Instruction Manual

Network Interface
Ethernet 8 * RJ45 and 0/2/4 * SFP
LAN by-Pass 1. LAN1/LAN2, LAN3/LAN4 support
by-pass
2. Reserve 1*3 pin Jumper for Hardware
select bypass status
I/O
Front panel From left to right:
1. LCM module
2. Up, Down, Left, Right key pad
3. Reset Button
4. Power LED/HDD/bypass 1 & 2 :
Green/Green/Yellow/Yellow
5. 0/2/4 * SFP (F1~F4)
6. COM port (RJ45)
7. 2 * USB 3.0
8. LAN 8/7/6/5/4/3/2/1
Internal I/O
1. LCM pin header(7-pin pinhead 2.54mm )
2. ATX 24pin Power input
3. 1*8 pin 2.54mm reserve
4. VGA pin header (2*5pin, 2.0mm)
5. ATX12V 4pin Power Input
Storage
CF 1 x Compact Flash socket
Support UDMA
HDD bay 2 x 2.5” HDD bay
SATA 1 x SATA2 1 x SATA3
Others
Watchdog Timer Software programmable 1~255 Seconds,
Battery Lithium Battery, 3V 220mAH (CR2032)
Hardware
monitoring
1. CPU voltage
2. CPU and System Temperature
3. CPU FAN speed
OS support Win 7 (32/64 bit) / 7 Embedded (32 bit),
Fedora 14 (32/64 bit), Ubuntu 10 (32/64 bit)
Mechanical
Dimension 440mm*371.5mm*44mm
Operating 0~40
o
C (32~104
o
F)
