www.andmercury.com.au PW-200 Users Manual V1.
Table of Contents 1. General Description...................................................................................1 2. Preparation for Use....................................................................................1 3. Installing the batteries................................................................................2 4. Display & Symbols....................................................................................3 5. Weighing.....................................................
1. General Description The PW-200 is a purpose built digital platform scale specifically designed for patient comfort and ease of use in the healthcare environment. The weight is displayed on a battery powered digital indicator in clear numbers on a high contrast liquid crystal display. The platform features a non slip surface making the unit ideal for personal weighing. All surfaces are easy to clean and may be wiped with a damp cloth. 2. Preparation for use 2.1.
3. Installing the Batteries Step 1 Turn off the display. Step 2 Press and slide to open the external cover. Press the hook of the internal cover to the left side and lift the cover. Step 3 Insert six new dry cells ensuring correct polarity (+,-). Battery size is `D' Step 4 Close the covers opened in step 2. Cautions Replace used dry cells with six new ones, when is displayed. Do not mix used and new batteries. It may cause damage to the battery or product.
4. Display and Symbols Stability mark. When the current weight value is not changing, this mark is displayed. The reading may now be taken. Zero point mark. With nothing on the pan and pressing the switch, this mark is displayed. The zero point is the starting point to weighing. Net mark. After pressing the switch this mark is displayed to show net weight is displayed Preset tare mark. When storing a tare with digital input this mark blinks. When the battery power is low this mark is displayed.
5. Weighing To weigh a patient the following steps should be carried out: 1. Ensure that the scale is correctly positioned on a level surface, using the level vial as reference, with the levelling legs adjusted to ensure there is no tipping of the scale. 2. Ensure the scale is empty and switch on the scale. 3. Wait for the reading to show 0.00 kg 4. The person can now step onto the scale platform ensuring there feet are postioned in the area identified by the “blue feet” on the platform surface 6.
