqAuth Set the authentication type of modem CWMP server for asynchronous connects. OPTIONAL qos-class Set the quality of service class for outgoing CWMP data. OPTIONAL bootdelayrange Set the delay on boot before inform is sent. OPTIONAL upgradedelay Set whether to delay upgrade if services are active. OPTIONAL am1Termination Set if am 1 session termination is enabled. OPTIONAL persistentSubscription The cwmp daemon has persistent subscriptions.
PAGE 100
cwmp Commands cwmp debug traceconfig Enable or disable tracing. SYNTAX: cwmp debug traceconfig [level = where: level 100 Set the tracelevel (0-2) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 101
cwmp Commands cwmp server config Configure the cwmpd towards the ACS. SYNTAX: cwmp server config [url = [username = [password = where: url Set the HTTP URL used to contact the ACS server. OPTIONAL username Set the username for ACS Digest Authentication. OPTIONAL password Set the password for ACS Digest Authentication. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 102
debug Command 102 E-DOC-CTC-20071119-0004 v1.
PAGE 103
debug Command debug Command Execute a 'Trace & Debug' command. For qualified personnel only. SYNTAX: debug exec cmd = where: cmd E-DOC-CTC-20071119-0004 v1.
PAGE 104
dhcp Commands 104 E-DOC-CTC-20071119-0004 v1.
PAGE 105
dhcp Commands dhcp Commands dhcp client debug clear Clear DHCP client statistics see page 109 dhcp client debug stats Print DHCP client statistics see page 110 dhcp client debug traceconfig Modify DHCP client trace configuration see page 111 dhcp client flush Delete all DHCP clients. see page 112 dhcp client ifadd Create a DHCP client. see page 113 dhcp client ifattach Activate a DHCP client. see page 114 dhcp client ifconfig Configure a DHCP client.
PAGE 106
dhcp Commands 106 dhcp relay delete Delete an entry from the DHCP forward list. see page 132 dhcp relay flush Flushes the DHCP relay settings. see page 133 dhcp relay ifconfig Configure a relay interface. see page 134 dhcp relay iflist Show the configuration of the relay interfaces. see page 135 dhcp relay list List the DHCP forward list. see page 136 dhcp relay modify Modify an entry from the DHCP forward list.
PAGE 107
dhcp Commands dhcp server option instlist List all DHCP server option instances see page 157 dhcp server option ruleadd Add a selection rule to a DHCP server option instance see page 158 dhcp server option ruledelete Delete a selection rule from a DHCP server option instance see page 159 dhcp server option tmpladd Add a DHCP server option template see page 160 dhcp server option tmpldelete Delete a DHCP server option template see page 161 dhcp server option tmpllist List all DHCP server opt
PAGE 108
dhcp Commands 108 dhcp spoofing list List the available SpoofingAssociations see page 183 dhcp spoofing option-add Add a DHCP Option Code to a Spoofing-Association. see page 184 dhcp spoofing option-delete Delete a DHCP Option Code from a Spoofing-Association. see page 185 E-DOC-CTC-20071119-0004 v1.
PAGE 109
dhcp Commands dhcp client debug clear Clear DHCP client statistics E-DOC-CTC-20071119-0004 v1.
PAGE 110
dhcp Commands dhcp client debug stats Print DHCP client statistics 110 E-DOC-CTC-20071119-0004 v1.
PAGE 111
dhcp Commands dhcp client debug traceconfig Modify DHCP client trace configuration SYNTAX: dhcp client debug traceconfig [state = <{disabled|enabled}]> where: state E-DOC-CTC-20071119-0004 v1.0 Enable/Disable tracing.
PAGE 112
dhcp Commands dhcp client flush Delete all DHCP clients. 112 E-DOC-CTC-20071119-0004 v1.
PAGE 113
dhcp Commands dhcp client ifadd Create a DHCP client. SYNTAX: dhcp client ifadd intf = <{Internet|LocalNetwork}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the interface on which a DHCP Client is defined.
PAGE 114
dhcp Commands dhcp client ifattach Activate a DHCP client. SYNTAX: dhcp client ifattach intf = <> where: intf 114 The name of the interface on which a DHCP Client is defined. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 115
dhcp Commands dhcp client ifconfig Configure a DHCP client. SYNTAX: dhcp client ifconfig intf = <> [label = <{None|DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [metric = [dnsmetric = [broadcast = <{disabled|enabled}]> [serverroute = <{disabled|enabled}]> [followlabel = <{disabled|enabled}]> where: intf The name of the dynamic interface to be configured. REQUIRED label Label for default gateway and static routes.
PAGE 116
dhcp Commands dhcp client ifdelete Delete a DHCP client. SYNTAX: dhcp client ifdelete intf = <> where: intf 116 The name of the interface on which a DHCP Client is defined. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 117
dhcp Commands dhcp client ifdetach De-activate a DHCP client and releases its lease. SYNTAX: dhcp client ifdetach intf = <> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the interface on which a DHCP Client is defined.
PAGE 118
dhcp Commands dhcp client iflist List DHCP clients. SYNTAX: dhcp client iflist [intf = <]> [expand = <{disabled|enabled}]> where: 118 intf The name of the interface on which a DHCP Client is defined. OPTIONAL expand Expand enabled/disabled. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 119
dhcp Commands dhcp client ifrenew Renew a DHCP lease. SYNTAX: dhcp client ifrenew intf = <> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the interface on which a DHCP Client is defined.
PAGE 120
dhcp Commands dhcp client rqoptions add Add a DHCP Option Code to the Parameter Request List.
PAGE 121
dhcp Commands dhcp client rqoptions delete Delete a DHCP Option Code from the Parameter Request List.
PAGE 122
dhcp Commands dhcp client rqoptions list List all DHCP Option Codes in the Parameter Request List. SYNTAX: dhcp client rqoptions list [intf = <]> where: intf 122 The name of the interface on which a DHCP Client is defined. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 123
dhcp Commands dhcp client rqoptions optionlist List all DHCP Option Codes that can be used in the Parameter Request List. E-DOC-CTC-20071119-0004 v1.
PAGE 124
dhcp Commands dhcp client txoptions add Add an option. SYNTAX: dhcp client txoptions add intf = <> option = <{subnet-mask|time-offset|defaultrouters|time-servers|ien116-name-impressservers|resource-location-servers|hostname|boot-file-size|merit-dump|domain-name| swap-server|root-path|extensions-path|ipforwarding|non-local-source-routing|policyfilter|max-dgram-reassembly|default-ip-ttl| path-mtu-aging-timeout|path-mtu-plateau-table| interface-mtu|all-subnets-local|broadcastaddress|perform-mask-discovery|.
PAGE 125
dhcp Commands dhcp client txoptions delete Delete an option.
PAGE 126
dhcp Commands dhcp client txoptions list List all options. SYNTAX: dhcp client txoptions list [intf = <]> [expand = <{disabled|enabled}]> where: 126 intf The name of the interface on which a DHCP Client is defined. OPTIONAL expand Expand enabled/disabled. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 127
dhcp Commands dhcp client txoptions optionlist Lists all DHCP Option Codes that can be used. E-DOC-CTC-20071119-0004 v1.
PAGE 128
dhcp Commands dhcp relay add Add an entry to the DHCP forward list. SYNTAX: dhcp relay add name = where: name 128 The forward entry name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 129
dhcp Commands dhcp relay config Sets the relay configuration settings. SYNTAX: dhcp relay config [agentinfo = <{disabled|enabled}]> [agentmismatch = <{disabled|enabled}]> where: agentinfo Set the relay agent info status (RFC3046). OPTIONAL agentmismatch Forward/Drop DHCP reply packet when a relay agent info mismatch is detected (RFC3046). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 130
dhcp Commands dhcp relay debug stats Print DHCP relay statistics. 130 E-DOC-CTC-20071119-0004 v1.
PAGE 131
dhcp Commands dhcp relay debug traceconfig Modify DHCP relay trace configuration SYNTAX: dhcp relay debug traceconfig [state = <{disabled|enabled}]> where: state E-DOC-CTC-20071119-0004 v1.0 Enable/Disable tracing.
PAGE 132
dhcp Commands dhcp relay delete Delete an entry from the DHCP forward list. SYNTAX: dhcp relay delete name = <{LocalNetwork_to_127.0.0.1}> where: name 132 The forward entry name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 133
dhcp Commands dhcp relay flush Flushes the DHCP relay settings. E-DOC-CTC-20071119-0004 v1.
PAGE 134
dhcp Commands dhcp relay ifconfig Configure a relay interface. SYNTAX: dhcp relay ifconfig intf = <{LocalNetwork|Internet}> [relay = <{disabled|enabled}]> [maxhops = [remoteid = [trusted = <{disabled|enabled}]> where: 134 intf The name of the relay interface to configure. REQUIRED relay Set the relay status. OPTIONAL maxhops Set the maximum number of hops allowed in the DHCP packet. OPTIONAL remoteid Set the remote id as specified in RFC3046.
PAGE 135
dhcp Commands dhcp relay iflist Show the configuration of the relay interfaces. SYNTAX: dhcp relay iflist [intf = <{LocalNetwork|Internet}]> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the relay interface.
PAGE 136
dhcp Commands dhcp relay list List the DHCP forward list. SYNTAX: dhcp relay list [name = <{LocalNetwork_to_127.0.0.1}]> where: name 136 The forward entry name. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 137
dhcp Commands dhcp relay modify Modify an entry from the DHCP forward list. SYNTAX: dhcp relay modify name = <{LocalNetwork_to_127.0.0.1}> [addr = [intf = <{None|LocalNetwork|Internet}]> [giaddr = [script = <]> where: name The forward entry name. REQUIRED addr The DHCP server IP address. OPTIONAL intf The name of the relay interface, 'None' to indicate no interface is specified. OPTIONAL giaddr The giaddr field to be used in relayed DHCP packets.
PAGE 138
dhcp Commands dhcp relay ruleadd Add a selection rule to a DHCP forward entry SYNTAX: dhcp relay ruleadd name = <{LocalNetwork_to_127.0.0.1}> [key = <{or|and}]> rulename = <> where: 138 name The name of the forward entry. REQUIRED key The logical key of the selection rule. OPTIONAL rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 139
dhcp Commands dhcp relay ruledelete Delete a selection rule from a DHCP forward entry SYNTAX: dhcp relay ruledelete name = <{LocalNetwork_to_127.0.0.1}> rulename = <> where: name The name of the forward entry. REQUIRED rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 140
dhcp Commands dhcp rule add Add a rule for DHCP conditional selection SYNTAX: dhcp rule add name = type = <{option|mac|vci|uci}> option [!] = <{subnet-mask|time-offset| default-routers|time-servers|ien116-servers| impress-servers|resource-location-servers| host-name|boot-file-size|merit-dump|domainname|swap-server|root-path|extensions-path| ip-forwarding|non-local-source-routing|policyfilter|max-dgram-reassembly|default-ip-ttl| path-mtu-aging-timeout|path-mtu-plateau-table| interface-mtu|all-sub
PAGE 141
dhcp Commands dhcp rule debug traceconfig Modify DHCP rule trace configuration SYNTAX: dhcp rule debug traceconfig [state = <{disabled|enabled}]> where: state E-DOC-CTC-20071119-0004 v1.0 Enable/Disable tracing.
PAGE 142
dhcp Commands dhcp rule delete Delete a DHCP rule SYNTAX: dhcp rule delete name = <> where: name 142 The name of the DHCP rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 143
dhcp Commands dhcp rule flush Flush all DHCP rules E-DOC-CTC-20071119-0004 v1.
PAGE 144
dhcp Commands dhcp rule list List all DHCP rules 144 E-DOC-CTC-20071119-0004 v1.
PAGE 145
dhcp Commands dhcp server config Print DHCP server configuration settings SYNTAX: dhcp server config [state = <{disabled|enabled}]> where: state E-DOC-CTC-20071119-0004 v1.0 Enable/Disable the DHCP server.
PAGE 146
dhcp Commands dhcp server debug clear Clear DHCP server statistics 146 E-DOC-CTC-20071119-0004 v1.
PAGE 147
dhcp Commands dhcp server debug stats Print DHCP server statistics E-DOC-CTC-20071119-0004 v1.
PAGE 148
dhcp Commands dhcp server debug traceconfig Modify DHCP server trace configuration SYNTAX: dhcp server debug traceconfig [state = <{disabled|enabled}]> where: state 148 Enable/Disable tracing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 149
dhcp Commands dhcp server flush Flush all DHCP server pool and lease entries E-DOC-CTC-20071119-0004 v1.
PAGE 150
dhcp Commands dhcp server lease add Add a DHCP server lease SYNTAX: dhcp server lease add clientid = pool = <{LAN_private}> [addr = [offset = [leasetime = [expirytime = [gateway = [macaddr = where: 150 clientid The DHCP client identification string of the host. REQUIRED pool The name of the DHCP server pool. REQUIRED addr The IP address for this client.
PAGE 151
dhcp Commands dhcp server lease delete Delete a DHCP server lease SYNTAX: dhcp server lease delete [clientid = [index = [expand = <{disabled|enabled}]> where: clientid The DHCP client identification string. OPTIONAL index The DHCP server lease table index. OPTIONAL expand Expand enabled/disabled. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 152
dhcp Commands dhcp server lease flush Flush all DHCP server leases SYNTAX: dhcp server lease flush [pool = <{LAN_private}]> where: pool 152 The name of the DHCP server pool. Only the leases belonging to this pool will be deleted. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 153
dhcp Commands dhcp server lease list List all DHCP server leases SYNTAX: dhcp server lease list [clientid = [index = [expand = <{disabled|enabled}]> where: clientid The DHCP client identification string. OPTIONAL index The DHCP server lease table index. OPTIONAL expand Expand enabled/disabled. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 154
dhcp Commands dhcp server option flush Flush all DHCP server option templates and instances 154 E-DOC-CTC-20071119-0004 v1.
PAGE 155
dhcp Commands dhcp server option instadd Add a DHCP server option instance SYNTAX: dhcp server option instadd name = tmplname = <> [policy = <{requested|always|rules}]> [dynamic = <{disabled|enabled}]> [maxuse = [enterprise = [suboption = value = where: name The name of the DHCP server option instance. REQUIRED tmplname The name of the DHCP server option template.
PAGE 156
dhcp Commands dhcp server option instdelete Delete a DHCP server option instance SYNTAX: dhcp server option instdelete name = <> [enterprise = [suboption = where: 156 name The name of the DHCP server option instance. REQUIRED enterprise The enterprise number (see http://www.iana.org/ assignments/enterprise- numbers) OPTIONAL suboption The suboption number OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 157
dhcp Commands dhcp server option instlist List all DHCP server option instances SYNTAX: dhcp server option instlist [name = <]> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the DHCP server option instance.
PAGE 158
dhcp Commands dhcp server option ruleadd Add a selection rule to a DHCP server option instance SYNTAX: dhcp server option ruleadd name = <> [key = <{or|and}]> rulename = <> where: 158 name The name of the DHCP server option instance. REQUIRED key The logical key of the selection rule. OPTIONAL rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 159
dhcp Commands dhcp server option ruledelete Delete a selection rule from a DHCP server option instance SYNTAX: dhcp server option ruledelete name = <> rulename = <> where: name The name of the DHCP server option instance. REQUIRED rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 160
dhcp Commands dhcp server option tmpladd Add a DHCP server option template SYNTAX: dhcp server option tmpladd name = optionid = [dynamic = <{disabled|enabled}]> where: 160 name The name of the DHCP server option template. REQUIRED optionid Specify the DHCP server option code. REQUIRED dynamic Enable/Disable option template as dynamic. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 161
dhcp Commands dhcp server option tmpldelete Delete a DHCP server option template SYNTAX: dhcp server option tmpldelete name = <> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the DHCP server option template.
PAGE 162
dhcp Commands dhcp server option tmpllist List all DHCP server option templates 162 E-DOC-CTC-20071119-0004 v1.
PAGE 163
dhcp Commands dhcp server policy Print DHCP server policy settings SYNTAX: dhcp server policy [verifyfirst = <{disabled|enabled}]> [trustclient = <{disabled|enabled}]> [rtbehaviour = <{traditional|standard|msft}]> where: verifyfirst Enable/Disable IP address conflict network probing before handing out an address to a client. OPTIONAL trustclient Whether or not the IP address suggested by a DHCP client should be taken into account.
PAGE 164
dhcp Commands dhcp server pool add Add a DHCP server pool SYNTAX: dhcp server pool add name = [index = where: 164 name The name of the DHCP server pool. REQUIRED index The number of the pool before which you want the new pool to be added. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 165
dhcp Commands dhcp server pool config Configure a DHCP server pool SYNTAX: dhcp server pool config name = <{LAN_private}> [state = <{disabled|enabled}]> [intf = <{Internet|LocalNetwork}]> [index = [poolstart = [poolend = [netmask = [gateway = [server = [primdns = [secdns = [dnsmetric = [primwins = [secwins = [
PAGE 166
dhcp Commands 166 secdns The IP address of the secondary DNS server for DHCP clients. OPTIONAL dnsmetric The DHCP server pool DNS route metric. OPTIONAL primwins The IP address of the primary WINS server for DHCP clients. OPTIONAL secwins The IP address of the secondary WINS server for DHCP clients. OPTIONAL leasetime The time in seconds a client is allowed to use an address (tip: 0 means infinite lease). OPTIONAL renewtime The time in seconds before a client switches to renewing.
PAGE 167
dhcp Commands dhcp server pool delete Delete a DHCP server pool SYNTAX: dhcp server pool delete name = <{LAN_private}> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the DHCP server pool.
PAGE 168
dhcp Commands dhcp server pool flush Flush all DHCP server pools 168 E-DOC-CTC-20071119-0004 v1.
PAGE 169
dhcp Commands dhcp server pool list List all DHCP server pools SYNTAX: dhcp server pool list [name = <{LAN_private}]> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the DHCP server pool.
PAGE 170
dhcp Commands dhcp server pool optadd Add an option instance to the DHCP server pool SYNTAX: dhcp server pool optadd name = <{LAN_private}> instname = <> where: 170 name The name of the DHCP server pool. REQUIRED instname The name of the DHCP server option instance. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 171
dhcp Commands dhcp server pool optdelete Delete an option instance from the DHCP server pool SYNTAX: dhcp server pool optdelete name = <{LAN_private}> instname = <> where: name The name of the DHCP server pool. REQUIRED instname The name of the DHCP server option instance. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 172
dhcp Commands dhcp server pool rtadd Add a route to the DHCP server pool SYNTAX: dhcp server pool rtadd name = <{LAN_private}> dst = [dstmsk = [gateway = where: 172 name The name of the DHCP server pool. REQUIRED dst The IP destination address of the route for DHCP clients. REQUIRED dstmsk The destination IP address mask. OPTIONAL gateway The IP address of the next hop.
PAGE 173
dhcp Commands dhcp server pool rtdelete Delete a route from the DHCP server pool SYNTAX: dhcp server pool rtdelete name = <{LAN_private}> dst = [dstmsk = [gateway = where: name The name of the DHCP server pool. REQUIRED dst The IP destination address of the route for DHCP clients. REQUIRED dstmsk The destination IP address mask. OPTIONAL gateway The IP address of the next hop.
PAGE 174
dhcp Commands dhcp server pool ruleadd Add a selection rule to the DHCP server pool SYNTAX: dhcp server pool ruleadd name = <{LAN_private}> [key = <{or|and}]> rulename = <> where: 174 name The name of the DHCP server pool. REQUIRED key The logical key of the selection rule. OPTIONAL rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 175
dhcp Commands dhcp server pool ruledelete Delete a selection rule from the DHCP server pool SYNTAX: dhcp server pool ruledelete name = <{LAN_private}> rulename = <> where: name The name of the DHCP server pool. REQUIRED rulename The name of the DHCP selection rule. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 176
dhcp Commands dhcp spoofing add Add a Spoofing-Association SYNTAX: dhcp spoofing add name = pool_name = <{LAN_private}> ifname = <> where: 176 name The name of the Association. REQUIRED pool_name The name of the pool to be associated. REQUIRED ifname The name of the interface on which a DHCP Client is defined. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 177
dhcp Commands dhcp spoofing attach Enable a Spoofing-Association SYNTAX: dhcp spoofing attach name = <{|||}> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the Association.
PAGE 178
dhcp Commands dhcp spoofing config Display/modify dhcp spoofing state SYNTAX: dhcp spoofing config [state = <{enabled|disabled}]> where: state 178 Enable/Disable spoofing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 179
dhcp Commands dhcp spoofing debug traceconfig Display/modify DHCP spoofing trace configuratin SYNTAX: dhcp spoofing debug traceconfig [state = <{disabled|enabled}]> where: state E-DOC-CTC-20071119-0004 v1.0 Enable/Disable tracing.
PAGE 180
dhcp Commands dhcp spoofing delete Delete a Spoofing-Association SYNTAX: dhcp spoofing delete name = <{|||}> where: name 180 The name of the Association. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 181
dhcp Commands dhcp spoofing detach Disable a Spoofing-Association SYNTAX: dhcp spoofing detach name = <{|||}> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the Association.
PAGE 182
dhcp Commands dhcp spoofing flush Flush all the associations and the options. 182 E-DOC-CTC-20071119-0004 v1.
PAGE 183
dhcp Commands dhcp spoofing list List the available Spoofing-Associations SYNTAX: dhcp spoofing list [name = <{|||}]> where: name E-DOC-CTC-20071119-0004 v1.0 The name of the Association.
PAGE 184
dhcp Commands dhcp spoofing option-add Add a DHCP Option Code to a Spoofing-Association. SYNTAX: dhcp spoofing option-add name = <{|||}> option = where: 184 name The name of the Association. REQUIRED option The option id. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 185
dhcp Commands dhcp spoofing option-delete Delete a DHCP Option Code from a Spoofing-Association. SYNTAX: dhcp spoofing option-delete name = <{|||}> option = where: name The name of the Association. REQUIRED option The option id. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 186
dns Commands 186 E-DOC-CTC-20071119-0004 v1.
PAGE 187
dns Commands dns Commands dns client config Modify the DNS resolver configuration. see page 188 dns client dnsadd Add a DNS server. see page 189 dns client dnsdelete Delete a DNS server. see page 190 dns client dnslist List all DNS servers. see page 191 dns client flush Remove all DNS servers. see page 192 dns client nslookup DNS lookup for a domain name or an address.
PAGE 188
dns Commands dns client config Modify the DNS resolver configuration. SYNTAX: dns client config [timeout = [retry = [search = <{disabled|enabled}]> [list = [trace = <{disabled|enabled}]> where: 188 timeout The query timeout in seconds. OPTIONAL retry The number of query retries before giving up. OPTIONAL search Use the searchlist to construct fully qualified domain names. OPTIONAL list Slash separated list of domain name suffixes.
PAGE 189
dns Commands dns client dnsadd Add a DNS server. SYNTAX: dns client dnsadd addr = [port = where: addr The DNS server IP address. REQUIRED port The DNS server port number. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 190
dns Commands dns client dnsdelete Delete a DNS server. SYNTAX: dns client dnsdelete index = where: index 190 The index number (shown by the 'list' command) of the server to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 191
dns Commands dns client dnslist List all DNS servers. E-DOC-CTC-20071119-0004 v1.
PAGE 192
dns Commands dns client flush Remove all DNS servers. 192 E-DOC-CTC-20071119-0004 v1.
PAGE 193
dns Commands dns client nslookup DNS lookup for a domain name or an address. SYNTAX: dns client nslookup host = where: host E-DOC-CTC-20071119-0004 v1.0 The DNS domain name string to query.
PAGE 194
dns Commands dns server config DNS server configuration settings SYNTAX: dns server config [domain = [timeout = [suppress = [state = <{disabled|enabled}]> [trace = <{disabled|enabled}]> [syslog = <{disabled|enabled}]> [WANDownSpoofing = <{disabled|enabled}]> [WDSpoofedIP = where: 194 domain The DNS server domain name. OPTIONAL timeout The forwarded DNS query timeout.
PAGE 195
dns Commands dns server debug clear Clear the DNS server/forwarder statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 196
dns Commands dns server debug spoof clear Clear the intercept cache table 196 E-DOC-CTC-20071119-0004 v1.
PAGE 197
dns Commands dns server debug spoof getaddress Get the real ip for the given spoofed ip SYNTAX: dns server debug spoof getaddress addr = where: addr E-DOC-CTC-20071119-0004 v1.0 The spoofed ip to look up.
PAGE 198
dns Commands dns server debug spoof getflags Get the error flags for the given spoofed ip SYNTAX: dns server debug spoof getflags addr = where: addr 198 The spoofed ip to look up. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 199
dns Commands dns server debug spoof list List the intercept cache table. E-DOC-CTC-20071119-0004 v1.
PAGE 200
dns Commands dns server debug spoof update update the intercept cache table 200 E-DOC-CTC-20071119-0004 v1.
PAGE 201
dns Commands dns server debug stats Print the DNS server/forwarder statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 202
dns Commands dns server flush Flush all local DNS hosts and routes. 202 E-DOC-CTC-20071119-0004 v1.
PAGE 203
dns Commands dns server host add Add a local DNS host SYNTAX: dns server host add name = [addr = [ttl = where: name The name of an IP host to add. REQUIRED addr The IP address of the host. OPTIONAL ttl The lifetime of the host. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 204
dns Commands dns server host delete Delete a local DNS host SYNTAX: dns server host delete name = where: name 204 The name of an IP host to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 205
dns Commands dns server host flush Flush all local DNS hosts E-DOC-CTC-20071119-0004 v1.
PAGE 206
dns Commands dns server host list List all local DNS hosts 206 E-DOC-CTC-20071119-0004 v1.
PAGE 207
dns Commands dns server route add Creates a DNS forwarding entry or template SYNTAX: dns server route add dns = [src = [srcmask = [domain = [metric = [label = <{None|DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [intf = <{loop|Internet|LocalNetwork}]> where: dns The IP address of a DNS server. If 0.0.0.
PAGE 208
dns Commands dns server route delete Deletes a DNS forwarding entry or template SYNTAX: dns server route delete dns = [domain = [intf = <{loop|Internet|LocalNetwork}]> where: 208 dns The IP address of a DNS server. REQUIRED domain The DNS domain string. OPTIONAL intf The interface associated with the DNS entry or DNS Template. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 209
dns Commands dns server route flush Removes all DNS forwarding entries and templates E-DOC-CTC-20071119-0004 v1.
PAGE 210
dns Commands dns server route list Lists all DNS forwarding entries and templates 210 E-DOC-CTC-20071119-0004 v1.
PAGE 211
dsd Commands dsd Commands dsd config Display/modify DSD framework configuration see page 212 dsd debug config Display/modify DSD debug settings see page 213 dsd debug connection list Display internal connection pool usage see page 214 dsd debug proxy Display/modify HTTPI fixed proxy settings see page 215 dsd debug recycling Display/modify HTTPI recycling settings see page 216 dsd debug stats Display/clear DSD framework and module statistics see page 217 dsd intercept config Display/modif
PAGE 212
dsd Commands dsd config Display/modify DSD framework configuration SYNTAX: dsd config [state = <{disabled|enabled|automatic}]> where: state 212 DSD framework operation mode OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 213
dsd Commands dsd debug config Display/modify DSD debug settings SYNTAX: dsd debug config [turbomode = <{disabled|enabled}]> where: turbomode E-DOC-CTC-20071119-0004 v1.
PAGE 214
dsd Commands dsd debug connection list Display internal connection pool usage SYNTAX: dsd debug connection list [expand = <{disabled|enabled}]> where: expand 214 Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 215
dsd Commands dsd debug proxy Display/modify HTTPI fixed proxy settings SYNTAX: dsd debug proxy [state = <{disabled|enabled}]> [dest = [port = <{at-echo|at-nbp|at-rtmp|at-zis|auth| bgp|biff|bootpc|bootps|chargen|data|gopher| h323|httpproxy|ike|ils|imap2|imap3|ingresnet|ipcserver|ipx|irc-o|irc-u|kerberos|ldap| login|netbios-dgm|netbios-ns|netbios-ssn| netwall|netware-ip|new-rwho|nfds|nicname|nntp| ntalk|ntp|pcmail-srv|pop2|pop3|printer|qotd| realaudio|rip|rtelnet|rtsp|sip|smtp|snmp| snmptrap|
PAGE 216
dsd Commands dsd debug recycling Display/modify HTTPI recycling settings SYNTAX: dsd debug recycling [state = <{disabled|enabled}]> [interval = [httpidle = [otheridle = where: 216 state Enable/disable stream recycling OPTIONAL interval Time between successive activity checks OPTIONAL httpidle Minimal idle count for recycling (filtered) http streams OPTIONAL otheridle Minimal idle count for recycling other streams OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 217
dsd Commands dsd debug stats Display/clear DSD framework and module statistics SYNTAX: dsd debug stats [name = <{intercept|urlfilter|recycling| syslog|all}]> [clear = <{no|yes}]> where: name Specify the name of a module OPTIONAL clear Clear the specified statistics OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 218
dsd Commands dsd intercept config Display/modify HTTP Intercept configuration SYNTAX: dsd intercept config [WDSpoofedIP = [servertimeout = [connecterrorurl = [categoryerrorurl = [monitorintercepturl = [unauthorizedrequrl = [imageredirect = <{disabled|enabled}]> [imageredirecturl = [alwaysuseip = <{disabled|enabled}]> where: 218 WDSpoofedIP IP address indicating unavailable WAN connection.
PAGE 219
dsd Commands dsd syslog config Display/modify HTTPI logging configuration SYNTAX: dsd syslog config [syslog = <{none|unauthorized|errors| intercepted|all}]> where: syslog E-DOC-CTC-20071119-0004 v1.
PAGE 220
dsd Commands dsd syslog list Display HTTPI log file 220 E-DOC-CTC-20071119-0004 v1.
PAGE 221
dsd Commands dsd urlfilter config Display/modify url filtering configuration SYNTAX: dsd urlfilter config [state = <{disabled|enabled}]> [blockproxy = <{disabled|enabled}]> [blockipaddress = <{disabled|enabled}]> [blockobscuredip = <{disabled|enabled}]> [defaultaction = <{block|accept}]> where: state Enable/disable url filtering OPTIONAL blockproxy Block HTTP requests via a proxy server OPTIONAL blockipaddress Block HTTP requests if host name is IP address OPTIONAL blockobscuredip Block HTTP r
PAGE 222
dsd Commands dsd urlfilter rule add Add a rule SYNTAX: dsd urlfilter rule add url = action = <{block|accept|redirect}> redirect = where: 222 url Definition of the url filter REQUIRED action Action to perform when url matches url REQUIRED redirect Redirection url REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 223
dsd Commands dsd urlfilter rule delete Remove a rule SYNTAX: dsd urlfilter rule delete index = [url = where: index Insertion position in the list REQUIRED url Definition of the url filter OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 224
dsd Commands dsd urlfilter rule flush Remove all current rules 224 E-DOC-CTC-20071119-0004 v1.
PAGE 225
dsd Commands dsd urlfilter rule list Display a list of current rules E-DOC-CTC-20071119-0004 v1.
PAGE 226
dsd Commands dsd urlfilter rule modify Modify an existing rule SYNTAX: dsd urlfilter rule modify index = [newurl = action = <{block|accept|redirect}> redirect = where: 226 index Insertion position in the list REQUIRED newurl Definition of the new url filter OPTIONAL action Action to perform when url matches url REQUIRED redirect Redirection url REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 227
dyndns Commands dyndns Commands dyndns add Add a dynamic DNS client. see page 228 dyndns delete Delete a dynamic DNS client. see page 229 dyndns flush Delete all dynamic DNS clients. see page 230 dyndns host add Add a fully qualified host name see page 231 dyndns host delete Delete a host name see page 232 dyndns host flush Delete all host names see page 233 dyndns host list List all host names see page 234 dyndns list List all dynamic DNS clients.
PAGE 228
dyndns Commands dyndns add Add a dynamic DNS client. SYNTAX: dyndns add name = where: name 228 The dynamic DNS client name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 229
dyndns Commands dyndns delete Delete a dynamic DNS client. SYNTAX: dyndns delete name = <> where: name E-DOC-CTC-20071119-0004 v1.0 The dynamic DNS client name.
PAGE 230
dyndns Commands dyndns flush Delete all dynamic DNS clients. 230 E-DOC-CTC-20071119-0004 v1.
PAGE 231
dyndns Commands dyndns host add Add a fully qualified host name SYNTAX: dyndns host add group = <> name = where: group The dynamic DNS host group. REQUIRED name The name of an IP host to add. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 232
dyndns Commands dyndns host delete Delete a host name SYNTAX: dyndns host delete name = <> where: name 232 The name of an IP host to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 233
dyndns Commands dyndns host flush Delete all host names E-DOC-CTC-20071119-0004 v1.
PAGE 234
dyndns Commands dyndns host list List all host names 234 E-DOC-CTC-20071119-0004 v1.
PAGE 235
dyndns Commands dyndns list List all dynamic DNS clients. E-DOC-CTC-20071119-0004 v1.
PAGE 236
dyndns Commands dyndns modify Modify a dynamic DNS client. SYNTAX: dyndns modify name = <> [intf = <{loop|Internet|LocalNetwork}]> [user = [password = [group = <]> [mx = [backmx = <{disabled|enabled}]> [wildcard = <{disabled|enabled}]> [offline = <{disabled|enabled}]> [service = <{dyndns|statdns|custom|No-IP| DtDNS|gnudip}]> [status = <{disabled|enabled}]> [trace = <{disabled|enabled}]> where: 236 name The dynamic DNS client name.
PAGE 237
dyndns Commands dyndns service list List all dynamic DNS services E-DOC-CTC-20071119-0004 v1.
PAGE 238
dyndns Commands dyndns service modify Modify specific dynamic DNS service settings SYNTAX: dyndns service modify name = <{dyndns|statdns|custom|No-IP|DtDNS| gnudip}> [server = [port = <{at-echo|at-nbp|at-rtmp|at-zis|auth| bgp|biff|bootpc|bootps|chargen|data|gopher| h323|httpproxy|ike|ils|imap2|imap3|ingresnet|ipcserver|ipx|irc-o|irc-u|kerberos|ldap| login|netbios-dgm|netbios-ns|netbios-ssn| netwall|netware-ip|new-rwho|nfds|nicname|nntp| ntalk|ntp|pcmail-srv|pop2|pop3|printer|qotd| realaudio|rip
PAGE 239
env Commands env Commands env flush Remove all non-system environment variables. see page 240 env get Gets an environment variable. see page 241 env list List all environment variables. see page 242 env set Sets an environment variable. see page 243 env unset Deletes an environment variable. see page 244 E-DOC-CTC-20071119-0004 v1.
PAGE 240
env Commands env flush Remove all non-system environment variables. 240 E-DOC-CTC-20071119-0004 v1.
PAGE 241
env Commands env get Gets an environment variable.
PAGE 242
env Commands env list List all environment variables. 242 E-DOC-CTC-20071119-0004 v1.
PAGE 243
env Commands env set Sets an environment variable. SYNTAX: env set var = value = where: var The name of the variable. REQUIRED value A translated quoted string defining the variable value. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 244
env Commands env unset Deletes an environment variable.
PAGE 245
eth Commands eth Commands eth bridge add Add a new bridge instance. see page 249 eth bridge clear Clear bridge statistics. see page 250 eth bridge config Modify/Display the bridge configuration settings. see page 251 eth bridge delete Delete a bridge instance. see page 252 eth bridge dynvlan actlist Display the active MAC entries for the dynamic VLAN membership. see page 253 eth bridge dynvlan add Add a dynamic VLAN membership entry.
PAGE 246
eth Commands 246 eth bridge igmpsnooping list Display bridge instance snooped groups. see page 272 eth bridge list Display the current bridge instances. see page 273 eth bridge macadd Add a static MAC address to a bridge interface. see page 274 eth bridge macdelete Remove a MAC address from the database. see page 275 eth bridge maclist Display the MAC address database. see page 276 eth bridge rule add Add a new constraint to the VLAN learning system.
PAGE 247
eth Commands eth bridge xtratag list Display all extra tag mapping entries. see page 294 eth device ifconfig Configure ethernet interface. see page 295 eth device iflist Show status of ethernet interfaces. see page 296 eth flush Flush all ETH interfaces. see page 297 eth ifadd Create a new ETH interface. see page 298 eth ifattach Attach an ETH interface. see page 299 eth ifconfig Modify an ETH interface. see page 300 eth ifdelete Delete an ETH interface.
PAGE 248
eth Commands 248 eth switch share list Display shared ports. see page 320 eth switch storm ifconfig Configure per port storm control parameters. see page 321 eth switch storm iflist Display storm control configuration per port. see page 322 eth vlan add Add a new virtual LAN. see page 323 eth vlan delete Delete a virtual LAN. see page 324 eth vlan flush Flush all virtual LAN's. see page 325 eth vlan list Display all virtual LAN's. see page 326 E-DOC-CTC-20071119-0004 v1.
PAGE 249
eth Commands eth bridge add Add a new bridge instance. SYNTAX: eth bridge add brname = where: brname E-DOC-CTC-20071119-0004 v1.0 The name of the new bridge instance.
PAGE 250
eth Commands eth bridge clear Clear bridge statistics. SYNTAX: eth bridge clear [brname = <{bridge}]> where: brname 250 The name of a bridge instance. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 251
eth Commands eth bridge config Modify/Display the bridge configuration settings. SYNTAX: eth bridge config [brname = <{bridge}]> [age = [filter = <{none|no_WAN_broadcast}]> [vlan = <{disabled|enabled}]> [precedencemap = where: brname The name of a bridge instance. OPTIONAL age The lifetime (in seconds) of a dynamically learned MAC address. OPTIONAL filter The bridge filter to be applied for all WAN bridge interfaces.
PAGE 252
eth Commands eth bridge delete Delete a bridge instance. SYNTAX: eth bridge delete brname = <{bridge}> where: brname 252 The name of a bridge instance. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 253
eth Commands eth bridge dynvlan actlist Display the active MAC entries for the dynamic VLAN membership. E-DOC-CTC-20071119-0004 v1.
PAGE 254
eth Commands eth bridge dynvlan add Add a dynamic VLAN membership entry. SYNTAX: eth bridge dynvlan add [id = hwaddr = vlan = <{default}> [remvlan = <{default}]> where: 254 id The id of the dynamic VLAN membership entry. OPTIONAL hwaddr The (masked) ethernet MAC address of the dynamic VLAN membership entry. REQUIRED vlan The VLAN for the dynamic VLAN membership entry. REQUIRED remvlan The VLAN that will be removed from the bridge interface.
PAGE 255
eth Commands eth bridge dynvlan config Modify the dynamic VLAN membership configuration. SYNTAX: eth bridge dynvlan config [timeout = where: timeout E-DOC-CTC-20071119-0004 v1.0 Timeout in seconds for the dynamic entries.
PAGE 256
eth Commands eth bridge dynvlan delete Delete a dynamic VLAN membership entry. SYNTAX: eth bridge dynvlan delete id = where: id 256 REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 257
eth Commands eth bridge dynvlan flush Flush all dynamic VLAN membership entries. E-DOC-CTC-20071119-0004 v1.
PAGE 258
eth Commands eth bridge dynvlan list Display a dynamic VLAN membership entry. 258 E-DOC-CTC-20071119-0004 v1.
PAGE 259
eth Commands eth bridge flush Flush all bridge instances with their interfaces and properties. SYNTAX: eth bridge flush [brname = <{bridge}]> where: brname E-DOC-CTC-20071119-0004 v1.0 The name of a bridge instance.
PAGE 260
eth Commands eth bridge ifadd Add a new bridge interface. SYNTAX: eth bridge ifadd [brname = <{bridge}]> intf = where: 260 brname The name of a bridge instance. OPTIONAL intf The new bridge interface name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 261
eth Commands eth bridge ifattach Attach a bridge interface. SYNTAX: eth bridge ifattach [brname = <{bridge}]> intf = <{}> where: brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 262
eth Commands eth bridge ifconfig Modify a bridge interface configuration.
PAGE 263
eth Commands regenprio The priority regeneration table for tagged ingress packets. OPTIONAL ingressfiltering Enable/disable discard of tagged ingress packets if the interface is not part of the VLAN. OPTIONAL acceptvlanonly Enable/disable receipt of tagged ingress packets. OPTIONAL mcastfilter Enable/disable discard of multicast packets for this interface. OPTIONAL dynvlan Enable/disable dynamic VLAN membership checking for this interface. OPTIONAL wan Enable/disable WAN for this interface.
PAGE 264
eth Commands eth bridge ifdelete Delete a bridge interface. SYNTAX: eth bridge ifdelete [brname = <{bridge}]> intf = <{ethport1|ethport2|ethport3|ethport4}> where: 264 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 265
eth Commands eth bridge ifdetach Detach a bridge interface. SYNTAX: eth bridge ifdetach [brname = <{bridge}]> intf = <{ethport1|ethport2|ethport3|ethport4}> where: brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 266
eth Commands eth bridge ifflush flush the bridge interfaces: detach/delete all interfaces. SYNTAX: eth bridge ifflush [brname = <{bridge}]> where: brname 266 The name of a bridge instance. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 267
eth Commands eth bridge iflist Display the current bridge interfaces. SYNTAX: eth bridge iflist [brname = <{bridge}]> [intf = <{OBC|ethport1|ethport2|ethport3| ethport4}]> where: brname The name of a bridge instance. OPTIONAL intf The name of a bridge interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 268
eth Commands eth bridge igmpsnooping clear Clear snooping statistics. SYNTAX: eth bridge igmpsnooping clear [brname = <{bridge}]> [intf = <{OBC|ethport1|ethport2|ethport3| ethport4}]> where: 268 brname The name of a bridge instance. OPTIONAL intf The bridge interface currently to be cleared. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 269
eth Commands eth bridge igmpsnooping config Configure bridge instance IGMP Snooping flags. SYNTAX: eth bridge igmpsnooping config [brname = <{bridge}]> [state = <{disabled|enabled}]> [floodrp = <{disabled|enabled}]> [floodmcast = <{disabled|enabled}]> where: brname The name of a bridge instance. OPTIONAL state Enable/Disable the IGMP Snooping. OPTIONAL floodrp Enable/Disable flooding reports to all ports. OPTIONAL floodmcast Enable/Disable flooding unregistered multicasts.
PAGE 270
eth Commands eth bridge igmpsnooping ifconfig Configure bridge interface IGMP snooping flags and mode. SYNTAX: eth bridge igmpsnooping ifconfig [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> [portmode = <{Host|Router|Auto}]> [fastleave = <{disabled|enabled}]> [exptrack = <{disabled|enabled}]> [mrdp = <{disabled|enabled}]> [rgmp = <{disabled|enabled}]> where: 270 brname The bridge instance currently to be configured.
PAGE 271
eth Commands eth bridge igmpsnooping iflist Display bridge interface IGMP status. SYNTAX: eth bridge igmpsnooping iflist [brname = <{bridge}]> [intf = <{OBC|ethport1|ethport2|ethport3| ethport4}]> where: brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 272
eth Commands eth bridge igmpsnooping list Display bridge instance snooped groups. SYNTAX: eth bridge igmpsnooping list [brname = <{bridge}]> where: brname 272 The name of a bridge instance. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 273
eth Commands eth bridge list Display the current bridge instances. SYNTAX: eth bridge list [brname = <{bridge}]> where: brname E-DOC-CTC-20071119-0004 v1.0 The name of a bridge instance.
PAGE 274
eth Commands eth bridge macadd Add a static MAC address to a bridge interface. SYNTAX: eth bridge macadd [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> hwaddr = [vlan = <{default}]> where: 274 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED hwaddr The ethernet MAC address of the new entry. REQUIRED vlan The VLAN. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 275
eth Commands eth bridge macdelete Remove a MAC address from the database. SYNTAX: eth bridge macdelete [brname = <{bridge}]> hwaddr = [vlan = <{default}]> where: brname The name of a bridge instance. OPTIONAL hwaddr The ethernet MAC address of the entry. REQUIRED vlan The VLAN. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 276
eth Commands eth bridge maclist Display the MAC address database. SYNTAX: eth bridge maclist [brname = <{bridge}]> where: brname 276 The name of a bridge instance. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 277
eth Commands eth bridge rule add Add a new constraint to the VLAN learning system. SYNTAX: eth bridge rule add type = vlan = [vlan2 [isi = <{shared|independant}> <{default}> = <{default}]> where: type Type of constraint. REQUIRED vlan The VLAN where the constraint belongs to. REQUIRED vlan2 The second VLAN for a shared constraint. OPTIONAL isi The indenpendent set id for an independent constraint. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 278
eth Commands eth bridge rule delete Delete a constraint from the VLAN learning system. SYNTAX: eth bridge rule delete index = where: index 278 Index of the constraint. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 279
eth Commands eth bridge rule flush Flush all constraints from the VLAN learning system. E-DOC-CTC-20071119-0004 v1.
PAGE 280
eth Commands eth bridge rule list Display all constraints from the VLAN learning system. 280 E-DOC-CTC-20071119-0004 v1.
PAGE 281
eth Commands eth bridge select Select the default bridge for configuring interfaces from (if not setting SYNTAX: eth bridge select brname = <{bridge}> where: brname E-DOC-CTC-20071119-0004 v1.0 The name of a bridge instance.
PAGE 282
eth Commands eth bridge unknownvlan ifadd Add bridge interface to unknown 'VLAN'. SYNTAX: eth bridge unknownvlan ifadd [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> [untagged = <{disabled|enabled}]> where: 282 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface to add to the unknown 'VLAN'. REQUIRED untagged Enable/disable interface as untagged for this unknown 'VLAN'. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 283
eth Commands eth bridge unknownvlan ifconfig Modify bridge interface from unknown 'VLAN'. SYNTAX: eth bridge unknownvlan ifconfig [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> [untagged = <{disabled|enabled}]> where: brname The name of a bridge instance. OPTIONAL intf The bridge interface from the unknown 'VLAN' to configure. REQUIRED untagged Enable/disable interface as untagged for this unknown 'VLAN'. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 284
eth Commands eth bridge unknownvlan ifdelete Delete bridge interface from unknown 'VLAN'. SYNTAX: eth bridge unknownvlan ifdelete [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> where: 284 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface to remove from the unknown 'VLAN'. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 285
eth Commands eth bridge unknownvlan iflist Display all interfaces of the unknown 'VLAN'. E-DOC-CTC-20071119-0004 v1.
PAGE 286
eth Commands eth bridge vlan ifadd Add bridge interface to virtual LAN. SYNTAX: eth bridge vlan ifadd name = <{default}> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> [untagged = <{disabled|enabled}]> where: 286 name The VLAN name. REQUIRED intf The name of the bridge interface to add to the VLAN. REQUIRED untagged Enable/disable interface as untagged for this VLAN. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 287
eth Commands eth bridge vlan ifconfig Modify bridge interface from virtual LAN. SYNTAX: eth bridge vlan ifconfig name = <{default}> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> untagged = <{disabled|enabled}> where: name The VLAN name. REQUIRED intf The bridge interface from the VLAN to configure. REQUIRED untagged Enable/disable interface as untagged for this VLAN. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 288
eth Commands eth bridge vlan ifdelete Delete bridge interface from virtual LAN. SYNTAX: eth bridge vlan ifdelete name = <{default}> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> where: 288 name The VLAN name. REQUIRED intf The name of the bridge interface to remove from the VLAN. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 289
eth Commands eth bridge vlan iflist Display all vitual LAN's. E-DOC-CTC-20071119-0004 v1.
PAGE 290
eth Commands eth bridge xtratag add Add an extra tag mapping entry. SYNTAX: eth bridge xtratag add [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> innervid = <{[1-4094]|all|}> outervid = <{[1-4094]|notag|transparant|}> where: 290 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED innervid The inner VLAN id [all,1-4094] (all = all inner vid will be translated to the outer vid).
PAGE 291
eth Commands eth bridge xtratag config Configure an extra tag mapping entry. SYNTAX: eth bridge xtratag config [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> innervid = <{[1-4094]|all|}> outervid = <{[1-4094]|notag|transparant|}> where: brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED innervid The inner VLAN id [all,1-4094] (all = all inner vid will be translated to the outer vid).
PAGE 292
eth Commands eth bridge xtratag delete Delete an extra tag mapping entry. SYNTAX: eth bridge xtratag delete [brname = <{bridge}]> intf = <{OBC|ethport1|ethport2|ethport3| ethport4}> innervid = <{[1-4094]|all|}> where: 292 brname The name of a bridge instance. OPTIONAL intf The name of the bridge interface. REQUIRED innervid The inner VLAN id [all,1-4094] (all = all inner vid will be translated to the outer vid). REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 293
eth Commands eth bridge xtratag flush Flush all extra tag mapping entries. E-DOC-CTC-20071119-0004 v1.
PAGE 294
eth Commands eth bridge xtratag list Display all extra tag mapping entries. 294 E-DOC-CTC-20071119-0004 v1.
PAGE 295
eth Commands eth device ifconfig Configure ethernet interface. SYNTAX: eth device ifconfig intf = <{ethif1|ethif2|ethif3|ethif4}> [type = <{auto|10BaseTHD|10BaseTFD|100BaseTHD| 100BaseTFD} or number]> [state = <{enabled|disabled}]> where: intf The name of a physical interface. REQUIRED type The ethernet type. OPTIONAL state The interface state. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 296
eth Commands eth device iflist Show status of ethernet interfaces. 296 E-DOC-CTC-20071119-0004 v1.
PAGE 297
eth Commands eth flush Flush all ETH interfaces. E-DOC-CTC-20071119-0004 v1.
PAGE 298
eth Commands eth ifadd Create a new ETH interface. SYNTAX: eth ifadd intf = where: intf 298 The name for the new ETH interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 299
eth Commands eth ifattach Attach an ETH interface. SYNTAX: eth ifattach intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the ETH interface.
PAGE 300
eth Commands eth ifconfig Modify an ETH interface. SYNTAX: eth ifconfig intf = <{ethoa_8_35}> [dest = <{bridge|ethoa_8_35}]> [retry = [wan = <{disabled|enabled}]> [priotag = <{disabled|enabled}]> [vlan = <{default}]> where: 300 intf The name of the ETH interface to configure. REQUIRED dest The destination interface for this ETH interface. OPTIONAL retry The number of times the ETH connection setup should retry before giving up.
PAGE 301
eth Commands eth ifdelete Delete an ETH interface. SYNTAX: eth ifdelete intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the ETH interface.
PAGE 302
eth Commands eth ifdetach Detach an ETH interface. SYNTAX: eth ifdetach intf = <{ethoa_8_35}> where: intf 302 The name of the ETH interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 303
eth Commands eth iflist Display the ETH interfaces. SYNTAX: eth iflist [intf = <{ethoa_8_35}]> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of an ETH interface.
PAGE 304
eth Commands eth switch group flush To set all ports to the default settings (all ports in group 0). 304 E-DOC-CTC-20071119-0004 v1.
PAGE 305
eth Commands eth switch group list List all configured groups. E-DOC-CTC-20071119-0004 v1.
PAGE 306
eth Commands eth switch group move Move a specified port to a specified group. SYNTAX: eth switch group move group = port = where: 306 group The group id. REQUIRED port The port. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 307
eth Commands eth switch info Display switch capabilities E-DOC-CTC-20071119-0004 v1.
PAGE 308
eth Commands eth switch mirror capture Define the specified port to be the Mirror Capture Port. SYNTAX: eth switch mirror capture port = where: port 308 The port. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 309
eth Commands eth switch mirror egress Enable or disable the specified port to be a Transmitted Port Mirroring. SYNTAX: eth switch mirror egress port = [state = <{enabled|disabled}]> where: port The port. REQUIRED state Enable/disable state. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 310
eth Commands eth switch mirror ingress Enable or disable the specified port to be a Received Port Mirroring. SYNTAX: eth switch mirror ingress port = [state = <{enabled|disabled}]> where: 310 port The port. REQUIRED state Enable/disable state. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 311
eth Commands eth switch qos config Configure common qos parameters. SYNTAX: eth switch qos config state = <{enabled|disabled}> [nbrOfQueues = [realtime = <{enabled|disabled}]> where: state Enable/disable QoS. REQUIRED nbrOfQueues Number of queues. OPTIONAL realtime Enable/disable realtime. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 312
eth Commands eth switch qos ifconfig Configure per port qos parameters. SYNTAX: eth switch qos ifconfig port = mode = <{none|802.1p|high|diffserv}> [flowcontrol = <{disabled|enabled}]> where: 312 port The port. REQUIRED mode Classifier. REQUIRED flowcontrol Enable/disable flow-control. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 313
eth Commands eth switch qos list Display qos configuration. E-DOC-CTC-20071119-0004 v1.
PAGE 314
eth Commands eth switch qos weights Configure the queue weights. SYNTAX: eth switch qos weights queue0 queue1 queue2 queue3 = = = = where: 314 queue0 Weight of queue 0 in WFQ (in %). REQUIRED queue1 Weight of queue 1 in WFQ (in %). REQUIRED queue2 Weight of queue 2 in WFQ (in %). REQUIRED queue3 Weight of queue 3 in WFQ (in %). REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 315
eth Commands eth switch shaper config Configure common ingress shaper parameters. SYNTAX: eth switch shaper config shaper = [unicast = <{enabled|disabled}]> [multicast = <{enabled|disabled}]> [broadcast = <{enabled|disabled}]> [control = <{enabled|disabled}]> [unknown = <{enabled|disabled}]> [discard = <{enabled|disabled}]> where: shaper The shaper instance. REQUIRED unicast Shape unicast traffic. OPTIONAL multicast Shape multicast traffic.
PAGE 316
eth Commands eth switch shaper ifconfig Configure per port shaper parameters. SYNTAX: eth switch shaper ifconfig port = ingress = <{enabled|disabled}> shaper = [state = <{enabled|disabled}]> [speed = [burstsize = <{}]> where: 316 port The port. REQUIRED ingress Ingress port = enabled; egress port = disabled. REQUIRED shaper The shaper instance. REQUIRED state Enable/disable shaping. OPTIONAL speed Speed in bits/sec.
PAGE 317
eth Commands eth switch shaper iflist Display shaper configuration per port. E-DOC-CTC-20071119-0004 v1.
PAGE 318
eth Commands eth switch share add Add a port to be shared. SYNTAX: eth switch share add port = shared = where: 318 port The port. REQUIRED shared The shared port. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 319
eth Commands eth switch share delete Delete a shared port. SYNTAX: eth switch share delete port = shared = where: port The port. REQUIRED shared The shared port. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 320
eth Commands eth switch share list Display shared ports. 320 E-DOC-CTC-20071119-0004 v1.
PAGE 321
eth Commands eth switch storm ifconfig Configure per port storm control parameters. SYNTAX: eth switch storm ifconfig port = [state = <{enabled|disabled}]> [rate = <{100|200|300|400}]> [burstsize = [broadcast = <{enabled|disabled}]> [multicast = <{enabled|disabled}]> [unknown = <{enabled|disabled}]> where: port The port. REQUIRED state Enable/disable storm control. OPTIONAL rate Rate in 10ths of percent. OPTIONAL burstsize Burst size in KBytes.
PAGE 322
eth Commands eth switch storm iflist Display storm control configuration per port. 322 E-DOC-CTC-20071119-0004 v1.
PAGE 323
eth Commands eth vlan add Add a new virtual LAN. SYNTAX: eth vlan add name = vid = [addrule = <{disabled|enabled}]> where: name The new VLAN name. REQUIRED vid The new VLAN id. REQUIRED addrule Add the default bridge constraint. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 324
eth Commands eth vlan delete Delete a virtual LAN. SYNTAX: eth vlan delete name = <{default}> where: name 324 The VLAN name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 325
eth Commands eth vlan flush Flush all virtual LAN's. E-DOC-CTC-20071119-0004 v1.
PAGE 326
eth Commands eth vlan list Display all virtual LAN's. 326 E-DOC-CTC-20071119-0004 v1.
PAGE 327
exit Command exit Command Exits this shell. E-DOC-CTC-20071119-0004 v1.
PAGE 328
expr Commands 328 E-DOC-CTC-20071119-0004 v1.
PAGE 329
expr Commands expr Commands expr add Add an expression. see page 330 expr delete Delete an expression. see page 333 expr flush Flush all expressions. see page 334 expr list List expressions. see page 335 expr modify Modify an expression. see page 336 E-DOC-CTC-20071119-0004 v1.
PAGE 330
expr Commands expr add Add an expression.
PAGE 331
expr Commands ftp-data|gopher|h323|httpproxy|ike|ils|imap2| imap3|ingres-net|ipcserver|ipx|irc-o|irc-u| kerberos|ldap|login|netbios-dgm|netbios-ns| netbios-ssn|netwall|netware-ip|new-rwho|nfds| nicname|nntp|ntalk|ntp|pcmail-srv|pop2|pop3| printer|qotd|realaudio|rip|rtelnet|rtsp|sip| smtp|snmp|snmptrap|snpp|sntp|sql*net|sqlnet|sqlserv|sunrpc|syslog|systat|talk|...
PAGE 332
expr Commands precedence [!] The precedence in the IP packet (part of tos). OPTIONAL If a value is preceded by a “!”, it means NOT. dscp [!] The diffserv code point in the IP packet (part of tos). OPTIONAL If a value is preceded by a “!”, it means NOT. proto [!] The IP protocol (name or number) in the IP packet. OPTIONAL If a value is preceded by a “!”, it means NOT. srcport [!] The TCP/UDP source port number or range begin. OPTIONAL If a value is preceded by a “!”, it means NOT.
PAGE 333
expr Commands expr delete Delete an expression. SYNTAX: expr delete name = <{wan|local|lan|tunnel|dmz|guest| private|ssdp_ip|mdap_ip|icmp|igmp|imaps|pop2| pop3|pop3s|smtp|ssh|dns|nntp|ipsec|esp|ah| ike|DiffServ|sip|h323|dhcp|rtsp|ssdp_serv| mdap_serv|syslog}> [index = where: name The name of an expression to delete. REQUIRED index The index of a subexpression. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 334
expr Commands expr flush Flush all expressions. 334 E-DOC-CTC-20071119-0004 v1.
PAGE 335
expr Commands expr list List expressions.
PAGE 336
expr Commands expr modify Modify an expression.
PAGE 337
expr Commands [dstport [!] = <{at-echo|at-nbp|at-rtmp|atzis|auth|bgp|biff|bootpc|bootps|finger|ftp| ftp-data|gopher|h323|httpproxy|ike|ils|imap2| imap3|ingres-net|ipcserver|ipx|irc-o|irc-u| kerberos|ldap|login|netbios-dgm|netbios-ns| netbios-ssn|netwall|netware-ip|new-rwho|nfds| nicname|nntp|ntalk|ntp|pcmail-srv|pop2|pop3| printer|qotd|realaudio|rip|rtelnet|rtsp|sip| smtp|snmp|snmptrap|snpp|sntp|sql*net|sqlnet|sqlserv|sunrpc|syslog|systat|talk|...
PAGE 338
expr Commands tos [!] The Type Of Service specification in the IP packet. OPTIONAL If a value is preceded by a “!”, it means NOT. precedence [!] The precedence in the IP packet (part of tos). OPTIONAL If a value is preceded by a “!”, it means NOT. dscp [!] The diffserv code point in the IP packet (part of tos). OPTIONAL If a value is preceded by a “!”, it means NOT. proto [!] The IP protocol (name or number) in the IP packet. OPTIONAL If a value is preceded by a “!”, it means NOT.
PAGE 339
firewall Commands firewall Commands firewall chain add Add a chain. see page 340 firewall chain delete Delete a chain. see page 341 firewall chain flush Flush all chains. see page 342 firewall chain list Display a list of chains. see page 343 firewall clear Clear firewall configuration. see page 344 firewall config Display/Modify firewall configuration. see page 345 firewall debug clear Clear firewall statistics. see page 346 firewall debug stats Display firewall statistics.
PAGE 340
firewall Commands firewall chain add Add a chain. SYNTAX: firewall chain add chain = where: chain 340 The name of the chain to add. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 341
firewall Commands firewall chain delete Delete a chain. SYNTAX: firewall chain delete chain = where: chain E-DOC-CTC-20071119-0004 v1.0 The name of the chain to delete.
PAGE 342
firewall Commands firewall chain flush Flush all chains. 342 E-DOC-CTC-20071119-0004 v1.
PAGE 343
firewall Commands firewall chain list Display a list of chains. SYNTAX: firewall chain list [format = <{pretty|cli}]> where: format E-DOC-CTC-20071119-0004 v1.0 The format of the chain list.
PAGE 344
firewall Commands firewall clear Clear firewall configuration. 344 E-DOC-CTC-20071119-0004 v1.
PAGE 345
firewall Commands firewall config Display/Modify firewall configuration. SYNTAX: firewall config [state = <{disabled|enabled}]> [keep = <{disabled|enabled}]> [tcpchecks = <{none|fast|exact}]> [udpchecks = <{disabled|enabled}]> [icmpchecks = <{disabled|enabled}]> [logdefault = <{disabled|enabled}]> [logthreshold = <{disabled|enabled}]> [tcpwindow = where: state Disable/Enable the firewall. OPTIONAL keep Disable/Enable keeping existing connections when firewall rules change.
PAGE 346
firewall Commands firewall debug clear Clear firewall statistics. 346 E-DOC-CTC-20071119-0004 v1.
PAGE 347
firewall Commands firewall debug stats Display firewall statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 348
firewall Commands firewall debug traceconfig Display/Modify firewall trace configuration. SYNTAX: firewall debug traceconfig [tcpchecks = <{disabled|enabled}]> [udpchecks = <{disabled|enabled}]> [icmpchecks = <{disabled|enabled}]> [sink = <{none|all|accept|deny|drop|reset} or number]> [forward = <{none|all|accept|deny|drop|reset} or number]> [source = <{none|all|accept|deny|drop|reset} or number]> where: 348 tcpchecks Disable/Enable tcpchecks traces.
PAGE 349
firewall Commands firewall level add Add a new security level. SYNTAX: firewall level add name = [index = [readonly = <{disabled|enabled}]> [udptrackmode = <{strict|loose}]> [service = <{disabled|enabled}]> [proxy = <{disabled|enabled}]> [text = [policy = <{default|drop|accept}]> where: name The name of the security level to add. REQUIRED index The index of the security level. OPTIONAL readonly Select whether the security level is readonly.
PAGE 350
firewall Commands firewall level delete Delete a security level. SYNTAX: firewall level delete name = where: name 350 The name of the security level to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 351
firewall Commands firewall level flush Flush security level configuration. E-DOC-CTC-20071119-0004 v1.
PAGE 352
firewall Commands firewall level list List all security levels. SYNTAX: firewall level list [format = <{pretty|cli}]> where: format 352 The format of the security level list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 353
firewall Commands firewall level modify Modify a security level. SYNTAX: firewall level modify name = [index = [readonly = <{disabled|enabled}]> [udptrackmode = <{strict|loose}]> [service = <{disabled|enabled}]> [proxy = <{disabled|enabled}]> [text = [policy = <{default|drop|accept}]> where: name The name of the security level to modify. REQUIRED index The index of this security level.
PAGE 354
firewall Commands firewall level set Set/Display active security level. SYNTAX: firewall level set [name = where: name 354 The name of the security level to set active. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 355
firewall Commands firewall list Display firewall configuration. SYNTAX: firewall list [format = <{pretty|cli}]> where: format E-DOC-CTC-20071119-0004 v1.0 The format of the firewall list.
PAGE 356
firewall Commands firewall rule add Add a rule.
PAGE 357
firewall Commands log Disable/Enable logging when this rule applies. OPTIONAL state Disable/Enable this rule. OPTIONAL action The action to be taken when this rule applies ('link' when clink is used). REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 358
firewall Commands firewall rule debug clear Clear rule statistics. SYNTAX: firewall rule debug clear [chain = [index = where: 358 chain The name of the chain. OPTIONAL index The index of the rule in the chain. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 359
firewall Commands firewall rule debug stats Display rule statistics. SYNTAX: firewall rule debug stats [chain = [index = where: chain The name of the chain. OPTIONAL index The index of the rule in the chain. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 360
firewall Commands firewall rule debug traceconfig Display/Modify rule trace configuration. SYNTAX: firewall rule debug traceconfig [state = <{disabled|enabled}]> where: state 360 Disable/Enable rule traces. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 361
firewall Commands firewall rule delete Delete a rule. SYNTAX: firewall rule delete chain = index = where: chain The name of the chain in which to delete the rule. REQUIRED index The number of the rule in the chain. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 362
firewall Commands firewall rule flush Flush all rules. SYNTAX: firewall rule flush [chain = where: chain 362 The name of the chain to flush. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 363
firewall Commands firewall rule list Display a list of rules. SYNTAX: firewall rule list [chain = [format = <{pretty|cli}]> where: chain The name of the chain to list the rules of. OPTIONAL format The format of the rule list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 364
firewall Commands firewall rule modify Modify a rule. SYNTAX: firewall rule modify chain = [index = [newindex = [name = [clink = [[!]srcintf] = [[!]srcip] = [[!]dstintf] = [[!]dstip] = [[!]serv] = [log = <{disabled|enabled}]> [state = <{disabled|enabled}]> [action = <{accept|deny|drop|reset|count| link}]> where: chain The name of the chain which contains the rule.
PAGE 365
firewall Commands state Disable/Enable this rule. OPTIONAL action The action to be taken when this rule applies ('link' when clink is used). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 366
grp Commands 366 E-DOC-CTC-20071119-0004 v1.
PAGE 367
grp Commands grp Commands grp config Set the grp configuration settings. see page 368 grp flush Flush grp interface settings and parameters. see page 369 grp rip config Set the RIP configuration settings. see page 370 grp rip flush Flush RIP interface settings and global parameters. see page 371 grp rip ifconfig Configure a RIP interface. see page 372 grp rip show Show the RIP settings and the routes in the RIP database.
PAGE 368
grp Commands grp config Set the grp configuration settings. SYNTAX: grp config [cdistance = [kdistance = [rdistance = [trace = <{disabled|enabled}]> where: 368 cdistance Set the distance of the connected route type. Default distance is 0. OPTIONAL kdistance Set the distance of the kernel route type. Default distance is 1. OPTIONAL rdistance Set the distance of the RIP route type. Default distance is 120.
PAGE 369
grp Commands grp flush Flush grp interface settings and parameters. E-DOC-CTC-20071119-0004 v1.
PAGE 370
grp Commands grp rip config Set the RIP configuration settings. SYNTAX: grp rip config state = <{disabled|enabled}> [version = <{rip_unspec|rip_v1|rip_v2}]> [updatetime = where: 370 state Enable/Disable the RIP daemon. REQUIRED version Set the RIP version. OPTIONAL updatetime Set the routing table update timer value. Default is 30 seconds. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 371
grp Commands grp rip flush Flush RIP interface settings and global parameters. E-DOC-CTC-20071119-0004 v1.
PAGE 372
grp Commands grp rip ifconfig Configure a RIP interface. SYNTAX: grp rip ifconfig intf = <{LocalNetwork|Internet}> [rip = <{disabled|enabled}]> [rxversion = <{rip_unspec|rip_v1|rip_v2| rip_v1-2}]> [authmode = <{none|cleartext}]> [authstr = [splithorizon = <{disabled|enabled}]> where: 372 intf The name of the RIP interface to configure. REQUIRED rip Enable/Disable the RIP status. OPTIONAL rxversion Set the RIP receive version. OPTIONAL authmode Set the RIP authentication mode.
PAGE 373
grp Commands grp rip show Show the RIP settings and the routes in the RIP database. E-DOC-CTC-20071119-0004 v1.
PAGE 374
grp Commands grp rtlist Show the current routes in the grp routing table. SYNTAX: grp rtlist [dst = [dstmsk = where: 374 dst The destination IP address using this route. Supports ip/mask notation. OPTIONAL dstmsk The destination IP address mask. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 375
help Command help Command Displays this help information E-DOC-CTC-20071119-0004 v1.
PAGE 376
hostmgr Commands 376 E-DOC-CTC-20071119-0004 v1.
PAGE 377
hostmgr Commands hostmgr Commands hostmgr add Add host device info to hostmgr see page 378 hostmgr clear Remove all hosts from list see page 379 hostmgr config Config hostmgr parameters see page 380 hostmgr delete Delete host device info from hostmgr see page 381 hostmgr flush Flushes hostmgr configuration (i.e. clean & to defaults) see page 382 hostmgr list List all host devices see page 383 E-DOC-CTC-20071119-0004 v1.
PAGE 378
hostmgr Commands hostmgr add Add host device info to hostmgr SYNTAX: hostmgr add mac_addr = [ip_addr = [name = [type = <{generic_device|desktop_computer| laptop_computer|set_top_box|pda| gaming_console|phone|mobile_phone|printer| mass_storage_device}]> [ipintf = <{loop|Internet|LocalNetwork}]> [ethintf = <{bridge|RELAY|ethoa_8_35}]> [physintf = <{ethif1|ethif2|ethif3|ethif4}]> where: 378 mac_addr Host MAC address REQUIRED ip_addr Host IP address OPTIONAL
PAGE 379
hostmgr Commands hostmgr clear Remove all hosts from list E-DOC-CTC-20071119-0004 v1.
PAGE 380
hostmgr Commands hostmgr config Config hostmgr parameters SYNTAX: hostmgr config [state = <{disabled|enabled}]> [scantime = [autosave = <{disabled|enabled}]> [trace = <{disabled|enabled}]> where: 380 state Enable/disable hostmgr deamon OPTIONAL scantime Time between two scans (sec) OPTIONAL autosave Enable/disable automatic saves to flash OPTIONAL trace Enable/disable hostmgr traces OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 381
hostmgr Commands hostmgr delete Delete host device info from hostmgr SYNTAX: hostmgr delete mac_addr = where: mac_addr E-DOC-CTC-20071119-0004 v1.
PAGE 382
hostmgr Commands hostmgr flush Flushes hostmgr configuration (i.e. clean & to defaults) 382 E-DOC-CTC-20071119-0004 v1.
PAGE 383
hostmgr Commands hostmgr list List all host devices SYNTAX: hostmgr list [expand = <{disabled|enabled}]> where: expand E-DOC-CTC-20071119-0004 v1.0 Expanded listing.
PAGE 384
ids Commands 384 E-DOC-CTC-20071119-0004 v1.
PAGE 385
ids Commands ids Commands ids clear Clear IDS statistics. see page 386 ids config Display/Modify IDS configuration. see page 387 ids parser list Display ids parser configuration. see page 388 ids parser modify Modify ids parser configuration. see page 389 ids pattern clear Reset pattern tracker. see page 390 ids pattern list Display patterns in pattern tracker. see page 391 ids pattern stats Display pattern tracker statistics.
PAGE 386
ids Commands ids clear Clear IDS statistics. 386 E-DOC-CTC-20071119-0004 v1.
PAGE 387
ids Commands ids config Display/Modify IDS configuration. SYNTAX: ids config [state = <{disabled|enabled}]> [trace = <{disabled|enabled}]> where: state Enable/Disable ids checks. OPTIONAL trace Enable/Disable ids traces. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 388
ids Commands ids parser list Display ids parser configuration. SYNTAX: ids parser list [parser = where: parser 388 The name of the parser. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 389
ids Commands ids parser modify Modify ids parser configuration. SYNTAX: ids parser modify [parser = state = <{disabled|enabled}> where: parser The name of the parser. OPTIONAL state The state of the parser. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 390
ids Commands ids pattern clear Reset pattern tracker. 390 E-DOC-CTC-20071119-0004 v1.
PAGE 391
ids Commands ids pattern list Display patterns in pattern tracker. SYNTAX: ids pattern list [size = <{10|100|full} or number]> where: size E-DOC-CTC-20071119-0004 v1.0 Modify the size of pattern tracker list.
PAGE 392
ids Commands ids pattern stats Display pattern tracker statistics. 392 E-DOC-CTC-20071119-0004 v1.
PAGE 393
ids Commands ids signature list Display ids signature configuration.
PAGE 394
ids Commands ids signature modify Modify ids signature configuration.
PAGE 395
ids Commands ids threshold clear Reset IDS thresholds. E-DOC-CTC-20071119-0004 v1.
PAGE 396
ids Commands ids threshold list Display IDS thresholds. 396 E-DOC-CTC-20071119-0004 v1.
PAGE 397
ids Commands ids threshold modify Modify IDS threshold. SYNTAX: ids threshold modify index = [window = [limit = [scaling = <{disabled|enabled}]> where: index The index of the threshold. REQUIRED window The time window of the threshold. OPTIONAL limit The limit of the threshold. OPTIONAL scaling Scaling of the threshold window. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 398
igmp Commands 398 E-DOC-CTC-20071119-0004 v1.
PAGE 399
igmp Commands igmp Commands igmp host config Display/Modify global IGMP configuration. see page 400 igmp host debug clear Clear IGMP statistics. see page 401 igmp host debug stats Print IGMP statistics. see page 402 igmp host flush Flush the IGMP settings. see page 403 igmp host ifconfig Configure an IGMP interface. see page 404 igmp host iflist Show the configuration of the IGMP interfaces. see page 405 igmp host list Show the IGMP groups.
PAGE 400
igmp Commands igmp host config Display/Modify global IGMP configuration. SYNTAX: igmp host config [requirera = <{disabled|enabled}]> where: requirera 400 Enable/Disable the router alert IP option check. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 401
igmp Commands igmp host debug clear Clear IGMP statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 402
igmp Commands igmp host debug stats Print IGMP statistics. 402 E-DOC-CTC-20071119-0004 v1.
PAGE 403
igmp Commands igmp host flush Flush the IGMP settings. E-DOC-CTC-20071119-0004 v1.
PAGE 404
igmp Commands igmp host ifconfig Configure an IGMP interface. SYNTAX: igmp host ifconfig intf = <{loop|Internet|LocalNetwork}> version = <{none|IGMPv1|IGMPv2|IGMPv3}> where: 404 intf The IP interface name. REQUIRED version The IGMP version of the IP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 405
igmp Commands igmp host iflist Show the configuration of the IGMP interfaces. SYNTAX: igmp host iflist [expand = <{disabled|enabled}]> where: expand E-DOC-CTC-20071119-0004 v1.0 Expanded listing.
PAGE 406
igmp Commands igmp host list Show the IGMP groups. SYNTAX: igmp host list [intf = <{loop|Internet|LocalNetwork}]> [expand = <{disabled|enabled}]> where: 406 intf The IP interface name. OPTIONAL expand Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 407
igmp Commands igmp proxy config Configure the IGMP proxy. SYNTAX: igmp proxy config [state = <{disabled|enabled}]> [qi = [qri = [lmqi = [rv = [advinter = [initadvinter = [initadvcount = [requirera = <{disabled|enabled}]> [localgroup = <{disabled|enabled}]> where: state Enable/Disable the IGMP proxy. OPTIONAL qi The interval in seconds between general queries sent by the querier.
PAGE 408
igmp Commands igmp proxy debug clear Clear IGMP proxy statistics 408 E-DOC-CTC-20071119-0004 v1.
PAGE 409
igmp Commands igmp proxy debug stats Print IGMP proxy statistics E-DOC-CTC-20071119-0004 v1.
PAGE 410
igmp Commands igmp proxy debug traceconfig Modify IGMP proxy trace configuration SYNTAX: igmp proxy debug traceconfig [state = <{disabled|enabled}]> where: state 410 Enable/Disable tracing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 411
igmp Commands igmp proxy flush Flush all IGMP proxy settings and learned groups E-DOC-CTC-20071119-0004 v1.
PAGE 412
igmp Commands igmp proxy grouplist Show the learned groups on an IGMP proxy interface. SYNTAX: igmp proxy grouplist [intf = <{LocalNetwork}]> [expand = <{disabled|enabled}]> where: 412 intf The name of the IGMP proxy interface to be listed. OPTIONAL expand Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 413
igmp Commands igmp proxy ifconfig Configure an IGMP proxy interface. SYNTAX: igmp proxy ifconfig intf = <{LocalNetwork|Internet}> [state = <{inactive|downstream|upstream}]> [version = <{IGMPv1|IGMPv2|IGMPv3}]> [fastleave = <{disabled|enabled}]> [exptrack = <{disabled|enabled}]> [mrd = <{disabled|enabled}]> where: intf The name of the IGMP proxy interface to be configured. REQUIRED state The state of the IGMP proxy interface. OPTIONAL version The IGMP version of the IGMP proxy interface.
PAGE 414
igmp Commands igmp proxy iflist Show the configuration of an IGMP proxy interface. SYNTAX: igmp proxy iflist [expand = <{disabled|enabled}]> where: expand 414 Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 415
igmp Commands igmp proxy mbslist Show the IGMP proxy membership database (merge of all learned groups). E-DOC-CTC-20071119-0004 v1.
PAGE 416
interface Command 416 E-DOC-CTC-20071119-0004 v1.
PAGE 417
interface Command interface Command Display interfaces. SYNTAX: interface list [expand = <{disabled|enabled}]> [reverse = <{disabled|enabled}]> where: expand Expanded listing. OPTIONAL reverse Reverse listing (lower layer iso. upper layer). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 418
ip Commands 418 E-DOC-CTC-20071119-0004 v1.
PAGE 419
ip Commands ip Commands ip arpadd Add an entry to the ARP cache of a broadcast IP interface. see page 421 ip arpdelete Delete an ARP entry. see page 422 ip arplist Display the ARP cache. see page 423 ip auto flush Flushes autoIP interfaces. see page 424 ip auto ifadd Creates a new autoIP interface. see page 425 ip auto ifattach Select and assign a link-local address to an autoIP interface. see page 426 ip auto ifconfig Configures an autoIP interface.
PAGE 420
ip Commands 420 ip ipadd Assign an IP address to an IP interface. see page 444 ip ipconfig Modify an IP address configuration. see page 445 ip ipdelete Remove an IP address from an IP interface. see page 446 ip iplist Display all configured IP addresses. see page 447 ip mcast flush Flush the multicast routing table. see page 448 ip mcast rtadd Add a multicast route to the multicast routing table. see page 449 ip mcast rtdelete Delete a multicast route from the multicast routing table.
PAGE 421
ip Commands ip arpadd Add an entry to the ARP cache of a broadcast IP interface. SYNTAX: ip arpadd intf = <{LocalNetwork}> ip = [hwaddr = where: intf The IP interface name. REQUIRED ip The IP address [range] of the entry to add. REQUIRED hwaddr The hardware address (e.g. Ethernet MAC address) of the entry to add. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 422
ip Commands ip arpdelete Delete an ARP entry. SYNTAX: ip arpdelete intf = <{LocalNetwork}> ip = [hwaddr = where: 422 intf The IP interface name. REQUIRED ip The IP address [range] of the entry to delete. REQUIRED hwaddr The hardware address (e.g. Ethernet MAC address) of the entry to delete. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 423
ip Commands ip arplist Display the ARP cache. E-DOC-CTC-20071119-0004 v1.
PAGE 424
ip Commands ip auto flush Flushes autoIP interfaces. 424 E-DOC-CTC-20071119-0004 v1.
PAGE 425
ip Commands ip auto ifadd Creates a new autoIP interface. SYNTAX: ip auto ifadd intf = <{loop|Internet|LocalNetwork}> [addr = where: intf The name of the IP interface for which a linklocal address has to be allocated. REQUIRED addr The preferred link-local IP address. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 426
ip Commands ip auto ifattach Select and assign a link-local address to an autoIP interface. SYNTAX: ip auto ifattach intf = <> where: intf 426 The name of the autoIP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 427
ip Commands ip auto ifconfig Configures an autoIP interface. SYNTAX: ip auto ifconfig intf = <> [addr = [poolstart = [poolend = [netmask = [claim = [defence = [probe = [interval = where: intf The name of the autoIP interface to configure. REQUIRED addr The preferred link-local IP address.
PAGE 428
ip Commands ip auto ifdelete Deletes an existing autoIP interface. SYNTAX: ip auto ifdelete intf = <> where: intf 428 The name of the autoIP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 429
ip Commands ip auto ifdetach Release the link-local address for the given autoIP interface. SYNTAX: ip auto ifdetach intf = <> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the autoIP interface.
PAGE 430
ip Commands ip auto iflist Shows the autoIP interfaces. SYNTAX: ip auto iflist [intf = <]> where: intf 430 The name of a autoIP interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 431
ip Commands ip config Display/Modify global IP stack configuration.
PAGE 432
ip Commands ip debug httpprobe Send HTTP probe to measure the round trip time taken to connect and access SYNTAX: ip debug httpprobe url = [version = <{1.0|1.1}]> where: 432 url The Uniform Resource location identifying the HTTP server. REQUIRED version The version of the HTTP Server. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 433
ip Commands ip debug sendto Send UDP packets. SYNTAX: ip debug sendto addr = [count = [size = [interval = [listen = <{disabled|enabled}]> [dffield = <{disabled|enabled}]> [srcaddr = [srcport = dstport = [dstintf = <{loop|Internet|LocalNetwork}]> where: addr The destination IP address. REQUIRED count The number of datagrams to send. OPTIONAL size The size of the datagram.
PAGE 434
ip Commands ip debug stats Display statistics. SYNTAX: ip debug stats proto = <{ip|udp|tcp|icmp}> where: proto 434 The protocol for which to display the statistics. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 435
ip Commands ip debug traceconfig Display/Modify IP stack trace configuration. SYNTAX: ip debug traceconfig [input = <{none|label|-telnet|-host|broadcast|all}]> [forward = <{none|label|-telnet|-host|broadcast|all}]> [output = <{none|label|-telnet|-host|broadcast|all}]> [drop = <{none|label|-telnet|-host|-broadcast| all}]> [path = <{none|label|-telnet|-host|-broadcast| all}]> [mode = <{line|dump}]> [arp = <{none|all}]> where: input Define the packets that will be traced.
PAGE 436
ip Commands ip flush Flush all static IP parameters. Dynamic info (e.g. from PPP links) remains. 436 E-DOC-CTC-20071119-0004 v1.
PAGE 437
ip Commands ip ifadd Create an IP interface. SYNTAX: ip ifadd intf = dest = <{ethoa_8_35}> where: intf An IP interface name. REQUIRED dest An network interface name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 438
ip Commands ip ifattach Attach an IP interface. SYNTAX: ip ifattach intf = <{}> where: intf 438 An IP interface name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 439
ip Commands ip ifconfig Modify an IP interface configuration. SYNTAX: ip ifconfig intf = <{loop|Internet|LocalNetwork}> [mtu = [status = <{down|up}]> [hwaddr = [group = <{wan|local|lan|tunnel|dmz|guest} or number]> [linksensing = <{disabled|enabled}]> [primary = <{disabled|enabled}]> [mcastpromisc = <{disabled|enabled}]> where: intf An IP interface name. REQUIRED mtu The maximum packet size (including IP header) to use on this interface.
PAGE 440
ip Commands ip ifdelete Delete an IP interface. SYNTAX: ip ifdelete intf = <{LocalNetwork}> where: intf 440 An IP interface name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 441
ip Commands ip ifdetach Detach an IP interface. SYNTAX: ip ifdetach intf = <{loop|LocalNetwork}> where: intf E-DOC-CTC-20071119-0004 v1.0 An IP interface name.
PAGE 442
ip Commands ip iflist Display all IP interfaces. SYNTAX: ip iflist [expand = <{disabled|enabled}]> where: expand 442 Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 443
ip Commands ip ifwait Wait for a status change of an IP interface. SYNTAX: ip ifwait intf = <{loop|Internet|LocalNetwork}> [timeout = [adminstatus = <{down|up}]> [operstatus = <{down|up}]> [linkstatus = <{down|up}]> where: intf An IP interface name. REQUIRED timeout The timeout in seconds. OPTIONAL adminstatus The administrative state of the interface. OPTIONAL operstatus The operational state of the interface. OPTIONAL linkstatus The link state of the interface.
PAGE 444
ip Commands ip ipadd Assign an IP address to an IP interface. SYNTAX: ip ipadd intf = <{loop|Internet|LocalNetwork}> addr = [netmask = [pointopoint = [addroute = <{disabled|enabled}]> where: 444 intf The IP interface name. REQUIRED addr The new IP address to add. REQUIRED netmask The subnetmask associated with this address. OPTIONAL pointopoint The remote address in case of a point-to-point link.
PAGE 445
ip Commands ip ipconfig Modify an IP address configuration. SYNTAX: ip ipconfig addr = [preferred = <{disabled|enabled}]> [primary = <{disabled|enabled}]> where: addr The IP address to configure. REQUIRED preferred Make IP address the preferred address for that subnet. OPTIONAL primary Make IP address the primary address for the interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 446
ip Commands ip ipdelete Remove an IP address from an IP interface. SYNTAX: ip ipdelete addr = where: addr 446 The IP address to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 447
ip Commands ip iplist Display all configured IP addresses. E-DOC-CTC-20071119-0004 v1.
PAGE 448
ip Commands ip mcast flush Flush the multicast routing table. 448 E-DOC-CTC-20071119-0004 v1.
PAGE 449
ip Commands ip mcast rtadd Add a multicast route to the multicast routing table. SYNTAX: ip mcast rtadd srcintf = <{loop|Internet|LocalNetwork}> [src = grp = dstintf = <{loop|Internet|LocalNetwork}> [ttl = [ttlincr = <{disabled|enabled}]> where: srcintf The source IP interface. REQUIRED src The source IP address. OPTIONAL grp The multicast group IP address. REQUIRED dstintf The destination IP interface.
PAGE 450
ip Commands ip mcast rtdelete Delete a multicast route from the multicast routing table. SYNTAX: ip mcast rtdelete srcintf = <{loop|Internet|LocalNetwork}> [src = grp = dstintf = <{loop|Internet|LocalNetwork}> where: 450 srcintf The source IP interface. REQUIRED src The source IP address. OPTIONAL grp The multicast group IP address. REQUIRED dstintf The destination IP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 451
ip Commands ip mcast rtlist Display the multicast routing table. SYNTAX: ip mcast rtlist [expand = <{disabled|enabled}]> where: expand E-DOC-CTC-20071119-0004 v1.0 Expanded listing.
PAGE 452
ip Commands ip rtadd Add a route to the routing table. SYNTAX: ip rtadd dst = [dstmsk = [label = <{None|DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [gateway = [intf = <{loop|Internet|LocalNetwork}]> [srcintf = <{loop|Internet|LocalNetwork}]> [metric = where: 452 dst The destination IP address(es) using this route. Supports ip/mask notation. REQUIRED dstmsk The destination IP address mask.
PAGE 453
ip Commands ip rtdelete Delete a route from the routing table. SYNTAX: ip rtdelete dst = [dstmsk = [label = <{None|DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [gateway = [intf = <{loop|Internet|LocalNetwork}]> where: dst The destination IP address specification of the route to delete. Supports ip/mask notation. REQUIRED dstmsk The destination IP address mask. OPTIONAL label The name of a label.
PAGE 454
ip Commands ip rtlist Display the routing table. SYNTAX: ip rtlist [expand = <{disabled|enabled}]> where: expand 454 Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 455
ipqos Commands ipqos Commands ipqos config Modify the IP QoS configuration for a given destination of an interface. see page 456 ipqos ef config Modify an IP QoS EF timer configuration for an interface. see page 457 ipqos ef list Display the IP QoS EF timers. see page 458 ipqos ef stats Display the IP QoS EF timer statistics. see page 459 ipqos list Display the IP QoS configuration. see page 460 ipqos queue clear Clear the IP QoS statistics.
PAGE 456
ipqos Commands ipqos config Modify the IP QoS configuration for a given destination of an interface.
PAGE 457
ipqos Commands ipqos ef config Modify an IP QoS EF timer configuration for an interface. SYNTAX: ipqos ef config intf = <{loop|Internet|LocalNetwork}> [state = <{disabled|enabled}]> [timeout = [mtu = where: intf The IP interface name. REQUIRED state Enable, disable IP QoS EF timer for the interface. OPTIONAL timeout The timeout in mili seconds. OPTIONAL mtu The MTU of the IP interface in case of EF data. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 458
ipqos Commands ipqos ef list Display the IP QoS EF timers. 458 E-DOC-CTC-20071119-0004 v1.
PAGE 459
ipqos Commands ipqos ef stats Display the IP QoS EF timer statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 460
ipqos Commands ipqos list Display the IP QoS configuration. 460 E-DOC-CTC-20071119-0004 v1.
PAGE 461
ipqos Commands ipqos queue clear Clear the IP QoS statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 462
ipqos Commands ipqos queue config Modify the IP QoS subqueue configuration. SYNTAX: ipqos queue config dest = <{atm_pvc_8_35}> queue = [propagate = <{disabled|enabled}]> [ecnmarking = <{disabled|enabled}]> [ackfiltering = <{disabled|enabled}]> [maxpackets = [maxbytes = [respackets = [resbytes = [hold = [markprob = where: 462 dest The destination of the interface. Typically, a phonebook entry.
PAGE 463
ipqos Commands ipqos queue list Display the IP QoS subqueue configuration. SYNTAX: ipqos queue list [dest = <{atm_pvc_8_35}]> where: dest E-DOC-CTC-20071119-0004 v1.0 The destination of the interface. Typically, a phonebook entry.
PAGE 464
ipqos Commands ipqos queue stats Display the IP QoS subqueue statistics. SYNTAX: ipqos queue stats [dest = <{atm_pvc_8_35}]> where: dest 464 The destination of the interface. Typically, a phonebook entry. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 465
label Commands label Commands label add Add a label. see page 466 label chain add Add a chain. see page 467 label chain delete Delete a chain. see page 468 label chain flush Flush all chains. see page 469 label chain list Display a list of chains. see page 470 label delete Delete a label. see page 471 label flush Flush all label. see page 472 label list Display the labels. see page 473 label modify Modify a label configuration. see page 474 label rule add Add a rule.
PAGE 466
label Commands label add Add a label. SYNTAX: label add name = where: name 466 The name of a label to add. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 467
label Commands label chain add Add a chain. SYNTAX: label chain add chain = where: chain E-DOC-CTC-20071119-0004 v1.0 The name of the chain to add.
PAGE 468
label Commands label chain delete Delete a chain. SYNTAX: label chain delete chain = where: chain 468 The name of the chain to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 469
label Commands label chain flush Flush all chains. E-DOC-CTC-20071119-0004 v1.
PAGE 470
label Commands label chain list Display a list of chains. SYNTAX: label chain list [format = <{pretty|cli}]> where: format 470 The format of the chain list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 471
label Commands label delete Delete a label. SYNTAX: label delete name = <{DSCP|Interactive|Management|Video| VoIP-RTP|VoIP-Signal|default}> where: name E-DOC-CTC-20071119-0004 v1.0 The name of a label.
PAGE 472
label Commands label flush Flush all label. 472 E-DOC-CTC-20071119-0004 v1.
PAGE 473
label Commands label list Display the labels. SYNTAX: label list [name = <{DSCP|Interactive|Management|Video| VoIP-RTP|VoIP-Signal|default}]> where: name E-DOC-CTC-20071119-0004 v1.0 The name of a label.
PAGE 474
label Commands label modify Modify a label configuration.
PAGE 475
label Commands label rule add Add a rule.
PAGE 476
label Commands label rule debug clear Clear rule statistics. SYNTAX: label rule debug clear [chain = [index = where: 476 chain The name of the chain. OPTIONAL index The index of the rule in the chain. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 477
label Commands label rule debug stats Display rule statistics. SYNTAX: label rule debug stats [chain = [index = where: chain The name of the chain. OPTIONAL index The index of the rule in the chain. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 478
label Commands label rule debug traceconfig Display/Modify rule trace configuration. SYNTAX: label rule debug traceconfig [state = <{disabled|enabled}]> where: state 478 Disable/Enable rule traces. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 479
label Commands label rule delete Delete a rule. SYNTAX: label rule delete chain = index = where: chain The name of the chain in which to delete the rule. REQUIRED index The number of the rule in the chain. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 480
label Commands label rule flush Flush all rules. SYNTAX: label rule flush [chain = where: chain 480 The name of the chain to flush. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 481
label Commands label rule list Display a list of rules. SYNTAX: label rule list [chain = [format = <{pretty|cli}]> where: chain The name of the chain to list the rules of. OPTIONAL format The format of the rule list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 482
label Commands label rule modify Modify a rule. SYNTAX: label rule modify chain = [index = [newindex = [name = [clink = [[!]srcintf] = [[!]srcip] = [[!]dstip] = [[!]serv] = [log = <{disabled|enabled}]> [state = <{disabled|enabled}]> [label = <{None|link|DSCP|Interactive| Management|Video|VoIP-RTP|VoIP-Signal| default}]> where: chain The name of the chain which contains the rule.
PAGE 483
language Commands language Commands language config Select a language. see page 484 language delete Delete one or all language archives. see page 485 language list List available languages archives. see page 486 E-DOC-CTC-20071119-0004 v1.
PAGE 484
language Commands language config Select a language. SYNTAX: language config [language = [complete = <{yes|no}]> where: 484 language Language code : OSI language code (2 chars) for language (en=English) OPTIONAL complete Enable translation for expert pages. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 485
language Commands language delete Delete one or all language archives. SYNTAX: language delete [file = [all = <{yes|no}]> where: file Filename : name of language archive to delete OPTIONAL all Deletes all languages archives. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 486
language Commands language list List available languages archives. 486 E-DOC-CTC-20071119-0004 v1.
PAGE 487
mbus Commands mbus Commands mbus client authenticate Authenticate a session see page 488 mbus client config Modify client parameters see page 489 mbus client exec Execute mbus command see page 490 mbus client register Register cli client to mbus see page 492 mbus client termsession Terminate a session see page 493 mbus client unregister Unregister cli client from mbus see page 494 mbus debug clearstats Reset mbus statistics.
PAGE 488
mbus Commands mbus client authenticate Authenticate a session SYNTAX: mbus client authenticate type = <{cleartext|md5|crypt|digest}> username = password = where: 488 type Authentication type REQUIRED username User name REQUIRED password password REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 489
mbus Commands mbus client config Modify client parameters SYNTAX: mbus client config [writelock = <{enabled|disabled}]> [wlgetimeout = [wlidletimeout = [path = [type = <{indexpath|objidpath|keystrpath}]> [id = where: writelock Get/release mbus writelock OPTIONAL wlgetimeout Writelock get timeout in seconds (forever=-1, *default=nowait=0) OPTIONAL wlidletimeout Writelock idle timeout in seconds (forever=-1, *default=30) OPTIONAL path Fully qualifie
PAGE 490
mbus Commands mbus client exec Execute mbus command SYNTAX: mbus client exec cmd = <{getpath|getcount|getnames|getvalues| setvalue|addobject|deleteobject|subscribe| unsubscribe|getaccessrights|setaccessrights}> [param = [value = [gettype = <{parameter|path|object}]> [depth = [processcmd = <{enabled|disabled}]> [onerrorrollback = <{enabled|disabled}]> [usecallback = <{enabled|disabled}]> [filter = [path = [flags = <[+/-]flag[+/-
PAGE 491
mbus Commands =, <, <=, >, >=, and, or, not. The left operand is a parameter name. The right operand is a parameter value. For boolean operators the operands are filters. Example: '(== Name eth0)'.
PAGE 492
mbus Commands mbus client register Register cli client to mbus SYNTAX: mbus client register [dmtree = <{igd|atomic|system}]> [type = <{indexpath|objidpath|keystrpath}]> [dlink = <{local_ipc|remote_inet}]> [mbusd_addr = [refresolv = <{disabled|enabled}]> where: 492 dmtree Select mbusd datamodel tree.
PAGE 493
mbus Commands mbus client termsession Terminate a session SYNTAX: mbus client termsession id = where: id E-DOC-CTC-20071119-0004 v1.
PAGE 494
mbus Commands mbus client unregister Unregister cli client from mbus 494 E-DOC-CTC-20071119-0004 v1.
PAGE 495
mbus Commands mbus debug clearstats Reset mbus statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 496
mbus Commands mbus debug loadobjects Load/sync object instances from plugins SYNTAX: mbus debug loadobjects [dmtree = <{igd|atomic|system}]> [path = [type = <{indexpath|objidpath|keystrpath}]> [flush = <{disabled|enabled}]> where: 496 dmtree Select mbusd datamodel tree. OPTIONAL path Fully qualified mbus path OPTIONAL type Path type (default = indexpath OPTIONAL flush Flush objects before load (default=disabled) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 497
mbus Commands mbus debug stats Display mbus statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 498
mbus Commands mbus debug traceconfig Modify mbus trace settings. SYNTAX: mbus debug traceconfig [level = where: level 498 Select mbus trace level (0-4). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 499
mbus Commands mbus debug unloadobjects Unload object instances SYNTAX: mbus debug unloadobjects [dmtree = <{igd|atomic|system}]> [path = [type = <{indexpath|objidpath|keystrpath}]> [flush = <{disabled|enabled}]> where: dmtree Select mbusd datamodel tree. OPTIONAL path Fully qualified mbus path OPTIONAL type Path type OPTIONAL flush Flush objects before load (default=disabled) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 500
mbus Commands mbus listcontexts Display the context instances SYNTAX: mbus listcontexts [dmtree = <{igd|atomic|system}]> [expand = <{disabled|enabled}]> where: 500 dmtree Select mbusd datamodel tree. OPTIONAL expand Details enabled/disabled OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 501
mbus Commands mbus listenums Display the registered enumtypes SYNTAX: mbus listenums [dmtree = <{igd|atomic|system}]> [name = [expand = <{disabled|enabled}]> where: dmtree Select mbusd datamodel tree. OPTIONAL name Filter enumtypes by (part of) the name OPTIONAL expand Details enabled/disabled OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 502
mbus Commands mbus listobjects Display the object instances SYNTAX: mbus listobjects [dmtree = <{igd|atomic|system}]> [path = [type = <{indexpath|objidpath|keystrpath}]> [output = <{tree|list}]> [showflags = <{disabled|enabled}]> where: 502 dmtree Select mbusd datamodel tree. OPTIONAL path Fully qualified mbus path to list.
PAGE 503
mbus Commands mbus listsubscriptions Display the subscription instances SYNTAX: mbus listsubscriptions [dmtree = <{igd|atomic|system}]> where: dmtree E-DOC-CTC-20071119-0004 v1.0 Select mbusd datamodel tree.
PAGE 504
mbus Commands mbus listtypes Display the registered objecttypes SYNTAX: mbus listtypes [dmtree = <{igd|atomic|system}]> [path = [expand = <{disabled|enabled}]> where: 504 dmtree Select mbusd datamodel tree. OPTIONAL path Fully qualified mbus path to list. OPTIONAL expand Details enabled/disabled OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 505
mbus Commands mbus pluginevent Simulate event from plugin SYNTAX: mbus pluginevent ctxid = type = <{addobj|delobj|updobj}> path = [name = [value = [orivalue = where: ctxid Plugin context id REQUIRED type Event type REQUIRED path Plugin event subpath REQUIRED name Plugin event name OPTIONAL value Plugin event value OPTIONAL orivalue Plugin event orivalue OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 506
mbus Commands mbus unregister Unregister a client/plugin context SYNTAX: mbus unregister id = where: id 506 Select message-based client/plugin context id. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 507
memm Commands memm Commands memm debug clearstats Clear time statistics. see page 508 memm debug lock stats Display lock statistics. see page 509 memm debug lock traceconfig Modify lock trace settings. see page 510 memm debug stats Display memm time statistics. see page 511 memm debug tag (Un)tag memory manager objects. see page 512 memm debug traceconfig Modify memm trace settings. see page 513 memm listobjects Display objects. see page 514 memm stats Display memm statistics.
PAGE 508
memm Commands memm debug clearstats Clear time statistics. 508 E-DOC-CTC-20071119-0004 v1.
PAGE 509
memm Commands memm debug lock stats Display lock statistics. E-DOC-CTC-20071119-0004 v1.
PAGE 510
memm Commands memm debug lock traceconfig Modify lock trace settings. SYNTAX: memm debug lock traceconfig [level = [name = where: 510 level Select memm trace level (0-4). OPTIONAL name application name filter for lock traces (empty displays all lock traces) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 511
memm Commands memm debug stats Display memm time statistics. SYNTAX: memm debug stats [name = where: name E-DOC-CTC-20071119-0004 v1.
PAGE 512
memm Commands memm debug tag (Un)tag memory manager objects. SYNTAX: memm debug tag [name = [tag = <{enabled|disabled}]> where: 512 name Select typename(s) to list (supports partial typename) OPTIONAL tag Set (or unset) the tag OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 513
memm Commands memm debug traceconfig Modify memm trace settings. SYNTAX: memm debug traceconfig [level = where: level E-DOC-CTC-20071119-0004 v1.0 Select memm trace level (0-4).
PAGE 514
memm Commands memm listobjects Display objects. SYNTAX: memm listobjects [name = [tagged = <{no|yes}]> [hidedeldynstr = <{no|yes}]> where: 514 name Select typename(s) to list (supports partial typename) OPTIONAL tagged Show only tagged (yes) or untagged (no) objects OPTIONAL hidedeldynstr Hide (yes) / show (no) deleted dynstrings (default = show) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 515
memm Commands memm stats Display memm statistics. SYNTAX: memm stats [name = where: name E-DOC-CTC-20071119-0004 v1.
PAGE 516
menu Command 516 E-DOC-CTC-20071119-0004 v1.
PAGE 517
menu Command menu Command Displays menu E-DOC-CTC-20071119-0004 v1.
PAGE 518
mlp Commands 518 E-DOC-CTC-20071119-0004 v1.
PAGE 519
mlp Commands mlp Commands mlp debug export Export all scores. see page 520 mlp debug stats Display mlp statisctics. see page 521 mlp debug traceconfig Modify mlp trace settings. see page 522 mlp flush Flush all mlp structures. see page 523 mlp import Import all scores. see page 524 mlp privilege add Add a privilege. see page 525 mlp privilege addzone Add a zone to a privilege. see page 526 mlp privilege config Modify the privilege.
PAGE 520
mlp Commands mlp debug export Export all scores. 520 E-DOC-CTC-20071119-0004 v1.
PAGE 521
mlp Commands mlp debug stats Display mlp statisctics. E-DOC-CTC-20071119-0004 v1.
PAGE 522
mlp Commands mlp debug traceconfig Modify mlp trace settings. SYNTAX: mlp debug traceconfig [trace = <{disabled|enabled|full}]> where: trace 522 Select mlp trace level. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 523
mlp Commands mlp flush Flush all mlp structures. E-DOC-CTC-20071119-0004 v1.
PAGE 524
mlp Commands mlp import Import all scores. SYNTAX: mlp import [trace = <{disabled|enabled|full}]> where: trace 524 Select import trace level. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 525
mlp Commands mlp privilege add Add a privilege. SYNTAX: mlp privilege add name = type = <{access|service}> [descr = where: name Privilege name. REQUIRED type Privilege type. REQUIRED descr Privilege description. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 526
mlp Commands mlp privilege addzone Add a zone to a privilege.
PAGE 527
mlp Commands mlp privilege config Modify the privilege. SYNTAX: mlp privilege config name = <> [descr = [score = <{hex-word}[:{hex-word}] ex: 'a12:c30f']> where: name Select the privilege by name. REQUIRED descr Set the description. OPTIONAL score Set the score. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 528
mlp Commands mlp privilege delete Delete a privilege. SYNTAX: mlp privilege delete name = <> where: name 528 Privilege name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 529
mlp Commands mlp privilege list Display the privileges. SYNTAX: mlp privilege list [name = <]> [type = <{access|service}]> [verbose = <{minimal|medium|all}]> where: name Privilege name. OPTIONAL type Privilege type. OPTIONAL verbose Limit the output list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 530
mlp Commands mlp privilege removezone Remove a zone from a privilege.
PAGE 531
mlp Commands mlp role add Add a role. SYNTAX: mlp role add name = parent = <> [descr = where: name Role name. REQUIRED parent Parent role name. REQUIRED descr Role description. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 532
mlp Commands mlp role addpriv Add a privilege. SYNTAX: mlp role addpriv name = <{Administrator|LAN_Admin|PowerUser| root|SuperUser|TechnicalSupport|User| WAN_Admin}> access = <{anyaccess|AP1|AP2|AP3|AP4|AP5|AP6| AP7|AP8|AP9}> service = <{anyservice|SP1|SP10|SP11|SP12| SP13|SP14|SP15|SP16|SP17|SP18|SP19|SP2|SP3| SP4|SP5|SP6|SP7|SP8|SP9}> where: 532 name Role name. REQUIRED access Access privilege to add. REQUIRED service Privilege name to add. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 533
mlp Commands mlp role config Modify the role. SYNTAX: mlp role config name = <> [parent = <]> [descr = where: name Role name. REQUIRED parent Parent role name. OPTIONAL descr Role description. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 534
mlp Commands mlp role delete Delete a role. SYNTAX: mlp role delete name = <> where: name 534 Role name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 535
mlp Commands mlp role list Display the roles. SYNTAX: mlp role list [name = <]> [verbose = <{minimal|medium|all}]> where: name Role name. OPTIONAL verbose Limit the output list. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 536
mlp Commands mlp role removepriv Remove a privilege. SYNTAX: mlp role removepriv name = <> access = <> [service = <]> where: 536 name Role name. REQUIRED access Access privilege to delete. REQUIRED service Privilege name to delete. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 537
nat Commands nat Commands nat config Modify global NAT configuration. see page 538 nat flush Flush current NAT configuration. see page 539 nat ifconfig Modify address translation on an IP interface. see page 540 nat iflist Display all interfaces. see page 541 nat mapadd Add an address mapping to a nat enabled interface. see page 542 nat mapdelete Delete an address mapping from a nat enabled interface. see page 543 nat maplist Display address mappings.
PAGE 538
nat Commands nat config Modify global NAT configuration. SYNTAX: nat config [trace = <{disabled|enabled}]> where: trace 538 Enable/disable traces. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 539
nat Commands nat flush Flush current NAT configuration. E-DOC-CTC-20071119-0004 v1.
PAGE 540
nat Commands nat ifconfig Modify address translation on an IP interface. SYNTAX: nat ifconfig intf = <{loop|Internet|LocalNetwork}> translation = <{disabled|enabled|transparent}> where: 540 intf The IP interface name. REQUIRED translation Disabled, enabled or tranparent address translation. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 541
nat Commands nat iflist Display all interfaces. E-DOC-CTC-20071119-0004 v1.
PAGE 542
nat Commands nat mapadd Add an address mapping to a nat enabled interface.
PAGE 543
nat Commands nat mapdelete Delete an address mapping from a nat enabled interface. SYNTAX: nat mapdelete intf = <{loop|Internet|LocalNetwork}> index = where: intf The IP interface name. REQUIRED index The map index as listed by ':nat maplist'. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 544
nat Commands nat maplist Display address mappings. SYNTAX: nat maplist [intf = <{loop|Internet|LocalNetwork}]> [expand = <{disabled|enabled}]> where: 544 intf The IP interface name. OPTIONAL expand Expanded listing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 545
nat Commands nat tmpladd Add an address mapping template.
PAGE 546
nat Commands weight 546 The weight to be used for the template instance(s). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 547
nat Commands nat tmpldelete Delete an address mapping template. SYNTAX: nat tmpldelete index = where: index E-DOC-CTC-20071119-0004 v1.0 The template index as listed by ':nat tmpllist'.
PAGE 548
nat Commands nat tmplinst Instantiate address mapping templates for a given dynamic address. SYNTAX: nat tmplinst intf = <{loop|Internet|LocalNetwork}> addr_index = dynamic_addr = where: 548 intf The IP interface name. REQUIRED addr_index The outside IP address index/key to instantiate for. REQUIRED dynamic_addr The dynamic address to substitute the index/key with. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 549
nat Commands nat tmpllist Display address mapping templates. SYNTAX: nat tmpllist [expand = <{disabled|enabled}]> where: expand E-DOC-CTC-20071119-0004 v1.0 Expanded listing.
PAGE 550
ping Command 550 E-DOC-CTC-20071119-0004 v1.
PAGE 551
ping Command ping Command Send ICMP ECHO_REQUEST packets. SYNTAX: ping proto = <{ip|atm}> addr = dest = <{atm_pvc_8_35}> [count = [size = [interval(ms) = [DF-bit = <{disabled|enabled}]> [srcaddr = where: proto The interface type to be used. REQUIRED addr The destination IP address. REQUIRED dest The destination address for the request. REQUIRED count The number of pings to send (0 is continuous ping).
PAGE 552
ppp Commands 552 E-DOC-CTC-20071119-0004 v1.
PAGE 553
ppp Commands ppp Commands ppp flush Flush all PPP interfaces. see page 554 ppp ifadd Create a new PPP interface. see page 555 ppp ifattach Attach a PPP interface. see page 556 ppp ifconfig Modify a PPP interface. see page 557 ppp ifdelete Delete a PPP interface. see page 560 ppp ifdetach Detach a PPP interface. see page 561 ppp iflist Display the PPP interfaces. see page 562 ppp ifscan Scan a PPP interface for available interfaces.
PAGE 554
ppp Commands ppp flush Flush all PPP interfaces. 554 E-DOC-CTC-20071119-0004 v1.
PAGE 555
ppp Commands ppp ifadd Create a new PPP interface. SYNTAX: ppp ifadd intf = where: intf E-DOC-CTC-20071119-0004 v1.0 The name for the new PPP interface. If not specified, the destination will double as interface name.
PAGE 556
ppp Commands ppp ifattach Attach a PPP interface. SYNTAX: ppp ifattach intf = <{Internet}> where: intf 556 The name of the PPP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 557
ppp Commands ppp ifconfig Modify a PPP interface.
PAGE 558
ppp Commands 558 servicename The service name for a PPP session. OPTIONAL pool Acquire IP subnet and assign it to a free DHCP pool. OPTIONAL pcomp Try to negotiate PPP protocol compression (LCP PCOMP). OPTIONAL accomp Try to negotiate PPP address & control field compression (LCP ACCOMP). OPTIONAL trace Enable verbose console logging. OPTIONAL concentrator The access concentrator is on this side of the PPP connection. OPTIONAL auth Authentication protocol to be used.
PAGE 559
ppp Commands dnsmetric DNS route metric to be used for the negotiated DNS servers. OPTIONAL idletime Maximum time the link may be idle (seconds). OPTIONAL idletrigger Consider the link being idle if no traffic is sent and/or received during the idle time. OPTIONAL unnumbered Take local IP address from 'laddr' field and remote IP address from the pool. SVC only. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 560
ppp Commands ppp ifdelete Delete a PPP interface. SYNTAX: ppp ifdelete intf = <{Internet}> where: intf 560 The name of the PPP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 561
ppp Commands ppp ifdetach Detach a PPP interface. SYNTAX: ppp ifdetach intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the PPP interface.
PAGE 562
ppp Commands ppp iflist Display the PPP interfaces. SYNTAX: ppp iflist [intf = <{Internet}]> where: intf 562 The name of a PPP interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 563
ppp Commands ppp ifscan Scan a PPP interface for available interfaces. SYNTAX: ppp ifscan intf = <{Internet}> [time = where: intf The name of the PPP interface to scan. REQUIRED time The time to scan for services (in seconds). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 564
ppp Commands ppp relay flush Remove all ethernet interfaces from the PPP relay agent list and terminate all 564 E-DOC-CTC-20071119-0004 v1.
PAGE 565
ppp Commands ppp relay ifadd Add an ethernet interface to the PPP relay list. SYNTAX: ppp relay ifadd intf = <{}> where: intf E-DOC-CTC-20071119-0004 v1.0 The ethernet intf to be added to the PPP relay agent list.
PAGE 566
ppp Commands ppp relay ifconfig Modify an ethernet interface from the PPP relay agent list. SYNTAX: ppp relay ifconfig intf = <{bridge|ethoa_8_35}> hwaddr = where: 566 intf The ethernet intf to be added to the PPP relay agent list. REQUIRED hwaddr The hardware address (e.g. Ethernet MAC address) of this interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 567
ppp Commands ppp relay ifdelete Delete an ethernet interface from the PPP relay agent list. SYNTAX: ppp relay ifdelete intf = <{bridge|ethoa_8_35}> where: intf E-DOC-CTC-20071119-0004 v1.0 The ethernet intf to be added to the PPP relay agent list.
PAGE 568
ppp Commands ppp relay iflist Display all ethernet interfaces added to the PPP relay agent list. 568 E-DOC-CTC-20071119-0004 v1.
PAGE 569
ppp Commands ppp relay sesslist Display all active PPP relay sessions. E-DOC-CTC-20071119-0004 v1.
PAGE 570
ppp Commands ppp rtadd Add a route to the routing table when PPP link comes up. SYNTAX: ppp rtadd intf = <{Internet}> dst = [dstmsk = [label = <{None|DSCP|Interactive|Management| Video|VoIP-RTP|VoIP-Signal|default}]> [src = [srcmsk = [metric = where: 570 intf The name of a PPP interface. REQUIRED dst The IP destination address specification for the route to be added when the link comes up.
PAGE 571
ppp Commands ppp rtdelete Delete the route for a PPP link. SYNTAX: ppp rtdelete intf = <{Internet}> where: intf E-DOC-CTC-20071119-0004 v1.0 The PPP interface name for which to delete the route settings.
PAGE 572
pptp Commands 572 E-DOC-CTC-20071119-0004 v1.
PAGE 573
pptp Commands pptp Commands pptp flush Flushes the PPTP configuration. see page 574 pptp ifadd Adds a PPTP profile (backwards compatible with previous release, use profiles see page 575 pptp list Shows PPTP configuration. see page 576 pptp profadd Defines a new PPTP profile. see page 577 pptp profdelete Deletes a PPTP profile. see page 578 pptp proflist Lists PPTP profiles. see page 579 E-DOC-CTC-20071119-0004 v1.
PAGE 574
pptp Commands pptp flush Flushes the PPTP configuration. 574 E-DOC-CTC-20071119-0004 v1.
PAGE 575
pptp Commands pptp ifadd Adds a PPTP profile (backwards compatible with previous release, use profiles SYNTAX: pptp ifadd dest = [rate = [encaps = <{vcmux|nlpid}]> [ac = <{never|always|keep}]> where: dest The WAN destination for this PPTP tunnel. Typically a phonebook name. REQUIRED rate Transmit speed in kbits/s for the WAN link. OPTIONAL encaps The WAN protocol encapsulation. OPTIONAL ac Enable/disable sending address and control field (0xFF03) on the WAN link.
PAGE 576
pptp Commands pptp list Shows PPTP configuration. 576 E-DOC-CTC-20071119-0004 v1.
PAGE 577
pptp Commands pptp profadd Defines a new PPTP profile. SYNTAX: pptp profadd name = [qos = <{default}]> [encaps = <{vcmux|nlpid}]> [ac = <{never|always|keep}]> where: name The name for the new PPTP profile. REQUIRED qos The name of the qosbook entry, containing the settings for this profile. OPTIONAL encaps The WAN protocol encapsulation to be used with this profile. OPTIONAL ac Enable/disable sending address and control field (0xFF03) on the WAN link.
PAGE 578
pptp Commands pptp profdelete Deletes a PPTP profile. SYNTAX: pptp profdelete name = <> where: name 578 The name of the profile to delete. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 579
pptp Commands pptp proflist Lists PPTP profiles. E-DOC-CTC-20071119-0004 v1.
PAGE 580
ra Commands 580 E-DOC-CTC-20071119-0004 v1.
PAGE 581
ra Commands ra Commands ra config Configure remote access parameters. see page 582 ra start Starts temporary mode. see page 583 ra stop Stops temporary mode. see page 584 E-DOC-CTC-20071119-0004 v1.
PAGE 582
ra Commands ra config Configure remote access parameters. SYNTAX: ra config [state = <{disabled|enabled}]> [secure = <{enabled|disabled}]> [port = [timeout = [mode = <{Permanent|Temporary}]> [ipintf = [randompassword = <{enabled|disabled}]> [randomport = <{enabled|disabled}]> [group = [user = where: 582 state Enable/disable RAD. OPTIONAL secure Use secure mode (https). OPTIONAL port The port number. OPTIONAL timeout The timeout value.
PAGE 583
ra Commands ra start Starts temporary mode. E-DOC-CTC-20071119-0004 v1.
PAGE 584
ra Commands ra stop Stops temporary mode. 584 E-DOC-CTC-20071119-0004 v1.
PAGE 585
saveall Command saveall Command Saves current configuration. E-DOC-CTC-20071119-0004 v1.
PAGE 586
script Commands 586 E-DOC-CTC-20071119-0004 v1.
PAGE 587
script Commands script Commands script add Add line to script. see page 588 script delete Delete complete script or line from script. see page 589 script flush Flush scripts. see page 590 script list List script. see page 591 script run Run script. see page 592 E-DOC-CTC-20071119-0004 v1.
PAGE 588
script Commands script add Add line to script. SYNTAX: script add name = [index = command = where: 588 name Name of script. REQUIRED index Line number (0 = add). OPTIONAL command Command. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 589
script Commands script delete Delete complete script or line from script. SYNTAX: script delete name = <{autopvc_add_qos|autopvc_delete_qos| autopvc_add_bridge|autopvc_delete_pppoerelay| autopvc_add_ipoa|autopvc_delete_ipoa| autopvc_add_ethoa|autopvc_delete_ethoa| autopvc_add_pppoa|autopvc_delete_pppoa| autopvc_add_pppoe|autopvc_delete_pppoe| autopvc_change_qos|wlbrintfadd|wlbrintfdel}> [index = where: name Name of script. REQUIRED index Line number. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 590
script Commands script flush Flush scripts. 590 E-DOC-CTC-20071119-0004 v1.
PAGE 591
script Commands script list List script. SYNTAX: script list [name = <{autopvc_add_qos|autopvc_delete_qos| autopvc_add_bridge|autopvc_delete_pppoerelay| autopvc_add_ipoa|autopvc_delete_ipoa| autopvc_add_ethoa|autopvc_delete_ethoa| autopvc_add_pppoa|autopvc_delete_pppoa| autopvc_add_pppoe|autopvc_delete_pppoe| autopvc_change_qos|wlbrintfadd|wlbrintfdel}]> where: name E-DOC-CTC-20071119-0004 v1.0 Name of script.
PAGE 592
script Commands script run Run script. SYNTAX: script run name = <{autopvc_add_qos|autopvc_delete_qos| autopvc_add_bridge|autopvc_delete_pppoerelay| autopvc_add_ipoa|autopvc_delete_ipoa| autopvc_add_ethoa|autopvc_delete_ethoa| autopvc_add_pppoa|autopvc_delete_pppoa| autopvc_add_pppoe|autopvc_delete_pppoe| autopvc_change_qos|wlbrintfadd|wlbrintfdel}> pars = where: 592 name Name of script. REQUIRED pars Parameters separated with comma e.q. a,b,c .
PAGE 593
service Commands service Commands service host add Add a service. see page 594 service host assign Assign a service to a host. see page 595 service host delete Delete a service. see page 596 service host disable Disable a service. see page 597 service host flush Flush all services. see page 598 service host list Display list of services. see page 599 service host rule add Create/define service portmap. see page 600 service host rule delete Delete a service portmap.
PAGE 594
service Commands service host add Add a service. SYNTAX: service host add name = [mode = <{server|client|custom}]> where: 594 name The name of the service. REQUIRED mode server, client or custom service ? OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 595
service Commands service host assign Assign a service to a host. SYNTAX: service host assign name = <{ABC (Another Bittorent Client)|Age of Empires|Age of Mythology|AIM BitTorrent| Black and White|Call of Duty|Call of Duty - UnitedOffensive|CarbonCopy32|Castle Wolfenstein|Championship Manager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and ConquerZero Hour|Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2and 4.
PAGE 596
service Commands service host delete Delete a service. SYNTAX: service host delete name = <{ABC (Another Bittorent Client)|Age of Empires|Age of Mythology|AIM BitTorrent| Black and White|Call of Duty|Call of Duty - UnitedOffensive|CarbonCopy32|Castle Wolfenstein|Championship Manager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and ConquerZero Hour|Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2and 4.
PAGE 597
service Commands service host disable Disable a service. SYNTAX: service host disable [name = <{ABC (Another Bittorent Client)| Age of Empires|Age of Mythology|BearShare| BitTorrent|Black and White|Call of Duty| Call of Duty -United Offensive|CarbonCopy32| Castle Wolfenstein|ChampionshipManager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and Conquer Zero Hour| Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2 and 4.
PAGE 598
service Commands service host flush Flush all services. 598 E-DOC-CTC-20071119-0004 v1.
PAGE 599
service Commands service host list Display list of services. SYNTAX: service host list [name = <{ABC (Another Bittorent Client)| Age of Empires|Age of Mythology|BearShare| BitTorrent|Black and White|Call of Duty| Call of Duty -United Offensive|CarbonCopy32| Castle Wolfenstein|ChampionshipManager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and Conquer Zero Hour| Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2 and 4.
PAGE 600
service Commands service host rule add Create/define service portmap. SYNTAX: service host rule add name = <{ABC (Another Bittorent Client)|Age of Empires|Age of Mythology|AIM BitTorrent| Black and White|Call of Duty|Call of Duty - UnitedOffensive|CarbonCopy32|Castle Wolfenstein|Championship Manager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and ConquerZero Hour|Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2and 4.
PAGE 601
service Commands triggerport Defines outbound trigger port. OPTIONAL triggerprotocol Protocol of the trigger port. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 602
service Commands service host rule delete Delete a service portmap. SYNTAX: service host rule delete name = <{ABC (Another Bittorent Client)|Age of Empires|Age of Mythology|AIM BitTorrent| Black and White|Call of Duty|Call of Duty - UnitedOffensive|CarbonCopy32|Castle Wolfenstein|Championship Manager 03-04| Checkpoint FW1 VPN|Command and Conquer Generals|Command and ConquerZero Hour|Counter Strike|Cu-SeeMe Cornell|Cu-SeeMe White Pine 3.1.2and 4.
PAGE 603
service Commands triggerport Defines outbound trigger port. OPTIONAL triggerprotocol Protocol of the trigger port. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 604
service Commands service host stats Service statistics. 604 E-DOC-CTC-20071119-0004 v1.
PAGE 605
service Commands service host triggerlist List all triggers. E-DOC-CTC-20071119-0004 v1.
PAGE 606
service Commands service system ifadd Add an interface to the access list. SYNTAX: service system ifadd name = <{PPTP|HTTP|HTTPs|FTP|TELNET|RIP-Query| DNS-S|SNMP_AGENT|SSDP|MDAP|PING_RESPONDER}> group = <{wan|local|lan|tunnel|dmz|guest} or number> where: 606 name The name of the service for this access list. REQUIRED group The interface group for this access list. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 607
service Commands service system ifdelete Delete an interface from the access list. SYNTAX: service system ifdelete name = <{PPTP|HTTP|HTTPs|FTP|TELNET|RIP-Query| DNS-S|SNMP_AGENT|SSDP|MDAP|PING_RESPONDER}> group = <{wan|local|lan|tunnel|dmz|guest} or number> where: name The name of the service for this access list. REQUIRED group The interface group for this access list. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 608
service Commands service system ipadd Add an ip address (range) to the access list. SYNTAX: service system ipadd name = <{PPTP|HTTP|HTTPs|FTP|TELNET|RIP-Query| DNS-S|SNMP_AGENT|SSDP|MDAP|PING_RESPONDER}> ip = where: 608 name The name of the service for this access list. REQUIRED ip The ip address (range) for this access list. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 609
service Commands service system ipdelete Delete an ip address (range) from the access list. SYNTAX: service system ipdelete name = <{PPTP|HTTP|HTTPs|FTP|TELNET|RIP-Query| DNS-S|SNMP_AGENT|SSDP|MDAP|PING_RESPONDER}> ip = where: name The name of the service for this access list. REQUIRED ip The ip address (range) for this access list. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 610
service Commands service system list Display services. SYNTAX: service system list [name = <{PPTP|PPTPD|PPTPGRE|SNTP| SLA_ICMP_PING|SLA_UDP_PING|HTTP|HTTPs|RAD| Dynamic DNS|dyndns|statdns|custom|No-IP|DtDNS| gnudip|DHCP-S|DHCP-R|SNMP_AGENT|SSDP|MDAP| CWMP-C|CWMP-S|RAS|SRAS|IP_COMMANDS|ICMP_PING| SENDTO|PING_RESPONDER|ICMP_TRACEROUTE| UDP_TRACEROUTE|HTTPPROBE}]> [expand = <{disabled|enabled}]> [dynamics = <{disabled|enabled}]> [members = <{disabled|enabled}]> where: 610 name The name of the service.
PAGE 611
service Commands service system mapadd Add a port map for a service.
PAGE 612
service Commands service system mapdelete Delete a port map for a service.
PAGE 613
service Commands service system modify Modify a service.
PAGE 614
snmp Commands 614 E-DOC-CTC-20071119-0004 v1.
PAGE 615
snmp Commands snmp Commands snmp community add Config an SNMP community string to allow snmp access over IP. see page 616 snmp community delete Delete an SNMP community string to prevent snmp access over IP. see page 617 snmp community list List all SNMP community strings in use for snmp access over IP. see page 618 snmp community modify Modify an SNMP community string to allow snmp access over IP. see page 619 snmp config Configure global SNMP parameters.
PAGE 616
snmp Commands snmp community add Config an SNMP community string to allow snmp access over IP. SYNTAX: snmp community add securityname = <{RWCommunity|ROCommunity}> communityname = where: 616 securityname Configure access rights/restrictions control for the community name. REQUIRED communityname Configure SNMP community name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 617
snmp Commands snmp community delete Delete an SNMP community string to prevent snmp access over IP. SYNTAX: snmp community delete securityname = <{RWCommunity|ROCommunity}> where: securityname E-DOC-CTC-20071119-0004 v1.0 Access rights/restrictions control of the community name to be deleted.
PAGE 618
snmp Commands snmp community list List all SNMP community strings in use for snmp access over IP. 618 E-DOC-CTC-20071119-0004 v1.
PAGE 619
snmp Commands snmp community modify Modify an SNMP community string to allow snmp access over IP. SYNTAX: snmp community modify securityname = <{RWCommunity|ROCommunity}> communityname = where: securityname Configure access rights/restrictions control for the community name. REQUIRED communityname Configure SNMP community name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 620
snmp Commands snmp config Configure global SNMP parameters. SYNTAX: snmp config [sysContact = [sysName = [sysLocation = where: 620 sysContact SNMP System Contact OPTIONAL sysName SNMP System Name OPTIONAL sysLocation SNMP System Location OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 621
snmp Commands snmp get Get from supplied object identity. e.g. get objectid=.1.3.6.1.2.1.1.1.0 SYNTAX: snmp get [objectid = where: objectid E-DOC-CTC-20071119-0004 v1.0 Object identity to get from ... must include the instance which is 0 for scalar objects e.g. .1.3.6.1.2.1.1.1.
PAGE 622
snmp Commands snmp getnext Get next from supplied object identity. e.g. getnext objectid= SYNTAX: snmp getnext [objectid = where: objectid 622 Object identity to getNext from e.g. .1.3.6.1.2.1.1 system returns sysDescription OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 623
snmp Commands snmp ifadd Create a new SNMP interface. SYNTAX: snmp ifadd intf = dest = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}> where: intf The name for the new SNMP interface. REQUIRED dest The destination interface for this SNMP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 624
snmp Commands snmp ifattach Attach an SNMP interface. SYNTAX: snmp ifattach intf = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}> where: intf 624 The name of the SNMP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 625
snmp Commands snmp ifconfig Modify an SNMP interface. SYNTAX: snmp ifconfig intf = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}> [securityname = <{RWCommunity|ROCommunity}]> [communityname = where: intf The name of the SNMP interface to configure. REQUIRED securityname Configure access rights/restrictions control for the community name. OPTIONAL communityname Configure SNMP community name. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 626
snmp Commands snmp ifdelete Delete an SNMP interface. SYNTAX: snmp ifdelete intf = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}> where: intf 626 The name of the SNMP interface. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 627
snmp Commands snmp ifdetach Detach an SNMP interface. SYNTAX: snmp ifdetach intf = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}> where: intf E-DOC-CTC-20071119-0004 v1.0 The name of the SNMP interface.
PAGE 628
snmp Commands snmp iflist Display the SNMP interfaces. SYNTAX: snmp iflist [intf = <{loop|ethif1|ethif2|ethif3|ethif4| ceoc|bridge|OBC|ethport1|RELAY|Internet| LocalNetwork}]> where: intf 628 The name of an SNMP interface. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 629
snmp Commands snmp walk Walk from supplied object identity. e.g. walk objectid=.1.3.6.1.2.1.1 SYNTAX: snmp walk [objectid = where: objectid E-DOC-CTC-20071119-0004 v1.0 Object identity to walk from e.g. .1.3.6.1.2.1.
PAGE 630
sntp Commands 630 E-DOC-CTC-20071119-0004 v1.
PAGE 631
sntp Commands sntp Commands sntp add Add NTP server see page 632 sntp config Modify/Display configuration see page 633 sntp debug traceconfig Modify SNTP client trace configuration see page 634 sntp delete Delete NTP server from list see page 635 sntp flush Flush NTP server list and SNTP client configuration see page 636 sntp list List the NTP servers see page 637 E-DOC-CTC-20071119-0004 v1.
PAGE 632
sntp Commands sntp add Add NTP server SYNTAX: sntp add [addr = [name = [version = where: 632 addr IP address of NTP server to be added to list OPTIONAL name DNS name of NTP server to be added to list. If both the IP address and the DNS name are provided, the IP address is ignored. OPTIONAL version SNTP version of server (1,2,3 or 4) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 633
sntp Commands sntp config Modify/Display configuration SYNTAX: sntp config [state = <{enabled|disabled}]> [poll = [pollpresync = where: state Enable/Disable SNTP client OPTIONAL poll polling interval (1 min, ... ,10080min(=7days)) OPTIONAL pollpresync polling interval before first sync (1 min, ... ,60min) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 634
sntp Commands sntp debug traceconfig Modify SNTP client trace configuration SYNTAX: sntp debug traceconfig [state = <{disabled|enabled}]> where: state 634 Enable/Disable tracing. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 635
sntp Commands sntp delete Delete NTP server from list SYNTAX: sntp delete [addr = [name = where: addr IP address of NTP server to be removed from list OPTIONAL name DNS name of NTP server to be removed from list OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 636
sntp Commands sntp flush Flush NTP server list and SNTP client configuration 636 E-DOC-CTC-20071119-0004 v1.
PAGE 637
sntp Commands sntp list List the NTP servers E-DOC-CTC-20071119-0004 v1.
PAGE 638
software Commands 638 E-DOC-CTC-20071119-0004 v1.
PAGE 639
software Commands software Commands software download Download parameters. see page 640 software upgrade Reboots the modem to initiate the SW upgrade. New software available on a see page 641 software version Displays the software version. see page 642 E-DOC-CTC-20071119-0004 v1.
PAGE 640
software Commands software download Download parameters. SYNTAX: software download filetype = <{firmware|configuration}> url = [username = [password = filesize = [targetfilename = where: 640 filetype The type of the file to be downloaded. REQUIRED url Set the HTTP URL where the file is to be found including remote filename. REQUIRED username Set the name to be used to authenticate to the download server.
PAGE 641
software Commands software upgrade Reboots the modem to initiate the SW upgrade. New software available on a E-DOC-CTC-20071119-0004 v1.
PAGE 642
software Commands software version Displays the software version. 642 E-DOC-CTC-20071119-0004 v1.
PAGE 643
system Commands system Commands system config Set or change system config parameters. see page 644 system debug autosave Autosave debugging commands see page 645 system debug stats Cpu and memory statistics see page 646 system dst Set daylight saving values see page 647 system flush Flush system configuration. see page 649 system locale Set/Get regional settings. see page 650 system ra config Configure Remote assistance params. see page 651 system reboot Reboot the modem.
PAGE 644
system Commands system config Set or change system config parameters.
PAGE 645
system Commands system debug autosave Autosave debugging commands SYNTAX: system debug autosave [trace = <{disabled|enabled}]> where: trace E-DOC-CTC-20071119-0004 v1.
PAGE 646
system Commands system debug stats Cpu and memory statistics SYNTAX: system debug stats [reset = <{disabled|enabled}]> where: reset 646 Reset cpu statistics. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 647
system Commands system dst Set daylight saving values SYNTAX: system dst [status = <{Disable|Enable}]> [mode = <{Absolute|Relative}]> [startdate =
[starttime = [enddate =
[endtime = [startweekday = <{Monday|Tuesday|Wednesday| Thursday|Friday|Saturday|Sunday}]> [starthour = [startweek = [startmonth = [endweekday = <{Monday|Tuesday|Wednesday| Thursday|Friday|Saturday|Sunday}]> [endhour = [endw
PAGE 648
system Commands 648 endweekday Set the end weekday of the daylight saving in the relative mode OPTIONAL endhour Set the end hour of the daylight saving in the relative mode OPTIONAL endweek Set the end week of the daylight saving in the relative mode OPTIONAL endmonth Set the end month of the daylight saving in the relative mode OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 649
system Commands system flush Flush system configuration. E-DOC-CTC-20071119-0004 v1.
PAGE 650
system Commands system locale Set/Get regional settings. SYNTAX: system locale [dec_symbol = <{,|.}]> [group_symbol = <{.|,}]> [date_separator = <{/|-|.
PAGE 651
system Commands system ra config Configure Remote assistance params. SYNTAX: system ra config [secure = <{disabled|enabled}]> [port = [timeout = where: secure Enable/Disable https. OPTIONAL port Set destination port. OPTIONAL timeout Set connection timeout in minutes. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 652
system Commands system reboot Reboot the modem. 652 E-DOC-CTC-20071119-0004 v1.
PAGE 653
system Commands system reset Reset to (factory or ISP) defaults: user specific settings will be cleared ! SYNTAX: system reset factory = <{yes|no}> proceed = <{no|yes}> where: factory Option to reset to factory REQUIRED proceed Confirmation for resetting the modem. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 654
system Commands system settime Set/Get date, time, timezone, daylight savings time, uptime. SYNTAX: system settime [time = [timezone = <(+ or -)hh:mm]> [daylightsaving = <{disabled|enabled}]> [geotimezonename = [rtc = <{disabled|enabled}]> where: 654 time Set the system time OPTIONAL timezone Set the system timezone(-12:00...
PAGE 655
system Commands system timedreboot Set or change editing mode timed reboot SYNTAX: system timedreboot [state = <{disabled|enabled}]> [time = [date = where: state Enable/Disable timed reboot OPTIONAL time Change default countdown time (Min). OPTIONAL date Set date/time to reboot (DD/MM/YYYY/HH:MM). OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 656
systemlog Commands 656 E-DOC-CTC-20071119-0004 v1.
PAGE 657
systemlog Commands systemlog Commands systemlog flush Flush all messages in syslog message buffer. see page 658 systemlog send Send messages to remote syslog server. see page 659 systemlog show Show messages in the syslog message buffer. see page 660 E-DOC-CTC-20071119-0004 v1.
PAGE 658
systemlog Commands systemlog flush Flush all messages in syslog message buffer. 658 E-DOC-CTC-20071119-0004 v1.
PAGE 659
systemlog Commands systemlog send Send messages to remote syslog server. SYNTAX: systemlog send [fac = <{kern|user|mail|daemon|auth|syslog| lpr|news|uucp|cron|security|ftp|local6| local7}]> [sev = <{emerg|alert|crit|err|warning|notice| info|debug}]> [hist = <{disabled|enabled}]> dest = where: fac Syslog facility level. OPTIONAL sev Syslog severity level.
PAGE 660
systemlog Commands systemlog show Show messages in the syslog message buffer. SYNTAX: systemlog show [fac = <{kern|user|mail|daemon|auth|syslog| lpr|news|uucp|cron|security|ftp|local6| local7}]> [sev = <{emerg|alert|crit|err|warning|notice| info|debug}]> [hist = <{disabled|enabled}]> where: 660 fac Syslog facility level. OPTIONAL sev Syslog severity level. OPTIONAL hist Syslog display message history (over several bootups) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 661
tls Commands tls Commands tls acs-client cert add Add a new certificate see page 662 tls acs-client cert delete Delete a certificate see page 663 tls acs-client cert list List certificates see page 664 tls acs-client config Display/modify tls settings see page 665 tls https-server cert add Add a new certificate see page 666 tls https-server cert delete Delete a certificate see page 667 tls https-server cert list List certificates see page 668 tls https-server config Display/modify tls
PAGE 662
tls Commands tls acs-client cert add Add a new certificate SYNTAX: tls acs-client cert add filename = where: filename 662 name of the certificate file REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 663
tls Commands tls acs-client cert delete Delete a certificate SYNTAX: tls acs-client cert delete index = where: index E-DOC-CTC-20071119-0004 v1.
PAGE 664
tls Commands tls acs-client cert list List certificates SYNTAX: tls acs-client cert list [index = [expand = <{disabled|enabled}]> where: 664 index Certificate index OPTIONAL expand Display more information OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 665
tls Commands tls acs-client config Display/modify tls settings SYNTAX: tls acs-client config [state = <{disabled|enabled}]> [auth-serv = <{disabled|enabled}]> [valid-date = <{disabled|enabled}]> [valid-domain = <{disabled|enabled}]> where: state SSL/TLS client for ACS state OPTIONAL auth-serv Request server authentication OPTIONAL valid-date Check certificate validity date OPTIONAL valid-domain Check certificate domain OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 666
tls Commands tls https-server cert add Add a new certificate SYNTAX: tls https-server cert add filename = where: filename 666 name of the certificate file REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 667
tls Commands tls https-server cert delete Delete a certificate SYNTAX: tls https-server cert delete index = where: index E-DOC-CTC-20071119-0004 v1.
PAGE 668
tls Commands tls https-server cert list List certificates SYNTAX: tls https-server cert list [index = [expand = <{disabled|enabled}]> where: 668 index Certificate index OPTIONAL expand Display more information OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 669
tls Commands tls https-server config Display/modify tls settings SYNTAX: tls https-server config [state = <{disabled|enabled}]> [auth-client = <{disabled|enabled}]> [valid-date = <{disabled|enabled}]> where: state SSL/TLS server for HTTPS state OPTIONAL auth-client Request client authentication OPTIONAL valid-date Check certificate validity date OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 670
tls Commands tls self cert list List certificates SYNTAX: tls self cert list [index = [expand = <{disabled|enabled}]> where: 670 index Certificate index OPTIONAL expand Display more information OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 671
traceroute Command traceroute Command Send ICMP/UDP packets to trace the ip path. SYNTAX: traceroute addr = [count = [size = [interval = [maxhops = [dstport = [maxfail = [type = <{icmp|udp}]> [utime = <{disabled|enabled}]> where: addr The destination IP address. REQUIRED count The number of times to reissue a traceroute request with the same time to live.
PAGE 672
upgrade Commands 672 E-DOC-CTC-20071119-0004 v1.
PAGE 673
upgrade Commands upgrade Commands upgrade config Change the upgrade daemon configuration see page 674 upgrade debug sesslist Display the list of sessions see page 675 upgrade debug traceconfig Enable/disable upgrade daemon tracing see page 676 upgrade profile add Add a new file profile description see page 677 upgrade profile delete Delete a file profile description see page 678 upgrade profile list Display a list of the file profile descriptions see page 679 upgrade profile modify Modif
PAGE 674
upgrade Commands upgrade config Change the upgrade daemon configuration SYNTAX: upgrade config [state = <{disabled|enabled}]> [protocol = <{tftp|ftp|http|https}]> where: 674 state The upgrade daemon state OPTIONAL protocol The transfer protocol to be used for file download OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 675
upgrade Commands upgrade debug sesslist Display the list of sessions E-DOC-CTC-20071119-0004 v1.
PAGE 676
upgrade Commands upgrade debug traceconfig Enable/disable upgrade daemon tracing SYNTAX: upgrade debug traceconfig state = <{disabled|enabled}> where: state 676 The upgrade daemon trace state REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 677
upgrade Commands upgrade profile add Add a new file profile description SYNTAX: upgrade profile add extension = <{sts|ini|bin}> [maxsize(KBytes) = action = <{none|config_load|script_load| reboot|upgrade}> where: extension The extension of the new file profile REQUIRED maxsize(KBytes) The maximum filesize (in KBytes) allowed for files with the extension of this profile OPTIONAL action The action to be done when the file with the extension of this profile is downloaded REQUIRED E-DOC-CT
PAGE 678
upgrade Commands upgrade profile delete Delete a file profile description SYNTAX: upgrade profile delete extension = <{sts|ini|bin}> where: extension 678 The extension of the file profile to be deleted REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 679
upgrade Commands upgrade profile list Display a list of the file profile descriptions E-DOC-CTC-20071119-0004 v1.
PAGE 680
upgrade Commands upgrade profile modify Modify a file profile description SYNTAX: upgrade profile modify extension = <{sts|ini|bin}> [maxsize(KBytes) = action = <{none|config_load|script_load| reboot|upgrade}> where: 680 extension The extension of the new file profile REQUIRED maxsize(KBytes) The maximum filesize (in KBytes) allowed for files with the extension of this profile OPTIONAL action The action to be done when the file with the extension of this profile is downloaded REQUIRE
PAGE 681
upgrade Commands upgrade start Start a new upgrade SYNTAX: upgrade start protocol = <{tftp|ftp|http|https}> [server = [filename = where: protocol The protocol to be used for the download REQUIRED server The server name or IP address OPTIONAL filename The file to be downloaded OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 682
upnp Commands 682 E-DOC-CTC-20071119-0004 v1.
PAGE 683
upnp Commands upnp Commands upnp config Config upnp parameter(s) see page 684 upnp flush Flushes upnp config (i.e. to defaults) see page 685 upnp list List all registered devices see page 686 E-DOC-CTC-20071119-0004 v1.
PAGE 684
upnp Commands upnp config Config upnp parameter(s) SYNTAX: upnp config [maxage = [writemode = <{full|natonly|readonly}]> [safenat = <{disabled|enabled}]> [preferredaddresses = where: 684 maxage ssdp advertisements MAX-AGE (default = 1800) OPTIONAL writemode Configuration access level for UPnP OPTIONAL safenat Enable / disable check on safe nat entries (limited to own host) OPTIONAL preferredaddresses CSV list of preferred ip addresses for UPnP (1 per lan ip-int
PAGE 685
upnp Commands upnp flush Flushes upnp config (i.e. to defaults) E-DOC-CTC-20071119-0004 v1.
PAGE 686
upnp Commands upnp list List all registered devices SYNTAX: upnp list [verbose = where: verbose 686 Verbose level (default = 1) OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 687
user Commands user Commands user add Add a user. see page 688 user config Modify the user. see page 689 user delete Delete a user. see page 690 user flush Flush the users. see page 691 user list Display the users. see page 692 user rights Display session rights. see page 693 E-DOC-CTC-20071119-0004 v1.
PAGE 688
user Commands user add Add a user. SYNTAX: user add name = password = role = <> [hash2 = [descr = [defuser = <{disabled|enabled}]> [defremadmin = <{disabled|enabled}]> [deflocadmin = <{disabled|enabled}]> where: 688 name User name. REQUIRED password User password. REQUIRED role Role name. REQUIRED hash2 The MD5 hash. OPTIONAL descr User description. OPTIONAL defuser Set this user as the default user.
PAGE 689
user Commands user config Modify the user. SYNTAX: user config name = <{Administrator|tech}> [password = [role = <]> [descr = [defuser = <{disabled|enabled}]> [defremadmin = <{disabled|enabled}]> [deflocadmin = <{disabled|enabled}]> where: name User name. REQUIRED password User password. OPTIONAL role Role name. OPTIONAL descr User description. OPTIONAL defuser Set this user as the default user.
PAGE 690
user Commands user delete Delete a user. SYNTAX: user delete name = <{Administrator|tech}> where: name 690 User name. REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 691
user Commands user flush Flush the users. E-DOC-CTC-20071119-0004 v1.
PAGE 692
user Commands user list Display the users. SYNTAX: user list [name = <{Administrator|tech}]> [channel = <{ftp|telnet|http|mdap|serial}]> [origin = <{lan|wan|local}]> [secure = <{disabled|enabled}]> where: 692 name User name. OPTIONAL channel The selected channel. OPTIONAL origin The selected origin. OPTIONAL secure The selected security level. OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 693
user Commands user rights Display session rights. E-DOC-CTC-20071119-0004 v1.
PAGE 694
xdsl Commands 694 E-DOC-CTC-20071119-0004 v1.
PAGE 695
xdsl Commands xdsl Commands xdsl config Modify/Display dsl configuration see page 696 xdsl debug bitloadinginfo Displays # bits per tone see page 697 xdsl debug deltconfig Dual Ended Line Testing interface see page 698 xdsl debug deltinfo Dual Ended Line Test result display see page 699 xdsl debug modemoptioninfo The modem options bitmap display see page 700 xdsl debug multimode Config custom multimode see page 701 xdsl debug traceconfig Config the adsl tracelevel see page 702 xdsl inf
PAGE 696
xdsl Commands xdsl config Modify/Display dsl configuration SYNTAX: xdsl config [adslmultimode = <{adsl|adsl2|adsl2plus}]> [detect-lop = <{disabled|enabled}]> [syslog = <{disabled|enabled}]> where: 696 adslmultimode Set/Show selected multimode type of the modem OPTIONAL detect-lop Detect Loss Of Power OPTIONAL syslog Log in syslog during showtime OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 697
xdsl Commands xdsl debug bitloadinginfo Displays # bits per tone E-DOC-CTC-20071119-0004 v1.
PAGE 698
xdsl Commands xdsl debug deltconfig Dual Ended Line Testing interface SYNTAX: xdsl debug deltconfig [state = <{disabled|enabled}]> where: state 698 Enable/Disable dual ended line testing OPTIONAL E-DOC-CTC-20071119-0004 v1.
PAGE 699
xdsl Commands xdsl debug deltinfo Dual Ended Line Test result display E-DOC-CTC-20071119-0004 v1.
PAGE 700
xdsl Commands xdsl debug modemoptioninfo The modem options bitmap display 700 E-DOC-CTC-20071119-0004 v1.
PAGE 701
xdsl Commands xdsl debug multimode Config custom multimode SYNTAX: xdsl debug multimode [config = <[+/-]flag[+/-flag...]{default t1.413issue2 g992.1_annex_a g992.2 g992.5_annex_m}]> where: config E-DOC-CTC-20071119-0004 v1.
PAGE 702
xdsl Commands xdsl debug traceconfig Config the adsl tracelevel SYNTAX: xdsl debug traceconfig level = <{0|1|2|3|4}> where: level 702 Trace Level (0=disable tracing; 1=enable dsl manager tracing; 2=enable dsl driver tracing) REQUIRED E-DOC-CTC-20071119-0004 v1.
PAGE 703
xdsl Commands xdsl info Displays status information about modem SYNTAX: xdsl info [expand = <{disabled|enabled}]> [g.997.1 = <{disabled|enabled}]> [counter_period_filter = <{current|15_minutes| 24_hours}]> [counters_reset = <{no|yes}]> where: expand Condensed / Expanded listing link information OPTIONAL g.997.
PAGE 704
xdsl Commands xdsl version Display xdsl version information. 704 E-DOC-CTC-20071119-0004 v1.
PAGE 705
