IP Outdoor Rugged Dome ACM-75x1 series Ver.
0 0 PRECAUTIONS 1. Read these instructions You should read all the safety and operating instructions before using this product. 2. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. 3. This symbol highlights several areas of concern. Please read descriptions next to each symbol carefully. a. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment. b.
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Table of Contents 0 PRECAUTIONS________________________________________________ 0-1 Trademarks ________________________________________________________________ 0-1 Liability ___________________________________________________________________ 0-1 FCC/CE Regulation __________________________________________________________ 0-1 1 2 INTRODUCTION ______________________________________________ 1-1 1.1 Package Contents _______________________________________________ 1-1 1.
11 1.
1.2 Features and Benefits The IP outdoor rugged dome series is a cutting-edge digital video transmission device. It can compress and transmit real time images with outstanding images quality (D1, 720x480) at reasonable bandwidth through a standard TCP/IP network. That is because it is Ethernet (LAN and WAN) ready and has the powerful ARM9 SoC and the MPEG-4 compression ASIC inside. In addition, with these powerful hardware platform, excellent SDK support and powerful respective apparatuses (e.g.
service. Everyone can use the virtual domain name to view the video from anywhere with internet acess. Built-in Hardware Motion Detection No more external motion sensors are required. Each IP device can be set with up to 3 detection areas. By tuning the object size and sensitivity, it can provide reliable motion detection in all kinds of environments. Moreover, hardware motion detection delivers better sensitivity andfaster response time than software motion detection.
1.3 Safety Instructions Don’t use the power supply with other voltages This device is likely to be damaged or damage other equipments / personnel if you use a power supply with a different voltage than the one marked on this device. All warranty of this product will be voided in the above situation. Don’t open the housing of the product Cleaning Disconnect this video product from the power supply before cleaning.
Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.
1.
1. Reset Button Step 1: Switch off IP device by disconnecting the power cable Step 2: Press and continue to hold the Reset Button with a pointed object. Reconnect the power cable while still holding the reset button. Step 3: Keep the reset button depressed for at least 16 seconds before releasing it. The unit will then start up with factory default settings. 2. Ethernet Port The IP outdoor rugged dome connects to the Ethernet via a standard RJ45 connector.
Connect the power adaptor here if your power input is DC12V. Please follow the description on the connector to connect to power. PIN 1 2 6. DESCRIPTION NAME 12V DC Power Input GND Ground Pin Conduit Hole These conduit holes provide alternative cable routing choices for different mounting scenarios.
22 Installation Procedure There are three types of installation of this IP outdoor rugged dome series. Surface mount Flush mount Wall mount ● ● Pictures Optional Bracket required The mounting procedure can be divided into two parts, 1st: Connecting the IP outdoor rugged dome series 2nd: Mounting the IP outdoor rugged dome series 2.1 Connecting the IP Outdoor Rugged Dome 2.1.1 Remove the cover Remove the dome cover with the special hex wrench that came with the camera in the accessory pack.
2.1.2 Insert the cable There are two conduit holes, one is at the dome bottom and the other one is at the side of rugged dome with plug. Remove the plug if your cable will go through the one at the side of rugged dome 2.1.3 Connect cables to connectors Please follow the instruction at Chapter 1.4: Physical Description, for how to connect to each connector.
2.1.4 LED Description There are three LEDs in the system. They are indicators for power, fan and heater respectively. According to the operating temperature, different LEDs will be lighted under different situations.
2.
2.
2.
33 3.1 Adjusting the camera Adjust zoom and focus Please adjust the camera direction first. Then move the focus and the zoom lever at the picture 1 to adjust the zoom and the focus. Fix the zoom and focus after adjusting. 3.2 Adjust camera functions Refer to picture 1 for what can be adjusted and how to adjust. Picture 1 1. 2. 3. 4. 5.
44 Product Specification 4-16
