Ethernet Module PER-C35L PER-C35L Intel® 82599 SFP/SFP + Fiber LAN Compatible PCI-Express 10 Gigabit Ethernet Acceleration Module PER-C35L Manual Rev.A 1st Ed.
Ethernet Module PER-C35L Copyright Notice This document is copyrighted, 2010. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable.
Ethernet Module PER-C35L Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PER-C35L Ethernet Module • 1 CD-ROM for manual (in PDF format) and drivers If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
Ethernet Module PER-C35L Contents Chapter 1 General Information 1.1 Features .................................................................... 1-2 1.2 Specifications ............................................................ 1-2 Chapter 2 Quick Installation Guide 2.1 Safety Precautions .................................................... 2-2 2.2 Location of Connectors and Jumpers ....................... 2-3 2.3 Mechanical Drawing .................................................. 2-4 2.
Ethernet Module PER-C35L Chapter 1 General Information Chapter 1 General Information 1 - 1
Ethernet Module PER-C35L 1.1 Features PCI-Express Host Interfaces 10Gigabit Ethernet SFP+ Fiber LAN x 2 1.
Ethernet Module PER-C35L Chapter 2 Quick Installation Guide Chapter 2 Quick Installation Guide 2-1
Ethernet Module PER-C35L 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components. Always ground yourself to remove any static charge before touching the board. Modern electronic devices are very sensitive to static electric charges. Use a grounding wrist strap at all times.
Ethernet Module PER-C35L 2.
Ethernet Module 2.
Ethernet Module PER-C35L 2.
Ethernet Module PER-C35L Step 3: Insert the LAN Module and fasten the screws Chapter 2 Quick Installation Guide 2-6
Ethernet Module PER-C35L Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) × ○ ○ ○ ○ ○ × ○ ○ ○ ○ ○ 印刷电路板 及其电子组件 外部信号 连接器及线材 O：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。 Chapter 2 Quick Installation Guide 2-7
Ethernet Module PER-C35L Chapter 3 Driver Installation Chapter 3 Driver Installation 3-1
Ethernet Module PER-C35L 3.1 Installation: Insert the PER-C35L CD-ROM into the CD-ROM Drive. And follow the instructions to install the driver. You can activate the installation items through Autorun program, which will install each driver directly. 1. Select the OS your server is and double click on the .exe file locates in each OS folder 2. Follow the instructions that the window shows 3.
