Installation Guide

Page 10
7
• Make two parallel cuts down the center of the board to be replaced, then remove the
center piece.
• Using a small pry bar, remove the remaining pieces of decking from the tabs.
• Using a reciprocating saw, remove the tabs on the side of the board with the screw heads showing.
• Position new board into place, and carefully drive onto remaining tabs.
• Once the board is set into position, secure the loose edges with L-Bracket, Cortex, stainless steel, or
high-quality coated deck screws.
HOW TO: REPLACE A BOARD
6
• When the deck is located in a corner
of the house, start with small
triangular piece of decking in the
corner and work your way out.
• Offset the center 1/2” towards the
long point of the joist, so screw will
not exit the side of the joist when
driven.
HOW TO: INSTALL ON DIAGONAL
8
• Create a 2” long groove on the edge of
the board at every joist. Do not groove
the full length of square shouldered
deck boards.
• Use TimberTech’s CONCEALoc Groove
Cutting Router Bit or a Freud model
#56-112 or Bosch model #85610M
1/4” slot cutting bit.
• Flip the board over and start the
groove 3/8” off the bottom of the
board.
• Set the depth of the cut from 7/16” to
1/2”deep.
Note: Be sure to ID the side of the board that has the directional
notch; the boards with IDs should be installed to the same side. See
Directional Notch on page 5.
HOW TO: USE CONCEALoc
®
FASTENERS
WITH SQUARE SHOULDER BOARDS
CONCEALoc
®
Hidden Fastener
3/8”
3/8” Depth
1/4”
2”
Incorrect Correct: Shift over 1/2”
ReliaBoard cannot be grooved. It must ONLY be face-fastened. Grooving ReliaBoard will void the warranty.
Do not use CONCEALoc Hidden Fasteners or L-Brackets for stair installations.
