RST1 LED2
Push this button to reset the
system.
UP :
Green1: Link LED
Yellow1: Active LED
Down :
Green2: Link LED
Yellow2: Active LED
CN3, CN4 LED1
Dual SFP Connector.
1000BASE-SX/LX SMALL
FORM-FACTOR
PLUGGABLE (SFP) OPTICAL FIBER
TRANSCEIVER OR MINI-GBIC
CONNECTOR
UP :
Green1: Link LED
Yellow1: Active LED
Down :
Green2: Link LED
Yellow2: Active LED
4.3.5. CF Socket
CF1
CF CARD Socket
