FAQ
There are 2 kinds of SATA modes --- AHCI & legacy IDE mode. When you use the Linux, We strongly
suggest to use AHCI mode. For legacy IDE mode, we found some SATA HDD could have compatibility
issue. Please confirm the BIOS setting is correct, thank you.
Does my system support Windows 8?
The system is designed and verified with Windows 7, Fedora 14 and Ubuntu 10. But, we did not verify this
system with Windows 8. Please check with Acrosser local sales rep. or authorized channels who will help you
to confirm whether we have provided new Windows 8 driver.
Where is the serial number located on my system?
The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis.
Memory:DDR3 2GB
CPU: i5 3550S
S/N:xxxxxxx I
P/N:010010xxx
Model: AMB-IB75N1
My system can not connect to internet?
If your system can not connect to internet, below are a few steps you can follow to attempt to correct the
issue.
Ensure that network adapter can be recognized in Device Manager
If there is question mark or exclamation mark in the network adapter, please re-install your OS and
network driver. If the problem did not solve, please contact your local FAE or sales rep for tests.
