Instruction Manual

1.6 SPECIFICATIONS
INPUT CHARACTERISTICS: M1Z3-6760P3V / M1Z3-6800P3V
l VOLTAGE: 90V ~ 264VAC
l FREQUENCY: 47Hz ~ 63Hz
l INPUT CURRENT: 20-10A MAX AT ANY LOW/HIGH INPUT VOLTAGE
l INRUSH CURRENT: 60/100A @ 115/230VAC (25℃)
l POWER FACTOR CORRECTION: 95% @ 110V, FULL LOAD
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT REGULATION OUTPUT
OUTPUT
VOLTAGE
MIN. [A] MAX. [A] LOAD LINE
RIPPLE & NOISE
MAX. [P-P]
5V 4.0 48 ± 5% ± 50mV 70mV
12V 5.0 50 ± 6% ± 50mV 120mV
-5V 0.2 1 +5%, -10% ± 50mV 120mV
-12V 0.2 1.5 +5%, -10% ± 50mV 120mV
3.3V 4.0 45 ± 5% ± 50mV 70mV
+5VSB 0.4 3.5 +5%, -6% ± 50mV 70mV
REMARKS:
1. THE OUTPUT POWER OF 5V & 3.3V MAX: 40A
2. EACH POWER MODULE OUTPUT MAX: 420W
3. TOTAL OUTPUT POWER MAX: 760W / 800W
SPECIFICATION:
l TEMPERATURE RANGE: OPERATING: 0℃ --- 40℃
STORAGE: -20℃ --- 80℃
l HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
l DIELECTRIC WITHSTAND: INPUT / OUTPUT 3000 VAC FOR 1 SECOND
INPUT TO FRAME GROUND 1500 VAC FOR 1 SECOND
l EFFICIENCY: 65% TYPICAL AT 115VAC FULL LOAD
l POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
l OVER POWER PROTECTION: 110% ~ 180%
OVER VOLTAGE PROTECTION: +5V à 5.7V ~ 6.5V, 3.3V à 3.9V ~ 4.7V
+12V à 13.3V ~ 14.3V
OVER CURRENT PROTECTION: 110% ~ 180%
l SHORT CIRCUIT PROTECTION: +5V, -5V, +12V, -12V, +3.3V
l EMI NOISE FILTER: FCC CLASS A, CISPR22 CLASS A
l SAFETY: UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950
l REMOTE ON / OFF CONTROL
THE UNIT SHALL ACCEPT A LOGIC OPEN COLLECTOR LEVEL WHICH WILL DISABLE /
ENABLE ALL THE OUTPUT VOLTAGE (EXCLUDE +5V STANDBY),
AS LOGIC LEVEL IS LOW, OUTPUTS VOLTAGE WERE ENABLE,
AS LOGIC LEVEL IS HIGH, OUTPUTS VOLTAGE WERE DISABLE.
l 3.3V REMOTE SENSING
l DIMENSION: 265 (D) x 101 (W) x 125 (H) mm
