Maintaining Groups 107
server links, use the LB option. To specify a resilient
server link group without load balancing, use the
RSL option.
For the LBRSL GROUP command syntax, see Server
Feature Commands on page 108.
3 Reboot the server.
The sample AUTOEXEC.NCF file in Figure 8 shows one
group of three NICs and one group of two NICs. The
primary NIC in slot 10001 is bound to two secondary NICs
in slot 10002 and slot 10003. The primary NIC in slot
10004 is bound to the secondary NIC in slot 10005.
Figure 8 AUTOEXEC.NCF File for Two Groups of NICs
load se
load lbrsl
;Define Group 1 primary NIC slot-frame instances
load 3c990 slot=10001 frame=ethernet_802.2 name=p1_802.2
load 3c990 slot=10001 frame=ethernet_ii name=p1_ii
;Define Group 1 secondary NIC slot-frame instances
load 3c990 slot=10002 frame=ethernet_802.2 name=p2_802.2
load 3c990 slot=10002 frame=ethernet_ii name=p2_ii
load 3c990 slot=10003 frame=ethernet_802.2 name=p3_802.2
load 3c990 slot=10003 frame=ethernet_ii name=p3_ii
;Define Group 2 primary NIC slot-frame instances
load 3c990 slot=10004 frame=ethernet_802.2 name=p4_802.2
load 3c990 slot=10004 frame=ethernet_ii name=p4_ii
;Define Group 2 secondary NIC slot-frame instances
load 3c990 slot=10005 frame=ethernet_802.2 name=p5_802.2
load 3c990 slot=10005 frame=ethernet_ii name=p5_ii
;Bind protocols to primary NICs
bind ipx to p1_802.2 net=FF02
bind ip to p1_ii address=192.1.1.1 mask=ff.ff.ff.00
bind ipx to p4_802.2 net=FF04
bind ip to p4_ii address=192.1.2.1 mask=ff.ff.ff.00
;Create Group 1 with NIC 10001 primary
;and NICs 10002 and 10003 secondary
lbrsl group lb 10001 10002 10003
;Create Group 2 with NIC 10004 primary
;and NIC 10005 secondary
lbrsl group lb 10004 10005
;To create resilient server link groups without load balancing
;use the rsl option:
;lbrsl group rsl 10001 10002 10003
;lbrsl group rsl 10004 10005
