Professional Enhanced Scan Tool User's Manual

Using This Manual
1 – 2 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
1
Functions and Selections
Diagnostic and tool functions performed by the scan tool are highlighted in bold.
Example:
The View Data function allows you to view the vehicle’s Parameter
Identification (PID) data in real time.
Menus
The menus on the scan tool display are referenced in the procedures and are
highlighted in bold-italic text.
Example:
When the OBDII Function List menu displays, the scan tool is ready for use.
Questions and Responses
Messages and user responses are CAPITALIZED.
Example:
The Scan Tool displays the Pending DTCs or a message stating SYSTEM
PASS: NO FAULT DETECTED.
Manual References
Used to reference other sections of the manual. References include the “Title”
and page number (section-page).
Example:
For more information on DTCs, refer to “Diagnostic Link Connectors (DLC)”
on page 2-5.
Screens
Certain Help messages, information, and data that are displayed on the scan
tool are also shown in graphical text boxes. The screens are presented as
examples and may change as the software is updated.
Example:
Main Menu ?
` Vehicle Diagnosis
Tool Setup [
Tool Self-Tests ~
