SubCompact Board GENE-TC05
1.3 Specifications
System
 Form Factor 3.5”
 Processor Intel
®
Atom™ E680 1.6GHz/ E620
600MHz/ E620T 600MHz (E620T is
for WiTAS2)
 System Memory Onboard DDR2 667/800 Memory
 Chipset Intel
®
EG20T PCH
 I/O Chipset Nuvoton W82627DHG-P, Fintek
F81216DG
 Ethernet Realtek RTL8211CL & Intel
®
82574L,
10/100/1000Base-TX, RJ-45 x 2
 BIOS AMI BIOS - 4MB SPI Flash
 Wake On LAN Yes
 Watchdog Timer Generate a time-out system reset
 H/W Monitor
Chipset
Supports power supply voltages and
temperature monitoring
 Expansion Interface Mini Card x 2 (one include SIM slot
and USB interface), LPC
 Battery Lithium battery
 Power Requirement +12V
 Board Size 5.75" x 4" (146mm x 101.6mm)
 Gross Weight 0.4kg
 Operating
Temperature
32°F ~ 140°F (0°C ~ 60°C)
WiTAS2: -40°F ~ 185°F (-40°C ~
85°C) (TF-GENE-TC05W2-A10-01)
