PICO-ITX Board PICO-HD01 PICO-HD01 AMD G-series Dual Core T40E/ Single Core T40R Processor Gigabit Ethernet 5 USB 2.0, 2 COM 4-bit Digital I/O 1 Mini Card/ mSATA(Half-size) 1 SATA 3.0Gb/s PICO-HD01 Manual Rev.A 2nd Ed.
PICO-ITX Board PICO-HD01 Copyright Notice This document is copyrighted, 2013. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable.
PICO-ITX Board PICO-HD01 Acknowledgments All other products’ name or trademarks are properties of their respective owners. AMI is a trademark of American Megatrends Inc. AMD is trademark of Advanced Micro Devices. Microsoft Windows® is a registered trademark of Microsoft Corp. ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. SoundBlaster is a trademark of Creative Labs, Inc.
PICO-ITX Board PICO-HD01 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: 1 Heatsink 1 SATA Power Cable 1 Power Cable 1 SATA Cable 1 DVD-ROM for Manual (in PDF Format) and Drivers 1 PICO-HD01 If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
PICO-ITX Board PICO-HD01 Contents Chapter 1 General Information 1.1 Introduction ................................................................ 1-2 1.2 Features .................................................................... 1-3 1.3 Specifications ............................................................ 1-4 Chapter 2 Quick Installation Guide 2.1 Safety Precautions .................................................. 2-2 2.2 Location of Connectors and Jumpers ...................... 2-3 2.
PICO-ITX Board PICO-HD01 2.18 External +12V Input Connector (CN6) .................. 2-16 2.19 Realtek LAN (RJ-45) Port Connector (CN7) ......... 2-16 2.20 Buzzer Connector (CN8) ....................................... 2-17 2.21 Audio Line In/Out and MIC Connector (CN9)........ 2-17 2.22 LPC Port Connector (CN10).................................. 2-18 2.23 USB 2.0 Ports 5 Connector (CN11) ...................... 2-19 2.24 VGA Port Connector (CN12) ................................. 2-20 2.25 USB 2.
PICO-ITX Board Appendix B PICO-HD01 I/O Information B.1 I/O Address Map ....................................................B-2 B.2 Memory Address Map ............................................B-4 B.3 IRQ Mapping Chart ................................................B-5 B.4 DMA Channel Assignments.……………………… .B-5 Appendix C Mating Connector C.1 List of Mating Connectors and Cables.................. C-2 Appendix D AHCI Setting D.1 Setting AHCI ......................................................
PICO-ITX Board PICO-HD01 Chapter 1 General Information Chapter 1 General Information 1- 1
PICO-ITX Board PICO-HD01 1.1 Introduction The PICO-HD01 is the embedded board with PICO-ITX form factor AAEON developed. It supports AMD G-series T40R/ T40E processor up to 1.0 GHz. Moreover, it equips AMD A50M chipset offers a high performance computing platform with low power consumption. This new product supports DDR3 SODIMM at speeds of 1066 MHz, up to 4 GB. One SATA 3.0Gb/s and one mSATA interfaces provide ample storages. With one Gigabit Ethernet, two COM ports, and five USB2.
PICO-ITX Board PICO-HD01 1.2 Features Onboard AMD G-Series T40R/T40E Single/Dua Processor AMD G-Series APU +A50M 204-pin SODIMM DDR3 1066MHz up to 4GB One Reatek RTL-8111E for 10/1000/1000Base-TX CRT, 18-bit Single Channel LVDS, HDMI HD Audio for Line-in/out & MIC SATA 3.0Gb/s x 1, mSATA (Half-Size) Slot x 1 Co-lay with Mini Card USB 2.
PICO-ITX Board PICO-HD01 1.3 Specifications System From Factor PICO-ITX Processor AMD G-series T40E/ T40R processor up to 1.0 GHz System Memory 204-pin SODIMM DDR3 1066 MHz, up to 4 GB Chipset AMD G-series + A50M I/O Chipset Fintek F81801U-I Ethernet Realtek RTL-8111E, 10/100/1000Base-TX, RJ-45 x 1 BIOS AMI BIOS-32 Mb ROM Wake On LAN Yes Watchdog Timer Programmable 255 levels system reset H/W Status Monitoring Vcore, +1.
PICO-ITX Board PICO-HD01 Display: Supports CRT/LCD, HDMI/DVI/LCD simultaneous / dual view displays AMD G-series Processor Chipset integrated Resolution Up to 1366 x 768 (18-bit) @ 60 Hz for LVDS; Up to 1920 x 1200 @ 60 Hz for CRT and HDMI LCD Interface I/O: Fintek F81801U-I Storage Serial Port 18-bit single channel LVDS with PWM function SATA 3.0Gb/s x 1 , mSATA x 1 co-lay with Mini Card RS-232 x 1 RS-232/422/485 x 1 USB USB2.
PICO-ITX Board PICO-HD01 Chapter 2 Quick Installation Guide Chapter 2 Quick Installation Guide 2-1
PICO-ITX Board PICO-HD01 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components. Always ground yourself to remove any static charge before touching the board. Modern electronic devices are very sensitive to static electric charges. Use a grounding wrist strap at all times.
PICO-ITX Board PICO-HD01 2.
PICO-ITX Board PICO-HD01 Solder Side Solder side Chapter 2 Quick Installation Guide 2-4
PICO-ITX Board PICO-HD01 2.
PICO-ITX Board Solder Side Solder side Chapter 2 Quick Installation Guide 2-6 PICO-HD01
PICO-ITX Board PICO-HD01 2.4 List of Jumpers The board has a number of jumpers that allow you to configure your system to suit your application.
PICO-ITX Board PICO-HD01 2.5 List of Connectors The board has a number of connectors that allow you to configure your system to suit your application.
PICO-ITX Board PICO-HD01 2.6 Setting Jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper you connect the pins with the clip. To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2 and 3.
PICO-ITX Board PICO-HD01 2.7 COM2 RI/+5/+12V Selection (JP1) Ring (Default) +5V JP1 +12V Function 1B 1-2 +12V 3-4 Ring 5-6 +5V (Default) 2.8 Clear CMOS Selection (JP2) 13 22 31 13 22 31 Normal (Default) Clear CMOS JP2 Function 2B 1-2 Normal (Default) 2-3 Clear CMOS 2.
PICO-ITX Board JP3 PICO-HD01 Function 3B 1-2 +12V 2-3 +5V (Default) 2.10 LVDS Operating Voltage Selection (JP4) +5V JP4 +3.3V (Default) Function 4B 1-2 +5V 2-3 +3.3V (Default) 2.11 LVDS Backlight Lightness Control Mode Selection (JP5) VR Mode JP5 PWM Mode (Default) Function 5B 1-2 VR Mode 2-3 PWM Mode (Default) 2.
PICO-ITX Board JP6 PICO-HD01 Function 6B 1-2 AT Mode 2-3 ATX Mod (Default) 2.13 Digital IO Port Connector (CN1) Pin Pin Name Signal Type Signal Level 1 +3.3V PWR +3.3V 2 DIO0 I/O +3.3V 3 DIO1 I/O +3.3V 4 DIO2 I/O +3.3V 5 DIO3 I/O +3.3V 6 GND GND GND 2.
PICO-ITX Board PICO-HD01 Pin Pin Name Signal Type Signal Level 1 DCDA IN 2 DSRA IN 3 RXA IN 4 RTSA OUT ±9V 5 TXA OUT ±9V 6 CTSA IN 7 DTRA OUT 8 RIA IN 9 GND GND ±9V 2.
PICO-ITX Board PICO-HD01 4 RTSB OUT ±9V 5 TXB OUT ±9V 6 CTSB IN 7 DTRB OUT ±9V 8 RI/+5V/+12V IN/ PWR +5V/+12V 9 GND GND Pin Pin Name Signal Type Signal Level 1 RS422_TX- OUT ±5V 2 NC 3 RS422_TX+ OUT ±5V 4 NC 5 RS422_RX+ 6 NC 7 RS422_RX- IN 8 NC/+5V/+12V PWR 9 GND GND Pin Pin Name Signal Type Signal Level 1 RS485_D- I/O ±5V 2 NC 3 RS485_D+ I/O ±5V 4 NC 5 NC RS-422 IN +5V/+12V RS-485 Chapter 2 Quick Installation Guide 2-14
PICO-ITX Board PICO-HD01 6 NC 7 NC 8 NC/+5V/+12V PWR 9 GND GND +5V/+12V Note 1: COM2 RS-232/422/485 can be set by BIOS setting. Default is RS-232. Note 2: Pin 8 function can be set by JP1. 2.16 +5V Output For SATA HDD Connector (CN4) +5V GND Pin Pin Name Signal Type Signal Level 1 +5V PWR +5V 2 GND GND GND Signal Level 2.
PICO-ITX Board PICO-HD01 5 SATA_RX- DIFF 6 SATA_RX+ DIFF 7 GND GND 2.18 External +12V Input Connector (CN6) Pin Pin Name Signal Type Signal Level 1 GND GND GND 2 GND GND GND 3 +12V PWR +12V 4 +12V PWR +12V 2.
PICO-ITX Board PICO-HD01 3 MDI1+ DIFF 4 MDI2+ DIFF 5 MDI2- DIFF 6 MDI1- DIFF 7 MDI3+ DIFF 8 MDI3- DIFF 2.20 Buzzer Connector (CN8) Pin Pin Name Signal Type Signal Level 1 +3.3V PWR +3.3V 2 SPK OUT 2.
PICO-ITX Board PICO-HD01 Pin Pin Name Signal Type Signal Level 1 MIC_L IN 2 MIC_R IN 3 GND_AUDIO GND 4 LINE_L_IN IN 5 LINE_R_IN IN 6 GND_AUDIO GND 7 LEFT_OUT OUT 8 GND_AUDIO GND 9 RIGHT_OUT OUT 10 +5V_AUDIO PWR +5V 2.22 LPC Port Connector (CN10) LAD0 LAD1 LAD2 LAD3 +3.3V LFRAME# LRESET# GND LCLK LDRQ0 LDRQ1 SERIRQ 1 12 Pin Pin Name Signal Type Signal Level 1 LAD0 I/O +3.3V 2 LAD1 I/O +3.3V 3 LAD2 I/O +3.
PICO-ITX Board PICO-HD01 4 LAD3 I/O +3.3V 5 +3.3V PWR +3.3V 6 LFRAME# IN 7 LRESET# OUT 8 GND GND 9 LCLK OUT 10 LDRQ0 IN 11 LDRQ1 IN 12 SERIRQ I/O +3.3V +3.3V 2.23 USB 2.
PICO-ITX Board PICO-HD01 2.
PICO-ITX Board PICO-HD01 2.25 USB 2.0 Port 3 Connector (CN13) Pin Pin Name Signal Type Signal Level 1 +5V PWR +5V 2 USB3_D- DIFF 3 USB3_D+ DIFF 4 GND GND 5 GND GND 2.26 USB 2.
PICO-ITX Board PICO-HD01 4 GND GND 5 GND GND 2.27 18-bits LVDS Output Connector (CN15) Pin Pin Name Signal Type 1 BKL_ENABLE OUT 2 BKL_CONTROL OUT 3 LCD_PWR 4 LCD_PWR PWR 5 LVDS_A_CLK- DIFF 6 LVDS_DA2+ DIFF 7 LVDS_A_CLK+ DIFF 8 LVDS_DA2- DIFF 9 LCD_PWR DIFF 10 GND GND 11 LVDS_DA0+ DIFF 12 LVDS_DA3+ DIFF 13 LVDS_DA0- DIFF Chapter 2 Quick Installation Guide 2-22 Signal Level +3.3V/+5V +3.3V/+5V +3.
PICO-ITX Board PICO-HD01 14 LVDS_DA3- DIFF 15 GND GND 16 GND GND 17 LVDS_DA1+ DIFF 18 DDC_DATA I/O 19 LVDS_DA1- DIFF 20 DDC_CLK I/O +3.3V +3.3V 2.
PICO-ITX Board 8 PICO-HD01 GND GND 2.
PICO-ITX Board PICO-HD01 17 NC NC 18 DPD_HPD IN 19 DPD_PWR PWR +5V 2.30 LVDS Port Inverter / Backlight Connector (CN18) 1 BLK_PWR 2 BKL_CONTROL 3 GND 4 GND 5 BKL_ENABLE Pin Pin Name Signal Type Signal Level 1 BKL_PWR PWR +5V / +12V 2 BKL_CONTROL OUT 3 GND GND 4 GND GND 5 BKL_ENABLE OUT +5V Signal Type Signal Level 2.
PICO-ITX Board 3 HDD_LED- 4 HDD_LED+ 5 SPEAKER- 6 SPEAKER+ 7 PWR_LED- 8 PWR_LED+ 9 H/W RESET- 10 H/W RESET+ PICO-HD01 2.32 DDR3 SODIMM Slot (DIMM1) Standard Specification 2.33 Mini Card Slot (PCIE1) Pin Pin Name Signal Type 1 PCIE_WAKE# IN 2 +3.3VSB PWR 3 NC 4 GND 5 NC 6 +1.5V PWR 7 PCIE_CLK_REQ# IN 8 UIM_PWR PWR 9 GND GND 10 UIM_DATA I/O Chapter 2 Quick Installation Guide 2-26 Signal Level +3.3V GND +1.
PICO-ITX Board PICO-HD01 11 PCIE_REF_CLK- DIFF 12 UIM_CLK IN 13 PCIE_REF_CLK+ DIFF 14 UIM_RST IN 15 GND GND 16 UIM_VPP PWR 17 NC 18 GND 19 NC 20 W_DISABLE# OUT 21 GND GND 22 PCIE_RST# OUT 23 PCIE_RX- DIFF 24 +3.3VSB PWR 25 PCIE_RX+ DIFF 26 GND GND 27 GND GND 28 +1.5V PWR 29 GND GND 30 SMB_CLK I/O 31 PCIE_TX- DIFF 32 SMB_DATA I/O 33 PCIE_TX+ DIFF 34 GND GND GND +3.3V +3.3V +3.3V +1.5V +3.3V +3.
PICO-ITX Board PICO-HD01 35 GND GND 36 USB_D- DIFF 37 GND GND 38 USB_D+ DIFF 39 +3.3VSB PWR 40 GND GND 41 +3.3VSB PWR 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 +1.5V 49 NC 50 GND 51 NC 52 +3.3VSB Chapter 2 Quick Installation Guide 2-28 +3.3V +3.3V GND PWR +1.5V GND PWR +3.
PICO-ITX Board PICO-HD01 Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 印刷电路板 及其电子组件 外部信号 连接器及线材 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) × ○ ○ ○ ○ ○ × ○ ○ ○ ○ ○ O：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。 Chapter 2 Quick Installation Guide 2-29
PICO-ITX Board PICO-HD01 Chapter 3 AMI BIOS Setup Chapter 3 AMI BIOS Setup 3-1
PICO-ITX Board 3.1 PICO-HD01 System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal. The system can usually continue the boot up sequence with non-fatal errors. System configuration verification These routines check the current system configuration stored in the CMOS memory and BIOS NVRAM.
PICO-ITX Board 3.2 PICO-HD01 AMI BIOS Setup AMI BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM and BIOS NVRAM so that it retains the Setup information when the power is turned off. Entering Setup Power on the computer and press or immediately. This will allow you to enter Setup. Main Set the date, use tab to switch between date elements.
PICO-ITX Board PICO-HD01 Setup Menu Setup submenu: Main Options summary: (default setting) System Date Day MM:DD:YYYY Change the month, year and century. The ‘Day’ is changed automatically. System Time HH : MM : SS Change the clock of the system.
PICO-ITX Board PICO-HD01 Setup submenu: Advanced Options summary: (default setting) ACPI Settings System ACPI Parameters S5 RTC Wake Settings Support S5 RTC Wake Function CPU Configuration CPU Configuration Parameters SATA Configuration SATA Device Options Settings USB Configuration Chapter 3 AMI BIOS Setup 3-5
PICO-ITX Board USB Configuration Parameters F81801 Super IO Configuration F81801 Super IO Configuration Parameters Digital IO Port Configuration DIO configuration H/W Monitor Monitor hardware status Chapter 3 AMI BIOS Setup 3-6 PICO-HD01
PICO-ITX Board PICO-HD01 ACPI Settings Options summary: (default setting) Enabled Enable Hibernation Disabled Enabled or disabled hibernate (OS/S4 Sleep State).
PICO-ITX Board PICO-HD01 S5 RTC Wake Settings Options summary: (default setting) Wake system with Disabled Fixed Time Enabled Enable or disable System wake on alarm event. Wake up time is setting by following settings.
PICO-ITX Board Wake up minute 0-59 Wake up second 0-59 Wake system with Disabled Dynamic Time Enabled PICO-HD01 Enable or disable System wake on alarm event. Wake up time is current time + Increase minutes.
PICO-ITX Board CPU Configuration Options summary: (default setting) Limit CPUID Maximum Disabled Enabled Disabled for Windows XP Chapter 3 AMI BIOS Setup 3-10 PICO-HD01
PICO-ITX Board PICO-HD01 SATA Configuration Options summary: (default setting) OnChip SATA Type IDE AHCI Configure SATA controller operating as IDE/AHCI mode.
PICO-ITX Board PICO-HD01 USB Configuration Options summary: (default setting) Legacy USB Support Enabled Disabled Auto Enables BIOS Support for Legacy USB Support. When enabled, USB can be functional in legacy environment like DOS. AUTO option disables legacy support if no USB devices are connected.
PICO-ITX Board PICO-HD01 Forced FDD Hard Disk CD-ROM If Auto. USB devices less than 530MB will be emulated as Floppy and remaining as Floppy and remaining as hard drive. Forced FDD option can be used to force a HDD formatted drive to boot as FDD(Ex.
PICO-ITX Board PICO-HD01 Serial Port 1 Configuration Options summary: (default setting) Serial Port Disabled Enabled En/Disable specified serial port.
PICO-ITX Board PICO-HD01 IO=3E8h; IRQ=3,4,5,7,10,11,12; IO=2E8h; IRQ=3,4,5,7,10,11,12; Select a resource setting for Super IO device. Serial Port 2 Configuration Options summary: (default setting) Serial Port Disabled Enabled En/Disable specified serial port.
PICO-ITX Board Change Settings PICO-HD01 Auto IO=2F8h; IRQ=3; IO=3F8h; IRQ=3,4,5,7,10,11,12; IO=2F8h; IRQ=3,4,5,7,10,11,12; IO=3E8h; IRQ=3,4,5,7,10,11,12; IO=2E8h; IRQ=3,4,5,7,10,11,12; Select a resource setting for Super IO device. Device Type RS232 RS422 RS485 Configure COM2 operated as RS232, RS422 or RS485.
PICO-ITX Board PICO-HD01 Digital IO Port Configuration Options summary: (default setting) GPIO1/GPIO2 Input Direction Output Set GPIO1/GPIO2 as Input or Output GPIO3/GPIO4 Input Direction Output Set GPIO3/GPIO4 as Input or Output Output Level Hi Low Set GPIO Level when used as Output Chapter 3 AMI BIOS Setup 3-17
PICO-ITX Board H/W Monitor Chapter 3 AMI BIOS Setup 3-18 PICO-HD01
PICO-ITX Board PICO-HD01 Setup submenu: Chipset Options summary: (default setting) Host Bridge Host Bridge Parameters South Bridge South Bridge Parameters Chapter 3 AMI BIOS Setup 3-19
PICO-ITX Board Host Bridge Options summary: (default setting) GFX Configuration Enter to set GFX Configuration Memory Information Show current memory information Chapter 3 AMI BIOS Setup 3-20 PICO-HD01
PICO-ITX Board PICO-HD01 GFX Configuration Options summary: (default setting) DP0 Output Mode LVDS Disabled LVDS Enable/Disable DP1 Output Mode HDMI Disabled HDMI Enable/Disable LVDS Panel Type 640x480 800x600 1024x768 Chapter 3 AMI BIOS Setup 3-21
PICO-ITX Board PICO-HD01 1280x768 1366x768 Select panel native resolution. Note: Only support 18-bit panels LVDS Backlight Level 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0% Select Backlight Level LVDS Backlight Type Normal Inverted Select Backlight control type. Inverted: Brightest for low PWM duty cycle and voltage. Normal: Brightest for high PWM duty cycle and voltage.
PICO-ITX Board PICO-HD01 South Bridge Options summary: (default setting) HD Audio Azalia Enabled Device Disabled HD Audio device Enable/Disable PCIe Enable Disabled miniCard as PCIe Enable/Disable RTL8111E Enabled Disabled RTL8111E LAN Enable/Disable Chapter 3 AMI BIOS Setup 3-23
PICO-ITX Board Power Mode PICO-HD01 ATX Type AT Type Select the power type used on the system Power Failure Power On Power Off Last State Select AC power state when power is re-applied after a power failure.
PICO-ITX Board PICO-HD01 Off Number Lock On/Off Quiet Boot Disabled Enabled En/Disable showing boot logo. Launch LAN PXE Disabled OpROM Enabled En/Disable PXE boot for RTL8111E LAN Boot Option #X/ XXXX Drive BBS Priorities The order of boot priorities.
PICO-ITX Board BBS Priorities Options summary: (default setting) Boot Option #x Disabled Device name Sets the system boot order Chapter 3 AMI BIOS Setup 3-26 PICO-HD01
PICO-ITX Board PICO-HD01 Setup submenu: Security Options summary: (default setting) Administrator Not set Password/ User Password You can install a Supervisor password, and if you install a supervisor password, you can then install a user password. A user password does not provide access to many of the features in the Setup utility. Install the Password: Press Enter on this item, a dialog box appears which lets you enter a password. You can enter no more than six letters or numbers.
PICO-ITX Board PICO-HD01 retype the password for confirmation. Press Enter after you have retyped it correctly. The password is required at boot time, or when the user enters the Setup utility. Removing the Password: Highlight this item and type in the current password. box press Enter to disable password protection.
PICO-ITX Board PICO-HD01 You can install a Master and User password. Before booting to OS, HDD will be set to frozen state. On S3 resume HDD will be unlocked using the HDD Password we entered while system booting. Install the Password: Press Enter on this item, a dialog box appears which lets you enter a password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password. A second dialog box asks you to retype the password for confirmation.
PICO-ITX Board PICO-HD01 Setup submenu: Exit Options summary: (default setting) Save Changes and Reset Reset the system after saving the changes Discard Changes and Reset Reset system setup without saving any changes Restore Defaults Restore/Load Default values for all the setup options.
PICO-ITX Board PICO-HD01 Restore User Defaults Restore the User Defaults to all the setup options Chapter 3 AMI BIOS Setup 3-31
PICO-ITX Board PICO-HD01 Chapter 4 Driver Installation .
PICO-ITX Board PICO-HD01 The PICO-HD01 comes with an AutoRun DVD-ROM that contains all drivers and utilities that can help you to install the driver automatically. Insert the driver DVD, the driver DVD-title will auto start and show the installation guide. If not, please follow the sequence below to install the drivers.
PICO-ITX Board 4.1 PICO-HD01 Installation: Insert the PICO-HD01 DVD-ROM into the DVD-ROM drive. And install the drivers from Step 1 to Step 6 in order. Step 1 – Install Chipset Driver 1. Click on the STEP1-CHIPSET folder and select the OS folder your system is 2. Double click on the Setup.exe file located in each OS folder 3. Follow the instructions that the window shows 4.
PICO-ITX Board PICO-HD01 folder your system is 2. Double click on the Setup.exe file located in each OS folder 3. Follow the instructions that the window shows 4. The system will help you install the driver automatically Step 5 – Bluetooth 3.0 & WiFi (optional) For Window® 7: 1. Click on the STEP5-Bluetooth 3.0 & WiFi(Optional) folder and then click the WIN7_32 folder 2. Click on the BT_7.4.0.98 folder and double click on the Bluetooth_Suite_win7.exe file in the folder to install Bluetooth driver 3.
PICO-ITX Board PICO-HD01 3. Follow the instructions that the window shows 4. The system will help you install the driver automatically 5. Back to the previous level and click on the folder of XP_9.2.0.458\Install_CD, double click on the setup.exe file in the folder to install WiFi driver 6. Follow the instructions that the window shows 7. The system will help you install the driver automatically Step 6 – Serial Port Driver (Optional) For Windows® XP: 1.
PICO-ITX Board PICO-HD01 For Windows® 7: 1. Create a password for Administrator account. 2.
PICO-ITX Board PICO-HD01 3. Reboot and Administrator login. 4. To run patch.bat with [Run as administrator].
PICO-ITX Board PICO-HD01 Appendix A Programming the Watchdog Timer Appendix A Programming the Watchdog Timer A-1
PICO-ITX Board PICO-HD01 A.1 Watchdog Timer Registers Table 1 : Watch dog relative IO address Default Value I/O Base Address Note I/O Base address for Watchdog operation. 0xA00 This address is assigned by SIO LDN7, register 0x60‐0x61.
PICO-ITX Board PICO-HD01 A.
PICO-ITX Board PICO-HD01 AaeonWDTEnable(); } ******************************************************************************* ******************************************************************************* // Procedure : AaeonWDTEnable VOID AaeonWDTEnable (){ WDTEnableDisable(1); } // Procedure : AaeonWDTConfig VOID AaeonWDTConfig (byte Counter, BOOLEAN Unit){ // Disable WDT counting WDTEnableDisable(0); // Clear Watchdog Timeout Status WDTClearTimeoutStatus(); // WDT relative parameter setting WDTParamete
PICO-ITX Board PICO-HD01 WDTSetBit(TimerReg, PSWidthBit, PSWidthVal); // Watchdog WDTRST# Enable WDTSetBit(DevReg, WDTRstBit, WDTRstVal); } VOID WDTClearTimeoutStatus(){ WDTSetBit(TimerReg, StatusBit, 1); } ******************************************************************************* ******************************************************************************* VOID WDTWriteByte(byte Register, byte Value){ IOWriteByte(WDTAddr+Register, Value); } byte WDTReadByte(byte Register){ return IOReadByte(WDTA
PICO-ITX Board PICO-HD01 Appendix B I/O Information Appendix B I/O Information B-1
PICO-ITX Board B.
PICO-ITX Board PICO-HD01 Appendix B I/O Information B-3
PICO-ITX Board B.
PICO-ITX Board PICO-HD01 B.3 IRQ Mapping Chart B.
PICO-ITX Board PICO-HD01 Appendix C Mating Connector Appendix C Mating Connector C - 1
PICO-ITX Board PICO-HD01 C.1 List of Mating Connectors and Cables The table notes mating connectors and available cables.
PICO-ITX Board CN11 USB Port 5 CATCH CN12 Analog CRT Display ASTRON CN13 USB Port 3 CATCH CN14 USB Port 4 CATCH CN15 CN16 18-bit LVDS Output USB Port 1 and 2 E-Call TechBest PICO-HD01 1201-700-05S USB Port 1700050207 Cable HDLH-B15-CF N/A HN1T-1-R USB Port 1201-700-05S Cable USB Port 1201-700-05S Cable 0110-01-553-20 N/A 0 KS-002D-ANB( N/A 2.
PICO-ITX Board PICO-HD01 Appendix D AHCI Setting Appendix D AHCI Setting D-1
PICO-ITX Board PICO-HD01 D.1 Setting AHCI OS installation to setup AHCI Mode. Step 1: Copy the files below from “Driver DVD -> STEP4AHCI\WinXP\SB8xx_RAID_XP_3.2.1540.
PICO-ITX Board PICO-HD01 Step 4: Press “F6” Step 5: Choose “S” Appendix D AHCI Setting D-3
PICO-ITX Board PICO-HD01 Step 6: Choose “AMD AHCI Compatible RAID Controller-x86 platform” Step 7: It will show the model number you select and then press “ENTER Step 8: Setup is loading files Appendix D AHCI Setting D-4
PICO-ITX Board PICO-HD01 Appendix E Electrical Specifications for I/O Ports Appendix E Electrical Specifications for I/O Ports E-1
PICO-ITX Board PICO-HD01 E.1 Electrical Specifications for Digital I/O Ports Table 1 : Digital Input/Output Pin Electrical Specification Input Threshold Pin Type Voltage Output Voltage Low High Low High DIO1 I/O 0.8 2.0 0 3.3 DIO2 I/O 0.8 2.0 0 3.3 DIO3 I/O 0.8 2.0 0 3.3 DIO4 I/O 0.8 2.0 0 3.3 Note: All DIO pins are 5V tolerance in input mode.
PICO-ITX Board PICO-HD01 E.2 DIO Programming PICO-HD01 utilizes FINTEK F81801U chipset as its Digital I/O controller. Below are the procedures to complete its configuration and the AAEON initial DIO program is also attached based on which you can develop customized program to fit your application. There are three steps to complete the configuration setup: (1) Enter the MB PnP Mode; (2) Modify the data of configuration registers; (3) Exit the MB PnP Mode.
PICO-ITX Board PICO-HD01 E.
PICO-ITX Board PICO-HD01 E.
PICO-ITX Board PICO-HD01 // Procedure : AaeonSetOutputLevel // Input : // Example, Set Digital I/O Pin 2 to high level AaeonSetOutputLevel(Pin2Bit, PinHigh); } ************************************************************************** ************************************************************************** Boolean AaeonReadPinStatus(byte PinBit){ Boolean PinStatus ; PinStatus = SIOBitRead(DIOLDN, StatusReg, PinBit); Return PinStatus ; } VOID AaeonSetOutputLevel(byte PinBit, byte Value){ ConfigDioMode(P
PICO-ITX Board PICO-HD01 SIOEnterMBPnPMode(); SIOSelectLDN(LDN); IOWriteByte(SIOIndex, Register); TmpValue = IOReadByte(SIOData); TmpValue &= ~(1 << BitNum); TmpValue |= (Value << BitNum); IOWriteByte(SIOData, TmpValue); SIOExitMBPnPMode(); } VOID SIOByteSet(byte LDN, byte Register, byte Value){ SIOEnterMBPnPMode(); SIOSelectLDN(LDN); IOWriteByte(SIOIndex, Register); IOWriteByte(SIOData, Value); SIOExitMBPnPMode(); } ******************************************************************************** Appen
PICO-ITX Board PICO-HD01 ************************************************************************** Boolean SIOBitRead(byte LDN, byte Register, byte BitNum){ Byte TmpValue; SIOEnterMBPnPMode(); SIOSelectLDN(LDN); IOWriteByte(SIOIndex, Register); TmpValue = IOReadByte(SIOData); TmpValue &= (1 << BitNum); SIOExitMBPnPMode(); If(TmpValue == 0) Return 0; Return 1; } VOID ConfigDioMode(byte PinBit, byte Mode){ Byte TmpValue; SIOEnterMBPnPMode(); SIOSelectLDN(DIOLDN); IOWriteByte(SIOIndex, DirReg); TmpValue =
