SubCompact Board GENE-TC05 GENE-TC05 ® Intel Atom™ E680/ E620/ E620T (E620T for WiTAS2) Processor Intel® EG20T PCH 10/100/1000Base-TX 1 SATA 3.0Gb/s, CFast™ 6 COM, 4 USB2.0, CAN BUS Digital I/O, 2 Mini Card GENE-TC05 Manual Rev.A 5th Ed.
SubCompact Board GENE-TC05 Copyright Notice This document is copyrighted, 2014. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable.
SubCompact Board GENE-TC05 Acknowledgments All other products’ name or trademarks are properties of their respective owners. AMI is a trademark of American Megatrends Inc. CFast™ is a trademark of the CompactFlash Association (CFA). Intel , and Atom™ are trademarks of Intel Corporation. Microsoft Windows is a registered trademark of Microsoft Corp. ITE is a trademark of Integrated Technology Express, Inc.
SubCompact Board GENE-TC05 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: CD-ROM for manual (in PDF format) and drivers GENE-TC05 with Passive Heatsink If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
SubCompact Board GENE-TC05 Contents Chapter 1 General Information 1.1 Introduction ................................................................ 1-2 1.2 Features .................................................................... 1-3 1.3 Specifications ............................................................ 1-4 Chapter 2 Quick Installation Guide 2.1 Safety Precautions .................................................... 2-2 2.2 Location of Connectors & Jumpers ........................... 2-3 2.
SubCompact Board GENE-TC05 2.18 COM Port #2 (CN5) ................................................. 2-13 2.19 +5V Output For SATA HDD (CN6) .......................... 2-14 2.20 System Fan (CN7)................................................... 2-14 2.21 COM Port #3 (CN8) ................................................. 2-14 2.22 +5VSB Output w/SMBus (CN9) .............................. 2-15 2.23 LVDS Output (CN10)............................................... 2-15 2.24 COM Port #4 (CN11) ..............
SubCompact Board GENE-TC05 2.43 Mini Card Slot #1 (PCIE1) ....................................... 2-23 2.44 Mini Card Slot #2 (PCIE2) ....................................... 2-24 Chapter 3 AMI BIOS Setup 3.1 System Test and Initialization. .................................. 3-2 3.2 AMI BIOS Setup ........................................................ 3-3 Chapter 4 Driver Installation 4.1 Installation .................................................................
SubCompact Board GENE-TC05 Chapter 1 General Information Chapter 1 General Information 1- 1
SubCompact Board GENE-TC05 1.1 Introduction AAEON, a leading embedded boards manufacturer, is pleased to announce the debut of their new generation 3.5” SubCompact Board—GENE-TC05. The GENE-TC05 is a cutting-edge product that provides high performance and low power consumption in the embedded market. GENE-TC05 adopts the latest Intel® Atom™ E680/E620/E620T (E620T is for WiTAS2 operating temperature) processor and the system memory deploys with onboard DDR2 667/800 memory.
SubCompact Board GENE-TC05 1.2 Features Intel® Atom™ E680/E620/E620T Processor (E620T is for WiTAS2) Intel® EG20T PCH Onboard DDR2 667/800 Memory Gigabit Ethernet x 2 VGA or DVI(Optional) , 24-bit Single Channel LVDS LCD 2CH HD Audio SATA 3.0Gb/s x 1, CFast™ x 1 CAN Bus x 1, USB2.
SubCompact Board GENE-TC05 1.3 Specifications System Form Factor 3.5” Processor Intel® Atom™ E680 1.
SubCompact Board GENE-TC05 Storage Temperature -40°F ~ 176°F (-40°C ~ 80°C) Operating Humidity 0% ~ 90% relative humidity, non-condensing Display: Supports VGA or DVI (Optional) / LVDS LCD Chipset Intel® E680/E620/E620T integrated (E620T is for WiTAS2) Memory Shared system memory up to 512MB Resolution Up to 1280x1024 for VGA, DVI Up to 1280x768 for LCD LCD Interface Up to 24-bit single channel LVDS Storage SATA 3.
SubCompact Board GENE-TC05 Chapter 2 Quick Installation Guide Chapter 2 Quick Installation Guide 2-1
SubCompact Board GENE-TC05 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components. Always ground yourself to remove any static charge before touching the board. Modern electronic devices are very sensitive to static electric charges. Use a grounding wrist strap at all times.
SubCompact Board GENE-TC05 2.
SubCompact Board Solder Side Chapter 2 Quick Installation Guide 2-4 GENE-TC05
SubCompact Board GENE-TC05 2.
SubCompact Board Solder Side Chapter 2 Quick Installation Guide 2-6 GENE-TC05
SubCompact Board GENE-TC05 2.4 List of Jumpers The board has a number of jumpers that allow you to configure your system to suit your application. The table below shows the function of each of the board's jumpers: Label Function JP1 LVDS Operating Voltage Selection JP2 LVDS Inverter Voltage Selection JP3 COM2 RI/+5/+12V JP5 Touch Screen 4/5/8-wire Mode Selection JP6 Auto Power Button Selection JP7 RS-232/422/485 Selection-1 JP8 RS-232/422/485 Selection-2 2.
SubCompact Board GENE-TC05 CN11 COM Port #4 CN12 COM Port #5 CN13 COM Port #6 CN14 USB Port #4 CN15 PS/2 Keyboard & Mouse CN16 Touch Screen I/F CN17 USB Port #3 CN18 Power Input (Vin) CN19 RJ-45 Ethernet #1 CN20 RJ-45 Ethernet #2 CN21 SATA CN22 I2C CN23 CAN Bus CN24 USB Port #1 and #2 CN25 Audio Line In/Out and MIC Connector CN26 CRT/DVI Display CN27 COM Port #1 CN28 SIM Card Socket CFD1 CFast™ Disk PCIE1 Mini Card Slot #1 PCIE2 Mini Card Slot #2 Note: ® (1) Becau
SubCompact Board GENE-TC05 to the CPU board to keep the fully energy of the battery, users have to assemble it yourselves on the “BAT1” connector. (3)If the CR-2450 battery is in low energy, the RTC (Real Time Clock) will lose in this condition and users have to change another CR-2450 battery. 2.6 Setting Jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch.
SubCompact Board GENE-TC05 2.7 LVDS Operating Voltage Selection (JP1) JP1 Function 1-2 +5V 2-3 +3.3V (Default) 2.8 LVDS Inverter Voltage Selection (JP2) JP2 Function 1-2 +12V 2-3 +5V (Default) 2.9 COM2 RI/5V/+12V Selection (JP3) JP3 Function 1-2 +12V 3-4 +5V 5-6 RI (Default) 2.10 Touch Screen 4/5/8-wire Mode Selection (JP5) JP5 Function 1-2 4/8-wire (Default) Open 5-wire 2.
SubCompact Board GENE-TC05 2.12 RS-232/422/485 Selection (JP7) JP7 Function 1-2 RS-232 (Default) 3-4 RS-422 5-6 RS-485 2.13 RS-232/422/485 Selection (JP8) JP8 Function 1-3, 2-4, 7-9, 8-10 RS-232 (Default) 3-5, 4-6, 9-11, 10-12 RS-422 3-5, 9-11 RS-485 2.14 LVDS Inverter Connector (CN1) Note: The max. rating of pin 1 is 1A Pin Signal 1 +5 Volt. / +12 Volt. 2 N/C 3 Ground 4 Ground 5 Backlight Enable (Controlled by CH7308C) 2.
SubCompact Board 5 +3.3V 6 LFRAME# 7 LRESET# 8 Ground 9 LPC_CLK 10 LDRQ#0 11 LDRQ#1 12 SERIRQ GENE-TC05 2.16 Front Panel (CN3) Pin Signal (-) 1-2 (+) ATX Power-on Button (-) 3-4 (+) HDD Active LED (-) 5-6 (+) External Speaker (-) 7-8 (+) Power LED (-) 9-10 (+) System Reset Button 2.17 Digital I/O Connector (CN4) This connector offers 4-pair of digital I/O functions and address is 6Eh.
SubCompact Board Port 8 @6Eh Port 7 @6Eh Port 6 @6Eh Port 5 @6Eh Port 4 @6Eh Port 3 @6Eh Port 2 @6Eh Port 1 @6Eh GENE-TC05 Output Input Pin 8 21h/Bit7 22h/Bit7 U8 Pin 20 (GPIO 27) Pin 7 21h/Bit6 22h/Bit6 U8 Pin 21 (GPIO 26) Pin 6 21h/Bit5 22h/Bit5 U8 Pin 22 (GPIO 25) Pin 5 21h/Bit4 22h/Bit4 U8 Pin 23 (GPIO 24) Pin 4 21h/Bit3 22h/Bit3 U8 Pin 24 (GPIO 23) Pin 3 21h/Bit2 22h/Bit2 U8 Pin 8 (GPIO 22) Pin 2 21h/Bit1 22h/Bit1 U8 Pin 7 (GPIO 21) Pin 1 21h/Bit0 22h/Bit0 U8 Pin 6 (
SubCompact Board 9 RS-485 Pin GENE-TC05 Ground Signal Pin Signal 1 TXD- 2 N/C 3 N/C 4 N/C 5 TXD+ 6 N/C 7 N/C 8 N/C / +5V / +12V 9 Ground 2.19 +5V Output For SATA HDD (CN6) Note: The max. output of CN6 is 1A @ 5V Pin Signal 1 +5V 2 Ground 2.20 System Fan (CN7) Pin Signal 1 Ground 2 +5 Volt. (Optional) / +12V 3 FAN Sense 2.
SubCompact Board GENE-TC05 2.22 +5VSB Output w/SMBus (CN9) Pin Signal 1 SMBDATA 2 Ground 3 SMBCLK 4 Ground 5 PSON# 6 +5V Standby 2.23 LVDS Output (CN10) Note: The total max. rating of pin 3, 7, 27 is 3A Pin Signal Pin Signal 1 Back-Light Enable 2 Back-Light Control 3 LCD Volt. 4 Ground 5 LA_CLK# 6 LA_CLK 7 LCD Volt.
SubCompact Board GENE-TC05 2.24 COM Port #4 (CN11) Pin Signal Pin Signal 1 DCDD 2 DSRD 3 RXD 4 RTSD 5 TXD 6 CTSD 7 DTRD 8 RID 9 Ground 2.25 COM Port #5 (CN12) Pin Signal Pin Signal 1 DCDE 2 DSRE 3 RXE 4 RTSE 5 TXE 6 CTSE 7 DTRE 8 RIE 9 Ground 2.26 COM Port #6 (CN13) Pin Signal Pin Signal 1 DCDF 2 DSRF 3 RXF 4 RTSF 5 TXF 6 CTSF 7 DTRF 8 RIF 9 Ground 2.
SubCompact Board 3 Data4+ 4 Ground 5 Ground GENE-TC05 2.28 PS/2 Keyboard and Mouse (CN15) Pin Signal Pin Signal 1 Keyboard Data 2 Keyboard Clock 3 Ground 4 +5V 5 Mouse Data 6 Mouse Clock 2.
SubCompact Board 5 GENE-TC05 Ground 2.31 Power Input (Vin) (CN18) Pin Signal 1 +12V 2 Ground 2.32 RJ-45 Ethernet #1 (CN19) Pin Signal Pin Signal R1 GPHY_MDIO0+ R2 GPHY_MDIO0- R3 GPHY_MDIO1+ R4 GPHY_MDIO1- R5 TCD0 R6 TCD1 R7 GPHY_MDIO2+ R8 GPHY_MDIO2- R9 GPHY_MDIO3+ R10 GPHY_MDIO3- L1 SPD100_LED L2 SPD1K_LED L3 ACT_LED L4 +3.3V 2.
SubCompact Board GENE-TC05 2.34 SATA Connector (CN21) Pin Signal 1 Ground 2 TX+ 3 TX- 4 Ground 5 RX- 6 RX+ 7 Ground 2.35 I2C (CN22) Pin Signal 1 +3.3V 2 SCL 3 SDA 4 Ground 2.36 CAN Bus (CN23) Pin Signal 1 CANH 2 Ground 3 CANL 4 N/C 2.
SubCompact Board GENE-TC05 2 Data1- 6 Data2- 3 Data1+ 7 Data2+ 4 Ground 8 Ground 2.38 Audio Line In/Out and MIC Connector (CN25) Pin Signal 1 MIC_L 2 MIC_R 3 Ground 4 Line IN_L 5 Line IN_R 6 Ground 7 Line OUT_L 8 Ground 9 Line OUT_R 10 +5V 2.
SubCompact Board GENE-TC05 13 N/C 14 +5V 15 Ground 16 DVI_DET 17 DVI_TDC0# 18 DVI_TDC0 19 Ground 20 N/C 21 N/C 22 Ground 23 DVI_TLC 24 DVI_TLC# 25 Ground 26 Ground 27 N/C 28 N/C Signal Pin Signal 29 DDCCLK 30 N/C 31 +5V 32 HSYNC 33 GREEN 34 Ground 35 N/C 36 Ground 37 Ground 38 VSYNC 39 BLUE 40 Ground 41 DDCDATA 42 RED 43 CRT_PLUG# CRT Pin 2.
SubCompact Board GENE-TC05 2.41 SIM Card Socket (CN28) Pin Signal Pin Signal 1 UIM_PWR 2 UIM_RST 3 UIM_CLK 4 Ground 5 UIM_VPP 6 UIM_DATA 2.
SubCompact Board P13 +3.3V P14 +3.3V P15 Ground P16 Ground P17 N/C GENE-TC05 2.43 Mini Card Slot #1 (PCIE1) Pin Signal Pin Signal 1 PCIE_WAKE# 2 +3.3V Standby 3 N/C 4 Ground 5 N/C 6 +1.5V 7 N/C 8 UIM_PWR 9 Ground 10 UIM_DATA 11 MCARD_CLK1# 12 UIM_CLK 13 MCARD_CLK1 14 UIM_RESET 15 Ground 16 UIM_VPP 17 N/C 18 Ground 19 N/C 20 W_DISABLE#1 21 Ground 22 PCIE_RST# 23 PCIE_RXN1 24 +3.3V Standby 25 PCIE_RXP1 26 Ground 27 Ground 28 +1.
SubCompact Board GENE-TC05 41 +3.3V Standby 42 N/C 43 Ground 44 N/C 45 N/C 46 N/C 47 N/C 48 +1.5V 49 N/C 50 Ground 51 N/C 52 +3.3V Standby 2.44 Mini Card Slot #2 (PCIE2) Pin Signal Pin Signal 1 PCIE_WAKE# 2 +3.3V Standby 3 N/C 4 Ground 5 N/C 6 +1.5V 7 N/C 8 N/C 9 Ground 10 N/C 11 MCARD_CLK2# 12 N/C 13 MCARD_CLK2 14 N/C 15 Ground 16 N/C 17 N/C 18 Ground 19 N/C 20 W_DISABLE#2 21 Ground 22 PCIE_RST# 23 PCIE_RXN2 24 +3.
SubCompact Board GENE-TC05 39 +3.3V Standby 40 Ground 41 +3.3V Standby 42 N/C 43 Ground 44 N/C 45 N/C 46 N/C 47 N/C 48 +1.5V 49 N/C 50 Ground 51 N/C 52 +3.
SubCompact Board GENE-TC05 Below Table for China RoHS Requirements 產品中有毒有害物質或元素名稱及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物質或元素 部件名稱 印刷電路板 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) × ○ ○ ○ ○ ○ × ○ ○ ○ ○ ○ 及其電子元件 外部信號 連接器及線材 O：表示該有毒有害物質在該部件所有均質材料中的含量均在 SJ/T 11363-2006 標準規定的限量要求以下。 X：表示該有毒有害物質至少在該部件的某一均質材料中的含量超出 SJ/T 11363-2006 標準規定的限量要求。 備註：此產品所標示之環保使用期限，系指在一般正常使用狀況下。 Chapter 2 Quick Installation Guide 2-26
SubCompact Board GENE-TC05 Chapter 3 AMI BIOS Setup Chapter 3 AMI BIOS Setup 3-1
SubCompact Board 3.1 GENE-TC05 System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal. The system can usually continue the boot up sequence with non-fatal errors. The GENE-TC05 CMOS memory has an integral lithium battery backup for system time retention.
SubCompact Board 3.2 GENE-TC05 AMI BIOS Setup AMI BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in NVRAM so that it retains the Setup information when the power is turned off. Entering Setup Power on the computer and press or immediately. This will allow you to enter Setup. Main Set the date, use tab to switch between date elements. Advanced Enable disable boot option for legacy network devices.
SubCompact Board Setup Menu Press ‘Delete’ Key to enter Setup menu Main Chapter 3 AMI BIOS Setup 3-4 GENE-TC05
SubCompact Board GENE-TC05 Advanced Chapter 3 AMI BIOS Setup 3-5
SubCompact Board GENE-TC05 ACPI Settings Options summary: Disable Enable Hibernation Enable Optimal Default, Failsafe Default Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS.
SubCompact Board GENE-TC05 Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.
SubCompact Board GENE-TC05 Enabled Optimal Default, Failsafe Default Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology) Disabled Execute Disable Bit Enabled Optimal Default, Failsafe Default XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.
SubCompact Board Enhanced C1 GENE-TC05 Disabled Optimal Default, Failsafe Default Enabled Enable or Disable Enhanced C1 State Enhanced C2 Disable Enable Optimal Default, Failsafe Default Enable or Disable Enhanced C2 State Enhanced C3 Disable Optimal Default, Failsafe Default Enable Enable or Disable Enhanced C3 State Enhanced C4 Disable Enable Optimal Default, Failsafe Default Enable or Disable Enhanced C4 State Chapter 3 AMI BIOS Setup 3-9
SubCompact Board GENE-TC05 Digital IO Options summary: Input GPI0-3 Device Optimal Default, Failsafe Default Output Set GPI0 as Input or Output Input GPO0-3 Device Output Optimal Default, Failsafe Default Set GPO0-3 as Input or Output Chapter 3 AMI BIOS Setup 3-10
SubCompact Board GENE-TC05 AHCI SATA Configuration Options summary: PORT 0 Disabled Enable Optimal Default, Failsafe Default Enable/Disable PORT 0 Set transfer mode programming PORT 1 Disabled Enable Optimal Default, Failsafe Default Enable/Disable PORT 1 Set transfer mode programming Chapter 3 AMI BIOS Setup 3-11
SubCompact Board GENE-TC05 Wake On Lan Configuration Options summary: Disabled Wake On Lan Enable Optimal Default, Failsafe Default Enable/Disable WOL Chapter 3 AMI BIOS Setup 3-12
SubCompact Board GENE-TC05 USB Configuration Options summary: Legacy USB Support Enabled Optimal Default, Failsafe Default Disabled Auto Enables BIOS Support for Legacy USB Support. When enabled, USB can be functional in legacy environment like DOS.
SubCompact Board GENE-TC05 10 sec 20 sec Optimal Default, Failsafe Default The time-out value for Control, Bulk, and Interrupt transfers 1 sec Device reset time-out 5 sec 10 sec 20 sec Optimal Default, Failsafe Default USB mass storage device Start Unit command time-out Device Name (Emulation Auto Optimal Default, Failsafe Default Type) Floppy Forced FDD Hard Disk CDROM If Auto. USB devices less than 530MB will be emulated as Floppy and remaining as Floppy and remaining as hard drive.
SubCompact Board GENE-TC05 Second Super IO Configuration Chapter 3 AMI BIOS Setup 3-15
SubCompact Board Serial Port 3 Configuration Chapter 3 AMI BIOS Setup 3-16 GENE-TC05
SubCompact Board GENE-TC05 Serial Port 4 Configuration Chapter 3 AMI BIOS Setup 3-17
SubCompact Board Serial Port 5 Configuration Chapter 3 AMI BIOS Setup 3-18 GENE-TC05
SubCompact Board GENE-TC05 Serial Port 6 Configuration Options summary: Serial Port Disabled Enabled Optimal Default, Failsafe Default Enable or Disable Serial Port (COM) Change Settings IO=3E8h; IRQ=10; Optimal Default, Failsafe Default (Serial Port 3) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Chapter 3 AMI BIOS Setup 3-19
SubCompact Board GENE-TC05 IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings IO=2E8h; IRQ=11; Optimal Default, Failsafe Default (Serial Port 4) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings IO=2F0h; IRQ=7; Optimal Default, Failsafe Default (Serial Port 5) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,1
SubCompact Board GENE-TC05 IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings IO=2E0h; IRQ=5; Optimal Default, Failsafe Default (Serial Port 6) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Select an optimal setting for Super IO device Chapter 3 AMI BIOS Setup 3-21
SubCompact Board Super IO Configuration Chapter 3 AMI BIOS Setup 3-22 GENE-TC05
SubCompact Board GENE-TC05 Serial Port 1 Configuration Chapter 3 AMI BIOS Setup 3-23
SubCompact Board GENE-TC05 Serial Port 2 Configuration Options summary: Serial Port Disabled Enabled Optimal Default, Failsafe Default Enable or Disable Serial Port (COM) Change Settings IO=3F8h; IRQ=4; (Serial Port 1) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Chapter 3 AMI BIOS Setup 3-24
SubCompact Board GENE-TC05 IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings IO=2F8h; IRQ=3; (Serial Port 2) IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Select an optimal setting for Super IO device Serial Port 2 Device RS232 Optimal Default, Type Failsafe Default RS422 RS485 Select RS232, RS422 or RS485 Chapter 3 AMI BIOS Setup 3-
SubCompact Board H/W Monitor Chapter 3 AMI BIOS Setup 3-26 GENE-TC05
SubCompact Board GENE-TC05 Chipset Chapter 3 AMI BIOS Setup 3-27
SubCompact Board GENE-TC05 North Bridge Chipset Configuration Options summary: IGD Mode Select Enabled, 1MB Enabled, 4MB Enabled, 8MB Optimal Default, Failsafe Default Enabled, 16MB Enabled, 32MB Enabled, 48MB Enabled, 64MB Chapter 3 AMI BIOS Setup 3-28
SubCompact Board GENE-TC05 Select the amount of system memory used by the Integrated Graphics Device. MSAC Mode Select Enabled, 512MB Enabled, 256MB Optimal Default, Failsafe Default Enabled, 128MB Select the size of the graphics memory aperture and untrusted space.
SubCompact Board GENE-TC05 Boot Display Configuration Options summary: Primary Display Auto Optimal Default, Failsafe Default IGD PEG Select which graphics controller to use as the primary boot display Boot Display Device Integrated LVDS External DVI External CRT Optimal Default, Failsafe Default Chapter 3 AMI BIOS Setup 3-30
SubCompact Board GENE-TC05 Select Boot Display Device Flat Panel Scaling Auto Optimal Default, Failsafe Default Forced Disabled Select Flat Panel Scaling Flat Panel Type 640x480 18Bit 640x480 24Bit 800x600 18Bit 800x600 24Bit 1024x768 18Bit Optimal Default, Failsafe Default 1024x768 24Bit 1280x768 18Bit 1280x768 24Bit Select Flat Panel Type DPST Control VBIOS-Default DPST Disabled DPST Enabled L1 DPST Enabled L2 DPST Enabled L3 Optimal Default, Failsafe Default DPST Enabled L4 DPST Enabled L5 Cha
SubCompact Board GENE-TC05 Select DPST Control South Bridge Chipset Configuration Options summary: Primary Display Auto Optimal Default, Failsafe Default IGD PEG Select which graphics controller to use as the primary boot display Chapter 3 AMI BIOS Setup 3-32
SubCompact Board GENE-TC05 PCI Express Ports Configuration Chapter 3 AMI BIOS Setup 3-33
SubCompact Board PCI Express Root Port 0 Chapter 3 AMI BIOS Setup 3-34 GENE-TC05
SubCompact Board GENE-TC05 PCI Express Root Port 1 Chapter 3 AMI BIOS Setup 3-35
SubCompact Board PCI Express Root Port 2 Chapter 3 AMI BIOS Setup 3-36 GENE-TC05
SubCompact Board GENE-TC05 PCI Express Root Port 3 Chapter 3 AMI BIOS Setup 3-37
SubCompact Board GENE-TC05 PCI-to-PCI Bridge Options summary: PCI Express Root Port 0 Disabled Enabled Optimal Default, Failsafe Default PCI Express Root Port 0 Settings PCI Express Root Port 1 Disabled Enabled Optimal Default, Failsafe Default PCI Express Root Port 1 Settings PCI Express Root Port 2 Disabled Chapter 3 AMI BIOS Setup 3-38
SubCompact Board Enabled GENE-TC05 Optimal Default, Failsafe Default PCI Express Root Port 2 Settings PCI Express Root Port 3 Disabled Enabled Optimal Default, Failsafe Default PCI Express Root Port 3 Settings Extra Bus Reserved 0 Optimal Default, Failsafe Default Extra Bus Reserved (0-7) for bridges behind this Root Bridge Chapter 3 AMI BIOS Setup 3-39
SubCompact Board GENE-TC05 PPM Config Options summary: C-state POPUP Disabled Enabled Optimal Default, Failsafe Default Enable/Disable C-state POPUP Chapter 3 AMI BIOS Setup 3-40
SubCompact Board GENE-TC05 Boot Options summary: Quiet Boot Disabled Enabled Optimal Default, Failsafe Default Enables or disables Quiet Boot option Fast Boot Disabled Enabled Optimal Default, Failsafe Default Enables/Disables boot with initialization of a minimal set of devices required to launch active boot option.
SubCompact Board GENE-TC05 Integer Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. On Bootup NumLock State Off Optimal Default, Failsafe Default Select the keyboard NumLock state Upon Request GateA20 Active Default Always UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling GA20; this option is useful when any RT code is executed above 1MB.
SubCompact Board GENE-TC05 Security Change User/Supervisor Password You can install a Supervisor password, and if you install a supervisor password, you can then install a user password. A user password does not provide access to many of the features in the Setup utility. If you highlight these items and press Enter, a dialog box appears which lets you enter a password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password.
SubCompact Board Chapter 3 AMI BIOS Setup 3-44 GENE-TC05
SubCompact Board GENE-TC05 Save & Exit Chapter 3 AMI BIOS Setup 3-45
SubCompact Board GENE-TC05 Chapter 4 Driver Installation Chapter 4 Driver Installation 4 -1
SubCompact Board GENE-TC05 . The GENE-TC05 comes with a CD-ROM that contains all drivers your need. Follow the sequence below to install the drivers: Step 1 – Install Chipset Driver Step 2 – Install VGA Driver Step 3 – Install PCH EG20T Driver Step 4 – Install LAN Driver Step 5 – Install Audio Driver Step 6 – Install Touch Driver Please read following instructions for detailed installations.
SubCompact Board GENE-TC05 4.1 Installation: Insert the GENE-TC05 DVD-ROM into the CD-ROM Drive. And install the drivers from Step 1 to Step 6 in order. Step 1 – Install Chipset Driver 1. Click on the Step 1 - Chipset INF folder and double click on the Setup.exe file 2. Follow the instructions that the window shows 3. The system will help you to install the driver automatically Step 2 – Install VGA Driver For the VGA drivers, there are three types.
SubCompact Board GENE-TC05 Step 4 – Install LAN Driver 1. Click on the Step 4 - Intel 82574L Ethernet folder and select the OS your system is 2. Double click on .exe file located in each OS folder 3. Follow the instructions that the window shows 4. The system will help you to install the driver automatically Step 5 – Install Audio Driver 1. Click on the Step 5 - Realtek ALC888 Audio Codec folder and select the OS your system is 2. Double click on .exe file located in each OS folder 3.
SubCompact Board GENE-TC05 Appendix A Programming the Watchdog Timer Appendix A Programming the Watchdog Timer A-1
SubCompact Board GENE-TC05 A.1 Programming GENE-TC05 utilizes W83627DHG-P chipset as its watchdog timer controller. Below are the procedures to complete its configuration and the AAEON intial watchdog timer program is also attached based on which you can develop customized program to fit your application.
SubCompact Board GENE-TC05 (3) Exit the W83627DHG config Mode. Undesired result may occur if the config Mode is not exited normally. (1) Enter the W83627DHG config Mode To enter the W83627DHG config Mode, two special I/O write operations are to be performed during Wait for Key state. To ensure the initial state of the key-check logic, it is necessary to perform two write operations to the Special Address port (2EH).
SubCompact Board = 010 GENE-TC05 Power LED pin is driven low. = 011 Power LED pin outputs 2Hz pulse with 50% duty cycle. = 100 Power LED pin outputs 1Hz pulse with 50% duty cycle. = 101 Power LED pin outputs 4Hz pulse with 50% duty cycle. = 110 Power LED pin outputs 0.25Hz pulse with 50% duty cycle. =111 Power LED pin outputs 0.25Hz pulse with 50% duty cycle.. Bit 4 Bit 3 Bit 2 : WDTO# count mode is 1000 times faster. =0 Disable. =1 Enable. : select WDTO# count mode.
SubCompact Board GENE-TC05 WatchDog Timer Register II (Index=F6h, Default=00h) Bit 7-0 = 0 x 00 Time-out Disable = 0 x 01 Time-out occurs after 1 second/minute = 0 x 02 Time-out occurs after 2 second/minutes = 0 x 03 Time-out occurs after 3 second/minutes ………………………………..
SubCompact Board =1 GENE-TC05 Force Watchdog Timer time-out event: this bit is self-clearing Bit 4 Bit 3-0 : Watchdog Timer Status. R/W =1 Watchdog Timer time-out occurred =0 Watchdog Timer counting : These bits select IRQ resource for Watchdog. Setting of 2 selects SMI.
SubCompact Board GENE-TC05 A.2 W83627DHG Watchdog Timer Initial Program Example: Setting 10 sec.
SubCompact Board GENE-TC05 ;/////////////////////////////////////////////////////////////////////////////////////////////// Dec dx Mov al,0f5h ;CRF5 (PLED mode register) Out dx,al Inc dx In al,dx And al,not 08h ;Set second as counting unit Out dx,al ;/////////////////////////////////////////////////////////////////////////////////////////////// Dec dx Mov al,0f6h ; CRF6 Out dx,al Inc dx Mov al,10 ;Set timeout interval as 10 sec.
SubCompact Board GENE-TC05 Appendix B I/O Information Appendix B I/O Information B - 1
SubCompact Board B.
SubCompact Board GENE-TC05 Appendix B I/O Information B - 3
SubCompact Board B.
SubCompact Board GENE-TC05 B.
SubCompact Board B.
SubCompact Board GENE-TC05 Appendix C Mating Connecotor Appendix C Mating Connector C - 1
SubCompact Board GENE-TC05 C.1 List of Mating Connectors and Cables The table notes mating connectors and available cables. Connector Label CN1 CN4 Mating Connector Function LVDS Inverter Connector Digital I/O Connector Vendor Model no.
SubCompact Board GENE-TC05 CN15 Keyboard / Mouse Connector Catch A003-290 CN17 USB Port Connector Molex 51021-0500 N/A N/A Neltron 7001-8P8C N/A N/A Neltron 7001-8P8C N/A N/A Molex 67582-0000 SATA Cable 1709070500 N/A N/A Audio Cable 1709100254 LIAN TAY H820-2X10 DVI Cable 1700250450 Molex 51021-0200 Battery Cable 175011901R CN18 CN19 CN20 CN21 CN25 CN26 BAT1 +12V Vin Connector RJ-45 Ethernet#1 Connector RJ-45 Ethernet#1 Connector SATA Connector Audio In/Out/CD-in and
SubCompact Board GENE-TC05 Appendix D AHCI Setting Appendix D AHCI Setting D-1
SubCompact Board GENE-TC05 D.1 WIN XP OS installation Note: BIOS Setting Requirement : “BIOS SettingAdvanced Launch Storage OpROM : Enable to enable HDD” Step 1: Copy the files below from “Driver CD” ->”STEP 3 PCH EG20T \EG20T_WinXP_WePOS_Package_220\FD_Inst_WinXP To Disk. Step 2: Connect the USB floppy (disk with AHCI files) to the board.
SubCompact Board GENE-TC05 Step 3: Setup OS Step 4: Press “F6” Appendix D AHCI Setting D-3
SubCompact Board GENE-TC05 Step 5: Choose “S” Step 6: Choose “Intel(R) PCH EG20T SATA AHCI Controller For Windows XP” Appendix D AHCI Setting D-4
SubCompact Board GENE-TC05 Step 7: It will show the model number you select and then press “ENTER” Step 8: Setup is starting Windows Appendix D AHCI Setting D-5
