CAUTION: Before proceeding to install, test or use your new ACR Electronics’ product, please read this Product Support Manual in its entirety. If you have questions regarding the contents of the manual, please contact our Technical Service Department at ACR Electronics, Inc., Telephone +1 (954) 981-3333. Please be ready to provide the technician with the page number you wish to discuss.
Table of Contents SECTION 1 - HOW THE ARX-50 WORKS _________________________ 2 SECTION 2 - PREPARING TO INSTALL ___________________________ 3 SECTION 3 - INSTALLATION ___________________________________ 5 SECTION 4 - OPERATION _____________________________________ 6 SECTION 5 - MAINTENANCE __________________________________ 9 APPENDIX A - SPECIFICATIONS ________________________________ 9 APPENDIX B - ACCESSORIES __________________________________ 10 APPENDIX C - WARRANTY, USEFUL LIFE POLICY, NOTICES ______
SECTION 1 - HOW THE ARX-50 WORKS The ARX-50 alarm receiver is designed as a companion to the ACR radio beacon transmitter model number RBL-30 (Mini B™300). It is intended to be used in a crew overboard (COB) alerting application. When properly powered and fitted with an external antenna, the signals from the Mini B™300 transmitter can be received by the ARX-50 up to several miles.
Controls and indicators Mounting bracket Coaxial (BNC) connector Alarm indicator Signal strength meter Weather resistant polycarbonate housing Speaker location On/Off switch Mode switch Frequency selector switch I/O cable Y1-03-0229C 4
Location selection Choose a dry, clean surface to install the ARX-50, giving consideration to the importance of the location. The user must be able to see the visual alarm and hear the audible alarm. CAUTION: When using the included antenna, the ARX-50 must be mounted vertically and the antenna must not be within 0.5 m of a metal panel or other metal objects. Ship’s power requirements The ARX-50 accepts ship’s power supply in the range of +10.5 to +28 V DC.
Connect the power supply The ship’s power supply is the source of power for the ARX-50. A onemeter I/O cable is supplied with the product. It is recommended that a qualified marine electronics professional or qualified electrician connect the power.
The ARX-50 has three large, circular push buttons and seven LEDs that indicate settings. The push buttons switch between alternate modes. Each button is assigned a set of functions. See Figure 1. Each button “beeps” when depressed. The LED indicators are either red or green to signify the system mode. Green LEDs signify that the system is in a normal state and red LEDs signify that the system is in an atypical state.
Monitor Low mode This mode is identical to the Monitor High mode except that the speaker volume is lower. NOTE: The ARX-50 reverts back to Alarm mode after 15 minutes in Monitor High mode. Training mode Operation in Training mode is identical to the live radio beacon detection mode. In Training mode, the ARX-50 receives a special training frequency (typically 121.65 MHz or 121.775 MHz).
SECTION 5 - MAINTENANCE The following maintenance schedule is recommended: Action Visual inspection Performance test Clean exterior Description Frequency Inspect the antenna, cables and connections. Ensure that the cable is attached properly and the unit has not been damaged.
APPENDIX B - ACCESSORIES The following are items that can be ordered for your alarm receiver: Description Mini B™300 ILS H2ON (water activated) Mini B™300 ILS (manually activated) ACR Part Number 2767 2766.6 APPENDIX C - WARRANTY, USEFUL LIFE POLICY, NOTICES Limited Warranty This product is warranted against factory defects in material and workmanship for a period of 1 (one) year* from date of purchase or receipt as a gift. During the warranty period ACR Electronics, Inc.
FCC Compliance Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses nd can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
EC DECLARATION OF CONFORMITY ACR Electronics, Inc. hereby declares that the following product is in conformity with Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on Radio Equipment and Telecommunications Terminal Equipment (R&TTE).
