Professional Enhanced Scan Tool User's Manual

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 4 – 11
Global OBDII Diagnostics
4
If additional tests are present use UP/DOWN arrow keys to view test results.
Refer to appropriate vehicle service manual for test IDs and definitions.
Press BACK key to return to the Diag Mon Test menu or press FUNC key to
return to OBDII Function List.
ON-BOARD SYSTEMS
The On-Board Systems test allows scan tool to control operation of vehicle
components, tests or systems. Some manufacturers do not allow tools to
control vehicle systems. A vehicle not supporting an on-board system is
identified by a message displayed when selected.
✓ Refer to vehicle service manual for on-board systems instructions.
Select On-Board Systems from
OBDII Function List and press
ENTER .
A list of on-board systems and components available for testing display on
screen.
Select a test and press
ENTER to activate test. Manufacturer is responsible for
determining criteria to automatically stop test. Refer to appropriate vehicle
service manual.
OBDII Function List ?
` 10)Record Data ]
11)Vehicle Info [
12)Modules Present ~
