COMMERCIAL White 2 User Guide U87-W2 Series Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 vax.co.uk Performance is everything.
Your machine 1 Handle 2 2-in-1 tool (crevice tool and dusting brush) 3 Brushbar height adjust 4 Cord wrap (hidden) 5 Separator 6 Dirt container 7 On/off button (hidden) 8 HEPA central filter 9 Hose 10 TurboTool (some models only) 11 TurboTool connector (some models only. NOTE: This will be attached to the TurboTool) 12 TurboTool holder (some models only) PLEASE NOTE: Some parts may vary according to model. Please check inside flap of box for more details.
General Safety Information FOR HOUSEHOLD USE ONLY. When using the vacuum cleaner, basic safety precautions should always be observed, including the following: 1. 2. 3. 4. 5. Only use the vacuum cleaner indoors on dry surfaces. Turn off the vacuum cleaner controls before disconnecting or connecting from the mains supply. Always unplug the vacuum cleaner before connecting or disconnecting the vacuum hose and accessories. Children should be supervised to ensure that they do not play with the appliance.
Getting started PLEASE READ SAFETY INFORMATION BEFORE USE (PAGE 3) Assembling your upright Using a crosshead screwdriver, remove the screw from the back of the unit as shown. Slide the handle down onto the main body of the unit. Return the screw and tighten, securing the handle into the main body of the unit. Connect the upper hose to the upper hose connector, rotate hose clockwise to secure. Insert the lower hose to the lower hose connector. Place the 2-in-1 tool into the holder.
Attaching the TurboTool holder 1 2 Attach the TurboTool holder to handle. Then fit the Turbotool to the TurboTool holder. vax.co.
How to use Operating the appliance IMPORTANT: Vax recommends that you raise the height of the brush bar to the hard floor position when using this cleaner on lino and hard floor due to constant rotation. Vax cannot be held responsible for damage to these surfaces if the consumer fails to take notice of this recommendation. Twist the upper cord wrap to fully unwrap the cord then plug the unit into the electrical socket and turn on. Select a floor height setting by adjusting the brush bar height.
Using the accessories Pull out the lower hose from the lower hose connector. Choose an accessory, then attach to the end of the hose. To use the dusting brush, push the tab and slide up the dusting brush until it clicks into place. IMPORTANT: When the vacuum cleaner is stood in the upright position, or when using the hose and tools, the brush bar height adjust must be set to the highest position. vax.co.
Looking after your machine Emptying and cleaning the dirt container Press dirt container release button to remove the dirt container. Always switch off the appliance and unplug the mains socket before carrying out any maintenance. Hold dirt container over a bin and press the dirt container latch to open, allowing dirt to fall out. Cleaning the separator Turn the lid of the dirt container anticlockwise to remove. 8 Wipe the separator with a cloth to remove any dirt.
Cleaning the HEPA filter IMPORTANT: It is very important to keep the filters clean to maintain maximum performance of the vacuum. Vax recommend that your filters should be cleaned at least every 3 months (depending on the level of use). Do not use detergent to clean the filters. Turn the lid of the dirt container anti- Remove the HEPA central filter clockwise to remove the lid. Then turn from the separator. the separator clockwise to remove filter from the dirt container lid.
Looking after your machine Replacing the belt Turn unit over and remove the six screws using a crosshead screwdriver as indicated by arrows. 10 Remove the brushbar cover from the base of the unit. Lift the brush bar out of the base of the unit. Next, remove the belt from the brushbar and from the motor spindle towards the rear of the floor head. Replace the belt.
FAQs Why won’t the vacuum cleaner turn on? • It may not be plugged into the electrical socket correctly; ensure that the plug is pushed in securely. • The electrical socket may not be working properly; check the fuse or breaker, or consult an electrician. • The motor thermostat may have tripped; switch off and unplug the vacuum cleaner, and leave for one hour before switching the cleaner back on.
Machine Overview Service & Help Any queries or concerns about using your Vax, simply visit; vax.co.uk/support - vaxireland.ie or, call the Vax Careline. Calls are charged at the UK local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling. Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 Monday-Friday 8.30 to 6.30 Saturday 9.00 to 5.00 Consumables To purchase spares and accessories, please visit vax.co.
Notes vax.co.
Notes 14
Notes vax.co.
COMMERCIAL Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK email: info@vax.co.uk website: vax.co.uk Version 1.0 Performance is everything.
