Using The Scan Tool
3
Display
The scan tool uses a 4 line by 20 character, back-lit Liquid Crystal Display
(LCD). The large viewing area displays messages, instructions, and diagnostic
information. The contrast can be adjusted.
Seven characters help you navigate
and operate the scan tool:
? appears in upper right corner of
display to indicate Help is available.
` identifies the selection.
[ indicates additional information is
available on the next screen.
] indicates additional information is available on the previous screen.
« identifies selected items in data lists.
~ Bell in lower right corner means the sound alert is on or active.
 Low battery symbol will appear in bottom right-hand corner of the screen
at power-up if the internal batteries need replacement or are not installed.
Keyboard
The scan tool’s software is designed for ease in operating and navigating
through menus. Do not use solvents such as alcohol to clean the keypad or
display. Use a mild nonabrasive detergent and a soft cotton cloth. Do not soak
the keypad as water might find its way inside the scan tool.
Function List ?
` 2)Read DTC(Codes) ]
3)Erase DTC(Codes) [
4)View Data ~
