Instruction Manual
Table Of Contents
- Chapter 1 Introduction
- Chapter 2 Procedures of Assembly/Disassembly
- Chapter 3 Board Introduction
- Chapter 4 H/W Information
- Chapter 5 BIOS Settings
- SATA Configuration
- W83627DHG Super IO Configuration
- Serial Port Console Redirection
- Intel(R) 82576 Gigabit Dual Port Network Connection
- N/A
- Configure Gigabit Ethernet device parameters
- Intel(R) 82574L Gigabit Network Connection
- N/A
- Configure Gigabit Ethernet device parameters
- SATA Mode Selection
- Port 1
- Port 2
- CF card
- COM1 Configuration
- COM2 Configuration
- LAN by Pass Function
- Change Settings
- Serial Port
- Change Settings
- Device Mode
- Console Redirection
- Console Redirection Settings
- EMS
- EMS Settings
- Terminal Type
- Bits per second
- Data Bits
- Parity
- Stop Bits
- Flow Control
- NIC Configuration
- Blink LEDs (range 0-1
- Link Status
- NIC Configuration
- Blink LEDs (range 0-1
- Link Status
- SYS temperature
- CPU temperature
- CPU Fan Speed
- VCORE
- LAN1 ~ 8
- USB Configuration
- xHCI Mode
- EHCI1
- Setup Prompt Timeout
- Boot up NumLock State
- Boot Logo
- PXE Function
Chapter 1 Introduction
ANR-IB75N1 is designed for rack-mounted platform for networking appliance, e.g. VPN, SSL,
UTM or firewall. With 3
rd
Generation Intel Core i7/i5/i3 Processors / Pentium CPU, It is a
powerful platform to satisfy different applications. By eight 10/100/1000Mbps LANs, the
ANR-IB75N1 is sufficient for the small to middle size business security solution.
ANR-IB75N1 can install 2 x HDD,BIOS and Jumper can control LAN bypass feature. It
provides flexibility to access Internet by user setting. For ANR-IB75N1A, it has 2 x SFP
fiber ports. For ANR-IB75N1B, it has 4 x SFP fiber ports. Customers can establish fiber
redundancy to secure their network.
1.1. System Specifications
Item Description Remark
Model Name ANR-IB75N1/A/B
Product
Descriptions
ANR-IB75N1/A/B Networking Rackmount Server with PCH B75, 8 *
RJ45 GbE LAN (2 pair bypass) and 0/2/4 SFP fiber GbE (w/o bypass)
PCB AMB-IB75N1/A/B
General
Thermal solution 1. CPU FAN + System FAN
CPU 3rd Generation Inter Core i7 Processors
i7-3770
3rd Generation Inter Core i5 Processors
i5-3550S
3rd Generation Inter Core i3 Processors
i3-3220
Intel Pentium Processor G2120
System Memory 2 x DIMM socket support DDR3
1333/1600 up to 16G
BIOS 1. Support Console re-direction
2. Support bypass setting(default disable)
3. Support boot from LAN(RJ45 L1~L8)
System Chipsets Intel PCH B75
