Starting the 3Com NIC Diagnostics Program 51
8 Restart Windows.
The installation is complete.
Starting the 3Com NIC Diagnostics Program
To start the 3Com NIC Diagnostics program:
1 Open the Windows Start menu.
2 Select Programs, and then 3Com NIC Utilities.
3 Click 3Com NIC Doctor.
The 3Com NIC Diagnostic screen appears. For instructions
on using the program, see Running the NIC Diagnostics
Tests on page 144.
Alternatively, you can also start the 3Com NIC Diagnostics
program using the following procedure if the 3Com NIC
Diagnostics icon is displayed on right side of the Windows
task bar:
1 Double-click the 3Com NIC Diagnostics icon.
The 3Com NIC Diagnostic screen appears. For instructions
on using the program, see Running the NIC Diagnostics
Tests on page 144.
Updating the Network Driver and NIC Software
The latest 3Com network drivers can be downloaded from:
http://support.3com.com/infodeli/tools/nic/
To update the network driver and NIC diagnostic software:
1 Turn on the power to the PC and start Windows.
2 Insert the EtherCD (or disk 1 downloaded from the
Web or created from the EtherCD) in the appropriate
drive in the PC.
The EtherCD Welcome screen appears.
3 Click NIC Software.
4 Click NIC Drivers and Diagnostics.
5 Click Update NIC Driver.
