User manual
Table Of Contents
- Table of Contents
- About This Guide
- Introduction
- ISDN LAN Modem Functionality Description
- Hardware Description and Installation
- Setting Up TCP/IP for Windows and Macintosh
- Configuring the ISDN LAN Modem
- Advanced Configuration
- Before you Begin
- Setting Up Additional Service Providers
- Editing Service Provider Profiles
- Restricting Workstations from Accessing Service Provider(s)
- Configuring Your LAN Parameters
- Changing Data Call Parameters
- Changing Voice Call Routing
- Reserving DHCP Addresses
- Selective Password Protection
- Changing Your Password
- Setting Up Your ISDN Line Manually
- Locking and Unlocking the Configuration
- Configuring the ISDN LAN Modem from a Remote Location
- Supplementary Voice Call Services
- Placing, Receiving and Disconnecting Calls
- Troubleshooting and Maintenance
- Networking Primer
- What is a network?
- What is a LAN?
- What is a WAN?
- How does a LAN connect to a WAN?
- What is a LAN modem?
- What is ISDN?
- How do different devices communicate with each other?
- What is TCP/IP?
- What is an IP Address?
- What is a Subnet Mask?
- Dynamic and Static IP Addresses
- What is DHCP?
- What is DNS?
- What is NAT?
- What are numbered and unnumbered links?
- How is overall throughput determined?
- What is a network?
- Using the Custom Web Browser
- ISDN LAN Modem Factory Defaults
- ISDN LAN Modem Specifications
- Ordering ISDN Service
- If You Place Your ISDN Order Through 3Com
- If You Place Your ISDN Order Through the Telephone Company
- Supplementary Voice Features Included with U, EZ-ISDN-1, V and EZ-ISDN 1A
- Limitations of ISDN Ordering Codes U, EZ-ISDN 1, V and EZ-ISDN 1A
- What If I Already Have ISDN Service?
- Table of ISDN Ordering Code Capabilities
- Glossary
- Index
- 3Com Corporation Limited Warranty
3
H
ARDWARE
D
ESCRIPTION
AND
I
NSTALLATION
Package Contents
The ISDN LAN Modem package includes:
■ OfficeConnect ISDN LAN Modem
■ Power cable with an AC wall transformer
■ RJ -11 ISDN telephone cable
■ 10BASE-T Ethernet cable
■ 3Com Companion Programs CD-ROM
■ OfficeConnect ISDN LAN Modem Getting Started Guide
■ Rubber feet and stacking clips
Before You Install the
ISDN LAN Modem
To install, configure and use the ISDN LAN Modem successfully, you must have the
following:
■ Correct ISDN service installed at your location with an available ISDN RJ-11 or
RJ-45 outlet. If you have not yet ordered ISDN service, refer to Appendix E.
■ A JavaScript-enabled and frames-capable Web browser. A Web browser is
provided on the 3Com Companion Programs CD-ROM. (For more information
refer to Appendix B.) If you use a different Web browser, make sure that it
supports frames such as Netscape 2.1 and later and Internet Explorer 3.0 and
later.
If you already have a version of the Internet Explorer Web browser installed and
would like to install a later version, you should first uninstall the previous version. If
you are asked to replace the older files, it is recommended that you do so.
■ A personal computer with TCP/IP and Ethernet connectivity that meets UL
standards in the United States or is certified to CSA standards in Canada.
■
For a PC, a 386 or higher processor is recommended and a 10BASE-T
Ethernet card is required.
■
For an Apple Macintosh computer, system 7.6 or later operating system and
Open Transport (provided as part of system 7.5). Built-in Ethernet
connectivity is provided through an Apple Ethernet port in all Power
Macintosh computers.
■
TCP/IP is provided as part of the Windows 98, 95, NT and Macintosh System
7.6 and later operating systems. For Windows 3.11 users, TCP/IP software is
provided on the 3Com Companion Programs CD-ROM.
You do not have to have available storage space on your computer’s hard drive
because nothing is copied as part of the ISDN LAN Modem installation. If you want
to copy any programs or documents from the CD-ROMs, ensure that you have
available hard disk space.
