EtherLink® 10/100 PCI Network Interface Card with 3XP Processor User Guide 3CR990-TX-95 3CR990-TX-97 3CR990SVR95 3CR990SVR97 10/100 Mbps PCI client and server network interface cards with DynamicAccess® technology http://www.3com.com/ http://www.3com.com/productreg Part No.
3Com Corporation ■ 5400 Bayfront Plaza ■ Santa Clara, California ■ 95052-8145 Copyright © 2000, 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation.
CONTENTS ABOUT THIS GUIDE Conventions 12 1 INTRODUCTION Overview 13 Onboard 3XP Processor 14 Data Encryption 14 LAN Encryption Software for Windows 95/98 14 High Encryption Pack for Windows 2000 15 3CR990 NIC Features 15 Advanced Server Features 17 Load Balancing 18 Self-Healing Drivers 18 Failover 18 VLANs 19 Traffic Prioritization 20 Server Features Using Other NICs 21 Remote Wake-Up 21 Remote Wake-Up Requirements 21 Remote Wake-Up Cable 22 Remote Wake-Up and Multiple NIC Installations 22 Integrated Bo
2 INSTALLING AND CONNECTING THE NIC Overview 27 Installation Overview 27 Safety Precautions 27 Installation Requirements 28 Installing Multiple NICs 29 Upgrading Windows 95 to Windows 98 29 Updating the Network Driver and NIC Software Installing From Diskette 29 Making a DOS-Bootable Diskette 30 Creating Installation Diskettes 30 Product Registration 31 Preparing the NIC and the Computer 32 Installing and Connecting the NIC 34 Connecting the Remote Wake-Up Cable 36 Installing Software 38 29 3 INSTALLING N
4 INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Overview 55 Installing the DynamicAccess LAN Agent for a Client NIC 55 Client PC Requirements 55 Installing the LAN Agent 56 Verifying Successful Installation 57 Configuring the DynamicAccess LAN Agent 57 Removing the DynamicAccess LAN Agent 58 Installing DynamicAccess Software for a Server NIC 58 Verifying Successful Installation 60 Configuring Groups and VLANs for a Server NIC 60 Planning the Configuration 60 Working With Server Features 63 Windows 2000 63 Wi
Installation Overview 77 Installing LAN Encryption Software on Windows 95 77 Installing LAN Encryption Software on Windows 98 82 Adding the Entrust File 85 Starting DynamicAccess LAN Encryption Software 86 Viewing the Administrator’s Guide Online 86 Uninstalling LAN Encryption Software 87 5 INSTALLING NETWARE CLIENT AND SERVER DRIVERS Overview 89 Installing and Configuring the NetWare Server Driver 89 Using the Latest Support Packs 89 Obtaining NetWare Loadable Modules 90 Server Software Installation Requi
help 109 link timeout 109 probe interval 109 receive timeout 110 retry count 110 send timeout 110 ungroup 111 wait timeout 111 Troubleshooting a Group Configuration 112 6 CONFIGURING THE NIC Overview 113 Default NIC Settings 113 Configuration Methods 116 Changing General NIC Configuration Settings 117 Using the 3Com NIC Diagnostics Program 117 Using the 3Com DOS Configuration Program 118 Configuring the Managed PC Boot Agent (MBA) 120 Enabling or Disabling the Boot ROM Setting 120 Booting From the Network
TROUBLESHOOTING THE NIC Overview 129 Interpreting the LEDs 129 Viewing the NIC LEDs in the Diagnostics Program Accessing 3Com Support Databases 131 Accessing the 3Com Knowledgebase 131 Accessing the 3Com NIC Help System 131 Accessing Release Notes and Frequently Asked Questions 131 Troubleshooting the NIC Installation 132 Problems/Error Messages 132 Cleaning Up a Failed Installation 132 Troubleshooting the Network Connection 133 Troubleshooting Remote Wake-Up 135 Troubleshooting a Network Connection 136 T
A OBTAINING DRIVERS B SPECIFICATIONS AND CABLING REQUIREMENTS 3CR990 NIC Specifications 153 Cabling Requirements 154 Twisted-Pair Cable 154 10BASE-T Operation 155 100BASE-TX Operation 156 RJ-45 Connector Pin Assignments Flow Control 157 Pause Frames 157 Link Negotiation 157 156 C INSTALLING THE 3COM DMI AGENT Overview 159 About the 3Com DMI Agent 159 System Requirements 160 Client PC Requirements 160 Network Management Requirements Installing the 3Com DMI Agent 161 161 D ETHERCD CONTENT AND NAVIGATION E
F TECHNICAL SUPPORT Online Technical Services 171 World Wide Web Site 171 3Com Knowledgebase Web Services 172 3Com FTP Site 172 3Com Bulletin Board Service 172 Access by Analog Modem 172 Access by Digital Modem 173 3Com Facts Automated Fax Service 173 Support from Your Network Supplier 173 Support from 3Com 174 Returning Products for Repair 175 INDEX FCC CLASS B STATEMENT FCC DECLARATION OF CONFORMITY INDUSTRY CANADA CLASS B EMISSION COMPLIANCE STATEMENT AVIS DE CONFORMITÉ À LA RÉGLEMENTATION D’INDUSTRIE C
ABOUT THIS GUIDE This guide describes how to install, configure, and troubleshoot the following 3Com® EtherLink® PCI network interface cards (NICs): NIC/Description Model Number EtherLink 10/100 Mbps PCI with 3XP Processor 3CR990-TX-95 Client NIC for DES (56-bit) encryption EtherLink 10/100 Mbps PCI with 3XP Processor 3CR990-TX-97 Client NIC for 3DES (168-bit) and DES (56-bit) encryption EtherLink Server 10/100 Mbps PCI NIC with 3XP Processor 3CR990SVR95 Server NIC for DES (56-bit) encryption Ether
CHAPTER : ABOUT THIS GUIDE You can download Acrobat Reader from the EtherCD or from Adobe Systems Incorporated Web site: http://www.3com.com/ Conventions The following tables list conventions that are used throughout this guide.
1 INTRODUCTION Overview This chapter describes the following 3Com® EtherLink® 10/100 Mbps PCI network interface card (NIC) models from the 3CR990 NIC family.
CHAPTER 1: INTRODUCTION Onboard 3XP Processor The 3CR990 NIC represents a new generation of secure, intelligent client NICs with an onboard RISC processor (3XP processor). The 3XP processor is designed to optimize system and network performance. The NIC off-loads key networking and security tasks from the host PC CPU (central processing unit) to the 3XP processor, even when running bandwidth-intensive applications such as voice, video, imaging, and Internet and intranet applications.
3CR990 NIC Features 15 High Encryption Pack for Windows 2000 The Windows 2000 High Encryption Pack allows you to enhance your system with the highest available encryption level (168-bit). You can download the High Encryption Pack from the following Microsoft World Wide Web site: http://www.microsoft.com/WINDOWS2000/downloads /recommended/encryption/default.asp The Windows 2000 High Encryption Pack is eligible for export from the U.S. to all customers worldwide, except to U.S. embargoed destinations.
CHAPTER 1: INTRODUCTION Figure 1 The 3CR990 NIC Supports Up to 168-bit (3DES) Encryption Encryption chip Remote Wake-Up (RWU) connector TX D ATA ACT 10 L 100 N K 3XP Processor The 3CR990 NIC provides these features for supported IP and IPX environments: ■ Advanced Server Features (for 3CR990 server NICs only)—Improved network performance, management, and control: ■ Load Balancing ■ Self-Healing Drivers ■ Failover ■ VLANs ■ Traffic Prioritization ■ Remote Wake-Up—Lets you power-on a computer remotel
3CR990 NIC Features ■ ■ ■ 17 across the network to a DMI 2.0-compliant management application. Remote System Alerts (heartbeat packets)—Can signal a possible computer power loss or theft. Hot Plug NIC Installation—Lets you add a new NIC or remove and replace a NIC without turning off power to the computer. Offline Diagnostics—Provides offline diagnostics programs for configuring, testing, and troubleshooting NICs.
CHAPTER 1: INTRODUCTION Load Balancing Load balancing maximizes bandwidth at the server through the use of multiple parallel resilient server links (RSLs) that share the network load. An RSL consists of two or more NICs that form a virtual NIC. Each virtual NIC has multiple physical NICs bound to it, forming a group. Each NIC in a group uses the same protocols and frame types. One NIC is designated the primary NIC and the others secondary NICs.
3CR990 NIC Features 19 failed NIC. The failover behavior of secondary NICs depends on how you set load balancing: ■ In a transmit load balancing arrangement, the primary NIC is the only one that receives packets. If the primary NIC fails, a secondary NIC assumes the configuration profile, network traffic, and active status of the failed primary NIC. ■ In a bidirectional load balancing arrangement, all NICs receive packets.
CHAPTER 1: INTRODUCTION be members of the same VLAN. Membership in a VLAN is determined by a VLAN tag that is transmitted with the Ethernet frame for use by a switch. With VLANs, you can define a network according to: ■ Organizational groups—For example, you can have one VLAN for the Marketing department and one for the Finance department. ■ Application groups—For example, you can have one VLAN for e-mail users and one for multimedia users.
3CR990 NIC Features 21 For detailed information on DynamicAccess technology products, go to: http://www.3com.com/dynamicaccess Server Features Using Other NICs One foreign NIC (one that is not a 3Com EtherLink Server NIC) is allowed in one group per server.
CHAPTER 1: INTRODUCTION ■ PCI 2.2-compliant bus or a 3-pin Remote Wake-Up connector on the computer motherboard and a 5-volt standby power supply unit rated at a minimum of 375 milliamperes If you are unsure whether your computer meets the requirements listed above, see the computer documentation or contact the computer manufacturer. For more information on Remote Wake-Up, including a list of computers that currently support this feature, go to: http://www.3com.
3CR990 NIC Features ■ ■ ■ 23 Configure or reconfigure multiple systems simultaneously. Scan for viruses. Back-up hard drives and perform disaster recovery tasks. In addition to firmware, MBA has a complete set of tools, utilities, and pre-OS software that enables network administrators to perform such tasks as: ■ Reconfiguring multiple systems at once. ■ Backing up hard drives automatically.
CHAPTER 1: INTRODUCTION The 3Com DMI Agent consists of a DMI browser with the following components: ■ DMI service layer ■ DMI agent ■ GUI installer ■ NDIS drivers DHCP Server Prevention This feature prevents the PC from acting like a DHCP server. All receive packets are passed through a DHCP filter and are discarded if they are deemed to be destined for the DHCP process. Remote System Alerts The NIC can be configured to continuously transmit a packet to an alert target management station.
DynamicAccess LAN Agent 25 Offline Diagnostics The NIC software includes offline diagnostics programs for configuring, testing, and troubleshooting NICs. The configuration program within the DOS diagnostics program is used for a PC running DOS or NetWare. The 3Com NIC diagnostics program (3Com NIC Doctor) is a windows-based program used for a PC running Windows 2000, Windows NT 4.0, Windows 98, or Windows 95.
CHAPTER 1: INTRODUCTION Windows 2000 Offload Features Additionally, the 3CR990 NIC supports Windows 2000 offload features in an IP environment. The Windows 2000 offload features are designed to enhance the Windows 2000 operating system capabilities by off loading key TCP/IP networking and security tasks from the Windows 2000 operating system: ■ IPSec Offload—reduces CPU utilization by allowing the 3XP processor and a crypto chip on the NIC to perform data encryption operations.
INSTALLING AND CONNECTING THE NIC 2 Overview This chapter describes how to install the NIC in your PC and connect it to an Ethernet or Fast Ethernet network. Installation Overview There are four steps to the NIC installation: 1 Register the product. 2 Install the NIC in the PC. 3 Connect the NIC to the network. 4 Install the network driver. Safety Precautions Observe the following safety precautions. WARNING: Computers operate with voltages that can be lethal.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC CAUTION: Install the NIC in a PCI slot that conforms to PCI 2.1 or higher specifications. Do not attempt to install the NIC in an ISA or EISA slot. Doing so may damage the NIC and the computer. WARNING: Make sure that the computer power cord is unplugged. Only properly trained and authorized personnel should perform service. Contact the computer manufacturer for information about safe service techniques.
Installing From Diskette 29 You can install the NIC base network driver on any Windows PC without having to also install a specific Microsoft Service Pack; however, 3Com recommends that you always try to use the most recent Service Pack available from Microsoft technical support (www.microsoft.com). Running 3Com DynamicAccess software on NetWare 4.0 requires Service Pack 6 or greater from Microsoft. Novell NetWare server version 3.12, 4.11, or 5.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC You can also download the EtherCD software from the 3Com World Wide Web site: http://support.3com.com/infodeli/tools/nic The installation diskettes allow you to install the network driver only. If you want to install the NIC diagnostics or desktop management software, you must install them from the EtherCD.
Product Registration 31 The EtherCD Welcome screen appears. 3 Click NIC Software. 4 Click NIC Drivers and Diagnostics. 5 Click Installation Utilities. 6 Click Create Installation Diskettes. The EtherCD Diskette Creation Utility Welcome screen appears. 7 Click Next. 8 Insert the blank, formatted diskette labeled EtherDisk 1 in the PC, and then click Next. Files are copied. EtherDisk 1 contains: ■ NDIS 2/3/4/5 drivers ■ DOS utilities ■ README.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC To be able to register electronically, a web browser must be installed on your system. You must also have an active Internet service provider (ISP) connection. The original version of Windows 95 (Build 950) does not automatically allow you to change your default browser, even if Microsoft Internet Explorer is not present. If you are running this version of Windows 95 on your PC, access the following site to register your 3CR990 NIC: http://www.3com.
Preparing the NIC and the Computer 33 2 Make sure that cable requirements are met. The RJ-45 port provides a 10 Mbps or 100 Mbps connection automatically, depending on the speed of the connected hub or switch. The following table shows the cable requirements and maximum network cable lengths for the RJ-45 port.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC 9 Write down the MAC address of the NIC and note the relative position of the intended PCI slot. This information is helpful when you are installing the network drivers and connecting the cables to the hub or switch. The MAC address is the 12-digit hexadecimal number printed on the small bar code label on the component side of the NIC. The next step is to install the NIC in the computer and connect it to the network.
Installing and Connecting the NIC 35 Figure 4 Installing the NIC 1 Remove slot cover 2 Insert NIC PCI slots 1 Carefully insert the NIC in the empty PCI slot, as shown. Press firmly to ensure that the NIC is fully seated in the slot. Secure the NIC with the screw if you removed one earlier. If you want to install the Remote Wake-Up cable, go to the next section, Connecting the Remote Wake-Up Cable to continue the installation. If you do not want to connect the cable, continue with step 2.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC 3 Plug the RJ-45 connector on the twisted-pair network cable into the RJ-45 port on the NIC backplate. 4 Connect the other end of the network cable to an active network port. Figure 5 Connecting the cable to the NIC backplate ta TX Da ACT 10 NL 100 K The next step is to install the software, as described in Installing Software on page 38.
Connecting the Remote Wake-Up Cable 37 WARNING: Make sure that the PC power cord is unplugged. Only properly trained and authorized personnel should perform service. Contact your PC manufacturer for information about safe service techniques. To connect the Remote Wake-Up cable: 1 Make sure that the NIC is properly installed in a PCI slot. 2 Insert the Remote Wake-Up cable into the RWU connector on the NIC. Twist the cable twice before attaching the cable to the PC.
CHAPTER 2: INSTALLING AND CONNECTING THE NIC Installing Software See the following topics for requirements and instructions on installing software in various operating systems: ■ Installing NIC Drivers in Windows on page 39 ■ Updating the Network Driver and NIC Software on page 51 ■ Installing NetWare Client and Server Drivers on page 89 The next step is to install the network driver. Go to Installing NIC Drivers in Windows on page 39 or Installing NetWare Client and Server Drivers on page 89.
3 INSTALLING NIC DRIVERS IN WINDOWS Overview This chapter explains the following tasks on a computer running Windows 2000, Windows NT, Windows 98, or Windows 95: ■ Install the network driver and NIC software using EtherCD ■ Update the network driver or NIC diagnostics program ■ Install multiple NICs To obtain the latest version of a driver, go to: http://www.3com.com/ The network driver can be used in both Microsoft and NetWare network environments.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS Getting Help To display the Help system during the software installation, click Help on any 3Com window. Installing the Network Driver Using the EtherCD To install the network driver using the EtherCD, follow the steps in the section that is specific to your Windows operating system. Before installing the network driver: ■ Make sure that the NIC is installed in the PC and that it is connected to the network.
Installing the Network Driver Using the EtherCD 41 3 Click Next. The Install Hardware Device Drivers screen appears. 4 Insert the EtherCD in the CD-ROM drive. 5 Select Search for a suitable driver for my device (recommended), and then click Next. The Locate Driver Files screen appears. 6 Select the CD-ROM drives option, clear any other checked options, and click Next. The Driver Files Search Results screen appears. Windows finds the driver on the EtherCD. 7 Click Next. The Hardware Install screen appears.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS 5 Select Properties on the pop-up menu. The Network window appears. 6 Click the Adapters tab. If networking has not been installed on your PC before, Windows NT asks you if you want to install networking. Click Yes. See the WINNT.TXT file located on the EtherCD or your Windows NT documentation for instructions. 7 Click Add. The Select Network Adapter dialog box appears. 8 Click Have Disk. The Insert Disk dialog box appears.
Installing the Network Driver Using the EtherCD 43 Refer to your system administrator or the Windows NT documentation for assistance. After entering the appropriate TCP/IP information and clicking OK, the Network Settings Change window appears. If the Microsoft TCP/IP Properties screen does not appear, the installation is complete. The Network Settings Change window appears. 14 Click Yes to restart the PC. The network driver installation is complete.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS 4 Select the CD-ROM drive option and clear any other check options that are selected. 5 Insert the EtherCD in the CD-ROM drive, and then click Next. Windows finds the driver file for the device. 6 Click Next. Files are copied. The Insert Disk screen appears, prompting you for the Windows 98 CD-ROM. 7 Click OK. The Copying Files dialog box appears.
Installing the Network Driver Using the EtherCD 45 Before installing the NIC software: ■ Make sure that the NIC is installed in the PC and connected to the network. ■ Make sure that you have the Windows 95 installation files. These files may be on a CD or diskettes, or they may have been copied to your hard disk when Windows 95 was installed on your PC. If you encounter problems during the installation, see W95NDIS.TXT and TROUBLE.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS ■ network, this entry must be exactly the same for all the PCs in your network. Computer Description—Displays additional details to other users on the network about this PC. For example, you could specify that the PC is connected to a printer. Filling in this field is optional. 4 The Insert Disk screen appears, prompting you for the Windows 95 CD-ROM. Click OK. The Copying Files screen appears.
Installing the Network Driver Using the EtherCD 47 2 Click Finish. ■ If networking has already been installed on your PC, go to step 4. ■ If this is the first time that networking is being installed on your PC, the Identification tab of the Network screen appears. Go to step 3. 3 In the specified fields of the Identification tab screen, enter the following information, and then click Close. ■ Computer Name—Identifies the PC on the network for other users.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS If the Windows 95 files were copied to your hard drive, enter the path to the directory containing these files, and then click OK. Files are copied. The Systems Settings Change screen appears, prompting you to restart your computer. ■ 8 Click Yes. After Windows restarts, double-click the Network icon in the Control Panel and make sure that the configuration settings are properly set for your network environment. Contact your system manager for assistance.
Verifying Successful Installation 49 Windows NT 4.0 To verify successful NIC installation: 1 Double-click the My Computer icon. The My Computer screen appears. 2 Double-click the Control Panel icon. The Control Panel screen appears. 3 Double-click the Network icon. The Network screen appears. 4 Select the Adapters tab. 5 Make sure that the name of the NIC appears in the list of network adapters. If the name of the NIC does not appear in the list of network adapters, the installation was not successful.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS 3 Double-click Network adapters and make sure that the name of the 3Com EtherLink NIC appears. If a red X or a yellow exclamation point (!) appears by the name of the NIC, the installation was not successful. See Troubleshooting the NIC Installation on page 132 for troubleshooting help. Installing the 3Com NIC Diagnostics Program This section describes how to install the 3Com NIC Diagnostics program after you have already installed the network driver.
Starting the 3Com NIC Diagnostics Program 51 8 Restart Windows. The installation is complete. Starting the 3Com NIC Diagnostics Program To start the 3Com NIC Diagnostics program: 1 Open the Windows Start menu. 2 Select Programs, and then 3Com NIC Utilities. 3 Click 3Com NIC Doctor. The 3Com NIC Diagnostic screen appears. For instructions on using the program, see Running the NIC Diagnostics Tests on page 144.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS 6 To update the network driver and NIC diagnostics software, click Update Drivers and Diagnostics Program. To update the network driver and remove the NIC diagnostics software, click Update Drivers and remove Diagnostics Program. The Update screen appears, displaying a message indicating the 3Com NIC Update Kit has successfully updated the network software, and informing you that you must restart your PC.
Installing Multiple NICs 53 4 Follow the prompts on the screen to install the network driver. See Windows 2000 on page 40, Windows 98 on page 43, or Windows 95 on page 44, earlier in this chapter for driver installation instructions. 5 After the network driver is installed, restart the PC. 6 After the PC restarts, exit Windows and turn the power off. Make sure that the PC is unplugged. 7 Install the second NIC in your PC and connect it to the network.
CHAPTER 3: INSTALLING NIC DRIVERS IN WINDOWS 8 Make sure that d:\ appears in the entry box (where d:\ represents the letter name of the CD-ROM drive), and then click OK. The Select OEM Option screen appears with the name of one of the NICs selected. Only one NIC appears on this screen. 9 Click OK. Files are copied. The Network screen appears with the name of the first installed NIC. 10 Close the Network screen. If you are prompted for network information, enter the requested information.
4 INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Overview This chapter explains the following tasks on a computer running Windows 2000, Windows NT, Windows 98, or Windows 95: ■ Installing the DynamicAccess LAN Agent for a client NIC ■ Installing DynamicAccess software for a server NIC ■ Configuring Groups and VLANs for a server NIC ■ Using Windows 2000 offload features ■ Installing DynamicAccess LAN Encryption Software Installing the DynamicAccess LAN Agent for a Client NIC This section explains how to ins
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS The following table lists the minimum client requirements and recommended Microsoft Service Packs (if any) for the version of the DynamicAccess LAN agent that is included on the EtherCD. Requirements for Running DynamicAccess Technology on a Client PC Recommended Microsoft Service Pack Windows 2000 486/66 MHz CPU 32 MB RAM 5 MB available hard drive space None required Windows NT 4.
Installing the DynamicAccess LAN Agent for a Client NIC 57 8 Do one of the following: ■ If you selected Windows 95/98, click Install DynamicAccess Technology for Windows 95/98. ■ If you selected Windows NT 4.0, click Install DynamicAccess Technology for Windows NT 4.0. The DynamicAccess Software Installation program starts. 9 When the DynamicAccess Technology installation is finished, exit the EtherCD, and then exit Windows. 10 Restart the PC. You must restart the PC to complete the installation.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS To configure the DynamicAccess LAN agent on a local client PC: 1 Double-click the 3Com DynamicAccess icon in the Windows Control Panel. The Traffic Prioritization tab of the DynamicAccess Setup screen appears. 2 Select the tab containing the information you want to configure. Traffic Prioritization—Allows you to prioritize applications, which can ease bottlenecks in your network and allow critical applications to take network precedence.
Installing DynamicAccess Software for a Server NIC 59 The EtherCD Welcome screen appears. 4 Click NIC Software. 5 Click DynamicAccess Technology. 6 Click Install DynamicAccess Technology. 7 Select the appropriate menu option for your operating system (Windows 2000 or Windows NT 4.0) Ignore the Windows 95/98 menu option. DynamicAccess server software is not supported on a PC running Windows 95 or Windows 98.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Verifying Successful Installation After the DynamicAccess software is installed on the server PC, the following changes are visible in the Windows Network control panel: ■ ■ ■ For each physical NIC installed in the client PC, a virtual NIC entry appears in the list of network adapters. All protocols are re-bound to the virtual NIC. The bindings to the physical NIC are still intact. A 3Com DynamicAccess entry appears as a protocol.
Configuring Groups and VLANs for a Server NIC ■ ■ ■ ■ ■ ■ ■ 61 Decide whether you want to use a foreign (non-3Com) NIC in one of the groups. One foreign NIC (one that is not a 3Com EtherLink Server NIC) is allowed in one group per server. Decide which NIC is to be the primary NIC in each group. If a foreign NIC is used, it must be designated the primary NIC. Disable load balancing if you have set failover for a group of NICs operating at different speeds.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS ■ Checksum, TCP Segmentation, and IP Sec). In this case, the offload support is limited to the features supported by all NICs in the group. For example, if two NICs in a group support all offload features but one NIC supports only TCP Checksum, then offload support for the group is limited to TCP Checksum. Observe these VLAN configuration guidelines: ■ Assign a VLAN ID number to each VLAN.
Configuring Groups and VLANs for a Server NIC 63 CAUTION: Before creating or removing a load balancing group or VLAN, take note of configuration information such as IP addresses and IPX network numbers. DynamicAccess server software does not restore a network configuration to its pre-DynamicAccess state. Always verify that the network configuration conforms to your expectations after creating or removing a load balancing group or VLAN.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Windows NT Start DynamicAccess server features under Windows NT as follows: 1 Log in to the Windows NT Administrator account. 2 From the Windows Start menu, select Settings/Control Panel.
Configuring Groups and VLANs for a Server NIC 65 3 Double-click the DynamicAccess SW Server icon. The DynamicAccess Resilient Server Link/Load Balance/VLAN Configuration window appears. Click the appropriate tab to configure server features. Creating a Group 1 Click the Load Balance/RSL tab. 2 In the Load Balance/RSL window, click Create Group. 3 In the Create Group dialog box, type a group name.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Adding NICs to a Group 1 Click the Load Balance/RSL tab. 2 In the Load Balance/RSL window: ■ Select a group from the Load Balancing/RSL Groups list. ■ Select a NIC from the Network Interface Cards list. 3 Click Add NIC. The NIC appears as part of the group in the Load Balancing/RSL list box. If you click Add NIC repeatedly, NICs are added to the group in the order that they are listed after the first NIC you selected.
Configuring Groups and VLANs for a Server NIC 67 Changing an IP Address If another device is using a bidirectional load balancing group's dedicated IP address, you must change either the other device’s IP address or that of the load balancing group. Use the appropriate procedure below: Changing the Other Device's IP Address After you change the other device's address, restart receive load balancing as follows: 1 In the Load Balancing/RSL window, select the group that had the duplicate address.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS In the next window, configure the IP address and subnet mask. Windows NT—Restart the computer when the software prompts you to do so. ■ Specifying Traffic Priorities You can use the DynamicAccess Software Setup window to specify traffic priorities. 1 Double-click the 3Com DynamicAccess icon in the Windows Control Panel. The DynamicAccess Software Setup window appears.
Configuring Groups and VLANs for a Server NIC 69 Disabling Load Balancing for a Group Follow these steps to disable load balancing for a group: 1 Click the Load Balance/RSL tab. 2 In the Load Balance/RSL window: ■ Select a group from the Load Balancing/RSL Groups list. ■ Click Properties. 3 In the Group Properties dialog box: To disable receive load balancing only—Clear the Receive Load Balance Enabled check box.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Deleting or Editing a VLAN When a VLAN is selected, you can delete it or edit its properties. 1 Click the VLANs tab. 2 In the VLANs window, select a VLAN. To delete the selected VLAN, click Delete VLAN. To edit the VLAN ID for the selected VLAN, click Edit VLAN. Displaying NIC Properties Follow these steps to display NIC properties: 1 Click the Load Balance/RSL tab. 2 In the Load Balance/RSL window, select a NIC. 3 Click Properties.
Configuring Groups and VLANs for a Server NIC 71 2 Add 3Com server NICs to the group. Add at least one 3Com Gigabit Etherlink Server NIC and at least one 3Com EtherLink Server 10/100 PCI NIC to the group. Designate the Gigabit Etherlink Server NIC as the primary NIC. See Adding NICs to a Group on page 66. 3 Disable load balancing for the group. See Disabling Load Balancing for a Group on page 69.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Table 1 Troubleshooting Load Balancing In Windows (continued) Symptom Tip Receive load balancing does not function across a router. Receive load balancing across a router is not supported. Clients across the router cannot use receive load balancing, but clients within the subnet get higher throughput from receive load balancing.
Using Windows 2000 Offload Features 73 miniport icon name. If a miniport is associated with an ungrouped NIC, you can identify the NIC by its MAC address as follows: 1 In the Network and Dial-up Connections window, right-click the miniport icon and select Properties from the menu. 2 In the DynamicAccess Properties window, click the General tab. 3 In the General tab, move the cursor over the miniport name. (Do not click the name.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Enabling Offloads Windows 2000 provides the capability to individually enable or disable each of the four offload features. (The default setting for these features is enabled.) To enable or disable individual offload settings in Windows 2000: 1 Right-click the My Network Places desktop icon and select Properties. The Network and Dial-up Connections screen appears. 2 Right-click the Local Area Connection icon and select Properties.
Using Windows 2000 Offload Features 75 3 Click Configure. The 3Com EtherLink 10/100 Mbps PCI NIC with 3XP Processor screen appears. 4 Click the Advanced tab. 5 Select Enable Offloads in the Property list box. 6 Select the appropriate value in the Value entry box (shown in the following table) for the desired offload state. 7 Close all open windows.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Configuring Offloads for a Group of Different NICs Your computer may contain a combination of installed NICs (including one or more 3CR990 EtherLink 10/100 PCI NICs with the 3XP Processor) with varying offload capabilities. If you have a mix of dissimilar NICs configured in a DynamicAccess group, then DynamicAccess will support only those offload functions that are supported by the all the NICs in the group.
Installing DynamicAccess LAN Encryption Software 77 Minimum Installation Requirements Your computer must meet the following requirements before you can successfully install the DynamicAccess LAN Encryption software. Hardware Requirements: ■ Pentium 90 or better ■ 24 MB RAM ■ 25 MB free hard disk space (Windows 95); 17 MB free hard disk space (Windows 98) ■ Color monitor Software Requirements: ■ Windows 95A or Windows 95B (OSR2) or Windows 98 or Windows 98SE.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS The installation process installs the following required system components: Winsock 2 and DUN 1.3. For this reason, you may be prompted to reboot the system several times during installation. (For Windows 95 PCs without the DUN 1.3 upgrade, you may see as many as three requests to reboot.) When you click Yes to reboot, the installation program ignores the reboot and continues to install the software.
Installing DynamicAccess LAN Encryption Software 79 8 If you need to close any open applications, click Cancel, close the applications, and then restart the installation process. (Alternatively, you can press Ctrl-Tab to display each open application and close it.) Once you are ready to proceed, click Next. The Software License Agreement screen appears. 9 Click Yes to continue. The Setup Type screen appears, offering you a Typical or Custom installation.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS 13 Verify that the displayed components are correct for installation on your computer and click Next. The system copies files from the EtherCD to the destination location, sets up the registry, builds drivers, and updates bindings. The Winsock2 Setup screen appears. Follow the rest of the setup wizard instructions to install the software properly. If you see “version conflict” messages, click Cancel to continue.
Installing DynamicAccess LAN Encryption Software 81 20 Insert the Windows 95 CD-ROM and click OK. If you are prompted to enter the path to the Windows 95 files (usually d:\win95), enter the appropriate path and click OK. The Insert Disk screen appears, prompting you to reinsert the Windows 95 CD-ROM. 21 Verify that the Windows 95 CD-ROM is inserted in the CD-ROM drive and click OK.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS To use the Certificate Authentication mode, copy the entrust.ini file to the Windows directory on the client computer and then restart the PC. You can find a sample of the entrust.ini file on the EtherCD. See “Adding the Entrust File” on page 85.
Installing DynamicAccess LAN Encryption Software 83 8 If you need to close any open applications, click Cancel, close the applications, and then restart the installation process. (Alternatively, you can press Ctrl-Tab to display each open application and close it.) Once you are ready to proceed, click Next. The Software License Agreement screen appears. 9 Click Yes to continue. The Setup Type screen appears, offering you a Typical or Custom installation.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS 13 Verify that the displayed components are correct for installation on your computer and click Next. The system copies files from the EtherCD to the destination location, sets up the registry, builds drivers, and updates bindings. After you have successfully installed the DynamicAccess LAN Encryption client, the physical adapters (NICs) and upper level protocols (TCP/IP, IPX, etc.
Installing DynamicAccess LAN Encryption Software 85 During installation, the policy files tssecmap.cfg and tssecdes.cfg are automatically copied from the EtherCD to your PC. See the “3Com LAN Encryption Secure Network Map File (tssecmap.cfg)” topic and the “Security Level Definition File (tssecdes.cfg)” topic in the administrator’s guide for more information. To use the Certificate Authentication mode, copy the entrust.ini file to the Windows directory on the client computer and then restart the PC.
CHAPTER 4: INSTALLING DYNAMICACCESS SOFTWARE IN WINDOWS Starting DynamicAccess LAN Encryption Software You start the DynamicAccess LAN Encryption software by choosing a secure profile. 1 Right-click the padlock icon in the taskbar to see the secure profiles on your system. 2 Select the secure profile you want to use from the list. ■ If your organization is set up to use certificates to authenticate the users on the network, you are prompted to provide your user name and password.
Installing DynamicAccess LAN Encryption Software 87 Once you have installed the DynamicAccess LAN Encryption software and downloaded the DynamicAccess LAN Encryption Software Administrator’s Guide to your computer’s hard drive, you can view the guide online by following these steps: 1 Click the Start button in the taskbar on your Windows desktop. 2 Select Programs. 3 Select 3Com. 4 Select DynamicAccess LAN Encryption Software Admin Guide.
INSTALLING NETWARE CLIENT AND SERVER DRIVERS 5 Overview This chapter describes how to install server drivers for Novell NetWare versions 3.12, 4.11, and 5.0. To obtain the latest shipping version of a driver, go to: http://www.3com.com/ Installing and Configuring the NetWare Server Driver This section describes how to install the NetWare driver on a Novell server running NetWare 3.12, 4.11, or 5.0. The \NWSERVER directory contains the network driver file (3C99X.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS NetWare Version Required Support Pack (continued) 4.11 Support Pack 6 or later for all types of operation. Support Pack 7 or higher is required for proper operation of the failover mechanism for the 3CR990 server NIC. 5.0 Support Pack 2 or later The required support pack must be loaded before you install the driver for the 3CR990 NIC. You can obtain the latest support packs from the Novell World Wide Web site: http://www.support.novell.
Installing and Configuring the NetWare Server Driver 91 Server Software Installation Requirements Before you install software, you may want to verify that the installed NICs are functional or change their configuration settings by running DOS diagnostics. Use the 3C99XCFG.EXE program located on the EtherCD. The instructions in this section demonstrate the fundamentals of setting up a sample server configuration.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Obtaining Slot Numbers The NetWare driver installation program requires you to enter a PCI slot number for each NIC. In older versions of NetWare software, the term slot number referred to the physical slot in which the NIC was installed in the server. Now, the slot number is a combination of the bus number, bus type, and the physical slot number. The value of a slot number can be 10001 or larger.
Installing and Configuring the NetWare Server Driver 93 The NLM file location is typically in the sys:system directory. You need a NetWare client system to copy the NLM files to the server. 2 Copy the LAN driver file (3C99X.LAN) from the EtherCD to the same directory. 3 Add the following two lines to the AUTOEXEC.NCF file: load sys:\system\3c99x.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS 4 Press Enter. The Internetworking Configuration screen appears. 5 In the displayed menu, select Boards, and then press Enter. 6 Press Insert. A list of currently installed drivers appears. 7 Press Insert again. The New Driver dialog box appears. 8 Specify the directory: a:\nwserver\3c99x.lan 9 Press Enter. An updated list of installed drivers appears. 10 Select 3C99x, and then press Enter. You are prompted to name the NIC, for example: 3c99x_1.
Installing and Configuring the NetWare Server Driver ■ 95 Select the board. For example, enter: 3c99x_1, and then press Enter. 16 When prompted, enter the network number, and then press Enter. 17 In the Frame Type field, press Enter to display a list of frames, choose a frame, and press Enter. 18 Press Esc. You are prompted to save the changes. 19 Press Enter to save the changes. The configured Protocol to Network Interface Bindings screen appears. 20 Press Esc to Exit. The main menu appears.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Loading the 3Com EtherCD NetWare 4.11 Insert the CD in the CD-ROM drive and enter these commands: load cdrom cd mount 3C99XC_TXM NetWare 5.0 Insert the CD in the CD-ROM drive and enter this command: load cdrom Wait for the message that states the CD is mounted successfully, and then proceed to copy the driver. Copying the Driver 1 Enter this command at the prompt: NetWare 4.11: load install NetWare 5.
Installing and Configuring the NetWare Server Driver 97 9 Select Yes at the prompt to confirm the name of the driver to copy. The installation program copies the driver to the appropriate server subdirectory. The Configuration screen appears. Specifying the Slot Number You need not specify the slot number if you are installing only one NIC. 1 In the Configuration screen, select Slot Number. 2 Enter the slot number of the NIC that you want to install.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Installing Multiple Server NICs To support more than one NIC in a NetWare server, change the AUTOEXEC.NCF file to the following format: load 3C99X.LAN slot= NAME= FRAME= bind ipx to net= load 3C99X.LAN slot= NAME= FRAME= bind ipx to net= The values and are the numbers of the PCI slots in which the NICs are physically installed.
Installing and Configuring the NetWare Server Driver 99 Verifying the PCI Slot Number To verify the PCI slot number in which a NIC is installed: 1 Boot the NetWare server with the -na option. This prevents the AUTOEXEC.NCF file from loading. For example, enter: server -na 2 Issue the load command for the NIC LAN driver without a slot parameter. For example, enter: load sys:\system\3C99X.lan 3 NetWare lists the valid slot number(s) for the NIC, depending on how many NICs are installed.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS 4 Enter this command: 3C99xC_TXM:\nwserver The following message appears: Product “3Com DynamicAccess Server Features” was found. Verify that this is the product you want to install before proceeding. Press to continue. Press to abort installation. 5 Press Enter. The system copies the DynamicAccess technology server features software to the SYS volume. Configuring Groups 1 Press Esc to return to the Installation Options screen.
Installing and Configuring the NetWare Server Driver 101 e Remove any protocol BIND commands from each secondary NIC. f For each group, add an LBRSL GROUP command to group the primary and secondary NICs together. There can be only one LBRSL GROUP command per group, and it must list the primary and all secondary NICs. Place this command after the LAN driver LOAD commands or the SYS:ETC\INITSYS.NCF command. To specify a load balancing group with resilient server links, use the LB option.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Figure 6 AUTOEXEC.NCF File for One Group of Two NICs load se load lbrsl ;Define primary NIC slot-frame instances load 3c990 slot=10001 frame=ethernet_802.2 name=p1_802.2 load 3c990 slot=10001 frame=ethernet_ii name=p1_ii ;Define secondary NIC slot-frame instances load 3c990 slot=10002 frame=ethernet_802.2 name=p2_802.2 load 3c990 slot=10002 frame=ethernet_ii name=p2_ii ;Bind protocols to primary NIC bind ipx to p1_802.
Changing NetWare Driver Configuration Parameters 103 2 Log in or map to the server. If you cannot log in or map to the server, the link is not functional. If the link is functional, the following message appears: Link integrity test for primary slot #XXXXX passed. Changing NetWare Driver Configuration Parameters You can change server configuration parameters using the NetWare installation program Configuration screen. The following table lists the parameters shown on the Configuration screen.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Maintaining Groups DynamicAccess technology server features allow you to configure load balancing groups. The load balancing features are described in Advanced Server Features on page 17.
Maintaining Groups ■ ■ ■ 105 Decide whether groups are to perform load balancing: ■ Load balancing groups provide failover and share the network load. ■ Resilient server link groups provide failover, but do not share the network load. ■ If you plan to form load balancing/failover groups, do not enable TCP/IP checksum offload. To use bidirectional load balancing, you must assign a dedicated IP address for each load balancing group. This address must be unique (not used elsewhere on the network).
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Figure 7 AUTOEXEC.NCF File for One Group of Three NICs load se load lbrsl ;Define primary NIC slot-frame instances load 3c990 slot=10001 frame=ethernet_802.2 name=p1_802.2 load 3c990 slot=10001 frame=ethernet_ii name=p1_ii ;Define secondary NIC load 3c990 slot=10002 load 3c990 slot=10002 load 3c990 slot=10003 load 3c990 slot=10003 slot-frame instances frame=ethernet_802.2 name=p2_802.2 frame=ethernet_ii name=p2_ii frame=ethernet_802.
Maintaining Groups 107 server links, use the LB option. To specify a resilient server link group without load balancing, use the RSL option. For the LBRSL GROUP command syntax, see Server Feature Commands on page 108. 3 Reboot the server. The sample AUTOEXEC.NCF file in Figure 8 shows one group of three NICs and one group of two NICs. The primary NIC in slot 10001 is bound to two secondary NICs in slot 10002 and slot 10003. The primary NIC in slot 10004 is bound to the secondary NIC in slot 10005.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Server Feature Commands DynamicAccess server feature commands for NetWare can be used to create sophisticated configurations of groups and for troubleshooting. You can enter them at the NetWare command line or add them to the appropriate NCF file. The commands are summarized below. As shown in the examples, all commands are preceded by the keyword lbrsl.
Maintaining Groups Syntax 109 lbrsl display status [pri_slot] where: pri_slot is the PCI slot number of the primary NIC in the group for which information is to be displayed. If this parameter is not specified, information for all groups is displayed. An example of the type of information displayed follows: Group NNN (LB group) Primary board id: Original NNN, Current NNN Load balancing on incoming IP packets: Enabled; IP Rx Addr: NN.NN.NN.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Syntax lbrsl probe interval seconds where seconds is the interval in seconds. Example lbrsl set probe interval 1 Default 1 second If the delay is longer than 1 second, NIC or link failures are not recognized as quickly. receive timeout This command sets the receive timeout individually for each group and displays a message for each loaded frame type.
Maintaining Groups Syntax 111 lbrsl send timeout pri_slot seconds where: pri_slot is the PCI slot number of the primary NIC. seconds is the time in seconds. Example lbrsl send timeout 1001 10 Default 10 ungroup This command deletes a group. The LAN driver for the group must not be loaded. The following message appears for all frame types that the NIC supports: Cleaning up resources for group associated with Primary Slot #xxxx.
CHAPTER 5: INSTALLING NETWARE CLIENT AND SERVER DRIVERS Troubleshooting a Group Configuration Use the troubleshooting tips below to solve problems that may occur in a group configuration. To access a database of technical information that can help you diagnose and solve NIC installation, configuration, and upgrade problems, go to: http://knowledgebase.3com.
6 CONFIGURING THE NIC Overview This chapter describes how to configure the NIC. Before you change the NIC configuration settings, contact your system administrator. Default NIC Settings The table below lists the configuration settings for the NIC. The default setting is shown in uppercase in the Settings column. Option Description NetBoot ROM Provides the ability to boot a PC over the network. Enables or disables the Netboot ROM (if a boot ROM is installed on the NIC).
CHAPTER 6: CONFIGURING THE NIC Option Description (continued) Duplex Determines if the NIC transmits data across the network in both directions simultaneously (full-duplex) or in one direction at a time (half-duplex). ■ Auto Select allows the NIC to automatically connect at the duplex mode of the connected hub or switch. When you select this setting, the Media Type is automatically set to Auto Select. ■ Full-Duplex sets the NIC to operate in full-duplex mode.
Overview Option Description (continued) Media Type Determines the type of media your network is using. ■ Auto Select allows the NIC to automatically select the Media Type for you. ■ If you set the NIC Duplex setting to Auto Select, the Media Type is automatically set to Auto Select. ■ If you set the NIC Duplex setting manually, you must set the Media Type setting manually.
CHAPTER 6: CONFIGURING THE NIC Configuration Methods The NIC can be configured using any of the methods listed in the table below. This section describes how to configure the NIC using the 3Com NIC Diagnostics program for Windows. For instructions on using the other two methods, see the file or section mentioned in the table. Method Description 3Com NIC Diagnostics program for Windows Configure the NIC locally using Windows 2000 the 3Com NIC Diagnostics program Windows NT 4.
Changing General NIC Configuration Settings 117 Method Description Requirement(s) DMI 2.0 or 2.0s Configure the NIC remotely using the 3Com DMI Agent software. 3Com DMI Agent and a DMI-compatible browser or a network management application that supports DMI 2.0 or 2.0s See Installing the 3Com DMI Agent on page 159 for more information. Windows 2000 Advanced Tab Configure the NIC locally as Windows 2000 described in Changing Windows 2000 Property Settings on page 72.
CHAPTER 6: CONFIGURING THE NIC 3 Click 3Com NIC Doctor. The 3Com NIC Diagnostics General screen appears. Click Help to obtain general information about the function of a screen. To obtain specific information about any topic on a screen, click the question mark (?) in the upper right corner of the screen, move it over a topic, and click once. 4 If your PC has more than one NIC installed, open the Network Interface Card (NIC) list box and select the NIC to be configured. 5 Click the Configuration tab.
Changing General NIC Configuration Settings 119 To run the DOS diagnostic program: 1 Boot to DOS (see note following), and then insert the EtherCD in the CD-ROM drive. If you do not have a DOS-bootable diskette, see Making a DOS-Bootable Diskette on page 30 for instructions. 2 Enter the following at the DOS prompt: d:\3c99xcfg.exe where d:\ is the drive containing the EtherCD. If multiple NICs are installed in the PC, select Select NIC on the first screen to display a list of installed NICs.
CHAPTER 6: CONFIGURING THE NIC Configuring the Managed PC Boot Agent (MBA) This section explains how to configure the Managed PC Boot Agent (MBA) boot ROM to boot from the network. For detailed information on using, configuring, and troubleshooting the MBA boot ROM, see the Managed PC Boot Agent User Guide, located with the MBA software on the EtherCD. Enabling or Disabling the Boot ROM Setting The default NIC boot ROM setting is Disabled. This setting must be enabled to boot from the network.
Configuring the Managed PC Boot Agent (MBA) 121 Refer to your PC documentation if you do not know which type of PC you have. BBS BIOS-Compatible PCs To enable a BBS BIOS-compatible PC to boot from the network using the MBA boot ROM: 1 Make sure that the NIC boot ROM setting is Enabled. See the previous section, Enabling or Disabling the Boot ROM Setting, for instructions. 2 Set the MBA manually as the first boot device in the PC BIOS.
CHAPTER 6: CONFIGURING THE NIC Non-BBS BIOS-Compatible PCs To enable a non-BBS BIOS-compatible PC to boot from the network using the MBA boot ROM: 1 Make sure that the NIC boot ROM setting is Enabled. See Enabling or Disabling the Boot ROM Setting on page 120 for instructions. 2 Change the MBA default boot setting from Local to Network. To change the default boot setting or any other MBA configurations, use the MBACFG utility or press Ctrl+Alt+B when the following message appears: Initializing MBA.
CONFIGURING IP SECURITY 7 Overview The EtherLink PCI NIC accelerates IP security (IPSec) data encryption from supported operating systems that provide this offload capability. This feature is currently available in the Microsoft Windows 2000 operating system. Data encryption is available for Windows 95 and Windows 98 through DynamicAccess LAN Encryption software provided on the EtherCD. See Data Encryption on page 14 for more information.
CHAPTER 7: CONFIGURING IP SECURITY Encryption Type Encryption Level Custom varies Description (continued) This provides encryption and an extra authentication that includes the IP header. Custom allows you to select options for both AH and ESP, such as MD%/SHA-1 and DES/3DES. And you can select the rate at which new keys are negotiated. Microsoft uses IKE key exchange to renew keys every x seconds or y bytes. However, this practice is computationally very high in overhead.
Creating a Security Policy 125 4 Click Add. The Add Standalone Snap-in screen appears. 5 Select IP Security Policy Management, and then click Add. The Select which computer this Snap-in will manage screen appears. 6 Enable the Local computer option. 7 Click Finish, Close, and then OK. Creating the Policy This sequence creates and names the new security policy. The Console1and Console Root screen appears with IP Security Policies on Local Machine displayed in the list.
CHAPTER 7: CONFIGURING IP SECURITY 11 Enable the default option This rule does not specify a tunnel, and then click Next. The Network Type screen appears. 12 Enable the default option All network connections, and then click Next. The Authentication Methods screen appears. 13 Enable the Use this string to protect the key exchange (preshared key): option, type the appropriate string text in the entry field, and then click Next. Creating a Filter This sequence creates a filter for the policy.
Creating a Security Policy 127 Binding the Filter This sequence attaches the new filter to the policy. The IP Filter List screen appears. 1 Enable the option for the new filter name and make sure that the new filter name is selected. 2 Click Next. Creating the Filter Action This sequence defines how the filter acts on the policy. The Filter Action screen appears. 1 Click Add. The Filter Action Wizard starts. 2 Click Next. The Filter Action Name screen appears.
CHAPTER 7: CONFIGURING IP SECURITY The Filter Action screen appears. 1 Enable the filter action option and make sure that the filter name is selected. (In this example, we used the filter name: 3DES to the Server.) 2 Click Next, Finish, and then Close. The newly created policy appears in the right pane of the Console Root\IP Security Policies on Local Machine screen. 3 Exit this screen and, when prompted, save the new policy information. Use a meaningful name for future reference.
TROUBLESHOOTING THE NIC 8 Overview This chapter describes procedures for locating problems you might have with the EtherLink PCI NIC. It explains how to: ■ Interpret the NIC LEDs. ■ Access 3Com support databases. ■ Troubleshoot NIC installation problems. ■ Troubleshoot NIC and network connection problems. ■ Troubleshoot Remote Wake-Up. ■ Remove the network driver.
CHAPTER 8: TROUBLESHOOTING THE NIC LED State Meaning (continued) 100 LNK (link) On If drivers are installed, the 100BASE-TX connection is active. If drivers are not installed, the NIC is receiving power. Off Something is preventing the connection between the NIC and the hub or switch. Blinking The cable polarity is reversed. Try a different network cable or contact the system administrator. ACT Blinking Network traffic is present. (activity) Steady Heavy network traffic is present.
Accessing 3Com Support Databases 131 Accessing 3Com Support Databases In addition to the 3Com support databases listed in this section, check the README.TXT files in the ENGLISH, INSTALLS, and NWSERVER subdirectories and check the Help text files located in the HELP directory on the EtherCD. Accessing the 3Com Knowledgebase To access a database of technical information that can help you diagnose and solve NIC installation, configuration, and upgrade problems, go to: http://knowledgebase.3com.
CHAPTER 8: TROUBLESHOOTING THE NIC 5 Click the Support tab. The Support screen appears. 6 Click Support Databases to display customer support databases about the NIC in three categories: Release notes—Display tips about installing and using the NIC. Frequently asked questions—Display common questions asked by customers and answered by 3Com support experts. Knowledgebase topics—Display NIC compatibility topics.
Troubleshooting the Network Connection ■ 133 Installs the latest network driver. You can reinstall the 3Com NIC Diagnostics program after completing this procedure. See Installing the 3Com NIC Diagnostics Program on page 50 for instructions. 1 Insert the EtherCD in the CD-ROM drive. The EtherCD Welcome screen appears. 2 Click Drivers, and then click Utilities. 3 Click Clean Up Failed Installation. 4 Click Proceed. A warning message appears. 5 Click OK.
CHAPTER 8: TROUBLESHOOTING THE NIC Tip Description Check the NIC hardware installation ■ Make sure that the NIC is installed correctly in a PCI slot. Check for specific hardware problems, such as broken traces or loose or broken solder connections. See Installing and Connecting the NIC on page 34. Check the NIC software installation ■ Make sure that the NIC software is installed correctly in the computer. See Verifying Successful Installation on page 48.
Troubleshooting Remote Wake-Up 135 Troubleshooting Remote Wake-Up If your computer does not boot in response to a Remote Wake-Up event, perform these troubleshooting steps: 1 Make sure that the computer meets the Remote Wake-Up Requirements on page 21. Wake-On-Error is enabled by default. 2 Make sure that you are using the latest driver for the NIC. This driver is shipped with the NIC on the EtherCD. It can also be downloaded from the 3Com Software Library.
CHAPTER 8: TROUBLESHOOTING THE NIC 5 If the previous steps have failed, install a known functioning Remote Wake-Up NIC in the computer. If Remote Wake-Up works with the new NIC installed, contact your computer vendor for a replacement NIC. If Remote Wake-Up does not work with the new NIC installed, there may be a problem with the computer motherboard. Contact your computer manufacturer.
Troubleshooting a Network Connection 137 Troubleshooting Hubs A crossover cable can be used to identify the type of failure when hub performance or connectivity is in question. To use a crossover cable: 1 Connect a file server and a client PC back-to-back with a crossover cable to verify that the NIC and network operating system are properly configured. 2 To make a crossover cable, connect TD+ to RD+ and TD– to RD–. The cable performs the crossover that is usually performed by the hub.
CHAPTER 8: TROUBLESHOOTING THE NIC is mismatched (that is, TD+ to RD– instead of TD+ to RD+), the LED blinks. Removing the Network Driver To remove the network driver from your computer, follow the steps for your operating system. Windows 2000 The Windows 2000 system does not allow you to uninstall the network driver from the Network and Dial-up Connections window. To remove the network driver: 1 Right-click the My Computer icon. 2 Select Properties on the pop-up menu.
Removing the Network Driver 139 Windows NT 4.0 To remove the network driver: 1 Double-click the My Computer icon, then the Control Panel icon, and then the Network icon. The Network screen appears. 2 Click the Adapters tab. 3 Highlight the name of the NIC in the Network Adapters box, and then click Remove. 4 Click Yes to confirm the removal. 5 Click Close to close the Network screen. You are prompted to restart the computer. If you are physically removing the NIC from the computer, click No.
CHAPTER 8: TROUBLESHOOTING THE NIC If you are reinstalling the NIC software, click Yes to restart the computer. Removing DynamicAccess Server Features Follow the steps in this section to remove DynamicAccess technology server features for your operating system. Windows NT 4.0 To remove DynamicAccess technology server features: 1 From the Start menu, select Settings/Control Panel. 2 Double-click the Network icon. 3 In the Network window, click the Protocols tab.
Removing DynamicAccess Server Features 141 NetWare To remove DynamicAccess technology server features: 1 Enter this command at the prompt: NetWare 4.11: load install NetWare 5.0: load nwconfig 2 In the Installation Options screen, select Product options. 3 In the Other Installation Actions screen, select View/Configure/Remove installed products. The Currently Installed Products screen appears, listing software products that are installed in the system.
9 RUNNING NIC DIAGNOSTICS Overview The EtherLink PCI NIC uses two types of NIC diagnostics programs: a Windows-based diagnostics program and a DOS-based diagnostics program. Before starting any diagnostics program, close all running applications. Use the Windows-based 3Com NIC Diagnostics program if you are running any of the following operating systems: ■ Windows 2000 ■ Windows NT 4.
CHAPTER 9: RUNNING NIC DIAGNOSTICS Running the 3Com DOS Diagnostics Program To start the 3Com DOS diagnostics program for DOS and NetWare installations: 1 Reboot the computer using a DOS-bootable diskette. CAUTION: If you are running Japanese DOS, you must switch to U.S. mode DOS before running the 3Com DOS diagnostics program For more information about how to make a DOS-bootable diskette, see Making a DOS-Bootable Diskette on page 30. 2 Insert the EtherCD in the CD-ROM drive.
Running the NIC Diagnostics Tests 145 Click Help to obtain general information about the function of a screen. To obtain specific information about any topic on a screen, click the question mark (?) in the upper right corner of the screen, move it over a topic, and click once. The following tabs are available for viewing NIC data: Tab Description General Select the General tab to display the node address, I/O address, and device ID for the installed NIC.
CHAPTER 9: RUNNING NIC DIAGNOSTICS To run the Network test: 1 On the Diagnostics screen, click Run Network Test. The Network Connectivity Test screen appears. 2 Click Start. If the test passes, the NIC connection to the network is functioning correctly. 3 Click Close. If the test fails: ■ Make sure that the NIC is properly connected to the network cable. ■ Make sure that the hub or switch to which the NIC is connected is powered on.
Viewing Network Statistics 147 3 Select Programs, and then 3Com NIC Utilities. 4 Click 3Com NIC Doctor. The 3Com NIC Diagnostics General screen appears and displays following LEDs: Link—lights if there is a valid connection between the NIC and the network. Transmit—lights if the NIC is transmitting information. Receive—lights if the NIC is receiving information.
CHAPTER 9: RUNNING NIC DIAGNOSTICS Using the 3Com Icon in the Windows System Tray The 3Com icon, which can be enabled to appear in the Windows system tray, allows you to start the 3Com NIC Diagnostics program. It also allows you to view the NIC’s link speed and number of frames sent and received. Enabling the Icon To show the 3Com icon in the Windows system tray: 1 Make sure that the NIC, the network driver, and the 3Com NIC Diagnostics program are installed. 2 Open the Windows Start menu.
Removing the 3Com NIC Diagnostics Program 149 Removing the 3Com NIC Diagnostics Program The 3Com NIC Diagnostics Program can be removed using the Add/Remove Programs Wizard in Windows, or by using the EtherCD. For instructions on using the Add/Remove Programs Wizard in Windows, see your Windows documentation. To remove the 3Com NIC Diagnostics program using the EtherCD: 1 Start Windows. 2 Insert the EtherCD in the CD-ROM drive. The EtherCD Welcome screen appears. 3 Click NIC Software.
A OBTAINING DRIVERS For a list of additional network drivers that are not included on the EtherCD, and instructions on how to install them, go to the following 3Com World Wide Web site: http://support.3com.
SPECIFICATIONS AND CABLING REQUIREMENTS B This appendix lists the specifications, standards conformance, cable requirements, and connector pin assignments for the EtherLink 10/100 PCI NIC. 3CR990 NIC Specifications The following table provides environmental, interface, and standards information for the EtherLink 10/100 PCI NIC with 3XP processor (3CR990 family). Hardware Memory 128 KB external RAM Bus interface PCI Local Bus Specification, Revision 2.
APPENDIX B: SPECIFICATIONS AND CABLING REQUIREMENTS Standards Conformance IEEE 802.3x full-duplex, auto-negotiation, and flow control IEEE 802.1p (General Attribute Registration protocol) for multicast addresses Microsoft PC98 PCI 2.1 and 2.2 DMI 2.0 and 2.0s ACPI 1.
Cabling Requirements 155 The EIA/TIA defines five categories of unshielded twisted-pair cable. Category Use 1 Traditional telephone cable. 2 Data transmissions up to 4 MHz. 3 Voice and data transmission up to 25 MHz. The cable typically has four pairs of wires. Category 3 is the most common type of installed cable found in older corporate wiring schemes. 4 Voice and data transmission up to 33 MHz. The cable normally has four pairs of wire. This grade of UTP is not common.
APPENDIX B: SPECIFICATIONS AND CABLING REQUIREMENTS 100BASE-TX Operation 100BASE-TX is the IEEE 802.3u standard for Fast Ethernet signaling over Category 5 UTP or STP wire at 100 Mbps. Based on an extension to the IEEE 802.3 Ethernet specification, Fast Ethernet characteristics include: ■ A data rate of 100 Mbps. ■ A broadcast architecture. ■ A specific media-access control (MAC) scheme.
Flow Control 157 Flow Control The 3CR990 NICs utilize flow control technology to throttle the incoming data packet stream and prevent the loss of packets. IEEE 803.2x flow control prevents the input buffers of a device from overflowing. By using pause frames to communicate buffer status between linked transmitting and receiving devices (transmitters and receivers).
INSTALLING THE 3COM DMI AGENT C Overview This appendix explains how to install the 3Com Desktop Management Interface (DMI) Agent on your PC. The 3Com DMI Agent allows any DMI-compatible browser or network management application that supports DMI 2.0 to remotely manage and configure advanced features of an EtherLink PCI NIC. For detailed information on the 3Com DMI Agent, see the 3Com DMI Agent User Guide included with the 3Com DMI Agent software on the EtherCD.
APPENDIX C: INSTALLING THE 3COM DMI AGENT Each PC that contains an EtherLink NIC and the 3Com DMI Agent generates a Management Information Format (MIF) file that contains information about the PC and the NIC. DMI applications use the information from the MIF to manage the PC and the NIC. The content of the MIF is based on the capabilities of the NIC driver found in the PC.
Installing the 3Com DMI Agent 161 Network Management Requirements Your network management station requires a DMI-compatible browser or a network management application that supports DMI 2.0, such as: ■ ■ ■ ■ ■ Hewlett Packard TopTools Tivoli Management Suite Dell OpenManage Compaq Insight Manager Management Station Intel LANDesk Client Manager Installing the 3Com DMI Agent This section describes how to install the 3Com DMI Agent on a PC running Windows NT 4.0, Windows 98, or Windows 95.
APPENDIX C: INSTALLING THE 3COM DMI AGENT 8 Restart the PC when prompted. To verify successful installation, use a DMI-compatible browser or a network management application that supports DMI 2.0 or 2.0s to verify that the 3Com NIC is present. If you have 3Com DynamicAccess software and a foreign (non-3Com) NIC installed, the foreign NIC is displayed as a 3Com NIC in the DMI browser. See the 3Com DMI Agent User Guide or contact your system administrator for instructions.
ETHERCD CONTENT AND NAVIGATION D EtherCD Navigation This section provides information about EtherCD content and navigation. If auto insert is enabled for your CD-ROM drive, the 3Com Welcome screen is displayed when you insert the EtherCD in your CD-ROM drive.
APPENDIX D: ETHERCD CONTENT AND NAVIGATION Root Subdirectories The following table lists and describes the root subdirectories included on the EtherCD that shipped with this product. Subdirectory Description English Each language subdirectory contains files specific to that language. This subdirectory contains copies of Adobe Acrobat Reader (4.0 or 3.
EtherCD Navigation 165 File Name File Description client32.txt Contains NetWare 4.11 on Windows 95/98 client driver installation notes. license.txt Includes the 3CR990 NIC software license agreement. netware.txt Explains how to install the ODI driver for the NetWare 4.1x and 5.0 server. You can also get NetWare installation instructions from README text files located in the following directories: \nwserver\readme.txt (client) \nwserver\readme_se.txt (server) \english\diskcopy\disk2\nwserver\readme.
E INSTALLING A 3COM NIC WHILE INSTALLING THE NOS Follow these instructions to install 3Com software while you are installing the network operating system. (This procedure is often called “performing a fresh installation.”) Windows Fresh Installation For installation requirements, see Installation Requirements on page 28. To display the Help system during the driver installation, click Help on any 3Com window. Windows NT For instructions, see the WINNT.TXT file in the HELP directory on the EtherCD.
APPENDIX E: INSTALLING A 3COM NIC WHILE INSTALLING THE NOS Installation Instructions These instructions are for installing from the 3Com EtherLink Server NIC CD. If you download 3Com software from the Web and make installation diskettes to use for the installation, the steps are slightly different (you do not need to remove and replace the NetWare CD). 1 Install the NIC hardware and connect it to the network. 2 Start the installation and proceed as usual until you reach the Device Types screen.
NetWare Fresh Installation 169 15 From the Options menu, select Continue. The installation continues. In NetWare 5.0, the Configure Server Properties windows appear. Locate the Network Boards list in the Protocols window. The installed NICs are listed in this window. Select each installed NIC and configure its protocols. Proceed with the installation, and reboot when you are prompted to do so. 16 When the installation is finished, edit the STARTUP.NCF file. Specify receive buffers for each installed NIC.
TECHNICAL SUPPORT F 3Com provides easy access to technical support information through a variety of services. This appendix describes these services. Information contained in this appendix is correct at time of publication. For the most recent information, 3Com recommends that you access the 3Com Corporation World Wide Web site.
APPENDIX F: TECHNICAL SUPPORT 3Com Knowledgebase Web Services This interactive tool contains technical product information compiled by 3Com expert technical engineers around the globe. Located on the World Wide Web at http://knowledgebase.3com.com, this service gives all 3Com customers and partners complementary, round-the-clock access to technical information on most 3Com products. 3Com FTP Site Download drivers, patches, software, and MIBs across the Internet from the 3Com public FTP site.
Support from Your Network Supplier 173 Country (Region) Data Rate Telephone Number Hong Kong Up to 14,400 bps 852 2537 5601 Italy Up to 14,400 bps 39 2 27300680 Japan Up to 14,400 bps 81 3 5977 7977 Mexico Up to 28,800 bps 52 5 520 7835 P.R. of China Up to 14,400 bps 86 10 684 92351 Taiwan Up to 14,400 bps 886 2 377 5840 U.K. Up to 28,800 bps 44 1442 438278 U.S.A.
APPENDIX F: TECHNICAL SUPPORT If you are unable to contact your network supplier, see the following section on how to contact 3Com. Support from 3Com If you are unable to obtain assistance from the 3Com online technical resources or from your network supplier, 3Com offers technical telephone support services. To find out more about your support options, call the 3Com technical telephone support phone number at the location nearest you.
Returning Products for Repair Country (Region) 175 Telephone Number Europe, South Africa, and Middle East From the following countries, you may use the toll-free numbers: Austria Belgium Denmark Finland France Germany Hungary Ireland Israel Italy Netherlands Norway Poland Portugal South Africa Spain Sweden Switzerland U.K.
APPENDIX F: TECHNICAL SUPPORT To obtain an authorization number, call or fax: Country (Region) Telephone Number Fax Number Asia, Pacific Rim +65 543 6500 +65 543 6348 Europe, South Africa, +31 30 6029900 and Middle East +31 30 6029999 Latin America 1 408 326 3355 1 408 326 2927 From the following countries, you may call the toll-free numbers; select option 2 and then option 2: Austria Belgium Denmark Finland France Germany Hungary Ireland Israel Italy Netherlands Norway Poland Portugal Sout
INDEX Numbers A 10 LNK LED troubleshooting with 129 100 LNK LED troubleshooting with 130 100BASE-TX cable requirements 33 Link LED 130 operation 156 10BASE-T cable requirements 33 Link LED 129 operation 155 3C99X.
INDEX carrier sense lost, viewing 147 CD-ROM, auto play 164 changing configuration, DOS 118 checksum offload (TCP/IP), enabling for NetWare 103 cleaning up a failed installation 132 collisions, viewing 147 commands for Netware server features display status 108 group 108 help 109 link timeout 109 probe interval 109 receive timeout 110 retry count 110 send timeout 110 ungroup 111 wait tmo 111 compliance, Year 2000 2 computer requirements 28 configuration guidelines for VLANs 62 configuration parameters
INDEX Fast IP 25 features 25 Help, accessing 58 installing 56 overview 25 removing 58 traffic prioritization 17, 20, 25 verifying installation 57, 60 DynamicAccess LAN Encryption software installing 76 overview 14 DynamicAccess server features NetWare commands 108 configuration guidelines 104 overview 17 removing 140 Windows adding NICs to a group 66 changing the primary NIC 69 creating a group 65 creating a VLAN 67 deleting or editing a VLAN 70 removing a NIC from a group 69 window, defined 63 Windows 200
INDEX G GARP Multicast Registration Protocol specification (GMRP) 62 General tab 145 GMRP 62 group command 108 groups 17, 18 adding NICs to NetWare 105 Windows 66 adding, NetWare 106 configuring during NetWare driver installation 100 displaying properties of, Windows 70 removing NICs from, Windows 69 Windows creating 65 disabling load balancing for 69 H half-duplex configuring 114 viewing 130, 147 hardware, installation 34 help command, NetWare server features 109 Help system, accessing 40, 131 Host
INDEX link negotiation 157 speed, viewing 148 timeout command 109 Link LED, viewing 130, 147 Load Balance/RSL window 63 load balancing bidirectional 19, 60, 105 dedicated IP address 66, 67 failure 19 defined 18 disabling, Windows 69 groups adding NICs to, Windows 66 adding, NetWare 106 configuring during NetWare driver installation 100 creating, Windows 65 maintaining, NetWare 104 maintaining, Windows 60 removing NICs from, Windows 69 resilient server links (RSLs) 17 transmit 19, 60 troubleshooting NetWare
INDEX diagnostic tests 144 driver installation 89 duplex setting 114 foreign defined 21 designating as primary 61 in NetWare groups 104 in Windows groups 61 groups 17 primary 18, 61, 69 properties displaying, Windows 70 editing, Windows 70 secondary 18 software, removing 138 speed setting 115 test, running 146 virtual 18 NIC diagnostic program Configuration tab 145 Diagnostics tab 145 Flash Update tab 145 General tab 145 starting 51 Statistics tab 145 Support tab 145 Node Address 103 Novell NetWare se
INDEX server features NetWare 141 Windows 2000 140 Windows NT 140 requirements 3Com DMI Agent 160 cabling 154 computer 28 driver installation NetWare 91, 167 Windows 39, 167 DynamicAccess LAN agent 55 hardware and software 28, 38 memory 28 PC 28 Remote Wake-Up 21 resilient server links (RSLs) 17, 18 retry count command 110 returning products for repair 175 RJ-45 port, pin assignments 156 RMON (remote monitoring) 25 root subdirectories, EtherCD 163 RWU 21 S safety precautions 27 secondary NICs 18, 69 secur
INDEX transmit deferrals, viewing 147 load balancing 19, 60 underruns, viewing 147 Transmit LED, viewing 130, 147 troubleshooting cable 134 cleaning up a failed installation 132 error messages 132 group configuration 112 hubs 137 hubs with crossover cable 137 LEDs 130 load balancing NetWare 112 Windows 71 MBA boot ROM 120 network connection 133, 136 NIC installation 132 Remote Wake-Up 135 Windows 2000 property settings 72 twisted-pair cable, description 154 U ungroup command 111 uninstalling DynamicA
INDEX Windows 98 installing driver 43 multiple NICs 52 removing NIC software 139 upgrading from Windows 95 29 verifying installation 49 Windows NT installing DynamicAccess 58 Windows NT 4.
FCC CLASS B STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 This device may not cause harmful interference, and 2 This device must accept any interference received, including interference that may cause undesired operation. WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
INDUSTRY CANADA CLASS B EMISSION COMPLIANCE STATEMENT This Class B digital apparatus complies with Canadian ICES-003. AVIS DE CONFORMITÉ À LA RÉGLEMENTATION D’INDUSTRIE CANADA Cet appareil numérique de la classe B est conform à la norme NMB-003 du Canada. VCCI CLASS B STATEMENT This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI).
ASSIGNMENT; NO REVERSE ENGINEERING: You may transfer the Software, Documentation and the licenses granted herein to another party in the same country in which you obtained the Software and Documentation if the other party agrees in writing to accept and be bound by the terms and conditions of this Agreement. If you transfer all copies of the Software and Documentation to the party or you must destroy any copies not transferred.
3Com is a registered trademark of 3Com Corporation. 3Com Corporation 5400 Bayfront Plaza, P.O. Box 58145 Santa Clara, CA 95052-8145 (408) 326-5000 © Copyright 2000, 3Com Corporation. All rights reserved PRODUCT REGISTRATION To ensure the very best service and support, register your 3Com product now. International Customers: Visit http://www.3com.com/productreg to register. U.S. Customers: Complete and mail the registration card, or visit http://www.3com.com/productreg to register.
