ACTiSYS ACT-IR2000UL Series
User’s Manual
2 INTRODUCTION
ACTiSYS IR2000UL is an advanced wireless Fast Infrared USB adapter designed to replace the serial
port or FIR controller based FIR/SIR wireless peripheral through the PC USB (Universal Serial Bus)
port. Taking advantage of the true plug-and-play nature and the high bandwidth of USB, IR2000UL
offers the easiest conversion of existing wireless to the legacy-free personal computer platform with
the following features:
 Fully compliant to USB specification 1.1 and IrDA specification 1.1
 Full-speed (12 Mbps) USB device operation
 Supports FIR (4Mbps) and all SIR speeds (9.6, 19.2, 38.4, 57.6 and 115.2Kbps).
 Bus-powered device. Obtain power from USB port. No external power supply required.
 Low power consumption in standby mode ( Standby current is less than 0.5 mA
 Not occupy PC's COM or Parallel port and has no complicated hardware port and resource
setting and conflict, such as IO address / IRQ / DMA numbers.
 True PNP (Plug And Play) device. Without re-installing USB driver when re-plugs in.
 package size: 2.4"L x 1.4"W x 0.74"H, 2.4 oz (65.0 gr)
3 PACKAGING CHECK LIST
The package includes
1. ACT-IR2000UL USB Dongle
2. ACT-USB Adapter Driver and CD for User’s manual.
4 SYSTEM REQUIREMENTS
To use ACT-IR2000UL, your computer MUST meet the following requirements.
1. Windows 98SE/ME/2000/XP.
2. One unoccupied USB port.
5 BIOS SETUP
Before you use this device, You MUST enable your computer USB port in BIOS Settings.
