RECORD DATA
The Record Data function records PIDs while vehicle is parked or being driven.
This function is mainly used for diagnosing intermittent driveability problems
that cannot be isolated by any other method.
Two people MUST be in vehicle when driving — one to
drive and the other to operate scan tool.
Select Record Data from OBDII
Function List and press
ENTER .
Follow all instructions on display.
Scan tool asks vehicle to provide global
PIDs vehicle supports.
✓ Scan tool can maintain only one recording per group. Make sure to
thoroughly review old recording before erasing.
If a recording currently exists in
memory, a message prompting to erase
data is displayed.
After list is generated, scan tool prompts to select type of data to record. Refer
to “Viewing Data” on page 3-11 to setup Entire or Custom Data Lists.
On next screen, select a triggering
method. Manual Trigger allows
technician to use
ENTER key. Trigger
On Codes automatically triggers when
a DTC is indicated by vehicle.
OBDII Function List ?
` 10)Record Data ]
11)Vehicle Info [
12)Modules Present ~
Validating PID Map
PID23of99
Please Wait
Cannot Record. Old
Recording Filled Up
Memory. Erase Old?
YES <No>
~
Pick Trigger Method
`1)Manual Trigger
2)Trigger On Codes
