Using The Scan Tool
3
Refer to the printer manual for the settings. The changes made reside in the tool
even when the tool is turned off.
Tool settings are as follows. Defaults are in [ . . . ]
❒ Baud Rate: [9,600], 1200, 2400
❒ Stop Bits: [1 Bit], 2 bits
❒ Parity: [None], Odd, Even
❒ Printer Speed: [Fast], Slow
Press
ENTER after selecting each setting. Follow the instructions displayed on
the screens. For the printer to work properly, the tool and the printer must be set
to the same configuration. Change the settings accordingly.
To change the settings,
press the LEFT arrow
and then
ENTER .
Use the
BACK key to
return to the previous
menu.
The new printer settings
are tested by printing the
ASCII character set.
Press to continue.
Make sure printer is
turned ON, ONLINE and
connected to the tool.
Press the
ENTER key to
begin printing.
If the printout is not OK, then retry or
change settings. If it is, press
ENTER
and the data transmits and prints.
A printout of the test looks similar to the
example shown.
Select Baud Rate
` 9600(Defalut)
1200 [
2400
Select Data Bits
` 8 (Default)
Select Stop Bits
1 Bit(Default)
`2 Bits
Select Parity
` None (Default)
Odd
Even
Printer
` Fast (Default)
Slow
The ASCII Character
Set Will Be Printed
Once.
Press ENTER to Cont.
Test Ends By Itself
In Approximately 10
Seconds.
Press ENTER to Cont.
Make Sure Device
Is Turned On, Online
& Connected To Tool.
ENTER To Print
-[ Print Test ]-
!"#$%&'()*+,-./01234
56789:;<=>?@ABCDEFGH
IJKLMNOPQRSTUVWXYZ[\
]^_`abcdefghijklmnop
qrstuvwxyz{|}~
