KP/KV/KVS Series KVM Rear Kit for LCD Console Drawer User Manual KP/KV/KVS Series: Combo KVM Switch 8/16 port with 1/2 user console 14628 Central Ave, Chino, CA 91710 tel:909.597.7588, fax:909.597.1939 © Copyright 2013 Acnodes, Inc. All rights reserved. Product description and product specifications are subject to change without notice. For latest product information, please visit Acnodes’ web site at www.acnodes.com.
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. Safety Instructions Please read all of these instructions carefully before you use the device. Save this manual for future reference.
Contents < Part 1 > Combo DB-15 KP802 1.1 1.2 1.3 1.4 1.5 1.6 KP1602 Package contents KVM port connection IP console connection IP console setting KVM Cascade Specifications < Part 2 > Combo DB-15 KV802 2.1 2.2 2.3 2.4 2.5 KVM Kit P.1 P.2 P.2 P.3 P.4 P.5 2-console KVM Kit KV1602 Package contents KVM port connection Remote console connection KVM Cascade Specifications P.6 P.7 P.7 - 8 P.9 P.10 < Part 3 > Combo DB-15 KVM Kit KVS801 3.1 3.2 3.3 3.
< Part 1 > Combo DB-15 < 1.1 > Package Contents KVM KP802 KP1602 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model.
< 1.2 > KVM port connection CE-6 / CE-10 / CE-15 ■ 6 / 10 / 15 ft Combo KVM cable ■ Support PS/2 or USB server USB Servers DB-1Combo KVM port Drawer KVM Rear Kit PS/2 Servers CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server < 1.3 > IP console connection CAT 5 / 6 cable max.
< 1.4 > IP console setting After the cable connection, please take the following steps to configure the IP KVM : 1. Download IPKVMsetup.exe 2. Double click IPKVMsetup.exe to configure the IP KVM by device setup as below. 3. Click Refresh Device to search the connected IP KVM 4. Select the M.A.C. address, which you want to setup, then click Query Device 5. Enter Super user login. The default is super 6. Enter Super user password. The default is pass 7. Enter the new super user password 8.
< 1.5 > KVM Cascade ■ ■ Cascade up to 8 levels, 128 servers Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVS801 / KVS1601. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. level 2 to 8).
< 1.
< Part 2 > Combo DB-15 2-console KVM < 2.1 > Package Contents KV802/1602 • Receiver box for remote console x 1 • Power adapter w/ power cord ( for receiver ) x 1 • 6ft Combo KVM cable for receiver box x 1 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model.
< 2.2 > KVM port connection CE-6 / CE-10 / CE-15 ■ 6 / 10 / 15 ft Combo KVM cable ■ Support PS/2 or USB server USB Servers Combo KVM port Drawer KVM Rear Kit CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server PS/2 Servers < 2.3 > Remote console connection Receiver Remote USB console CAT 5 / 6 cable max.
Combo DB-15 2-console KVM How to use a receiver to connect a remote console Receiver Local Computer Monitor Remote I/O Front Rear Power USB K/B Mouse Local Remote Button to PC Button to KVM switch The receiver provides a hotkey function for remote console. Please refer to P.
< 2.4 > KVM Cascade ■ ■ Cascade up to 8 levels, 128 servers Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVS801 / KVS1601. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. level 2 to 8).
< 2.
< Part 3 > Combo DB-15 KVM < 3.1 > Package Contents KVS801 /1601 KVM Rear Kit back The power of the KVM rear kit may be changed to external power design based on the LCD console drawer series and model.
< 3.
< 3.3 > KVM Cascade ■ ■ Cascade up to 8 levels, 128 servers Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVS801 / KVS1601. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. level 2 to 8).
< 3.
Part 4. Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch finally computer Front Panel - Port LED Indications 8 ports Bank no. PC port LEDs Channel button 16 ports Bank no.
< 4.2 > Password The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password 1. Press the KVM hotkey Scroll Lock + Scroll Lock + U 2. Logout the KVM by pressing the hotkey Scroll Lock + Scroll Lock + P 3. In SUPERVISOR level, enter “00000000” eight zeros in user name & password field (Do not use “0” on number pad) 4.
< 4.
< 4.4 > KVM Hotkey & Remote Console Hotkey Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + PgUp / PgDn Switch to previous bank or next bank Scroll Lock + Scroll Lock + Bank no. + Port no.
< 4.5 > DC Power 12V, 24V, 48V Input Model 12V 24V 48V Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA Output voltage: 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.
