Professional Enhanced Scan Tool User's Manual

Global OBDII Diagnostics
4 – 16 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
4
4
MODULES PRESENT
The Scan Tool identifies the module IDs and communication type
for OBDII modules in the vehicle.
Select Modules Present
from the OBDII Function
List and press
ENTER .
✓ Types of Protocols (communication types) supported by
Scan tool are:
•ISO 9141-2 protocol will be shown as ISO
•SAE J1850 protocol will be shown as VPWM OR PWM
OR
•ISO 15765-4 protocol will be shown as CAN.
OBDII Function List ?
10)Record Data ]
1 1)Vehicle Info [
`12)Modules Present
ID Protocols
$41 ISO*
$40 ISO*
ID Protocols
$10 VPWM*
ID Protocols
$10 PWM*
ID Protocols
$01 CAN*7e9
$00 CAN*7e8
