5.2. Advanced Setup
Option Choice Description
SATA Configuration
N/A SATA Device Options Settings
W83627DHG Super
IO Configuration
N/A System Super IO Chip Parameters.
Serial Port Console
Redirection
N/A Serial Port Console Redirection
Intel(R) 82576
Gigabit Dual Port
Network Connection
N/A Configure Gigabit Ethernet device parameters
Intel(R) 82574L
Gigabit Network
Connection
N/A Configure Gigabit Ethernet device parameters
35
