Manual

SubCompact Board
G E N E - T C 0 5
Chapter 2 Quick Installation Guide 2-19
2.34 SATA Connector (CN21)
Pin
Signal
1
Ground
2
TX+
3
TX-
4
Ground
5
RX-
6
RX+
7
Ground
2.35 I2C (CN22)
Pin
Signal
1
+3.3V
2
SCL
3
SDA
4
Ground
2.36 CAN Bus (CN23)
Pin
Signal
1
CANH
2
Ground
3
CANL
4
N/C
2.37 USB Port #1 & #2 (CN24)
Pin
Signal
Pin
Signal
1
+5V Standby
5
+5V Standby
